Raritan MCC4 Bedienungsanleitung

UUsseerr’’ssMMaannuuaall

MCC4, MCC8, MCC16

MCC4R, MCC8R, MCC16R

MCC8RD, MCC16RD

Raritan Computer, Inc.

Ver. 0C, AUG, 2000

UUsseerr’’ssMMaannuuaall

MCC4, MCC8, MCC16

MCC4R, MCC8R, MCC16R

MCC8RD, MCC16RD

Raritan CComputer, IInc.

400 Cottontail Lane

Somerset, NJ 08873

U.S.A.

Tel. 1-732-764-8886

Fax 1-732-764-8887

E-mail [email protected]

http://www.raritan.com

Raritan CComputer EEurope, BB.V.

Eglantierbaan 16

2908 LV Capelle aan den IJssel

The Netherlands

Tel. 31-10-284-4053

Fax 31-10-284-4049

E-mail [email protected]

http://www.raritan.com

Raritan CComputer TTaiwan, IInc.

5F,121,Lane 235,Pao-Chiao Rd,

Hsin-Tien City,Taipei Hsien

Taiwan,ROC

Tel. 886-2-8919-1333

Fax 886-2-8919-1338

E-mail:[email protected]

http://www.raritan.com

Raritan CComputer JJapan, IInc.

Kuga Building 7F, 11-6

Kuramae 4-chome Taitoo-Ku

Tokyo 111-0051, Japan

Tel. 81-3-5833-6360

Fax 81-3-5833-6336

Email [email protected]

http://www.raritan.com

FCC Information

This equipment has been tested and found to comply with the limits for a Class

A digital device, pursuant to Part 15 of the FCC Rules. These limits are

designed to provide reasonable protection against harmful interference in a

commercial installation. This equipment generates, uses and can radiate radio

frequency energy and, if not installed and used in accordance with the instruc-

tions, may cause harmful interference to radio communications. Operation of

this equipment in a residential environment may cause harmful interference.

Product names mentioned in this document are trademarks or registered trade-

marks of their respective companies. MasterConsole MX4, MasterConsole, and

their respective logos are registered trademarks of Raritan Computer, Inc. PS/2,

RS/6000, and PC/AT are registered trademarks of the International Business

Machines Corporation. Mac is a registered trademark of Apple Computer, Inc.

Sun is a registered trademark of Sun Microsystems. Alpha is a registered trade-

mark of Digital Equipment Corporation. HP9000 is a registered trademark of

Hewlett Packard. SGI is a registered trademark of Silicon Graphics, Inc.

Japanese Approvals

Table of Contents

FCC INFORMATION I

TABLE OF CONTENTS II

TABLE OF FIGURES III

WELCOME 1

OVERVIEW 1

FEATURES 1

ONE-TIER AND TWO-TIER CONFIGURATIONS 2

GETTING STARTED 3

ONE-TIER CONFIGURATION 4

INSTALLING MASTERCONSOLE II (ONE-TIER) 4

CONFIGURING MASTERCONSOLE II (ONE-TIER) 6

ASSIGNING NAMES AND SCAN RATES (ONE-TIER) 8

USING MASTERCONSOLE II SECURITY FEATURE (ONE-TIER) 10

Passwords 10

Turning Security on/off and Changing Passwords: 10

OPERATING MASTERCONSOLE II

USING ON-SCREEN USER INTERFACE (ONE-TIER) 12

Selecting a Computer 12

Setting AutoScan 14

OPERATING MASTERCONSOLE II

USING FRONT PANEL BUTTONS (ONE-TIER) 14

TWO-TIER CONFIGURATION 16

INSTALLING MASTERCONSOLE II (TWO-TIER) 16

Install Base Unit (First-Tier) MasterConsole II 16

Connect Second-Tier MasterConsole(s) to the Base Unit 17

Connect Computers to Second-Tier MasterConsole(s) 18

CONFIGURING THE BASE MASTERCONSOLE II (TWO-TIER) 19

ASSIGNING NAMES AND SCAN RATES (TWO-TIER) 21

USING THE MASTERCONSOLE II SECURITY FEATURES (TWO-TIER) 23

OPERATING MASTERCONSOLE II (TWO-TIER) 23

Selecting a Computer 23

REMOTE ACCESS USING CAT5 REACH 27

APPENDICES 28

SYSTEM DEFAULT SETTINGS 28

ON-SCREEN USER INTERFACE FUNCTION KEYS 29

MASTERCONSOLE CONFIGURATIONS AND

PROGRAMMING MASTERCONSOLE II AT POWER UP 30

MasterConsole II product Design Background and Considerations 30

Programming MasterConsole II 30

MASTERCONSOLE II CONFIGURATION DIAGRAMS 31

GLOSSARY 34

TROUBLESHOOTING 38

SPECIFICATIONS 41

Main Unit 41

Universal Cable Kits 42

Accessories 42

Remote Access Kit 42

TABLE OF FIGURES

FIGURE 1. ONE-TIER CONFIGURATION 2

FIGURE 2. TWO-TIER CONFIGURATION (WITH OPTIONAL REMOTE ACCESS) 2

FIGURE 3. MASTERCONSOLE II BACK PANEL 4

FIGURE 4. ONE-TIER CONFIGURATION CABLING DETAILS 5

FIGURE 5. CABLE ADAPTERS TO CONVERT PS/2 TO AT 5

FIGURE 6. MASTERCONSOLE II FRONT PANEL 6

FIGURE 7. MASTERCONSOLE II FRONT PANEL (CHANNEL LIGHTS) 6

FIGURE 8. CONFIGURATION MENU 6

FIGURE 9. EDIT NAMES AND SCAN RATE MENU (ONE-TIER) 9

FIGURE 10. ADMINISTRATION MENU 11

FIGURE 11. SELECTION MENU (ONE-TIER, SORTED BY CHANNEL ID) 12

FIGURE 12. TWO-TIER CONFIGURATION (WITH OPTIONAL REMOTE ACCESS KIT) 16

FIGURE 13. TWO-TIER CONFIGURATION CABLING DETAILS 17

FIGURE 14. CONFIGURATION MENU (TWO-TIER) 19

FIGURE 15. DEVICE TYPES 20

FIGURE 16. DEVICE FIELD 20

FIGURE 17. DEFAULT MASTERCONSOLE II CHANNEL IDS AND NAMES 21

FIGURE 18. EDIT NAMES AND SCAN RATE MENU (BASE MASTERCONSOLE II) 22

FIGURE 19. EDIT NAMES AND SCAN RATE MENU (SECOND-TIER MCC8) 23

FIGURE 20. SELECTION MENU (TWO-TIER, BASE MASTERCONSOLE II) 25

FIGURE 21. SELECTION MENU (TWO-TIER, SECOND TIER) 26

FIGURE 22. REMOTE ACCESS WITH CAT5 REACH 27

FIGURE 23. TWO-TIER CONFIGURATION WITH SATELLITE UNIT 27

FIGURE 24. BASIC ONE-TIER CONFIGURATIONS 31

FIGURE 25. ONE-TIER WITH REMOTE ACCESS KIT 31

FIGURE 26. TWO-TIER CONFIGURATION OF UP TO 256 COMPUTERS 32

FIGURE 27. TWO-TIER CONFIGURATION WITH MASTERCONSOLE P MODEL 32

FIGURE 28. TWO-TIER CONFIGURATION WITH SATELLITE UNIT 33

Welcome

Overview

Raritan's keyboard/video/mouse (KVM) switches are engineered to pro-

vide reliable, cost-effective, central control of multiple computers. This

eliminates the cost and clutter of unnecessary equipment, reclaims

space, and improves productivity for a host of applications.

MasterConsole II enables control of any mix of 2 to 256 computers

from a single keyboard, monitor, and mouse. MasterConsole II user

interface provides simple on-screen control and system management.

Raritan's unique emulation technology dedicates a keyboard/mouse

emulator for each computer to ensure that each computer always 'sees'

its own keyboard and mouse. This means smooth, flawless switching

and operation, even when computers are running the most demanding

operating systems.

Features

·Models for 4, 8, or 16 computers

·Mix any brand PCs, Macs, Suns, Alphas, RS/6000s, HP9000s, SGIs

·“Keep-alive” emulation ensures non-stop computer operation in the

event of power loss to the switch

·High resolution video-1600x1280

·Tangle-proof, double-shielded coaxial cable from 6.5, to 30 feet

·On-screen user interface for simple control and system management

·Assign meaningful names to computers for quick identification and

selection

·Operate with front panel buttons or hot-keys with on-screen menus

·AutoSkip function to bypass inactive channels

·AutoScan computers at variable rates

·Password Security to ensure authorized access to computers

·Optional Dual Remote access capability with Cat5 Reach

·Compatible with MasterView ready MasterConsole P Models (MCPn)

·Cascade from a multi-user MasterConsole MX4

·One year warranty for parts and labor

One-Tier and Two-Tier Configurations

MasterConsole II can be configured in one or two tiers, depending on the

number of computers you want to control. In a one-tier configuration,

only computers are connected to a single MasterConsole II unit. See

Figure 1. In a two-tier configuration, either a computer or another

MasterConsole unit is connected to each channel of the base

MasterConsole II unit. See Figure 2.

Figure 1. One-Tier Configuration

Figure 2. Two-Tier Configuration (With optional Remote Access)

Getting Started

MasterConsole II is designed for quick, easy installation and operation.

Follow the steps for either one-tier or two-tier configuration to be up and

running within minutes:

1. Install MasterConsole II (connect computers).

2. Configure MasterConsole II.

3. Assign computer names and set channel-specific Scan

Rates for attached computers.

4. Turn ON security and change passwords if you want to

restrict access to computers connected to MasterConsole II.

5. Operate using On-Screen User Interface or front panel buttons.

6. Install optional Cat5 Reach for remote console or satellite unit.

Quick-Start Operation

After you connect computers to your MasterConsole II

you may wish to explore MasterConsole II operation

with the default names and parameters.

You may operate using the front panel buttons and/or

the On-Screen User Interface. To activate On-Screen

User Interface, press the <ScrollLock>> key twice

rapidly. The Selection Menu will appear. To select a

computer, use the <Ï>/<Ð>keys to highlight the

desired channel (computer) and press <Enter>or

press the desired computer's Key number (located in

the left-hand column). To select another computer,

use front panel buttons or re-activate the On-Screen

User Interface.

One-Tier Configuration

Installing MasterConsole II (One-Tier)

1. Shut down and power off all computers to be connected to

MasterConsole II.

2. Plug a keyboard, monitor, and mouse into the keyboard, moni-

tor, and mouse ports on the MasterConsole II back panel. See

Figure 3 and Figure 4.

3. Power ON the MasterConsole II unit.

4. Using a universal cable kit (CCPnnU), plug the 25-pin connector

into one of the numbered channels on the MasterConsole II back

panel.

5. Plug the cable's other connectors into the computer's keyboard,

monitor, and mouse ports. Use supplied adapters for AT style

PCs. See Figure 5.

6. Power ON the connected computer.

7. Select the connected computer by pressing the corresponding

front panel button. Verify that the monitor attached to

MasterConsole II displays the video for the connected computer.

Use the keyboard and mouse attached to MasterConsole II to

verify that they operate the connected computer.

8. Repeat Steps 4through 7to connect the remaining computers to

MasterConsole II.

Figure 3. MasterConsole II Back Panel

Note: An amber channel light above a numbered channel button on

the MasterConsole II front panel indicates that the channel is

active; that is, a computer is connected and powered on. A

green light above a numbered channel button indicates the cur

rently displayed channel. See Figure 6 and Figure 7.

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Raritan Schalten Handbücher

Raritan

Raritan Dominion KX IV-101 Bedienungsanleitung

Raritan

Raritan PARAGON II Series Bedienungsanleitung

Raritan

Raritan DOMINION DKX116 Bedienungsanleitung

Raritan

Raritan Dominion KX Bedienungsanleitung

Raritan

Raritan Front 1088IP Montageanleitung

Raritan

Raritan Dominion SX DSXA-16-DL Bedienungsanleitung

Raritan

Raritan Dominion KX Bedienungsanleitung

Raritan

Raritan Dominion KX 1.4 Installationsanleitung

Raritan

Raritan DOMINION KSX II Bedienungsanleitung

Raritan

Raritan Dominion KX II Bedienungsanleitung

Raritan

Raritan PX3TS Bedienungsanleitung

Raritan

Raritan UST-IP Bedienungsanleitung

Raritan

Raritan SwitchMan USB-Combo SW4 Bedienungsanleitung

Raritan

Raritan dominion kx III Service-Handbuch

Raritan

Raritan DOMINION KSX II Bedienungsanleitung

Raritan

Raritan KX II Bedienungsanleitung

Raritan

Raritan dominion kx III Service-Handbuch

Raritan

Raritan DKX2-V2.3.5-0N-E Bedienungsanleitung

Raritan

Raritan PX3TS Bedienungsanleitung

Raritan

Raritan dominion kx III Bedienungsanleitung

Raritan

Raritan Dominion KX II-101-V2 Bedienungsanleitung

Raritan

Raritan Dominion KX II Bedienungsanleitung

Raritan

Raritan Exprezo EZ-108 Bedienungsanleitung

Raritan

Raritan PARAGON II Series Bedienungsanleitung

Beliebte Schalten Handbücher anderer Marken

URC

URC Total Control MFS-8 Bedienungsanleitung

Azbil

Azbil HPQ-D11 Bedienungsanleitung

Sony

Sony DFS-900M Bedienungsanleitung

SICK

SICK i17S Bedienungsanleitung

F&F

F&F SZR-277 Bedienungsanleitung

Shure

Shure UAMS/BK Bedienungsanleitung

Dräger

Dräger X-zone Switch Off Bedienungsanleitung

Asco

Asco Joucomatic 349 Series Bedienungsanleitung

BT Mini Hub Bedienungsanleitung

D-Link

D-Link DES-1226G Bedienungsanleitung

Johnson Controls

Johnson Controls FS80-C Bedienungsanleitung

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Bedienungsanleitung

MicroNet

MicroNet SP1200A Bedienungsanleitung

Ruijie

Ruijie RG-PF2920 Series Installations- und Betriebsanleitung

Altinex

Altinex DA1914SX Bedienungsanleitung

MiLAN

MiLAN MIL-SM2401M Bedienungsanleitung

RJM

RJM MASTERMIND PBC/6X Bedienungsanleitung

Atlas

Atlas MMK-KVM8 Bedienungsanleitung
