Red Sea ReefRun® Dual Controller
3
User Manual
ReefRun Dual Controller
Red Sea ReefRun® Dual Controller
4
ENG
Red Sea ReefRun® Dual Controller
5
Contents
Introduction....................................................................................6
Safety..............................................................................................7
Guide to the ReefRun Dual Controller (RRDC) ............................8
LED Indicators.................................................................................9
Introduction to the ReefBeat app ..............................................11
Preparations before installing ...................................................11
Connection Diagram....................................................................12
Connection and initial Setup.......................................................13
ReefBeat Device Manager..........................................................17
Troubleshooting ...........................................................................19
Certificate of Warranty................................................................20
Red Sea ReefRun® Dual Controller
6
Introduction
Congratulations on your purchase of Red Sea’s ReefRun Dual Controller.
The ReefRun Dual controller provides control of up to 2 ReefRun
compatible DC return pumps, DC skimmer or a combination of both.
The ReefRun Dual controller provides the basic functionality of switching
each pump on/off and setting the flow intensity. The ReefBeat App
provides a complete range of features for controlling each of the pumps
connected to the ReefRun Dual controller such as daily schedules or
pulsing wave programs.
The ReefRun controller also allows the installation of an optional dual
action Skim-sensor that enables the automatic self-leveling to prevent
over-skimming and collection cup overflow.
The ReefRun Dual Controller is part of Red Sea’s suite of smart devices
that are operated via Wi-Fi by Red Sea’s ReefBeat® App, which needs to
be installed on a smart mobile device with internet connectivity.
Welcome to Red Sea’s smart reef-keeping.
Sincerely,
The Red Sea Team
ENG
Red Sea ReefRun® Dual Controller
7
Safety
PLEASE READ AND FOLLOW ALL SAFETY INSTRUCTIONS
THIS DEVICE IS INTENDED FOR INDOOR USE ONLY.
DANGER: To avoid possible electric shock, special care should be
taken when handling a wet aquarium. For each of the
following situations, do not attempt repairs yourself; return
the appliance to an authorized service facility for service or
discard the appliance.
WARNING: To guard against injury, basic safety precautions should be
observed, including the following:
Do not operate any appliance if it has a damaged cord or plug, if it is
malfunctioning, or if it is dropped or damaged in any manner.
This appliance can be used by children aged from 8 years and above and
persons with
reduced physical, sensory, or mental capabilities or lack of experience
and knowledge if they
have been given supervision or instruction concerning use of the
appliance in a safe way and
understand the hazards
involved. Children shall not play
with the appliance. Cleaning
and user maintenance shall not
be made by children without
supervision.
The appliance is only to be used
with the power supply unit
provided with the appliance.
Close supervision is necessary when any appliance is used by or near
children.
To avoid injury, do not contact moving parts.
Always unplug an appliance from an outlet when not in use, before
putting on or taking off parts, and before cleaning. Never pull the cord
itself to remove the plug from the outlet. Grasp the plug and pull to
disconnect.
Do not use an appliance for anything other than its intended use.
The use of attachments not recommended or sold by the appliance
manufacturer may cause unsafe conditions.
Do not install or store the appliance where it will be exposed to the
weather or to temperatures below freezing point.
Make sure an appliance is securely installed before operating it.
Read and observe all the important notices on the appliance.
Note: A cord rated for less amperes or watts than the appliance
rating may overheat. Care should be taken to arrange the cord
so that it cannot be tripped over or pulled accidentally.
Do not use if cord is damaged. In case of need, do not
attempt to replace or repair yourself; return the appliance
to an authorized service facility for service or discard the
appliance.
In case of need, do not attempt to replace yourself; return
the appliance to an authorized service facility for service or
discard the appliance.
Red Sea ReefRun® Dual Controller
8
Guide to the ReefRun Dual Controller (RRDC)
Buttons & ports LED indicators
1 2
Pump 1
Pause/Resume
Flow intensity dial
Pump 1
Port Settings
Button RSK
Sensor
Port
Pump 2
Port
Pump 2
Pause/Resume
Flow intensity dial
1 2
Pump 1
Flow Intensity
Indicator LEDs
Pump 1
Status LED Settings
Indicator
LED
RSK
Sensor
Status LED
Pump 2
Status LED
Pump 2
Flow Intensity
Indicator LEDs
ENG
Red Sea ReefRun® Dual Controller
9
LED Indicators
Pump 1 - 2 Status LED Indicator:
• Solid Red light – Pump PSU is attached.
• No Red light – Pump PSU is not attached.
Settings LED Indicator:
• Solid Red light – RRDC is connected to the home-network.
• Blinking Red light – RRDC is in Wi-Fi Access Point (AP) mode (can
be discovered by Wi-Fi devices).
• Rapid Blinking Red light – Controller cannot access the home-
network (network name and/or password are incorrect or known
network has become unavailable)
• No Red light – RRDC Wi-Fi is off.
• Double blink – indicates change of status / end of process.
RSK Sensor Status LED Indicator:
• Solid Red light – Self-leveling is enabled
• No Red light –Self-leveling is disabled.
• Blinking Red light – Pump intensity is “Self-leveling”
Flow intensity LED Indicator:
• Solid Red lights – Pump intensity from 10% to 100%
• No Red lights – Pump is OFF.
• Blinking Red lights 10% & 100% – Pump is missing/disconnected
• Blinking Red lights 20%,30%,80% & 90% – Pump malfunction
(stalled or not in water)
Pump Disconnect
Pump malfunction
100%
100%
10%
10%
90%
90%
20%
20%
80%
80%
30%
30%
70%
70%
40%
40%
60%
60%
50%
50%
Red Sea ReefRun® Dual Controller
10
Settings Button – Function
If indicator LED is off (ReefRun Dual Controller Wi-Fi is off): Pressing
button for 5 seconds (until double blink) activates Wi-Fi AP mode.
If indicator LED is blinking (ReefRun Dual Controller Wi-Fi is in AP mode):
Pressing button for 5 seconds (until double blink) switches Wi-Fi off.
If indicator LED is on (ReefRun Dual Controller Wi-Fi is connected
to a Wi-Fi network): Pressing button for 5 seconds (until double blink)
disconnects the ReefRun Dual Controller from the network and switches
it to Wi-Fi AP mode. (Note: before disconnecting a ReefRun Dual
Controller from a network, delete the specific ReefRun Dual Controller
from the ReefBeat App via the Device Manager).
Note: All settings are retained and can be restored when reconnected to
the ReefBeat.
Reboot: Pressing and releasing the button for less than 2 seconds will
cause the unit to shut down and restart. Wi-fi and pumps will stop
momentarily during the process. User settings are not affected.
Clear Settings: Pressing the button for 15 seconds (until double blink)
deletes all user settings and switches the Wi-Fi to AP mode. Complete
the reset process by disconnecting and reconnecting the DC power.
Pause/Resume and Flow-intensity Dial
After a pump has been set up on the RRDC the Pause/Resume and
Flow-intensity Dial becomes active.
When a pump is running, a short press on the dial will switch the pump
off. A second short press will switch the pump back on and resume
whatever intensity is currently scheduled for the pump.
If a pump is in a malfunction state, and after the issue has been
resolved, a short press on the dial will restart the pump.
To manually change the flow intensity for a pump from the controller,
press on the dial for 5 seconds until the indicator LEDs around the dial
start to blink. While the LEDs are blinking, rotate the dial clockwise /
counter-clockwise to increase / decrease the flow intensity. When you
have reached the desired new intensity press on the dial for 5 seconds
to save the new settings.
Note: In the App, flow intensity can be set in increments of 1%. The LED
indicators on the dial show the intensity in 10% bands. When rotating
the dial, each “click” is equivalent to a 2% change in intensity so it will
take 5 clicks to advance from one indicator LED to the next.
