RCA RNSM2403 Bedienungsanleitung

Manufactured under license from Dolby Laboratories.

Dolby,Dolby Audio,Pro logic, and the double-D symbol are

trademarks of Dolby Laboratories.

INSTRUCTION MANUAL

Before using the TV, please read this manual thoroughly, and

retain it for future reference.

RNSM2403

TABLE OF CONTENTS

TV Feet Installation Instructions

OPERATING INSTRUCTIONS

Install and Connect TV

Preparations Guide

HOME PAGE

USB

Instructions

Main Men u


Sound

Setting

Lock

Program

Network

About

USB

Limited Product Warranty 22

USB FORMAT MODE

Caution

The lightening flash with arrowhead symbol, within an equilateral triangle is

intended to alert the user to the presence of un-insulated "dangerous voltage"

within the products enclosure that may be of sufficient magnitude to constitute a

risk of electric shock to the persons.

The exclamation point within an equilateral triangle is intend to alert the user to

the presence of important operating and maintenance (servicing) instructions in

the literature accompanying the appliance.

Correct disposal of this Product

W aste Electrical & Electronic Equipment (WEEE)

Your product is designed and manufactured with high quality materials and

components which can be recycled and reused.

This symbol means that electrical and electronic equipment, at their end-of-life,

should be disposed of separately from your household waste.

Please dispose of this equipment at your local community waste

collection/recycling centre.

In the European Union there are separate collection systems for used electrical

and electronic products. Please help us to conserve the environment we live in!

This is class Ⅱ apparatus whis double insulation, and no protective earth provided.

This device complies with Part 15 of the FCC Rules.

Operation is subject to the following two conditions:

(1) this device might not cause harmful interference, and

(2) this device must accept any interference received,

including interference that might cause undesired operation

Instruction s

a tip-ov er and/or injury.

EXAMPLE OF ANTENNA GROUNDING AS PER THE NATIONAL ELECTRICAL CODE

ANTENNALEADIN WIRE

ANTENNA

DIS CHAGRE UNIT

(NEC SECTION 810-2 0)

GROUNDIN G CONDUCTORS

(NEC SECTION 810-2 1)

GROUND CLAMPS

POWER SERVICE GROUNDING

ELECTRODE SYSTEM

(NEC ART 250,R ARTH)

GROUND

CLAMP

ELEC TRIC SERVICE

EQUIPMENT

NEC-NATIONAL ELECTRICAL CODE

S2898A

26)

designed in such a way that it does not require a safety connection to electrical earth.

27) Correct disposal of this product. This marking indicates that this product should not

be disposed with other household waste. To prevent possible harm to the environment or

human health from uncontrolled waste disposal, recycle it responsibly to promote the

sustainable reuse of material resources.

This equipment is a Class II or double insulated electrical appliance. It has been

Instruction s

Warning: batteries(pack or batteries installed) should not be exposed to excessive heat

such as sunshine, fire or other heat sources.

Instruction s

have bright spots/pixels.

10cm

below

Instruction s

Note: Drawing is a representative example only

operat e

To avoid damage to the TV, place the TV on a table, face down on a soft surface.

the

TV Buttons and Connections

AV input

External AV Signal Input and

Right/Left Audio Inputs.

VIDEO R L

INPUT

OPTICAL

Digital Audio Output.

OPTICAL

USB Input

Connect to your USB device.

ANT 75/RF Connection

Connect to the antenna/cable TV

output of your device or wall plate.

HDMI Input

(HDMI1,HDMI2,HDMI3/ARC)

Connect to a HDMI output

connection on your external device.

HDMI

HEADPHONE JACK

Plug earphones into jack for private

listening. Overrides speakers.

HEADPHONE

RJ45

Connect to the Internet.

RJ 45

RJ45 connection

RJ 45

1. :Turn on the TV or enter standby mode.

2. :Turn on/off the sound by pressing this button.

3.0~9: Figures “0-9” are used to directly input channel number.

4.EPG:Press to display Electronic Program Guide and select

your favorite channel.

5.-/--:Press to change the channel which name contains “.”.

6. : Input source selection button.

7. :Press to enter the Home Page.

8.V+: Increase the volume.

9.V-:Decrease the volume.

10.P :Channel up.

11.P : .Channel down

12. :Start system menu.

13. :Press to display the source and channel's display.

14.OK:To confirm the choice of a highlighted menu item.

15. / :Press these buttons to move within the menu.

16. / :Press these buttons to move .within the menu

17.BACK:Go back to the previous step.

18.EXIT:Press to exit the OSD menu.

19. :Press to launch Netflix.

20. :Press to launch YouTube.

21. :Press to launch NetRange app store.

22. :Press to launch VUDU.

23.GREEN/RED/YELLOW/CYAN buttons: Press these buttons according the different prompts.

24. :Press to fast reverse in USB mode.

25. :Press to fast forward in USB mode.

26. :Press to play the video and press again to pause the video.

27.CC:Press to display the close caption.

28. :Hold on or off for current page display/Press to stop in the USB mode.

29.AUDIO:Press to change the language when paly the stream which contains multi-language.
