Rev.3.00 Jul. 01, 2004 page 1 of 10

HD74LVC1G66

Single Analog Switch

REJ03D0026–0300Z

Rev.3.00

Jul. 01, 2004

Description

The HD74LVC1G66 has an analog switch in a 5-pin package. Switch section has its enable input control (CONT).

High-level voltage applied to CONT turns on the switch section. Applications include signal gating chopping,

modulation or demodulation (modem), and signal multiplexing for analog to digital to analog conversion systems. Low

voltage and high-speed operation is suitable for the battery powered products (e.g., notebook computers), and the low

power consumption extends the battery life.

Features

•The basic gate function is lined up as renesas uni logic series.

•Supply voltage range: 1.65 to 5.5 V

Operating temperature range: –40 to +85°C

•Control input: VIH (Max.) = 5.5 V (@VCC = 0 V to 5.5 V)

•Ordering Information

Part Name Package Type Package Code Package

Abbreviation Taping Abbreviation

(Quantity)

HD74LVC1G66CPE TBS-5V CP

HD74LVC1G66CLE WCSP-5 pin TBS-5AV CL E (3,000 pcs/reel)

Article Indication

E 9 Y M

Marking

Year code

Month code

Function Table

Control Switch

LOFF

HON

H: High level

L: Low level

= 0 V to 5.5 V)

Package Type Package Code Package

Abbreviation

TBS-5V

TBS-5AV CL

HD74LVC1G66

Rev.3.00 Jul. 01, 2004 page 2 of 10

Pin Arrangement

(Bottom view) (Top view)

CONT

34GND

Height 0.5 mm

0.5 mm pitch

0.17 mm 5–Ball (CP)

0.23 mm 5–Ball (CL)

0.9 mm

1.4 mm

OUT/IN

IN/OUT V

Pin#1 INDEX

Logic Diagram

IN/OUT OUT/IN

CONT

Absolute Maximum Ratings

Item Symbol Ratings Unit Test Conditions

Supply voltage range VCC –0.5 to 6.5 V

Input voltage range *1 VI–0.5 to 6.5 V

Output voltage range *1, 2 VO–0.5 to VCC +0.5 V Output : H or L

Control Input clamp current IIK –50 mA VI< 0

Output clamp current IOK ±50 mA VO< 0 or VO> VCC

Continuous output current IO±50 mA VO= 0 to VCC

Continuous current through

VCC or GND ICC or IGND ±100 mA

154 CPPackage Thermal impedance θja 132 °C/W CL

Storage temperature Tstg –65 to 150 °C

Notes: The absolute maximum ratings are values, which must not individually be exceeded, and furthermore no two

of which may be realized at the same time.

1. The input and output voltage ratings may be exceeded if the input and output clamp-current ratings are

observed.

2. This value is limited to 5.5 V maximum.

(Top view)

OUT/IN

Absolute Maximum Ratings

Symbol

Ratings

–0.5 to 6.5

–0.5 to V

Control Input clamp current I

HD74LVC1G66

Rev.3.00 Jul. 01, 2004 page 3 of 10

Recommended Operating Conditions

Item Symbol Min Max Unit Conditions

Supply voltage range VCC 1.65 5.5 V

Control Input voltage range VI05.5V

Input/Output voltage range VI/O 0V

CC V

020VCC = 1.65 to 1.95 V,

2.3 to 2.7 V

010 VCC = 3.0 to 3.6 V

Input transition rise or fall rate ∆t / ∆v

010

ns / V

VCC = 4.5 to 5.5 V

Operating free-air temperature Ta–40 85 °C

Note: Unused or floating inputs must be held high or low.

Electrical Characteristics

Ta = –40 to 85°C

Item Symbol VCC (V) Min Typ Max Unit Test condition

1.65 to 1.95 VCC×0.65 — —

2.3 to 2.7 VCC×0.7 — —

3.0 to 3.6 VCC×0.7 — —

VIH

4.5 to 5.5 VCC×0.7 — —

1.65 to 1.95 — — VCC×0.35

2.3 to 2.7 — — VCC×0.3

3.0 to 3.6 — — VCC×0.3

Input voltage

VIL

4.5 to 5.5 — — VCC×0.3

1.65 — 13 30 IS= 4 mA

2.3 — 9 20 IS= 8 mA

3.0 — 7.5 15 IS= 24 mA

On–state switch

resistance RON

4.5 — 5.5 10 IS= 32 mA

VI=VCC or GND

1.65 — 74.5 120 IS= 4 mA

2.3 — 20 30 IS= 8 mA

3.0 — 11.5 20 IS= 24 mA

Peak on resistance RON(P)

4.5 — 7.5 15

Ω

IS= 32 mA

VI=VCC to GND

— — ±1.0Off-state switch

leakage current IS (OFF) 5.5 — — ±0.1*1

µAV

I= VCC and VO= GND or

VI= GND and VO= VCC,

VC= VIL

— — ±1.0On-state switch

leakage current IS (ON) 5.5 — — ±0.1*1

µAV

I= VCC or GND, VC= VIH

VO= Open

— — ±1.0

Control input

current IIN 5.5 — — ±0.1*1

µAV

IN = VCC or GND

— — 10ICC 5.5 — — 1.0*1

µAV

IN = VCC or GNDQuiescent

supply current

∆ICC 5.5 — — 500 µAV

C= VCC–0.6 V

Control input

capacitance CIC 5.0 — 3.0 — pF

CI/O(OFF) 5.0 — 6.0 —Switch terminal

capacitance CI/O(ON) 5.0 — 13 — pF

Note: 1. Ta = 25°C

(V) Min Typ Max Unit Test condition

0.7 — —

1.65 to 1.95 — — V

0.35

2.3 to 2.7 — — V

0.3

3.0 to 3.6 — — V

0.3

4.5 to 5.5 — — V

0.3

1.65 — 13 30

— 9 20

— 7.5 15

4.5

— 5.5 10

1.65 — 74.5 120

2.3

— 20 30

3.0

— 11.5 20

4.5 — 7.5 15

— — ±1.0

5.5

HD74LVC1G66

Rev.3.00 Jul. 01, 2004 page 4 of 10

Switching Characteristics

VCC = 1.8 ± 0.15 V

Ta = –40 to 85°C

Item Symbol Min Max Unit Test Conditions FROM

(Input) TO

(Output)

Propagation delay time*1tPLH

tPHL

2.0 CL= 30 pF, RL= 1.0 kΩINOUT or

OUTIN OUTIN or

INOUT

Enable time tZH

tZL

2.5 12.0 CL= 30 pF, RL= 1.0 kΩCONT INOUT or

OUTIN

Disable time tHZ

tLZ

2.2 10.0

CL= 30 pF, RL= 1.0 kΩCONT INOUT or

OUTIN

VCC = 2.5 ± 0.2 V

Ta = –40 to 85°C

Item Symbol Min Max Unit Test Conditions FROM

(Input) TO

(Output)

Propagation delay time*1tPLH

tPHL

1.2 CL= 30 pF, RL= 500 ΩINOUT or

OUTIN OUTIN or

INOUT

Enable time tZH

tZL

1.9 6.5 CL= 30 pF, RL= 500 ΩCONT INOUT or

OUTIN

Disable time tHZ

tLZ

1.4 6.9

CL= 30 pF, RL= 500 ΩCONT INOUT or

OUTIN

VCC = 3.3 ± 0.3 V

Ta = –40 to 85°C

Item Symbol Min Max Unit Test Conditions FROM

(Input) TO

(Output)

Propagation delay time*1tPLH

tPHL

0.8 CL= 50 pF, RL= 500 ΩINOUT or

OUTIN OUTIN or

INOUT

Enable time tZH

tZL

1.8 5.0 CL= 50 pF, RL= 500 ΩCONT INOUT or

OUTIN

Disable time tHZ

tLZ

2.0 6.5

CL= 50 pF, RL= 500 ΩCONT INOUT or

OUTIN

VCC = 5.0 ± 0.5 V

Ta = –40 to 85°C

Item Symbol Min Max Unit Test Conditions FROM

(Input) TO

(Output)

Propagation delay time*1tPLH

tPHL

0.6 CL= 50 pF, RL= 500 ΩINOUT or

OUTIN OUTIN or

INOUT

Enable time tZH

tZL

1.5 4.2 CL= 50 pF, RL= 500 ΩCONT INOUT or

OUTIN

Disable time tHZ

tLZ

1.4 5.0

CL= 50 pF, RL= 500 ΩCONT INOUT or

OUTIN

Note: 1. The propagation delay is calculated RC time constant of typical on-state resistance of the switch and the

specified load capacitance, when driven by an ideal voltage source (zero output impedance).

= 30 pF, R

= 500

Unit Test Conditions

0.8 C

= 50 pF, R

= 500

= 50 pF, R

= 500

2.0 6.5

0.8 Cns0.8 C

= 50 pF, R

Ta = –40 to 85°C

Symbol

Min Max

Unit Test Conditions

PLH

PHL



0.6 C

1.5 4.2

1.4 5.0

Note: 1. The propagation delay is calculated RC time constant

specified load capacitance, when driven by an i

HD74LVC1G66

Rev.3.00 Jul. 01, 2004 page 5 of 10

Analog Switch Characteristics

Ta = 25°C

Item VCC (V) Min Typ Max Unit Test conditions FROM

(Input) TO

(Output)

1.65 — 35 —

2.3 — 120 —

3.0 — 175 —

4.5 — 195 —

CL= 50 pF,

RL= 600 Ω

1.65 — >300 —

2.3 — >300 —

3.0 — >300 —

Frequency response

(Switch ON)

4.5 — >300 —

MHz

CL= 5 pF,

RL= 50 Ω

Adjust fin voltage to obtain

0dBm at output when fin is

1MHz (sine wave).

Increase fin frequency until

the dB–meter reads –3 dBm.

20 log(VO/VI) = –3 dBm

INOUT or

OUTIN OUTIN or

INOUT

1.65 — 35 —

2.3 — 50 —

3.0 — 70 —

Crosstalk

(Control input to signal

output) 4.5 — 100 —

mV CL= 50 pF,

RL= 600 Ω

Adjust RL value to obtain 0A

at IIN/OUT when fin is 1MHz

(square wave)

CONT OUTIN or

INOUT

1.65 — –58 —

2.3 — –58 —

3.0 — –58 —

4.5 — –58 —

CL= 50 pF,

RL= 600 Ω

1.65 — –42 —

2.3 — –42 —

3.0 — –42 —

Feed through

attenuation

(Switch OFF)

4.5 — –42 —

CL= 5 pF,

RL= 50 Ω

Adjust fin voltage to obtain

0dBm at input when fin is

1MHz (sine–wave)

INOUT or

OUTIN OUTIN or

INOUT

1.65 — 0.1 —

2.3 — 0.025 —

3.0 — 0.015 —

4.5 — 0.01 —

CL= 50 pF,

RL= 10 kΩ

fin = 1 kHz

(sine–wave)

1.65 — 0.15 —

2.3 — 0.025 —

3.0 — 0.015 —

Sine–wave distortion

4.5 — 0.01 —

CL= 50 pF,

RL= 10 kΩ

fin = 10 kHz

(sine–wave)

VI=1.4VP–P, VCC=1.65V

VI=2.0VP–P, VCC=2.3V

VI=2.5VP–P, VCC=3.0V

VI=4.0VP–P, VCC=4.5V

INOUT or

OUTIN OUTIN or

INOUT

Operating Characteristics

Ta = 25°C

Item Symbol VCC (V) Min Typ Max Unit Test Conditions

1.8 — 8 —

2.5 — 9 —

3.3 — 9 —

Power dissipation capacitance CPD

5.0 — 11 —

pF f = 10 MHz

Adjust fin voltage to obtain

0dBm at input when fin is

1MHz (sine–wave)

= 50 pF,

= 10 k

Ω

fin = 1 kHz

(sine–wave)

1.65 — 0.15 —

2.3 — 0.025 —

3.0 — 0.015 —

4.5 — 0.01 —

= 50 pF,

= 10 k

Ω

fin = 10 kHz

(sine–wave)

=1.4V

P–P

, V

=1.65V

=2.0V

P–P

, V

=2.3V

=2.5V

P–P

, V

=4.0V

P–P

Operating Characteristics

Symbol V

Power dissipation capacitance C

HD74LVC1G66

Rev.3.00 Jul. 01, 2004 page 6 of 10

Test Circuit

OUT

+ –

GND

(ON)

V =V

C IH

V =V

• R

IN CC

IN–OUT

R =

(Ω)

IN–OUT

GND

(OFF)A

V =V

C IL

V =V

or GND

IN CC

V =GND

or V

OUT

GND

(ON)A

V =V

C IH

V =V

or GND

IN CC

OPEN

OUT

• I (off), I (on)

V =GND

or V

OUT

V =GND

OUT

V =GND

or V

V =V

C IH

V =V

C IH

V =V

or GND

V =V

HD74LVC1G66

Rev.3.00 Jul. 01, 2004 page 7 of 10

Test Circuit (cont.)

OPEN OPEN

TEST S1

VTT

GND GND

t / t

PLH PHL

t / t

ZH HZ

t / t

ZL LZ

1.8±0.15

2.5±0.2

3.3±0.3

5.0±0.5

INPUTS

(V)

2× V

/ 2

ref

∆VVTT

/ t

500 Ω

0.15 V

0.3 V

500 Ω

1.0 kΩ

Load circuit

From Output

≤ 2 ns

≤ 2.5 ns

30 pF

50 pF

ref

0 V

PLH

PHL

Input

Output

Control

Input V

ref

– ∆V

+ ∆V

ref

0 V

Output

(Waveform – A)

Output

(Waveform – B)

Notes: 1. C

includes probe and jig capacitance.

2. Waveform–A is for an output with internal conditions such that the output is low except

when disabled by the output control.

3. Waveform–B is for an output with internal conditions such that the output is high except

when disabled by the output control.

4. All input pulses are supplied by generators having the following characteristics:

PRR ≤ 10MHz, Zo = 50 Ω.

5. The output are measured one at a time with one transition per measurement.

ref

PHL

ref

HD74LVC1G66

Rev.3.00 Jul. 01, 2004 page 8 of 10

Frequency response (Switch ON)

V = V

0.1 µF

OUT

f = sine wave

GND

(ON)

C = 50 pF

R =600

Ω

R = 50

Ω

V /2

or 50 Ωor 5 pF

Feedthrough attenuation (Switch OFF)

V = V

0.1 µF

OUT

V /2

GND

(OFF)

C = 50 pF or 5 pF

R =

600

Ω

V /2

R =

600

Ω

R =

Ω

600 Ω

Crosstalk (Control input to signal output)

OUT

V /2

C = 50 pF

R =

600

Ω

V /2

R =

600

Ω

GND

R =

Ω

Sine-wave distortion

V = V

10 µF

OUT

V /2

GND

10 µF

(ON)

C = 50 pF

R =

10 k

Ω

or 50 Ωor 50

Feedthrough attenuation (Switch OFF)

V = V

0.1

V = V

(OFF)

V /2

R =

600

R =

Ω

R =

Ω

V /2

C = 50 pF

R =

600

R =

Ω

GND

Sine-wave distortion

or 50

Ω

HD74LVC1G66

Rev.3.00 Jul. 01, 2004 page 9 of 10

Package Dimensions

TBS-5V

EIAJ Package Code JEDEC Code Mass(g) Lead Material

0.001



Symbol Dimension in Millimeters

Min Typ Max

A 0.50

0.15

0.35

0.05

0.20

0.19

0.90

1.40

0.50

0.20

0.15 0.17

0.10

Pin #1 index area A

Seating plane

5× φ b

Cφ xMA B

y C

Cφ xM

C/ /

Symbol

HD74LVC1G66

Rev.3.00 Jul. 01, 2004 page 10 of 10

TBS-5AV

EIAJ Package Code JEDEC Code Mass(g) Lead Material

0.001



Symbol Dimension in Millimeters

Min Nom Max

A 0.50

0.185

(0.315)*

0.05

0.20

0.25

0.90

1.40

0.50

0.20

0.155

Pin #1 index area A

Seating plane

*Reference value.

5 ×φ b

Cφ x

A B

y C

Cφ x

y1C/ /

Inhaltsverzeichnis

Andere Renesas Computerhardware Handbücher

Renesas

Renesas HA31005ANP Bedienungsanleitung

Renesas

Renesas M16C/29 Bedienungsanleitung

Renesas

Renesas DA14AVDDECTDEVKT Bedienungsanleitung

Renesas

Renesas FemtoClock 2 Bedienungsanleitung

Renesas

Renesas M37515T-PTC Bedienungsanleitung

Renesas

Renesas RZ/G2L Benutzerhandbuch

Renesas

Renesas EMMA Mobile 1 Bedienungsanleitung

Renesas

Renesas M3T-SSOP42B-450 Bedienungsanleitung

Renesas

Renesas R8C/11 Series Montage- und Bedienungsanleitung

Renesas

Renesas RA6 Series Bedienungsanleitung

Renesas

Renesas RX Family Montage- und Bedienungsanleitung

Renesas

Renesas F-ZTAT Series Bedienungsanleitung

Renesas

Renesas FP-144H Bedienungsanleitung

Renesas

Renesas CK-RX65N Bedienungsanleitung

Renesas

Renesas Single-Chip Microcomputer M37900T2-RPD-E Bedienungsanleitung

Renesas

Renesas mPD720231 Bedienungsanleitung

Renesas

Renesas R0E521000CPE00 Bedienungsanleitung

Renesas

Renesas H8/36014 Bedienungsanleitung

Renesas

Renesas H8S/2615 Series Bedienungsanleitung

Renesas

Renesas CPU Board M3A-HS19 Bedienungsanleitung

Renesas

Renesas Single-Chip Microcomputer M306NKT3 Bedienungsanleitung

Renesas

Renesas 8V19N49 Series Bedienungsanleitung

Renesas

Renesas M30290T-EPB Bedienungsanleitung

Renesas

Renesas R8C/Tiny Series Montageanleitung

Beliebte Computerhardware Handbücher anderer Marken

EMC2

EMC2 VNX Series Betriebsanleitung

Panasonic

Panasonic DV0PM20105 Bedienungsanleitung

Mitsubishi Electric

Mitsubishi Electric Q81BD-J61BT11 Bedienungsanleitung

Gigabyte

Gigabyte B660M DS3H AX DDR4 Bedienungsanleitung

Raidon

Raidon iT2300 Bedienungsanleitung

National Instruments

National Instruments PXI-8186 Bedienungsanleitung

Hauppauge

Hauppauge WinTV-HVR-2250 Bedienungsanleitung

Kontron

Kontron CP6002 Bedienungsanleitung

Manhattan

Manhattan 702843 Bedienungsanleitung

Aphex

Aphex 230 Bedienungsanleitung

AMD

AMD Phenom II Betriebshandbuch

Intel

Intel NUC 12 Pro Bedienungsanleitung

dbx

dbx Zone Pro 1260 Bedienungsanleitung

Galaxy

Galaxy GHDX2-2430S-24F4D Bedienungsanleitung

Intel

Intel AXXRMFBU4 Bedienungsanleitung

Kontron

Kontron DIMM-PC/MD Bedienungsanleitung

ST X-NUCLEO-SAFEA1B Betriebsanleitung

STEINWAY LYNGDORF

STEINWAY LYNGDORF SP-1 Bedienungsanleitung
