1
SmartCopier
(Parameter Read /Write Function)
User Manual
RealSYS
V2.21
2
iNOTE
•The specifications and contents of this product are subject to change for
performance improvement.
•Prohibit replication without permission, change, and the use in other applications
of software and related documentations.
•Free A/S is possible within the warranty period and if the failure is due to
carelessness of user handling, the repair costs may be paid by user.
•The person who actually use the products is responsible for damage, if it is
caused by the user’s carelessness or the safety precautions are not taken into
account.
•Except what is described in this book,
•When the product is damaged due to the improper use or approaches which is
not described in this manual, repair requests can be rejected.
SMART COPIER
3
•OPERATING PRECAUTIONS
•Use provided insulated DC 5V, above 2A product for external adapter.
•Use four reliable AA-type batteries for internal power source.
(Since the power consumption by inverter model is different,
it is recommended to use a lithium-ion battery.)
◈Power Supply
◈SD Card and USB
•When inserting or removing SD card, check that the product is in non-
operating state or the power is turned off in advance.
(SD card supports up to SDHC 64GB, but this takes a long time to initialize,
so it is recommended that no more than 8GB.)
•Do not turn off the power or separate the cable from the device before the
USB is disconnected in the user PC application program or PC is turned off
during USB communication.
◈Firmware Download
•Do not turn off the power during functional operations before success or
failure screen is displayed.
•Do not remove the SD card from the device during functional operations.
•Do not apply power to an inverter during functional operations.
•Do not disconnect the down load gender or cable during functional operations.
◈Parameter Read/Write
•Do not connect/disconnect RJ-45 cable terminal during functional operations.
•Do not remove the SD card from the device during functional operations.
◈Inverter Connector and Gender
•Be careful not to pinch the conductive material in the gap of the connector
terminal or gender.
•Be careful with the direction of polarity when connecting the gender to the
inverter.
!
SMART COPIER
4
Contents
1. Specifications …… 5
2. Exterior …… 6
3. Monitor Functions …… 8
4. Input Devices …… 11
5. Operation and Use Description …… 14
6. Smart Copier Firmware Update …… 21
SMART COPIER
5
Item Description Note
Product •SmartCopier Firmware/Parameter combined
•SmartCopier Parameter only
Display •Black and white graphic LCD 128 x 64 (green backlight
available)
•Power / Error / Read / Write State LED
Input Device •Main body power ON / OFF switch
•Up / Down / Mode / Enter / Shift button key
•USB 2.0 Communication Terminal
Output Device •RJ45 Communication Terminal ( for Parameter Comm. )
•Connector / Flat 10P Cable (for Gender Firmware Download
Memory Card •SD Card SDHC (Up to 64GB, recommend 8GB)
•FAT32
Power
Standard
•Battery for internal power (four general AA-type batteries)
(In the case of providing the battery, and enables
Parameter features more than 500 times)
Adapter for external power (insulated DC 5V, above 2A)
Refer
to
16page
Software •Support window file conversion and management program
•Support window device driver
•Windows XP, Windows Vista, Windows 7, 8,10 compatible.
Main Function •Firmware Download / Parameter Read / Parameter Write
•Target power supply
•USB insulation function
Supporting
Model & CPU
Type
•S100 / H100 / iS7 Inverter Model
•Freescale Coldfire MCF51JM32
•Freescale Coldfire MCF51JM128
•TI-DSP TMS320F2809
•TI-DSP TMS320F2811
Size & Weight •70 x 190 x 30 ( Width x Length x Height )
•Weight 250g ( except battery weight )
mm
Package •Main Body 1Set / User Manual / Software CD / USB2.0
Cable / SD Card 8GB / DC Power Adapter (절연형) /
AA Lithium-ion Battery Set / RJ-45 Cable
Certification •MIC Certification KOREA
1. Specifications
SMART COPIER
6
2. Exterior
2.1 Front
LCD Display
2.1 Side
Power Switch
SMART COPIER
State LED
Key Button
<Left Side> <Right Side>
USB Terminal
External Power
Input Terminal
SD Card Slot
Battery Cover
7
2.2 Top
Firmware
Download Terminal
Parameter
Communication
Terminal ( RJ-45 )
2.3 Back
Battery Case
( AA-Size x4 )
SMART COPIER
Battery Cover
8
3. Monitor Functions
Status bar
Contents display
Cursor display
3.1 LCD Monitor Display
- Type of state Icon
/ /
: Firmware Download Mode Display
: Parameter Read/Write Mode Display
: Inverter Model Display
: Parameter Write Mode Display
: Parameter Read Mode Display
: BDM Write Mode Display
: Real DSP-UT Write Mode Display
/ : Battery Status Display
: USB Connection Status Display
: SD Card Insertion Status Display
SMART COPIER
9
- Information message type
This screen is displayed when SD Card is empty in
the SD Card slot terminal of the product. If you
press the Shift key, you can ignore the message.
This screen is displayed in the process of
recognizing the Card when you insert the SD card
to slot terminal. Do not remove the SD Card at this
time.
This screen is displayed when the inverter is
turned on and in the operating state. To continue
the operation, turn off the power of the inverter of
disconnect the connector from the inverter.
This screen is displayed when the application
installed on the user’s PC and the main body of
product are communicating. Until it is
disconnected from the PC program, the user can
not execute any operation.
SMART COPIER
10
①Power Status LED
②Error Status LED
3.2 Display Functions
③Read Status LED
④Write Status LED
LED Color Waveform State Description
Power
Status LED
Green ON Steady power input state
Green Toggle
(1s intervals) Low battery state
Error Status
LED
Red Toggle
(1s intervals) Operation error or failure state
Red Toggle
(1s intervals)
Not under functional operating
condition
Read Status
LED Green Toggle
(1s intervals)
State of reading data from the
target
Write Status
LED Green Toggle
(1s intervals)
State of writing data to the
target
ON continue
ON repeat
ON repeat
ON repeat
ON repeat
ON repeat
- LED Display State
SMART COPIER
① ② ③ ④
