Redmond KP1106 Bedienungsanleitung
USER MANUAL
WO006
Model NO: KP1106
WINE OPENER
Package Contents
a) 1 x Wine Opener d) 1 x Foil cutter
b) 1 x Wine Preserver e) 1 x Charging base
c) 2 x Wine Stoppers f) 1 x Power Adaptor
g) 1 x Wine Pourer
• If you find any of the above is missing, please
contact your retailer
IMPORTANT SAFETY INSTRUCTIONS
Please read these instructions thoroughly before using the
product.
1. This Wine Opener and Wine Preserver Set is intended for
household use only.
2. This Wine Opener and Wine Preserver Set is intended to
extract
the corks from standard wine bottles.
3. Do not operate the Wine Opener and Wine Preserver Set
with a damaged AC/DC Adapter or Charging Base. If the AC/DC
Adapter is damaged it must be replaced by the manufacturer or
a suitably qualified person.
4. Do not place the appliance near an open flame, cooking or
heating appliance, or hot surface.
5. This appliance is not intended for use in wet or damp
conditions.
6. Ensure that the power cord is positioned so that it will
not get damaged or cause a trip hazard.
Wine Opener
Wine Preserver
Charging Base
Wine Pourer Foil Cutter
Wine Stoppers
7. Use only the AC/DC Adapter and Charging Base supplied with
the appliance.
8. Do not immerse the appliance in water or any other liquid.
9. For indoor use only. Do not expose the Wine Opener and Wine
Preserver Set or Charging Base to rain or other extreme
conditions.
10. Never force the Wine Opener and Wine Preserver Set onto a
bottle or attempt to speed up the mechanism. The Cork Remov-
er will work best when it is operated at its intended speed.
11. Do not touch or adjust the Wine Opener and Wine Preserver
Set mechanism or the corkscrew spiral. Only hold the
Cork Remover by its plastic housing.
12. This appliance contains a re-chargeable battery. Do not
dispose
of the product on a fire as this may cause an explosion.
13. This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities,
or lack of experience and knowledge unless they have been
given supervision or instruction concerning use of the appliance
by a person responsible for their safety. Children should be
supervised to ensure that they do not play with the appliance.
14. To avoid electric shock do not open the casing. There are no
user serviceable parts inside.
CAUTION: The corkscrew is sharp. Keep body parts (e.g.
fingers) and utensils away from the operating end of the Wine
Opener.
OPERATION
1. Charging the Wine Opener and Wine Preserver Set
It is recommended that the Wine Opener and Wine Preserver Set
is charged for at least 12 hours before using it for the first time.
Please follow the instructions for charging the unit below:
Connect the DC Power Plug into the DC Power Socket at the
back of the Charging Base.
Place the Wine Opener and Wine Preserver Unit into the
Charging Base. Ensure that the arrows on the Unit and Base
align with each other so that the electrical connections are
made correctly.
Insert the AC/DC Adapter into a mains socket and switch on
the supply.
The Charging Indicator will illuminate blue, indicating that the
battery is charging. The light will turn off when fully charge the
battery . It will take 10-12 hours to fully charge the battery.
Switch off the supply and remove the AC/DC Adapter from the
mains socket. Remove the DC Power Plug from the Charging
Base.
The Wine Opener can be used to open up to 30 bottles when
fully recharged.
2. Opening a Wine Bottle by Wine Opener
Before extracting the cork please remove any seal from the
bottle using the Foil Cutter provided (see Fig.2)
Place the Wine Opener on top of the wine bottle making sure
that it remains as upright as possible at all times. If you hold
the Wine. Opener at an angle to the bottle it will not remove the
cork properly. (see Fig.3)
2
3
IHold the Wine Opener and bottle firmly. Press and hold the
Pull ▼ Button. The corkscrew spiral will turn in a clockwise
direction and enter the cork, then gradually remove it from the
bottle. When the Cork Remover mechanism stops, the cork will
be visible through the transparent window and the blue indica-
tor will go off.
Lift the Wine Opener away from the bottle. To remove the cork
simply press and hold the Release ▲ Button and the spiral will
turn in an anticlockwise direction and release the cork. (see
Fig.4)
Return the Cork Remover to the Charging Base when not in
use, so as to protect the mechanism.
This Wine Opener is designed for use with traditional corks,
but it may be used with synthetic corks as well. Synthetic corks
are smaller and do not expand like normal cork so sometimes
they may stick on the spiral. If this happens, hold the cork
firmly with a small pair of pliers. Press the Release ▲Button
as normal and allow the cork to be slowly released.
3.Serve Wine by Wine Pourer
Place the Aerating pourer into the bottle neck snugly to allow
the wine to pour smoothly without splashing the drinker or
other places.
4
4. Vacuuming a wine bottle by Wine Preserver
Notes: Not all bottles need to be vacuumed.
We recommend you to vacuum the bottle with wine
remaining if you want to keep fresh for 3-5days Operating Process.
1).Place the wine bottle on a flat surface
2). Insert a wine stopper into the wine bottle (Fig.1).
3). Hold the wine stopper & wine bottle neck securely in one hand
and place the non-slip mouth of the Wine Preserver on the wine
stopper (Fig.2).
4). Keep the Wine Preserver as straight as possible and in line with
the wine bottle.
5). Push down on the wine stopper and press the power ‘on’ button
at the same time.
6). The Wine Preserver starts to work removing the air from the
bottle while making a clacking noise.
7). The clacking noise will become slower and stop suddenly after
20 seconds.
8). Do not release the power button until the unit stops.
9). Remove the Wine Preserver and replace on its charging base
until it is needed again.
Note: The non-slip mouth may attach itself to the wine stopper. In
this case, hold the wine stopper and the neck of the bottle
securely in one hand and tilt the Wine Preserver away from the
wine stopper to break the suction. This should prevent air
from re-entering the bottle. If in doubt, repeat the above operating
process.
Fig.1
Fig.2
Suggestion: For more than half a bottle of wine remaining – one
session should suffice. For less than half a bottle we suggest
you repeat the above process a 2nd time.
4.Date Indicators
1. Use the “ ▼ ” symbol to indicate the date when the bottle was
sealed with your Wine Preserver.
2. Gently swivel the silver ring to left or right until the correct
date is in line with the “ ▼ ” symbol (Fig.3).
Opening
• Firmly hold the bottle in one hand and gently ease the wine
stopper away from the bottle with the other hand.
• Store the wine stoppers in a clean safe place until next
required.
After Use
• We recommend that you return your Wine Opener and Wine
Preserver to the Charging base so that it is fully charged and
available to use at any time.
• Wipe the Wine Opener and Wine Preserver Set and Charging
Base with a soft, dry cloth.
Battery & Product Disposal Information
Recycling and Disposal
• This Wine Preserver contains rechargeable batteries. Before
you dispose of your Wine Opener and Wine Preserver you
should remove the batteries and dispose of them responsibly.
To take out the battery pack remove the screws from the rear
cover. Dispose of the rechargeable batteries and product
responsibly.
Fig.3
Recycling and Disposal
The WEEE directive (Waste Electrical and Electronic Equipment;
2002/96/EC) has been put in place to ensure that products are
recycled using best available treatment, recovery and recycling
techniques to ensure human health and high level environment
protection. Your product is designed and manufactured with
high quality materials and components, which can be recycled
and reused.
Do not mix products bearing the crossed out bin symbol with
your general household waste. Please recycle where facilities
exist. Check with your Local Authority or retailer for recycling
advice.
