Renesas MCU Board M30850T2-EPBM Bedienungsanleitung

(1/3)

M30850T2-EPBM

MCU Board for Replacing M30850T2-EPB, M30850T3-CPE and M30850T2-CPE

User’s Manual

CAUTION If the requirements shown in the "CAUTION" sentences are ignored,

the equipment may cause personal injury or damage to the products.

Renesas Tools Homepage http://www.renesas.com/tools

Rev.2.00

Apr. 25, 2007

REJ10J1492-0200

(2/3)

1. Outline

The M30850T2-EPBM is an MCU board for replacing the emulation probe M30850T2-EPB and the compact emulator

M30850T3-CPE for the M32C/80, 84, 85, 86 and 8A Groups, or the compact emulator M30850T2-CPE for the M32C/84, 85 and 86

Groups.

2. Components

Package components

Description Quantity

M30850T2-EPBM MCU board for replacing the M30850T2-EPB, the M30850T3-CPE and

the M30850T2-CPE 1

M30850T2-EPBM User’s manual (This manual) 1

M30850T2-EPBM User’s manual (Japanese) 1

3. Replacing the MCU Board

How to replace the MCU board is shown in Figure 3.1.

(1) Unscrew the four screws included with the M30850T2-EPB, the

M30850T3-CPE or the M30850T2-CPE.

(2) Pull out the M30850T2-EPBM from the PCA7501EPBA of the

M30850T2-EPB, or from the M30803T2-CPEA of the

M30850T3-CPE or the M30850T2-CPE. Note that pull them out

vertically, otherwise the connectors may be damaged.

(3) Attach the new M30850T2-EPBM to the PCA7501EPBA of the

M30850T2-EPB, or to the M30803T2-CPEA of the M30850T3-CPE

or the M30850T2-CPE. The connecting directions are as follows

-With the M30850T2-EPB

PCA7501EPBA J3 connector to M30850T2-EPBM J1 connector

PCA7501EPBA J4 connector to M30850T2-EPBM J2 connector

-With the M30850T3-CPE or the M30850T2-CPE

M30803T2-CPEA J3 connector to M30850T2-EPBM J1 connector

M30803T2-CPEA J4 connector to M30850T2-EPBM J2 connector

(4) Tighten the four screws in an even, crisscross pattern to secure the

new M30850T2-EPBM with a screwdriver.

(5) After replacing the board, perform the self-check to make sure that it

has been installed properly. For details on the self-check, refer to the

user’s manual of each product.

Figure 3.1 Replacing the MCU board

4. Applicable Emulator Debugger for this product

[M30850T2-EPB]

(1) M32C PC7501 emulator debugger V.1.00 Release 00 or later

(2) M3T-PD308F V.3.20 Release1 or later

[M30850T2-CPE]

(1) M32C compact emulator debugger V.1.00 Release 01 or later

(2) M3T-PD308MF V.1.00 Release01 or later

[M30850T3-CPE]

(1) M32C compact emulator debugger V.1.02 Release 00 or later

PCA7501EPBA or

M30803T2-CPEA

M30850T2ーEPBM

Screw x4

M30850T2-EPBM REV.B

PCA7501EPBA or

M30803T2-CPEA

M30850T2-EPBM

(this product)

M30850T2-EPBM REV.B

(3/3)

5. Precautions

CAUTION

Cautions to Be Taken for Handling This Product:

●Before you replace the MCU board, shut off the power, otherwise internal circuits may be damaged.

●Insert or pull out the MCU board vertically, otherwise the connectors may be damaged.

●For the M30850T2-EPB, after replacing the MCU board, be careful about the direction for connecting to the PC7501.

IMPORTANT

Regarding This Product:

●For inquiries about this product or the contents of this manual, contact your local distributor.
