model: InView™ Pedometer
Data Visible Only to the User
Featuring:
• Step & Distance Tracking
• Time in Motion
• Calories Burned
RB5298IS01SPO.indd 1RB5298IS01SPO.indd 1 6/16/11 3:33 PM6/16/11 3:33 PM
INDEX
BUTTON FUNCTIONS pg04
ACTIVATE YOUR PEDOMETER pg05
INSTALLING THE CLIP pg06
RESETTING PEDOMETER pg07
MODES pg08-13
overview pg09
steps pg10
distance pg11
calories pg12
activity timer pg13
SET UP pg14-20
entering set up pg15
units of measure pg16
weight pg17
height pg18
stride pg19
exiting set up pg20
APPENDIX pg21-27
measuring stride length pg22
care & maintence pg23
warnings & cautions pg24
battery replacement pg25
battery safety info pg26
restore factory settings pg27
WARRANTY pg28
We’d like to thank you for choosing a REEBOK tness
product to guide you on your journey to improved
health and tness.
We strive to create quality products which are
functional, accurate, well designed and easy to use.
We believe everyone should have access to information
which will help them achieve their tness goals.
If you have questions, comments or need assistance
please contact Customer Support by calling
1-866-694-4575.
RB5298IS01SPO.indd 2-3RB5298IS01SPO.indd 2-3 6/16/11 3:33 PM6/16/11 3:33 PM
4 5
PRODUCT OVERVIEW
PRODUCT OVERVIEW
Use a coin to unscrew battery cap. Remove the clear plastic battery tab,
reinsert the battery, then screw the cap back into place.
MODE/RESET
SET
INCREASE
DECREASE
BATTERY
COVER
RESTORE
FACTORY
SETTINGS
remove clear
plastic sheet
BUTTON FUNCTIONS ACTIVATING THE PRODUCT
RB5298IS01SPO.indd 4-5RB5298IS01SPO.indd 4-5 6/16/11 3:33 PM6/16/11 3:33 PM
6 7
INSTALLING THE CLIP
PRODUCT OVERVIEW
PRODUCT OVERVIEW
Installing the clip is easy. Simply tuck one edge of the pedometer
into the clip, then push the other side into place.
To reset all pedometer functions to zero,
press & hold the MODE (REEBOK) button for 3 seconds.
Press &
HOLD
RESET PREVIOUS WALK DATA
RB5298IS01SPO.indd 6-7RB5298IS01SPO.indd 6-7 6/16/11 3:33 PM6/16/11 3:33 PM
8 9
MODES
features & functions.
MODES
Press the MODE (REEBOK) button to advance through the functions
(STEPS, DISTANCE, CALORIES, ACTIVITY TIMER)
Press to cycle
through
functions
RB5298IS01SPO.indd 8-9RB5298IS01SPO.indd 8-9 6/16/11 3:33 PM6/16/11 3:33 PM
10 11
MODES
MODES
MODE 1: STEPS
The step counter will begin counting after 5 consecutive steps
to eliminate false readings.
Distance is measured based on a stride length calculated in the setup.
MODE 2: DISTANCE
RB5298IS01SPO.indd 10-11RB5298IS01SPO.indd 10-11 6/16/11 3:33 PM6/16/11 3:33 PM
12 13
MODES
MODES
MODE 3: CALORIES BURNED
Calories are calculated based on the weight you enter in the setup. Activity Time (TMR) is the total time you are actually moving throughout
the day. If you are not moving, the timer will not increase.
MODE 4: ACTIVITY TIME
RB5298IS01SPO.indd 12-13RB5298IS01SPO.indd 12-13 6/16/11 3:33 PM6/16/11 3:33 PM
14 15
SETUP
SETUP
Press MODE button until you are on the STEP screen. Press & hold the SET
button for 3 seconds to enter SETUP. The screen will empty & “LB”will ash
on the far right of the screen to indicate that you are now in SETUP MODE.
Press & hold
SET to enter
SETUP
TIP: Ensure set button is fully
depressed. You may need
to use an object if you are
unable to use your nger.
STEP 1:
ENTER SETUP MODE
RB5298IS01SPO.indd 14-15RB5298IS01SPO.indd 14-15 6/16/11 3:33 PM6/16/11 3:33 PM
16 17
SETUP
SETUP
Select your preferred units of measure:
IMPERIAL (lbs/miles) or METRIC (kg/km).
change
accept
setting
Set your weight. Be sure to go back & update
your weight as you meet your tness goals.
accept
setting
decrease
increase
STEP 2:
UNIT OF MEASURE
STEP 3:
SET WEIGHT
LB
RB5298IS01SPO.indd 16-17RB5298IS01SPO.indd 16-17 6/16/11 3:33 PM6/16/11 3:33 PM
18 19
SETUP
SETUP
Height setting creates an automatic stride length.
See following page for more details.
accept
setting
decrease
increase
Stride length is the average length of your stride.
It is based on your height setting, but can be adjusted
for your preference. See appendix for more details.
NOTE: The number
shown is based on the
height you entered, so
it may be something
other than the “30”
shown here.
accept
setting
decrease
increase
STEP 4:
SET HEIGHT
STEP 5:
STRIDE LENGTH
RB5298IS01SPO.indd 18-19RB5298IS01SPO.indd 18-19 6/16/11 3:33 PM6/16/11 3:33 PM
