USER’S

GUIDE

Important Information

WARNING

To reduce the risk of fire or

shock hazard, do not expose

this TV to rain or moisture.

To reduce the risk of electric shock, do not remove

cover (or back). No user serviceable parts inside.

Refer servicing to qualified service personnel.

This symbol indicates

"dangerous voltage" inside

the product that presents a

risk of electric shock or

personal injury.

This symbol indicates

important instructions

accompanying the product.

WARNING

RISK OF ELECTRIC

SHOCK DO NOT OPEN

Caution: To reduce the risk of electric shock, match wide

blade of plug to wide slot, fully insert.

Attention: Pour éviter les chocs électriques, introduire la

lame la plus large de la fiche dans la borne

correspondante de la prise et pousser jusqú au fond.

Refer to the identification/rating label located on the back panel of your

product for its proper operating voltage.

FCC Regulations state that unauthorized changes or modifications to this

equipment may void the user’s authority to operate it.

If fixed (non-moving) images are left on the screen for long periods,

they may be permanently imprinted on the screen. Such images

include network logos, phone numbers, and video games. This

damage is not covered by your warranty. Extended viewing of

channels displaying these images should be avoided.

Cable TV Installer: This reminder is provided to call your attention to

Article 820-40 of the National Electrical Code (Section 54 of the Canadian

Electrical Code, Part 1) which provides guidelines for proper grounding and,

in particular, specifies that the cable ground shall be connected to the

grounding system of the building as close to the point of cable entry as

practical.

VCR Plus+, C3, PlusCode and GUIDE Plus+ are trademarks of Gemstar Development Corporation.

Product Registration

Please fill out the product registration card and return it immediately. Returning the card allows us to contact you if needed.

Keep your sales receipt to obtain warranty parts and service and for proof of purchase. Attach it here and record the serial and model

numbers in case you need them. The numbers are located on the back of the television.

Model No. _________________________________________________________

Serial No. _________________________________________________________

Purchase Date: ________________________________________________

Dealer/Address/Phone: ___________________________________________________________________________________

Table of Contents

Setup and Connections ..........................................................3

Step 1: Unpack the TV......................................................................4

Step 2: Connect Your TV ..................................................................4

TV Only .......................................................................................4

The Basic Connection.................................................................5

Advanced Connections ..............................................................6

Step 3: Connect the IR Controller....................................................9

Step 4: Plug in the TV.....................................................................10

Step 5: Place Batteries in Remote..................................................10

Step 6: Turn On the TV...................................................................10

Step 7: Program the TV..................................................................10

Interactive Setup .................................................................... 11

Using Point and Select ...................................................................12

Entering Setup................................................................................12

Selecting a Language.....................................................................13

Auto Channel Search .....................................................................13

The GUIDE PIus+ System ................................................................14

Setting Up the GUIDE PIus+ System........................................14

Setting the Time .............................................................................16

Setting the VCR1 Channel .............................................................17

Setting the VCR2 Channel .............................................................17

Setting the DVD Channel...............................................................18

Setting the SAT/CABLE Channel ....................................................19

Labeling the Channels ...................................................................20

Using the Remote..................................................................... 21

Remote Buttons..............................................................................22

Front Panel .....................................................................................24

Using the Menus.......................................................................25

Menus and Control Panels.............................................................26

Audio Menu....................................................................................28

Picture Quality Menu .....................................................................29

Screen Menu...................................................................................29

Using Closed Captioning .........................................................30

Channel Menu ................................................................................31

Table of Contents

Time Menu......................................................................................32

Other Menus...................................................................................32

Features and Controls......................................................... 33

GUIDE PIus+ Menu .........................................................................34

About the GUIDE PIus+ System .....................................................34

Getting In & Out of the Guide PIus+ System..........................35

Downloading Data ..................................................................35

The Different GUIDE PIus+ System Menus .............................36

Grid Guide..........................................................................37

Sort.....................................................................................38

Schedule.............................................................................39

Messages............................................................................40

Editor .................................................................................41

Channel Marker..............................................................................43

Parental Controls and V-Chip ........................................................44

V-Chip TV Rating Limit ............................................................45

V-Chip Movie Rating Limit ......................................................49

V-Chip Unrated Program Block ...............................................50

Channel Block ..........................................................................51

Front Panel Block .....................................................................51

Lock/Unlock Parental Controls ................................................51

Reference.....................................................................................52

Troubleshooting .............................................................................52

Care and Cleaning..........................................................................55

Limited Warranty ...........................................................................56

Accessory Information ...................................................................58

Index ............................................................................................. 61

Setup and Connections

Getting started

This manual is designed to get you started quickly.

The first five sections of the manual show you how to

get your TV Setup and Connected, run the Interactive

Setup, and use all of the menus, features, and

controls of your TV.

The Reference section in the back of the book

contains troubleshooting tips, care and cleaning

instructions, accessory ordering information and your

warranty.

Well… if your TV’s out of the box, let’s get started.

Check out the notes that have been added

throughout the manual in these Tip

Boxes. There are some important tips that

will help you get the most from your TV.

➣

Setup and connections

Interactive Setup

➣➣

Using the Menu System

Using the remote

➣

Features and Controls

➣

Reference

Setup and Connections

Step 1: Unpack the TV

Make sure to locate the remote control.

Step 2: Connect Your TV

There are three types of connections outlined in this section:

TV Only: If you’re only going to connect the

TV to your home antenna or cable

system.

The Basic Connection: If you’re going to connect the TV to a

VCR or satellite receiver.

Advanced Connections: If you’re going to make multiple

connections, hooking up the TV to a

VCR and a satellite receiver.

Cable information and illustrations are given for each type of connection.

Once you have completed your desired connection you may skip forward

to Step 3.

TV Only

This is a basic connection from an antenna or cable system to your TV.

Connect the cable into the Cable/Antenna jack as shown.

Cables

You will use the following cable to make your connection:

Coaxial Cable: These cables carry audio and

video signals to the TV from an antenna, cable, or

cable box.

CABLE, CABLE BOX, OR ANTENNA

CABLE/

ANTENNA

VCR

CONTROL

Once you have completed this connection you may skip to Step 3,

“Connect the IR Controller.”

Important Stand Information

CAUTION: Choose the location for your TV

carefully. Take precautions that the stand

or other furniture on which the TV is

placed is properly located (see Important

Safeguards sheet) and of adequate size

and strength to prevent the TV from

accidentally being tipped over, pushed off,

or pulled off. This could cause damage to

the TV and/or personal injury.

Before You Connect

Protect against power surges:

• Connect all components before

plugging any power cords into the wall

outlet.

• Turn off the TV and/or component

before connecting or disconnecting any

cables.

• Make sure all antennas and cables are

properly grounded. Refer to the

Important Safeguards sheet packed

with your TV.

Setup and Connections

The Basic connection

The basic connection below (TV and VCR) is the most common

connection and is therefore used to illustrate a single component

connection with your TV. For multiple component connection

information refer to the next section, Advanced Connections.

Cables

You will use the following type of cable to make your connection:

Coaxial Cables: In this connection, two Coaxial

Cables are used: one connects from an antenna,

cable, or cable box to the VCR, and one connects

from the VCR to the TV. These cables carry both

audio and video signals.

VCR 1

AUDIO

VIDEO

OUT

IN FROM ANT

OUT TO TV

CH3

CH4

CABLE, CABLE BOX, OR ANTENNACABLE, CABLE BOX, OR ANTENNA

CABLE/

ANTENNA

VCR

CONTROL

Once you have completed this connection you may skip to Step 3,

“Connect the IR Controller.”

How to View the VCR

To watch the VCR in this connection, tune

the TV to Channel 3 or 4.

Setup and Connections

CABLE/

ANTENNA

VCR

CONTROL

Advanced Connections

Advanced connections enable you to connect multiple components.

This section describes the types of inputs available on the back of your

TV and suggests ways you can use them for optimum performance.

Back of the TV

The diagram below describes each of the back panel jacks.

Once you have made your connections,

you will need to program the TV to tune

to the correct channel in order to see and

hear audio and video from the

component.

VCR Control

Connect the GUIDE Plus+

system IR controller for

one-button recording

and channel tuning from

the GUIDE Plus+ system.

Cable/Antenna

Takes the signal input from a cable,

cable box, or an off-air antenna. Can also

be used for basic component connections.

Setup and Connections

Sample Connections

The following are sample connection scenarios you may encounter when

connecting components to your TV.

Cables

You will use the following type of cable to make

your connection:

Coaxial Cables: Carries the signal from the

antenna or cable directly to the television or

through a cable box, as needed by your cable

system.

TV and VCR

Cautions:

Position Cables to Avoid Audio Hum

or Interference

• Insert all cables firmly into jacks.

• Try not to coil any twin-lead cables and

keep them away from any audio/video

cables.

Protect Your Components From

Overheating

• Do not block ventilation holes in any of

the components. Arrange the

components so that air can circulate

freely.

• Do not stack components.

• Allow adequate ventilation when

placing your components in a stand.

• Place an amplifier on the top shelf of

the stand so heated air rising from it

will not flow around other

components.

How to View Your VCR

To watch the VCR in this connection, turn on

both the TV and the VCR, then tune the TV to

the channel you specify on the back of the VCR

(in this case, channel 3).

VCR 1

IN FROM ANT

OUT TO TV

CH3

CH4

CABLE/

ANTENNA

VCR

CONTROL

CABLE, CABLE BOX, OR ANTENNA

Setup and Connections

How to View Your Components

To watch the satellite receiver in this

connection, turn on the TV and the satellite

receiver and press 03 (or 04) to tune the TV to

the correct channel.

To watch the VCR in this connection, turn on

the TV and VCR, enter 03 (or 04) to tune to the

VCR channel, and use the VCR buttons to play,

rewind, etc.

TV, VCR and Satellite Receiver

SATELLITE RECEIVER

VCR 1

IN FROM ANT

OUT TO TV SATELLITE

CH3

CH4

IN FROM ANT

OUT TO TV

CH3

CH4

CABLE/

ANTENNA

VCR

CONTROL

SATELLITE SIGNAL

CABLE, CABLE BOX, OR ANTENNA

Andere Handbücher für F27615

Inhaltsverzeichnis

Andere RCA Fernseher Handbücher

Beliebte Fernseher Handbücher anderer Marken

Philips

Philips Colour Television Bedienungsanleitung

Toshiba

Toshiba 27A10 Bedienungsanleitung

Philips

Philips 42PF9630A/37 Bedienungsanleitung

Hitachi

Hitachi 32FX48B Bedienungsanleitung

DAEWOO ELECTRONICS

DAEWOO ELECTRONICS DTQ-14V1FC Bedienungsanleitung

Changhong Electric

Changhong Electric uhd55b6000is Bedienungsanleitung

Philips

Philips Matchline 21CE7551 Bedienungsanleitung

Panasonic

Panasonic Genus TX-G10 Bedienungsanleitung

Toshiba

Toshiba 19A20 Bedienungsanleitung

Philips

Philips 25PT4523-16 Bedienungsanleitung

Sony

Sony XBR-100Z9D Bedienungsanleitung

Philips

Philips PR0930X3 Bedienungsanleitung

Philips

Philips Brilliance 231P4QPY Bedienungsanleitung

Samsung

Samsung 55S9 B Series Bedienungsanleitung

Philips

Philips 32HF9385D Fehlerbehebungshandbuch

Sharp

Sharp LC-40FI5012E Bedienungsanleitung

Loewe

Loewe Table Stand Reference 55 Bedienungsanleitung

Philips

Philips 32PFH5300 Bedienungsanleitung
