Renesas H8S/2276 Bedienungsanleitung

H8S/2276R, H8S/2276 Series TFP-100B

User System Interface Cable

(HS2276ECH61H)

for E6000 Emulator

User’s Manual

HS2276ECH61HE(B)

Cautions

1. Renesas neither warrants nor grants licenses of any rights of Renesas’s or any third party’s

patent, copyright, trademark, or other intellectual property rights for information contained in

this document. Renesas bears no responsibility for problems that may arise with third party’s

rights, including intellectual propertyrights, in connection with use of the information contained

in this document.

2. Products and product specifications may be subject to change without notice. Confirm that you

have received the latest product standards or specifications before final design, purchase or use.

3. Renesas makes every attempt to ensure that its products are of high quality and reliability.

However, contact Renesas’s sales office before using the product in an application that demands

especially high quality and reliability or where its failure or malfunction may directly threaten

human life or cause risk of bodily injury, such as aerospace, aeronautics, nuclear power,

combustion control, transportation, traffic, safety equipment or medical equipment for life

support.

4. Design your application so that the product is used within the ranges guaranteed by Renesas

particularly for maximum rating, operating supply voltage range, heat radiation characteristics,

installation conditions and other characteristics. Renesas bears no responsibility for failure or

damage when used beyond the guaranteed ranges. Even within the guaranteed ranges, consider

normally foreseeable failure rates or failure modes in semiconductor devices and employ

systemic measures such as fail-safes, so that the equipment incorporating Renesas product does

not cause bodily injury, fire or other consequential damage due to operation of the Renesas

product.

5. This product is not designed to be radiation resistant.

6. No one is permitted to reproduce or duplicate, in any form, the whole or part of this document

without written approval from Renesas.

7. Contact Renesas’s sales office for any questions regarding this document or Renesas

semiconductor products.

Preface

Thank you for purchasing this user system interface cable (HS2276ECH61H) for the Renesas’s

original microcomputer H8S/2276R, H8S/2276 series.

The HS2276ECH61H is a user system interface cable that connects an H8S/2214 series E6000

emulator (HS2214EPI61H; hereinafter referred to as the emulator) through the expansion board to

the IC socket for a TFP-100B package for the H8S/2276R, H8S/2276 series MCU on the user

system.

Contents

Section 1 Configuration....................................................................................1

Section 2 Connection Procedures......................................................................3

2.1 Connecting User System Interface Cable to Emulator Station .........................................3

2.2 Connecting User System Interface Cable to User System................................................5

2.2.1 Installing IC Socket .............................................................................................5

2.2.2 Soldering IC Socket.............................................................................................5

2.2.3 Inserting Cable Head ...........................................................................................6

2.2.4 Fastening Cable Head..........................................................................................6

2.2.5 Fastening Cable Body..........................................................................................8

2.3 Recommended Dimensions for User System Mount Pad.................................................9

2.4 Dimensions for User System Interface Cable Head..........................................................10

2.5 Resulting Dimensions after Connecting User System Interface Cable.............................11

Section 3 Installing the MCU to the User System.............................................12

Section 4 Verifying Operation...........................................................................14

Section 5 Notice ................................................................................................17

Section 1 Configuration

CAUTION

Use an IC149-100-054-B51 socket (manufactured by

YAMAICHI ELECTRONICS Co., Ltd.) for the TFP-100B

package IC socket on the user system.

Figure 1 shows the configuration of the HS2276ECH61H user system interface cable for the

TFP-100B package.

Figure 1 HS2276ECH61H User System Interface Cable

Table 1 lists the HS2276ECH61H components. Please make sure you have all of these components

when unpacking.

Table 1 HS2276ECH61H Components

No. Component Quantity Remarks

1 Cable body 1 Flat cable

2 Cable head 1

3 IC socket 1 For the TFP-100B package

4 Socket cover 1 For installing a TFP-100B packaged MCU

5 Screws (M2.6 x 12 mm) 4 For fastening cable head (with four flat washers)

6 Screws (M2.6 x 6 mm) 4 For installing a TFP-100B packaged MCU (with

four flat washers)

7 Documentation 1 User’s manual for HS2276ECH61H (this manual)

Section 2 Connection Procedures

2.1 Connecting User System Interface Cable to Emulator Station

WARNING

Observe the precautions listed below. Failure to do so

will result in a FIRE HAZARD and will damage the user

system and the emulator product or will result in

PERSONAL INJURY. The USER PROGRAM will be

LOST.

1. Always switch OFF the user system and the emulator

product before the USER SYSTEM INTERFACE CABLE

is connected to or removed from any part. Before

connecting, make sure that pin 1 on both sides are

correctly aligned.

2. The user system interface cable dedicated to the

emulator must be used.

To connect the cable body to the emulator station, follow the instructions below.

1. Make sure the user system and emulator station are turned off.

CAUTION

When connecting or removing the user system interface

cable, apply force only in the direction suitable for

connection or removal, while making sure not to bend or

twist the cable or connectors. Otherwise, the connectors

will be damaged. The user system interface cable must be

connected to an H8S/2214 series E6000 emulator through

the H8S/2276R, H8S/2276 series expansion board. Do not

connect the user system interface cable directly to the

E6000 emulator.

2. [1] After making sure the direction of the expansion board connector labeled E6000

EMULATOR is correct, firmly insert the expansion board connector into the emulator

station connector labeled USER INTERFACE ([1] in figure 2).

[2] Connect the expansion board labeled USER INTERFACE CABLE and the user system

interface cable body.

6000

USER INTERFACECABLE

E6000 EMULATOR

E6000

[2]

160kHz

Emulator station

Expansion board

[1]

Subclock selection

Cable body connector

User system interface cable

Figure 2 Connecting User System Interface Cable to Expansion Board

2.2 Connecting User System Interface Cable to User System

WARNING

Always switch OFF the user system and the emulator

product before the USER SYSTEM INTERFACE CABLE

is connected to or removed from any part. Before

connecting, make sure that pin 1 on both sides are correctly

aligned. Failure to do so will result in a FIRE HAZARD and

will damage the user system and the expansion board or

will result in PERSONAL INJURY. The USER PROGRAM will

be LOST.

To connect the cable head to the user system, follow the instructions below.

2.2.1 Installing IC Socket

After checking the location of pin 1 on the IC socket, apply epoxy resin adhesive to the bottom of

the IC socket for a TFP-100B package, and fasten it to the user system before soldering.

2.2.2 Soldering IC Socket

After fastening, solder the IC socket for a TFP-100B package to the user system. Be sure to

completely solder the leads so that the solder slops gently over the leads and forms solder fillets.

(Use slightly more solder than the MCU.)

2.2.3 Inserting Cable Head

CAUTION

Check the location of pin 1 before inserting.

Align pin 1 on the IC socket for a TFP-100B package on the user system with pin 1 on the user

system interface cable head, and insert the user systeminterface cable head into the IC socket on the

user system, as shown in figure 3.

2.2.4 Fastening Cable Head

CAUTION

1. Use a Philips-type screwdriver whose head matches the

screw head.

2. The tightening torque must be 0.294 N•m or less.

If the applied torque cannot be accurately measured,

stop tightening when the force required to turn the screw

becomes significantly greater than that needed when first

tightening. If a screw is tightened too much, the screw

head may break or an IC socket contact error may be

caused by a crack in the IC socket solder.

3. If the emulator does not operate correctly, cracks might

have occurred in the solder. Check conduction with

a tester and re-solder the IC socket if necessary.
