Reliable Digital Steam Press Bedienungsanleitung

DIGITAL STEAM PRESS

INSTRUCTION MANUAL

Features of the Digital Steam Press.........................................1

Safety Reminders.....................................................................2

Part Identification.................................................................3-4

oreparation for use...........................................................5

oFilling the water tank.......................................................5

oTurning on the power.......................................................5

oSelecting the temperature.................................................6

oSteam Control Notes........................................................7

oPressing............................................................................8

oFinishing Pressing............................................................9

oCleaning.........................................................................10

Suggestion for Success...........................................................11

Use of the Pressing Cushion..................................................12

Techniques for Pressing......................................................13-14

Troubleshooting..................................................................15-16

AA a

Steam Press Operation

CONTENTS

Digital Steam Press Instruction Manual

Digital Steam Press Instruction Manual Page1

Features of the Digital Steam Press

Your Steam Press provides clean, professional results every time!

The pressing surface is seven times larger than most hand-held irons

Reduces ironing time by up to 50%

Multiple dry-heat and steam settings for all types of fabric

Burst setting removes stubborn wrinkles

Variable temperature selection

Automatic shut-off safety feature while open or closed with audible alert

Over 100lbs. of even pressure ensures sharp, long lasting creases

Easy-to-use one hand operation

Protects delicate fabrics like silk

Non-stick padded ironing board cover

Non stick coating on pressing plate reduces starch build-up and eases cleaning

Locking handle makes unit portable

Stores upright

Digital Steam Press Instruction Manual

Page2

SAFETY REMINDERS

WARNING - Read all of the instructions and then save them for future reference.

THIS UNIT IS FOR HOUSEHOLD USE ONLY.

SAVE THESE INSTRUCTIONS

To protect against the risk of electric shock, do not

immerse the appliance in water.

Do not let the cord hang over the edge of counters.

Do not allow the cord to touch hot surfaces.

Always allow the appliance to cool for at least thirty

minutes before storing.

Always put the appliance in a secure place on a table or

counter when using.

Do not move the appliance without unplugging it first.

The appliance has very hot surfaces - Do not allow

unsupervised children to use the appliance.

Always disconnect the appliance from the outlet before

filling with or removing water. Be careful to avoid

spilling water on the appliance when filling.

Use distilled water in the appliance. Do not use perfumed

or products containing alcohol in the appliance.

Always disconnect the appliance when not in use.

Do not use the appliance if the cord gets damaged. Return

the appliance or have the cord repaired by the

manufacturer, his service agent or a similarly qualified

person.

Do not operate the appliance if it has been dropped or

damaged. Do not disassemble the appliance. Incorrect

reassembly can cause a risk of electric shock. Send it to

an authorized service center for repair.

Do not operate another high wattage appliance on the

same circuit.

If an extension cord is necessary, use a

NOTE: Extension cords rated for less amperage

may overheat.

This appliance must be grounded. Do not alter the plug

or attempt to defeat this feature.

Be careful. Burns can occur from touching hot metal

parts, hot water or steam.

120V; 60Hz; 1350W

Digital Steam Press Instruction Manual Page3

PART IDENTIFICATION

The Pressing Handle raises and lowers the Pressing Plate.

By lowering the Pressing Handle until it reaches the lowest

point possible you automatically obtain maximum pressure.

The Locking Knob will lock together the Pressing Plate and

Ironing Board. Turn the Locking Knob to the locked position

to carry or store the Steam Press.

The Red Steam Burst Button on the handle grip produces a

burst of steam when pressed.

The Pressing plate is the temperature controlled surface that

heats and presses the fabric.

The Ironing Board is the padded surface that holds the

fabric during pressing.

The Power Light (Red) is illuminated when the unit is on.

The Ready Light (Green) goes off when the Press has

reached the selected temperature.

The Steam Ready Light (yellow) goes on when the unit is

ready to produce bursts of steam.

The *POWER* button to turn ON/OFF the appliance.

Press the *SELECT* button arrows to set the desired

temperature for each fabric. NOTE: Steam will only be

available on the three highest settings.

The Water Tank slides forward and is filled through holes

in the top. The Water Level can be seen through the front of

the tank. Slide the tank forward for a better view.

The Ironing Board Cover is removable and washable for

extended use.

10.

11.

12.

Digital Steam Press Instruction Manual

Page4

The multiple function safety features of this appliance turn off electric power to the heater when the Pressing plate has been left against

the Ironing Board for about 10 seconds. If the Pressing plate is left in the open (up) position without use after approximately 15 minutes,

the unit will be automatically shut-off. In either case, to restore the unit, you have to press the *POWER* button again.

13. The Pressing Cushion is a fabric covered pad used for pressing gathered or

contoured areas such as sleeves, darts, and yokes.

14. A plastic water Spray Bottle is used for dampening fabric before pressing.

15. A Water Container is used for filling the Water Tank.

AAA

The following information is provided for service by a qualified electrician only:

Rated voltage:

WARNING:

This appliance must be grounded. Use only the proper type outlet when plugging in the appliance. Do not attempt to override the ground

wire feature.

120V; 60Hz; 1350W

Digital Steam Press Instruction Manual Page5

STEAM PRESS OPERATION

STEP1 - PREPARATION FOR USE

Set the appliance on a sturdy work surface. Unlock the Locking Knob.

STEP 2 - FILLING THE WATER TANK

BEFORE PLUGGING IN THE APPLIANCE, fill the water tank;

a. Always make sure the appliance is unplugged before filling the tank.

b. Fill the Water Tank with the Pressing Plate lifted to the raised (up) position.

Slide the Water Tank towards the front of the unit. It will not come

completely out so do not force it to do so. Using the Water Container,

slowly pour the distilled water into the Water Tank Fill Holes(C).

c. Be careful to avoid spilling water onto the Steam Press when filling.

d.Slide the Water Tank back into its recessed position.

STEP 3 - TURNING ON THE POWER

a. Make sure the Locking Knob (D) is in the open position allowing free

movement of the Pressing Plate before plugging in the appliance.

b. Lift the Pressing plate to the fully raised (up) position.

c. Plug the appliance into an electric outlet.

d. Press the *POWER* button and the Red Power light will shine.

Digital Steam Press Instruction Manual

Page6

STEP 4 SELECTING THE TEMPERATURE

Press the *SELECT* arrow buttons to choose the kind of fabric you wish to press. Press to move selection to higher setting and

press to move selection to lower setting.

a. Examine the garment label if unsure and look up the type on the chart.

IMPORTANT NOTE: If you can not determine the type of fabric, begin with the lowest setting and increase the temperature as

desired until you obtain the proper results.

b. When the Green Ready Light goes off, the Pressing Plate has reached the temperature for the desired setting.

c. When changing the setting from a higher selection to a lower setting allow several minutes for the Pressing Plate to cool

sufficiently after making the change.

IMPORTANT NOTE: You may find it more efficient to arrange your fabrics from those requiring the lowest setting to those

requiring the highest setting and proceed accordingly. This will avoid any unnecessary delay or wait for

the Pressing Plate to cool.

XXX

Digital Steam Press Instruction Manual Page7

STEP 5 - STEAM CONTROL

IMPORTANT NOTE: Steam is produced only when the Yellow Steam

Ready light is on.

The Green Ready Light goes off when the unit has reached the desired

temperature. The Yellow Steam Ready Light will come on when the unit is

ready to produce steam.

IMPORTANT NOTE: If this is the first time you are using the Steam Press

or you have been storing it for some time, lift the

Pressing plate into the raised position and press the

Steam Burst Button several times until the steam

begins to flow.

IMPORTANT NOTE: The Steam Burst function can only be used when the

Steam Ready Light is on AND the steam press is in

a slightly opened position. Do not use the Steam

Burst function when the steam press is closed, or

you may damage the unit.

IMPORTANT NOTE: Do not press the Steam Burst Button for more than 5

seconds or water may drip on your garment.

Digital Steam Press Instruction Manual

Page8

IMPORTANT NOTE: If you forget to raise the Pressing Plate or become distracted, the machine will give a warning beep and

automatically shut-off heating after approximately 10 seconds. The steam press will be completely shut-off after

15 minutes of no activity with the press in the open position.

STEP 6 - PRESSING

a. Lift the Pressing Handle (A). The Pressing Plate (B) moves to the up

position.

b. Carefully arrange the garment to be pressed onto the Ironing Board (C).

c. Grasp the handle of the Pressing Plate(A) and lower it onto the Ironing

Board (C), capturing the garment between the two halves of the Steam

Press. For light duty Pressing, simply lowering the handle and allowing the

Pressing Plate to rest on the Ironing Board will be sufficient. Return to the

open position. For heavier duty pressing, continue to grasp the handle and

press downward until the Pressing Plate is pushed to its lowest position,

then open the press.

d. If the temperature is set high enough you may give the fabric a burst of

steam by pressing the Steam Burst Button (D) to remove stubborn wrinkles.

Lower the pressing plate until it is about two inches from the garment.

Press the Steam Burst Button for about 3-5 seconds. After releasing the

Steam Burst Button you may fully lower the pressing plate.

NOTE: Do not press the Steam Burst Button when the pressure plate is

in its lowest (closed) position.

e. After a few seconds, lift the handle and raise the Pressing Plate back to the

raised position.

Inhaltsverzeichnis

Andere Reliable Eisen Handbücher

Reliable

Reliable The IronMaven J420 Bedienungsanleitung

Reliable

Reliable Velocity V50 Bedienungsanleitung

Reliable

Reliable VELOCITY 160IR Bedienungsanleitung

Reliable

Reliable S300 Bedienungsanleitung

Reliable

Reliable THE BOARD 120IB Bedienungsanleitung

Reliable

Reliable The Board C60 Bedienungsanleitung

Reliable

Reliable 523HA Bedienungsanleitung

Reliable

Reliable 624HA Bedienungsanleitung

Reliable

Reliable Longboard C55LB Bedienungsanleitung

Reliable

Reliable Empressa S500 Bedienungsanleitung

Reliable

Reliable IronMaven J490A Bedienungsanleitung

Reliable

Reliable 5000 SERIES Bedienungsanleitung

Reliable

Reliable 426HAB Bedienungsanleitung

Reliable

Reliable MAVEN 100IS Bedienungsanleitung

Reliable

Reliable MAVEN 125IS Bedienungsanleitung

Reliable

Reliable i700 Bedienungsanleitung

Reliable

Reliable i300 Bedienungsanleitung

Reliable

Reliable 4100IS Bedienungsanleitung

Reliable

Reliable 2150IR Bedienungsanleitung

Reliable

Reliable VELOCITY 230IR Bedienungsanleitung

Reliable

Reliable i300 Bedienungsanleitung

Reliable

Reliable C88 Bedienungsanleitung

Reliable

Reliable THE DIGITAL VELOCITY V100 Bedienungsanleitung

Reliable

Reliable Sensor Velocity v200 Bedienungsanleitung

Beliebte Eisen Handbücher anderer Marken

Clatronic

Clatronic DB 3703 Bedienungsanleitung

TEFAL

TEFAL FV4093Z0 Bedienungsanleitung

Gorenje

Gorenje SIH 2200 BS Bedienungsanleitung

Philips

Philips GC6012 Bedienungsanleitung

Bosch

Bosch 2 Series Bedienungsanleitung

Riffel

Riffel Catena KB-819 Bedienungsanleitung

Texi

Texi Hestia Bedienungsanleitung

Maxwell

Maxwell MW-3010 Bedienungsanleitung

TREVIDEA

TREVIDEA Girmi ST60 Bedienungsanleitung

Philips

Philips HI5914/30 Bedienungsanleitung

Primula

Primula Vapormat Bedienungsanleitung

Magio

Magio MG-541 Bedienungsanleitung

Scarlett

Scarlett SC-1334S Bedienungsanleitung

Bosch

Bosch Sensixx B22L Bedienungsanleitung

Philips

Philips GC651 Bedienungsanleitung

Vitek

Vitek VT-1247 VT Bedienungsanleitung

Cleanmaxx

Cleanmaxx 3397 Bedienungsanleitung

Philips

Philips GC800 Bedienungsanleitung
