STEREO HEADPHONES WITH MICROPHONE
GD-500MV
USER’S MANUAL
Technical support: www.real-el.com
1
ENG
User’s Manual
GD-500MV
Congratulations on purchasing the ТМ REAL-EL headphones!
APPLICATION
GD-500MV stereo headphones with a microphone are designed for opera-
tion with PC sound cards and other compatible systems. They can be also
used in VoIP telephony, video conferencing, multimedia applications, inter-
active games, for speech recognition and learning foreign languages.
SAFETY PRECAUTIONS
•Don’t use the stereo headphones while driving.
•Don’t use the stereo headphones at high volume for a long time (more
than 15 minutes), as this may cause hearing impairment.
PACKAGE CONTENTS
•Stereo headphones – 1 pc
•User’s Manual – 1 pc
•Warranty card – 1 pc
SPECIAL FEATURES
•2 × 3.5 mm (3 pin) connector for PC
•Rotary microphone arm
•Volume control wheel on the cable
•Adjustable headband
CONNECTION AND OPERATION
•Connect the headphones connector to the audio output jack of your audio
source (PC, laptop, MP3 player), as shown in Fig. 1.
•Insert the microphone connector into the microphone input jack of your
audio source.
•Adjust the headphones volume level as desired with the volume control wheel
on the cable.
ENG
Technical support: www.real-el.com
2
Stereo Headphones with Microphone
GD-500MV
TECHNICAL SPECIFICATIONS
Parameter, measurement unit
Sensitivity, dB
Frequency range, Hz
Membrane, mm
Impedance, Ohm
Connection type
Cable length, m
Weight, g
Value
headphones: 106 ± 2
microphone: -48 ± 3
headphones: 18 – 22,000
microphone: 50 – 16,000
Ø 40
32
2 × Ø 3.5 mm (3 pin) stereo mini-jack
2.2
160
Notes:
• Technical specifications given in this table are supplemental informati-
on and cannot give occasion to claims.
• Technical specifications and package contents are subject to change
without notice due to improvement of TM REAL-EL production.
Fig. 1. Connection diagram
Volume control
wheel
Microphone
connector Microphone
Sound card
Phone out
Mic in
Рhone connector
Model: GD-500MV
Manufacturer: ENEL GROUP OU, Joe tn 5-39, Tallinn, Harjumaa 10151, Estonia.
Made in China.
® Registered Trademark of ENEL GROUP OU. Estonia.
