Owners &

Installation Manual



Installer



Homeowner:

MODELS: GEM54-NG

GEM54-LPG

GEM54-ULPG

LISTINGS AND CODE APPROVALS

These gas appliances have been tested in

accordance with AS4558 / NZS 5262 and

have been certied by the Australian Gas

Association for installation and operation

as described in these Installation and

Operating Instructions.





2Regency Gemﬁre™ Gas Fireplace

To the New Owner:

Congratulations!

You are the owner of a state-of-the-art Gas Fireplace by REGENCy®. The Gem54 has been

designed to provide you with all the warmth and charm of a wood replace at the ick of a switch.

The model Gem54 has been approved by AGA for both safety and efciency. As it also bears

our own mark, it promises to provide you with economy, comfort and security for many trouble

free years to follow. Please take a moment now to acquaint yourself with these instructions and

the many features of your Regency® Fireplace.

Regency Gemﬁre™ Gas Fireplace 33

TABLE OF CONTENTS

DATA BADGE

Copy of Data Badge ......................................................4

DIMENSIONS

Unit Dimensions ............................................................5

Faceplate & Door frame overlay Dimensions ................5

INSTALLATION

Important Message ......................................................6

Before You Start ............................................................6

General Safety...............................................................6

Information.....................................................................6

Installation Checklist ......................................................7

Locating Your Gas Fireplace .........................................7

Clearances ....................................................................8

Non-Combustible Requirements ...................................8

Mantel Clearances.........................................................9

Mantel Leg Clearances..................................................9

Framing & Finishing.....................................................10

Unit Assembly Prior To Installation ..............................12

Standoff Assembly ...............................................12

Nailing Strips ........................................................12

Venting Introduction .....................................................12

Vent Restrictor Position ...............................................13

Exterior Flue Termination Locations ............................14

Venting Arrangements ................................................15

Horizontal Termination (Flex) ...............................15

Rigid Pipe Venting Systems ........................................16

Basic Horizontal & Vertical Terminations .............16

5” x 8” Rigid Pipe Cross Reference Chart ...................17

Venting Arrangements ................................................19

Allowable Horizontal Terminations .......................19

Venting Arrangements ................................................20

Allowable Horizontal Terminations for Gem54-lpg/

ulpg ......................................................................20

Venting Arrangements ................................................23

Allowable Vertical Terminations for Gem54-ng ....23

Venting Arrangements ................................................24

Allowable Vertical Terminations for Gem54-lpg/

ULPG ...................................................................24

Unit Installation with Horizontal Termination ................25

Unit Installation with Vertical Termination ....................26

Unit Installation ............................................................27

High Elevation .............................................................28

Gas Line Installation ....................................................28

Pilot Adjustment ...........................................................28

Gas Pipe Pressure Testing ..........................................28

S.I.T. Valve Description ................................................28

Conversion Kit # 476-967 from NG to LPG ................29

Conversion Kit #476-968 from NG to ULPG................29

Aeration Adjustment ....................................................32

Wiring Diagram ...........................................................32

Optional Stainless Steel ..............................................33

Reective Panel Installation ........................................33

Glass Crystals or optional ceramic stones ..................34

Installation On Burner ..................................................34

Optional Pebble Installation .........................................34

Log Set Installation ......................................................35

Screen & Door frame overlay Installation ....................38

Faceplate installation ...................................................39

OPERATING INSTRUCTIONS

Operating Instructions .................................................41

First Fire ......................................................................41

Lighting Procedure ......................................................41

Shutdown Procedure ...................................................41

Normal Operating Sounds of Gas Appliances .............41

Copy of Lighting Plate Instructions ..............................42

MAINTENANCE

Fan Service .................................................................43

Wiring ..........................................................................45

Maintenance Instructions.............................................46

General Vent Maintenance ..........................................46

Thermopile / Thermocouple .........................................46

Glass Gasket ...............................................................46

Glass Door...................................................................46

Glass Replacement .............................................46

Glass Door Removal ...................................................47

DC Spark Box Battery Replacement ...........................48

DC Spark Box Replacement........................................48

Valve Tray Replacement ..............................................49

PARTS LIST

Main Assembly ............................................................51

Accessories .................................................................52

WARRANTY

Warranty ......................................................................55

4Regency Gemﬁre™ Gas Fireplace

SAFETY LABEL

This is a copy of the badge that accompanies each Gem54™-NG Direct Vent Gas Fireplace. We have printed a copy of the contents here for your review.

NOTE: Regency® units are constantly being improved. Check the badge on the unit and if there is a difference, the badge on the unit is the correct

one.

COPY OF DATA BADGE

Electrical: Millivolt Only

Serial

Number 345

918-785

N2134

Regency Gas Fireplace

Gas Type NG LPG ULPG

Model Gem54-NG Gem54-LP Gem54-ULPG

Gas Consumption 35.9 mj. 32.2mj. 28.7mj.

Manifold Pressure 0.88 kPa 2.49kPa 2.49 kPa

Injector Size 1 x #32 1 x#51 1 x #52

2.95mm 1.70mm 1.61mm

Model

AGA Approval number to: # 7493

Code AS4558 / NZ5262

Distributed by:

Western Australia:

Eastern Australia:

Air Group Australia

28 Division St

Welshpool WA 6106

To be installed by an authorised person in

accordance with installation instructions provided

with the appliance.

Fireplace Products

Australia Pty. Ltd.

21-23 South Link Blvd.

Dandenong, VIC 3175

DO NOT

OPERATE THIS APPLIANCE BEFORE READING THE

INSTRUCTIONS BOOKLET.

PLACE ARTICLES ON OR AGAINST THIS APPLIANCE

STORE CHEMICALS OR FLAMMABLE MATERIALS

SPRAY AEROSOLS IN THE VICINITY OF THIS

APPLIANCE WHILE IN OPERATION.

OPERATE WITH PANELS, COVERS OR GUARDS

REMOVED FROM THIS APPLIANCE.

ENCLOSE THIS APPLIANCE.

DO NOT MODIFY THIS APPLIANCE.

NEAR THIS APPLIANCE.

DO NOT

908-602a

(Australia Only)

909-133

“PRIMARILY A DECORATIVE

APPLIANCE NOT CERTIFIED

AS A SPACE HEATER”

WARNING:

Regency Gemﬁre™ Gas Fireplace 5

DIMENSIONS

59” (1499mm)

52-5/8” (1337mm)

48-1/2” (1232mm) 20-1/2” (521mm)

19-3/4” (502mm)

10-5/8”

(270mm)

1-1/2”

(38mm)

31-5/8” (803mm)

46-3/8” (1178mm)

35-1/4” (895mm)

22-3/8” (568mm)

17-1/8” (435mm)

5-11/16”

(144mm)

FACEPLATE & DOOR FRAME OVERLAY DIMENSIONS

UNIT DIMENSIONS

6Regency Gemﬁre™ Gas Fireplace

INSTALLATION

13) Do not slam shut or strike the glass door.

 Under no circumstances should any solid

fuels (wood, paper, cardboard, coal, etc.) be

used in this appliance.

 The appliance area must be kept clear and

free of combustible materials, (gases and

other ammable vapours and liquids).

IMPORTANT MESSAGE

SAVE THESE

INSTRUCTIONS

The Gem54™ Direct Vent Fireplace must be

installed in accordance with these instructions.

Carefully read all the instructions in this manual

rst. Consult the "authority having jurisdiction"

to determine the need for a permit prior to

starting the installation. It is the responsibility of

the installer to ensure this replace is installed

in compliance with manufacturers instructions

and all applicable codes and complies with a

S5601 / AG601 clause 5.12, 13.2 and 5.12, 13.5.

BEFORE YOU START

INSTALLATION AND REPAIR SHOULD

BEDONEBYANAUTHORIZEDSERVICE



CLOTHING OR OTHER FLAMMABLE

MATERIALSHOULDNOTBEPLACED



GENERAL SAFETY

INFORMATION

SHOULD BE INSPECTED BEFORE

USE AND AT LEAST ANNUALLY BY A

  

MORE FREQUENT CLEANING MAY

BE REQUIRED DUE TO EXCESSIVE

LINT FROM CARPETING, BEDDING

    

THAT CONTROL COMPARTMENTS,

BURNERS AND CIRCULATING AIR

PASSAGEWAYS OF THE APPLIANCE



DUE TO HIGH TEMPERATURES, THE

APPLIANCE SHOULD BE LOCATED

OUT OF TRAFFIC AND AWAY FROM



WARNING: FAILURE TO INSTALL THIS

APPLIANCE CORRECTLY WILL VOID

YOUR WARRANTY AND MAY CAUSE



CHILDREN AND ADULTS SHOULD BE

ALERTED TO THE HAZARDS OF HIGH

SURFACE TEMPERATURES, ESPE

CIALLY THE FIREPLACE GLASS, AND

SHOULD STAYAWAY TO AVOID BURNS



YOUNG CHILDREN SHOULD BE CARE

FULLY SUPERVISED WHEN THEY

ARE IN THE SAME ROOM AS THE



1) The appliance installation must conform with

local codes or, in the absence of local codes,

with the current Installation and Building

Codes.

2) The appliance when installed, must be

electrically grounded in accordance with

local codes.

3) See general construction and assembly

instructions. The appliance and vent should

be enclosed.

 This appliance must be connected to the

specied vent and termination cap to the

outside of the building envelope. Never vent

to another room or inside a building. Make

sure that the vent is tted as per Venting

instructions.

 Inspect the venting system annually for

blockage and any signs of deterioration.

6) Venting terminals shall not be recessed into

a wall or siding.

7) Any safety glass removed for servicing must

be replaced prior to operating the appliance.

8) To prevent injury, do not allow anyone who

is unfamiliar with the operation to use the

replace.

9) Wear gloves and safety glasses for protection

while doing required maintenance.

10) Be aware of electrical wiring locations in

walls and ceilings when cutting holes for

termination.

11) Under no circumstances should this

appliance be modied. Parts that have to be

removed for servicing should be replaced

prior to operating this appliance.

12) Installation and any repairs to this appliance

should be done by an authorized service

person. A professional service person should

be called to inspect this appliance annually.

Make it a practice to have all of your gas

appliances checked annually.

"THIS UNIT MUST ALWAYS

TERMINATE / VENT

DIRECTLY TO THE OUTDOORS."

Regency Gemﬁre™ Gas Fireplace 7

INSTALLATION

This includes:

1) Clocking the appliance to ensure the correct

ring rate (rate noted on label 41,500 Btu/h,

after burning appliance for 15 minutes.

2) If required, adjusting the primary air to ensure

that the ame does not carbon. First allow

the unit to burn for 15-20 min. to stabilize.



     

       



LOCATING YOUR

GAS FIREPLACE

A) Flat on Wall

B) Flat on Wall Corner

C) Recessed into Wall/Alcove

D) Corner

Diagram 1

1) When selecting a location for your replace,

ensure that the clearances are met.

2) The appliance must be installed on a at,

solid, continuous surface For example a

wood, metal or concrete oor or in a raised (on

the wall) application. The appliance must be

installed on a metal or wood panel extending

the full width and depth of the appliance.

3) The Gem54 Direct Vent Gas Fireplace can

be installed in a recessed position or framed

out into the room as in A, B, C and D. See

Diagram 1.

7) Test Gas Pressure (Refer to "Gas Pipe Pres-

sure Testing" section).

8) Install standard and optional features. Refer

to the following sections:

a) Glass Crystals

b) Optional Firebox Base Pebbles

c) Optional Stainless Steel Reective

Panels

d) Faceplate / Door Frame Overlay

e) Remote Control or Wall Thermostat

9) Wall Mounted ON/OFF Switch:

Use the toggle wall switch supplied with the

manual package. Use of a “decor” switch

causes higher resistance which is a problem

on gas replaces.

10) Final check.

Before leaving this unit with the customer, the

installer must ensure that the appliance is ring

correctly and    

customer.

INSTALLATION

CHECKLIST

1) Locate appliance

a) Room location (Refer to "Locating Your

Gas replace" section)

b) Clearances to Combustibles (Refer to

"Clearances" section)

c) Mantle Clearances (Refer to "Mantel

Clearances" section)

d) Framing & Finishing Requirements

(Refer to "Framing & Finishing" section)

e) Venting Requirements (Refer to "Venting"

section)

2) Assemble the standoffs and nailing strips

(Refer to "Unit Assembly Prior to Installation).

3) Slide unit into place.

 Install vent (Refer to "Venting Arrangement"

sections).

 Make gas connections (Refer to "Gas Line

Installation section).

6) Test the pilot (Refer to "Pilot Adjustment"

section).

 This appliance is Listed for bedroom

installations using the standard Remote

(millivolt thermostat system). Some areas

may have further requirements, check local

codes before installation.

 The Gem54 Direct Vent Gas Fireplace

is approved for alcove installations, see

"Clearances" section for details.

6) We recommend that you plan your installation

on paper using exact measurements for

clearances and floor protection before

actually installing this appliance. Have an

authorized inspector, dealer, or installer

review your plans before installation.

     

"Exterior Vent Termination Locations"



8Regency Gemﬁre™ Gas Fireplace

INSTALLATION

Caution Requirements

The top, back and sides of the replace are dened by

standoffs. The metal ends of the standoff may NOT be

recessed into combustible construction.

WARNING









CLEARANCES







Installed Close

to Floor

48" (1219mm)

(102mm) 5-11/16”

(144mm)

28”

(711mm)

20"

(508mm)

22-1/2”

52-5/8”

60-1/2" (1537mm)

Non-combustible

Material

Non-combustible Material

Metal Stud (header)

Wood Stud

Clearance: Dimension Measured From:

 20" (508mm) Top of Fireplace Opening

B: Sidewall 4" (102mm) Side of Fireplace Opening



 40-7/8" (1038mm) Top of Fireplace Opening

 13" (330mm) 30" Above Fireplace Opening

 83" (2108mm) Sidewall to Sidewall (Minimum)

 36" (914mm) Front to Back Wall (Maximum)

Note 0" No hearth required

Installed Close

to Ceiling



Flue Clearances

Horizontal - Top 3" (76mm)

Horiztonal - Side 2" (51mm)

Horiztonal - Bottom 2" (51mm)

Vertical 2" (51mm)

Regency Gemﬁre™ Gas Fireplace 9

INSTALLATION

MANTEL CLEARANCES

 

     



MANTEL LEG CLEARANCES

Combustible mantel leg clearances as per diagram:

Allowable mantel

leg projection

11-1/2” (292mm)

14” (356mm)

15-3/4” (400mm)

1.5" (38mm)

MANTEL LEG

4”(102mm) Non-Combustible

Drywall

12 64

810

Top of

Fireplace

Opening

13" (330mm)

3 ½" (89mm)

Standoff

Metal Stud

(On Edge)

Non-combustible

Facing

To Floor

1" (25mm)

30” (762mm)

20”

21”

28-1/8”

(724mm)

(51mm)

(102mm)

(152mm)

(203mm)

(254mm)

(305mm)

(356mm)



Combustible mantel

clearances from top of front facing are shown in the

diagram on the right.

     



       



10 Regency Gemﬁre™ Gas Fireplace

INSTALLATION

 



2) For exterior walls, insulate the enclosure to the same degree as the

rest of the house, apply vapour barrier and drywall, as per local instal-

lation codes. 



         



         



3) The unit does not have to be completely enclosed in a chase. You

must maintain clearances from the vent to combustible materials: See

"Clearances" section. Combustible materials can be laid against the

side and back standoffs and the stove base.

 If material such as brick, stone, etc extends past the faceplate depth,

when nishing around the faceplate, the minimum opening dimen-

sions noted below must be adhered to ensuring for the removal of the

faceplate.

FRAMING & FINISHING

1) Frame in the enclosure for the unit with framing material.

IMPORTANT: Header All other framing may be

of combustible type such as 2x4 (0.6m x 1.2m) / 2x6 (0.6m x 1.8m)

framing materials.

58-3/16” (1478mm)

26-5/8” (676mm)

 When nishing around the faceplate, if material such as brick, stone,

etc. extend past the faceplate depth - the minimum opening

dimensions noted below must be adhered to, this is to assure

removal of the faceplate.

Finished

Material

Nailing Strip

Position

13mm 25mm

Factory

Setting

25mm 13mm

38mm 0mm (ush)

Unit

Nailing Strip

1” Forward

Unit

Nailing Strip

½” Forward

Unit

Nailing Strip

Flush w/unit

Factory Set

Nailing Strips

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Regency Fireplace Products Kamin im Innenbereich Handbücher

Regency Fireplace Products

Regency Fireplace Products Greenfire GF950L Series Kurzanleitung

Regency Fireplace Products

Regency Fireplace Products HZ54E Kurzanleitung

Regency Fireplace Products

Regency Fireplace Products Grandview G800EH Kurzanleitung

Regency Fireplace Products

Regency Fireplace Products CI2600 Kurzanleitung

Regency Fireplace Products

Regency Fireplace Products P48 Kurzanleitung

Regency Fireplace Products

Regency Fireplace Products NARRABRI F100B-1 Kurzanleitung

Regency Fireplace Products

Regency Fireplace Products B41XTE-NG1 Service-Handbuch

Regency Fireplace Products

Regency Fireplace Products V18M2-NG/LP Betriebsanleitung

Regency Fireplace Products

Regency Fireplace Products Grandview G600C-1 Kurzanleitung

Regency Fireplace Products

Regency Fireplace Products Skope E110-2 Bedienungsanleitung

Regency Fireplace Products

Regency Fireplace Products P42 Kurzanleitung

Regency Fireplace Products

Regency Fireplace Products Panorama P36 Kurzanleitung

Regency Fireplace Products

Regency Fireplace Products Classic H2100M Kurzanleitung

Regency Fireplace Products

Regency Fireplace Products Gi29LE Kurzanleitung

Regency Fireplace Products

Regency Fireplace Products HZ54E-NG1 Kurzanleitung

Regency Fireplace Products

Regency Fireplace Products City Series Kurzanleitung

Regency Fireplace Products

Regency Fireplace Products Greenfire GF900C-NG2 Kurzanleitung

Regency Fireplace Products

Regency Fireplace Products Bellavista B41XT Kurzanleitung

Regency Fireplace Products

Regency Fireplace Products FPI E33 Kurzanleitung

Regency Fireplace Products

Regency Fireplace Products PROFIBUS I1150S Kurzanleitung

Regency Fireplace Products

Regency Fireplace Products PG33-NG Kurzanleitung

Regency Fireplace Products

Regency Fireplace Products P48-1 Kurzanleitung

Regency Fireplace Products

Regency Fireplace Products Albany Kurzanleitung

Regency Fireplace Products

Regency Fireplace Products MONTROSE Kurzanleitung

Beliebte Kamin im Innenbereich Handbücher anderer Marken

Brigantia

Brigantia 35-DVRS31N-2 Betriebsanleitung

Nordpeis

Nordpeis Bergen Bedienungsanleitung

Superior

Superior BCT2536TMN Bedienungsanleitung

Quadra-Fire

Quadra-Fire 5100I-GD-B Bedienungsanleitung

Renaissance

Renaissance RUMFORD 1000 Bedienungsanleitung

Lacunza

Lacunza IV-800 Bedienungsanleitung

Baxi

Baxi 940 Gebrauchsanweisung

Dru

Dru Maestro 60/2 Tall RCH Bedienungsanleitung

Diamond Fireglass

Diamond Fireglass SS-O22 Bedienungsanleitung

HearthStone

HearthStone Windsor Bay 8830 Programmierhandbuch

Napoleon

Napoleon ASCENT B42 Bedienungsanleitung

Enviro

Enviro E33GI Bedienungsanleitung

Smeg

Smeg L30 FABE Montageanleitung

KEDDY

KEDDY K700 Bedienungsanleitung

Godin

Godin 3451 Bedienungsanleitung

Jøtul

Jøtul Jotul GI 535 DV IPI New Harbor Bedienungsanleitung

Austro Flamm

Austro Flamm Heidi Back 2.0 945048 Bedienungsanleitung

Desa

Desa CCFPDFT Bedienungsanleitung
