Television User’s Guide

Changing Entertainment. Again.

Please read these instructions before

operating this product for the first time.

TOCOM 15920020

Model: F19421

This symbol indicates "dangerous

voltage" inside the product that

presents a risk of electric shock or

personal injury.

Caution: To prevent electric shock, match wide blade of plug to wide slot, fully insert.

Attention: Pour éviter les chocs électriques, introduire la lame la plus large de la fiche dans la borne correspondante de la prise et

pousser jusqú au fond.

Power Consumption: 120V ~60 Hz, 66 W (for model F19421)

FCC Regulations state that unauthorized changes or modifications to this equipment may void the user’s authority to operate it.

Caution: Using video games or any external accessory with fixed images for extended periods of time can cause them to be

permanently imprinted on the picture tube (or projection TV picture tubes). ALSO, some network/program logos, phone numbers, etc.

may cause similar damage. This damage is not covered by your warranty.

Cable TV Installer: This reminder is provided to call your attention to Article 820-40 of the National Electrical Code (Section 54 of the Canadian

Electrical Code, Part 1) which provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the

grounding system of the building as close to the point of cable entry as practical.

Product Registration

Please fill out the product registration card (packed separately) and return it immediately. Returning the card allows us to contact you if needed.

Product Information

Keep your sales receipt to obtain warranty parts and service and for proof of purchase. Attach it here and record the serial and model numbers in

case you need them. These numbers are located on the product.

Model No. __________________________________________________________________________________________________________________

Serial No. ___________________________________________________________________________________________________________________

Purchase Date: ______________________________________________________________________________________________________________

Dealer/Address/Phone: _______________________________________________________________________________________________________

Caution: To reduce the risk of electric shock, do not remove

cover (or back). No user serviceable parts inside. Refer

servicing to qualified service personnel.

This symbol indicates important

instructions accompanying the

product.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

WARNING

To reduce the risk of fire or electric

shock, do not expose this product to

rain or moisture.

Table of Contents

Chapter 1: Getting Started

Things to Consider Before You Connect ...................... 2

Setup and Connections ................................................. 3

Step 1: Connect your TV ......................................... 3

Step 2: Plug in the TV .............................................. 3

Step 3: Put Batteries in the Remote ....................... 3

Step 4: Turn on the TV ............................................ 3

Step 5: Auto Channel Search .................................. 4

Step 6 (optional): Connect other components ......4

The Buttons on the Remote Control ............................ 5

Chapter 2: Using the TV’s Features

Channel Marker ............................................................. 7

Front Panel Lock ............................................................ 7

V-Chip Parental Controls ............................................... 8

How V-Chip Works .................................................. 8

V-Chip Movie Rating Limit ...................................... 9

TV Rating Limit ...................................................... 10

Blocking Specific Content Themes ....................... 14

Viewing Specific Content Themes ........................ 15

V-Chip Unrated Program Block ............................ 16

Lock/Unlock Parental Controls ............................. 16

Chapter 3: Using the TV’s Menu System

How to Use Your TV’s Menu System .......................... 17

Picture Quality Menu .................................................. 18

Screen Menu ................................................................ 18

Using Closed Captioning ....................................... 19

Channel Menu.............................................................. 20

Time Menu ................................................................... 20

Chapter 4: Other Information

Troubleshooting........................................................... 21

TV Problems ........................................................... 21

The Remote Control Doesn’t Work ...................... 22

Problems with V-Chip/Parental Controls .............. 23

The Front of Your TV – Front Panel ............................ 23

Care and Cleaning ....................................................... 24

Limited Warranty ......................................................... 25

Accessory Information ................................................ 28

How To Order ........................................................ 28

Chapter 1: Getting Started

2Graphics contained within this publication are for representation only. Your unit might differ slightly.

Things to Consider Before You Connect

Protect Against Power Surges

• Connect all components before you plug any of their power cords into the wall outlet.

• Turn off the TV and/or component before you connect or disconnect any cables.

• Make sure all antennas and cables are properly grounded. Refer to the Important Safeguards sheet packed with your TV.

Protect Components from Overheating

• Don’t block ventilation holes on any of the components. Arrange the components so that air can circulate freely.

• Don’t stack components.

• When you place components in a stand, make sure you allow adequate ventilation.

• If you connect an audio receiver or amplifier, place it on the top shelf so the heated air from it won’t flow around other components.

Position Cables Properly to Avoid Audio Interference

• Insert each cable firmly into the designated jack.

• If you place components above the TV, route all cables down the side of the back of the TV instead of straight down the middle

of the back of the TV.

• If your antenna uses 300-ohm twin lead cables, do not coil the cables. Also, keep the twin lead cables away from audio/video cables.

Important Stand and Base Safety Information

Choose the location for your TV carefully. Place the TV on a stand or base that is of adequate size and strength to prevent the TV

from being accidentally tipped over, pushed off, or pulled off. This could cause personal injury and/or damage the TV. Refer to the

Important Safeguards sheet packed with your TV.

Use Indirect Light

Don’t place the TV where sunlight or room lighting will be directed toward the screen. Use soft or indirect lighting.

Chapter 1: Getting Started

Graphics contained within this publication are for representation only. Your unit might differ slightly.

Setup and Connections

Step 1: Connect your TV

Connect the cable from your cable system or off-air antenna to the cable in-jack on the back

of the TV, as shown on the left.

Step 2: Plug in the TV

Plug the end of the power cord into the wall outlet. Match the wide blade of the plug with

the wide slot in the outlet. Insert the plug completely into the outlet.

Step 3: Put Batteries in the Remote

1. Remove the battery compartment cover on the remote.

2. Insert new batteries. Match the polarities (+ and -) on the batteries with the diagram on

the remote.

3. Put the battery compartment cover back on the remote.

Step 4: Turn on the TV

Press the POWER button on the remote or on the front panel.

TV (Back Panel)

ANTENNA

ANTENNA, CABLE, CABLE BOX OR VCR

Chapter 1: Getting Started

4Graphics contained within this publication are for representation only. Your unit might differ slightly.

Step 5: Auto Channel Search

Perform an Auto Channel Search (described in the Channel menu section).

Step 6 (optional): Connect other components to your TV

Use the jacks on the front panel of your TV to connect components to your TV. You can see

what’s playing on the component you connected by pressing the INPUT button on your

remote until VID appears on the screen.

VIDEO (in) Allows you to connect a component such as a VCR, camcorder or Internet access

device.

AUDIO (mono in) Receives audio signals from another component such as a VCR,

camcorder or Internet access device.

Cables Needed to Connect Components to Your TV

The pictures on the left show the cables needed to connect components to your TV.

Notes: Audio/Video cables (A/V cables for short) are often sold as a bundled set. When

connecting components to your TV, use the cable with the yellow end to connect the

video and the cable with the white end to connect the audio. Leave the cable with the

red end (if there is one) unconnected.

VIDE

Audio/Video

cables

Coaxial cable

Chapter 1: Getting Started

Graphics contained within this publication are for representation only. Your unit might differ slightly.

MUTE PREV CH

INPUT SKIP

DISPLAY

456

798

POWER

CLEAR RESET

CHAN

VOL VOL

CHAN

The Buttons on the Remote Control

0-9 (Number buttons) Enter channel numbers directly through the remote control. This button

can also be used to select numbered menu items directly.

To enter a two-digit channel, press the two digits. To enter a three-digit channel, press and hold

the first digit for two seconds until two dashes appear to the right of the number, then add the

second two. Example: to tune to channel 123, press and hold 1 for two seconds, press 2, then

press 3.

CHAN (up and down) buttons Scan up or down through the current channel list. Press once

to change the channel up or down; press and hold to continue changing channels. Also used as

up and down arrows in the menu system.

CLEAR Removes any menu or display from the screen and returns you to TV viewing. Also

cancels the SKIP timer.

DISPLAY Brings up available channel information. This button is also referred to as INFO in

the TV’s menu system.

INPUT Changes your TV to its video input channel. The Video Input Channel is the channel

your TV must tune to in order for you to access a component that’s connected to the AUDIO and

VIDEO jacks on the front of your TV. Example: to view a tape from your camcorder, connect the

camcorder to the TV’s AUDIO and VIDEO jacks on the TV’s front panel with the audio/video

cables.

MENU Brings up the Main menu. When in the menu system, selects highlighted items or

returns you to the previous menu.

MUTE Lowers the volume to its minimum level. Press again to restore volume.

Continues on next page...

Chapter 1: Getting Started

6Graphics contained within this publication are for representation only. Your unit might differ slightly.

MUTE PREV CH

INPUT SKIP

DISPLAY

456

798

POWER

CLEAR RESET

CHAN

VOL VOL

CHAN

POWER Turns the TV on and off.

PREV CH Returns you to the previous channel.

RESET Returns all picture settings back to their factory defaults.

SKIP (Commercial Skip) Press once before changing channels. The TV will wait 30 seconds

before returning you to the original channel. Press again to add more time. Press CLEAR to cancel

the SKIP timer.

VOL – and VOL + Decreases or increases the TV’s volume. Also used as left and right arrows

in the menu system.

The Buttons on the Remote Control (continued)

Chapter 2: Using the TV’s Features

Graphics contained within this publication are for representation only. Your unit might differ slightly.

Channel Marker

There are several indicators that might appear when you press the DISPLAY button on

the remote. This display is called the Channel Marker. The following list describes the

items on the Channel Marker screen (left to right and top to bottom).

12:01 Displays the current time.

60 Displays the current channel or input channel (VID).

SLEEP Displayed when the Sleep Timer has been set.

CC Displayed when Closed Captioning is available on the current channel.

MUTE Displayed when you mute the audio.

1:30 Displayed to count down time left on the commercial skip (SKIP) timer.

Front Panel Lock

This feature allows you to lock the buttons on the front of the TV. Even when the front

panel lock feature is on, the TV operates with the remote control.

To lock the buttons on the front of the TV:

1. Make sure the TV is on.

2. Press and hold the POWER button on the remote for approximately 5 seconds.

To turn off the front panel lock:

1. Make sure the TV is off.

2. Press and hold the POWER button on the remote for approximately 5 seconds.

Sample displays on a Channel Marker. The Channel

Marker shown is just an example of what your

screen may look like.

12:01 60

SLEEP CC

1:30

Mute

Chapter 2: Using the TV’s Features

8Graphics contained within this publication are for representation only. Your unit might differ slightly.

V-Chip Parental Controls

The V-Chip Parental Controls menu allows you to program your TV so that children cannot

see certain programs.

The first three choices in the Parental Controls menu involve software inside your TV

(referred to as V-Chip) which allows you to block TV programs and movies based on

violence, sex, or other content you may believe children should not view. In other words, it

lets you program your TV so it won’t display certain programs.

Once you block programs, you or other adults can unblock programs by entering a

password.

By default, the software inside your TV is turned “off,”so if you don’t want to use this

feature, you can just ignore it.

How V-Chip Works

When turned “on,”the V-Chip software reads a code that most broadcasters send with

programs. That code tells the software the program’s age-based rating (TV-MA, TV-14, etc.)

and content themes [(Violence (V), Adult Language (L), etc.)]. If you have blocked the rating

and/or content themes that the program contains, you will receive the message, “This

program is blocked. Change channel or press DISPLAY to enter password,”when you tune to

that particular channel.

Broadcasters are not required to provide content themes, so programs received with no

content themes will only be blocked if you block their age-based rating. You can also block

out programs that have been given a rating of “Not Rated,”and programs that are considered

“unrated”because no code has been sent by the broadcaster.

TV Main Menu

1 Picture Quality

2 Screen

3 Channel

4 V-Chip Parental Controls

5 Time

0 Exit

Andere Handbücher für F19421

Inhaltsverzeichnis

Andere RCA Fernseher Handbücher

RCA

RCA 20F530T Bedienungsanleitung

RCA

RCA P46728 Bedienungsanleitung

RCA

RCA F27703 Bedienungsanleitung

RCA

RCA MR13401, M14300, M19401, M2030 Bedienungsanleitung

RCA

RCA LED42A45RQ Benutzerhandbuch

RCA

RCA J32DE220 Bedienungsanleitung

RCA

RCA F25209 Bedienungsanleitung

RCA

RCA F32676SBFM2CD2 Bedienungsanleitung

RCA

RCA F27450 Bedienungsanleitung

RCA

RCA F27250 Bedienungsanleitung

RCA

RCA MR20035 Bedienungsanleitung

RCA

RCA Victor 730TV1 Bedienungsanleitung

RCA

RCA 5inch BLACK & WHITE TVwith CD Player and AM/FM... Bedienungsanleitung

RCA

RCA RLED1540A Bedienungsanleitung

RCA

RCA R52WH73 Bedienungsanleitung

RCA

RCA 20F514TD Bedienungsanleitung

RCA

RCA EO9310 Bedienungsanleitung

RCA

RCA F27242GY Bedienungsanleitung

RCA

RCA Victor CTC9A Montageanleitung

RCA

RCA MM36100 Bedienungsanleitung

RCA

RCA P50830 Bedienungsanleitung

RCA

RCA E13309 Bedienungsanleitung

RCA

RCA 27GT720TX2AX1 Bedienungsanleitung

RCA

RCA F27440 Bedienungsanleitung

Beliebte Fernseher Handbücher anderer Marken

Philips

Philips Colour Television Bedienungsanleitung

Toshiba

Toshiba 27A10 Bedienungsanleitung

Philips

Philips 42PF9630A/37 Bedienungsanleitung

Hitachi

Hitachi 32FX48B Bedienungsanleitung

DAEWOO ELECTRONICS

DAEWOO ELECTRONICS DTQ-14V1FC Bedienungsanleitung

Changhong Electric

Changhong Electric uhd55b6000is Bedienungsanleitung

Philips

Philips Matchline 21CE7551 Bedienungsanleitung

Panasonic

Panasonic Genus TX-G10 Bedienungsanleitung

Toshiba

Toshiba 19A20 Bedienungsanleitung

Philips

Philips 25PT4523-16 Bedienungsanleitung

Sony

Sony XBR-100Z9D Bedienungsanleitung

Philips

Philips PR0930X3 Bedienungsanleitung

Philips

Philips Brilliance 231P4QPY Bedienungsanleitung

Samsung

Samsung 55S9 B Series Bedienungsanleitung

Philips

Philips 32HF9385D Fehlerbehebungshandbuch

Sharp

Sharp LC-40FI5012E Bedienungsanleitung

Loewe

Loewe Table Stand Reference 55 Bedienungsanleitung

Philips

Philips 32PFH5300 Bedienungsanleitung
