Raven AutoBoom Bedienungsanleitung
GVM Predator - 2007 & Older
AutoBoom™ Installation Manual
While every effort has been made to ensure the accuracy of this document,
Raven Industries assumes no responsibility for omissions and errors. Nor is any
liability assumed for damages resulting from the use of information contained
herein.
Raven Industries shall not be held responsible or liable for the effects of
atmospheric conditions and sunspot activity on the performance of our products.
Raven Industries cannot guarantee the accuracy, integrity, continuity, or
availability of the GPS signal from the U.S. Department of Defense/NAVSTAR
GPS satellites, the OmniSTAR correction service, or the WAAS correction
service. Raven Industries accepts no responsibility for the use of the signal for
other than the stated purpose.
Raven Industries shall not be responsible or liable for incidental or consequential
damages or a loss of anticipated benefits or profits, work stoppage or loss, or
impairment of data arising out of the use, or inability to use, this system or any of
its components.
Disclaimer
Table of Contents
Manual No. 016-0230-050 i
Chapter 1 Important Safety Information................................................. 1
Important Safety Information ..................................................................................................... 1
Hydraulic Safety .................................................................................................................. 2
Electrical Safety ................................................................................................................... 2
Chapter 2 Introduction............................................................................. 3
Introduction ............................................................................................................................... 3
Recommendations .............................................................................................................. 4
Preparing for Installation ..................................................................................................... 4
Point of Reference ............................................................................................................... 4
Hydraulic Fittings ................................................................................................................. 4
Chapter 3 PowerGlide Plus ..................................................................... 5
PowerGlide Plus Kit Contents ................................................................................................... 5
Install the PowerGlide Plus Hydraulic System ......................................................................... 9
Remove the Orifice Fittings ................................................................................................. 9
Install Fittings on the AutoBoom Valve .............................................................................. 12
Mount the AutoBoom Valve ............................................................................................... 13
Install the Left and Right Cylinder Hoses .......................................................................... 15
PowerGlide Plus Hydraulic Schematic .............................................................................. 16
Install the Gauge Wheels ........................................................................................................17
Gauge Wheel Mounting Location ...................................................................................... 17
Install the PowerGlide Plus Wiring .......................................................................................... 18
Install the AutoBoom Node ................................................................................................ 18
Connect the Harness Cable to the Boom Function Controls ............................................. 19
Connect the Harness Cable to the Controller Cable ......................................................... 20
Connect the Controller (If Applicable) ............................................................................... 20
Connect the Field Computer (If Applicable) ...................................................................... 20
Connect the Power Leads ................................................................................................. 20
PowerGlide Plus Wiring Schematics ....................................................................................... 21
AutoBoom Controller ......................................................................................................... 21
Envizio Plus ....................................................................................................................... 22
SCS 4000/5000 ................................................................................................................. 23
Viper Pro & Envizio Pro ..................................................................................................... 24
Chapter 4 UltraGlide............................................................................... 25
UltraGlide Kit Contents ............................................................................................................ 25
Install the UltraGlide Hydraulic System .................................................................................. 29
Install Fittings on the AutoBoom Valve .............................................................................. 30
Install Fittings on the Logic Valve ...................................................................................... 30
Mount the AutoBoom Valve ............................................................................................... 31
Install the Left and Right Cylinder Hoses .......................................................................... 33
Table of Contents
ii GVM Predator (2007 & Older) AutoBoom Installation Manual
UltraGlide Hydraulic Schematic ......................................................................................... 34
Install the UltraGlide Sensors ..................................................................................................35
Boom Sensor Mounting Locations ..................................................................................... 35
Mount the Center Rack Sensor ......................................................................................... 36
Connect the Sensor Cables ...............................................................................................36
Install the Gauge Wheels - Optional ........................................................................................ 37
Gauge Wheel Mounting Location ...................................................................................... 37
Install the UltraGlide Wiring ..................................................................................................... 38
Install the AutoBoom Node ................................................................................................ 38
Connect the Harness Cable to the Boom Function Controls ............................................. 39
Connect the Harness Cable to the Sensors ...................................................................... 40
Connect the Harness Cable to the Controller Cable ......................................................... 40
Connect the Controller (If Applicable) ................................................................................ 40
Connect the Field Computer (If Applicable) ....................................................................... 40
Connect the Power Leads ................................................................................................. 40
UltraGlide Wiring Schematics .................................................................................................. 41
AutoBoom Controller ......................................................................................................... 41
Envizio Plus ....................................................................................................................... 42
SCS 4000/5000 ................................................................................................................. 43
Viper Pro & Envizio Pro ..................................................................................................... 44
Chapter 5 Replacement Parts ............................................................... 45
Valve Blocks ............................................................................................................................ 45
Wheels .................................................................................................................................... 46
Sensors ................................................................................................................................... 46
CHAPTER
1
Manual No. 016-0230-050 1
C hapt er 1
Important Safety
Information
Important Safety Information
Read this manual and the operation and safety instructions included with your implement and/or controller
carefully before installing the AutoBoom™ system.
•Follow all safety information presented within this manual.
•If you require assistance with any portion of the installation or service of your Raven equipment, contact
your local Raven dealer for support.
•Follow all safety labels affixed to the AutoBoom system components. Be sure to keep safety labels in good
condition and replace any missing or damaged labels. To obtain replacements for missing or damaged
safety labels, contact your local Raven dealer.
When operating the machine after installing AutoBoom, observe the following safety measures:
•Be alert and aware of surroundings.
•Do not operate AutoBoom or any agricultural equipment while under the influence of alcohol or an illegal
substance.
•Remain in the operator’s position in the machine at all times when AutoBoom is engaged.
•Disable AutoBoom when exiting from the operator’s seat and machine.
•Do not drive the machine with AutoBoom enabled on any public road.
•Determine and remain a safe working distance from other individuals. The operator is responsible for
disabling AutoBoom when the safe working distance has been diminished.
•Ensure AutoBoom is disabled prior to starting any maintenance work on AutoBoom or the machine.
NOTICE
Chapter 1
2 GVM Predator (2007 & Older) AutoBoom Installation Manual
•When starting the machine for the first time after installing AutoBoom, be sure that all persons stand clear,
in case a hose has not been properly tightened.
•The machine must remain stationary and switched off, with the booms unfolded and supported while
installation or maintenance is conducted.
Hydraulic Safety
•Raven Industries recommends that appropriate protective equipment be worn at all times when working on
the hydraulic system.
•Never attempt to open or work on a hydraulic system with the equipment running. Care should always be
taken when opening a system that has been previously pressurized.
•When disconnecting the hydraulic hoses or purging is required, be aware that the hydraulic fluid may be
extremely hot and under high pressure. Caution must be exercised.
•Any work performed on the hydraulic system must be done in accordance with the machine manufacturer’s
approved maintenance instructions.
•When installing AutoBoom hydraulics or performing diagnostics, maintenance, or routine service, ensure
that precautions are taken to prevent any foreign material or contaminants from being introduced into the
machine’s hydraulic system. Objects or materials that are able to bypass the machine’s hydraulic filtration
system will adversely reduce performance and possibly damage the AutoBoom hydraulic valves.
Electrical Safety
•Always verify that the power leads are connected to the correct polarity as marked. Reversing the power
leads could cause severe damage to the equipment.
•Ensure that the power cable is the last cable to be connected.
WARNING
CAUTION
CHAPTER
2
Manual No. 016-0230-050 3
C hapt er 2
Introduction
Introduction
Congratulations on your purchase of the Raven AutoBoom system! This system is designed to provide
automated boom height adjustment for agricultural equipment.
This manual applies to the following machines. For future reference, write your serial number in the space
below.
MAKE: GVM
MODEL: Predator
YEAR: 2007 & Older
SERIAL NUMBER:
FIGURE 1. GVM Predator
Note: This manual contains the installation instructions for the PowerGlide Plus and UltraGlide systems.
Be sure to identify which system you have and follow only the instructions for that system.
Chapter 2
4 GVM Predator (2007 & Older) AutoBoom Installation Manual
Recommendations
Raven Industries recommends the following best practices when installing the AutoBoom system:
•Use part numbers to identify the parts.
•Do not remove the plastic wrap from a part until it is necessary for installation.
•Do not remove plastic caps from a part until it is necessary for installation.
Tools Needed
The following tools are recommended for installation of the AutoBoom system:
•SAE standard-sized wrenches
•Cable ties
•Set of tools
Preparing for Installation
Before installing AutoBoom, park the machine where the ground is level, clean, and dry. Leave the machine
turned off for the duration of the installation process.
During the installation process, follow good safety practices. Be sure to carefully read the instructions in this
manual as you complete the installation process.
Point of Reference
The instructions in this manual assume that you are standing behind the machine, looking toward the cab.
Hydraulic Fittings
This manual may reference the following types of hydraulic fittings:
•SAE O-ring fittings
•ORFS (O-Ring Face Seal) fittings
•JIC fittings
JIC fitting (M)
ORFS fitting
SAE O-ring fitting
CHAPTER
3
Manual No. 016-0230-050 5
C hapt er 3
PowerGlide Plus
PowerGlide Plus Kit Contents
This section contains a list of the components that are included in the PowerGlide Plus AutoBoom kit. Before
beginning the AutoBoom installation, compare the items in the AutoBoom kit with the components on this list. If
you have questions about the kit, contact your Raven dealer.
TABLE 1. PowerGlide Plus Installation Kit (P/N 117-0231-050)
Picture Item Description Part Number Qty.
Not Pictured Manual - GVM Predator (2007 & Older)
AutoBoom Installation 016-0230-050 1
Valve - PowerGlide Plus AutoBoom 063-0131-125 1
Valve - Spool A Pilot to Close Spool-Type
Logic 334-0003-075 1
Plate - Hydraulic Block Mounting 107-0171-802 1
Cable - Weatherpack Boom Sense Adapter 115-0171-558 2
U-Bolt - 3-1/16” W x 4” L x 3/8” Thread 107-0171-608 2
Chapter 3
6 GVM Predator (2007 & Older) AutoBoom Installation Manual
Bolt - 5/16”-18 x 7/8” Zinc Hex 311-0052-104 4
Bolt - 3/8”-16 x 1-1/4” Zinc Hex 311-0054-106 3
Nut - 3/8”-16 Zinc Flanged Lock 312-1001-164 7
Washer - 5/16” Zinc Plated Lock 313-1000-019 4
TABLE 2. Hydraulic Kit (P/N 117-0134-050)
Picture Item Description Part Number Qty.
Fitting - 9/16” JIC M/F 90° Swivel Elbow 333-0012-042 2
Fitting - 9/16” JIC M/M/F Swivel Run Tee 333-0012-043 2
Fitting - 9/16” JIC (M) to 9/16” SAE O-Ring
(M) Straight Adapter 333-0012-045 3
Fitting - 9/16” JIC (M) TO 3/4” SAE O-Ring
(M) Straight Adapter 333-0012-046 4
Fitting - 9/16” JIC (M) TO 7/16” SAE O-Ring
(M) Straight Adapter 333-0012-050 1
Fitting - 11/16” Hex to 9/16” SAE O-Ring Plug 333-0012-194 2
TABLE 1. PowerGlide Plus Installation Kit (P/N 117-0231-050)
Picture Item Description Part Number Qty.
Andere Handbücher für AutoBoom
26
Inhaltsverzeichnis
Andere Raven Spritzpistole Handbücher
Raven
Raven ISO AutoBoom Case IH 3230 Bedienungsanleitung
Raven
Raven AutoBoom Bedienungsanleitung
Raven
Raven AutoBoom Bedienungsanleitung
Raven
Raven AutoBoom Bedienungsanleitung
Raven
Raven AutoBoom Bedienungsanleitung
Raven
Raven RCM-Sprayer Hawkeye 2 Gebrauchs- und Pflegehandbuch
Raven
Raven SmartBoom Spra-Coupe 7000 Series Bedienungsanleitung
Raven
Raven AutoBoom Bedienungsanleitung
Raven
Raven Case IH 50 Series Bedienungsanleitung
Raven
Raven SmartBoom Case IH 3150 Bedienungsanleitung
