Introduction
Thank you for purchasing the Rhythmz
BluBox digital Bluetooth speaker！
This system features multiple functions. It
performs with perfect audio quality, high
reliability, and elaborate appearance,
bringing you a super enjoyment of
Crystal clear highs and powerful bass to
music lovers like you.
FUNCTIONS
* Buletooth Speaker
* AUX-in play with music
* Equalizer（FLAT，ROCK，POP，
CLASS， JAZZ，）
* Remote control
Notice
Before initial use, please read the
instructions first, ensure you can use this
product correctly. To offer improved
features, the product performance and
specifications may have changed. This user
manual is subject to change without prior
notice.
To get a good performance, do not use the
product in a cold, hot, dusty or damp place.
Pay more attention specifically to the
following circumstances:
Definition of keys and jacks
1．USB（1000mA）: Suitable for charging
all kinds of mobile phones and other
portable devices that can utilize a USB
Port To charge
2．AUX IN：3.5mm AUX IN jack
3．DC IN：DC power input jack
1． ：Press to turn down the volume, or
press and hold to turn down the
volume rapidly
2．：Press to turn up the volume, or
press and hold to turn up the volume
rapidly
3．: In Bluetooth playback status,
pressing the key can stop the music；In
search or standby mode, pressing and
holding the key for over 3s can pair the
detected device
4．：press power key
5．Location of the remote control receiver
6．Function indicator：green light bright /
Bluetooth mode、red light bright / AUX
IN Mode
Remote control function
1．：Press to power on/off
2．：Press to turn down the volume，
press and hold the key to turn down the
volume faster
3．：Press to turn up the volume，press
and hold the key to turn up the volume
faster
4．:In Bluetooth playing mode, pressing
it can make the music pause / play;
In search mode, pressing and holding
the key for over 3s will cause the unit to
enter into pairing mode
5．：Mute Button
4). Select “Rhythmz BluBoxHD” from the
devices found from your search
5). Enter identification code “0000” for
mobile phones and press OK key to pair the
BluBox Bluetooth speaker with the mobile
phone. After successful pairing, the
green/blue LED indicator will be on.
6). Press return key on mobile phone to
return to menu. Make sure there is no
obstruction within 10 meters between the
Bluetooth device and mobile phone. Then,
you can answer the call or listen to music
via the BluBox Bluetooth speaker.
Notice
1. If the time of pairing exceeds three
minutes, the device will enter into
time-out standby mode.
2. If pairing is successful, the device will
enter into the connection mode.
Search Mode
When powering on or in pairing mode,
press and hold “ ” key to enter into pairing
mode, and the blue indicator will flash once
every one second. The device will try to
connect the last connected device. If
detected, the device will enter the
connection mode. If the search time
exceeds 10s, the device will enter into the
standby mode.
input(As for the AUX IN equipment, please
adjust the volume in a reasonable level and
in the playing mode）, At the same time,
you can press or press and hold “ ”/“ ”
key to turn up or down the volume. When
AUX IN cable is plugged out, the system will
enter into Bluetooth search mode and
search the last connected device.
The Bluetooth function will stop
automatically once you plug the AUX IN
cable in AUX IN JACK, the blue LED
indicator will be off and enter the AUX IN
mode,
Volume control：In Bluetooth playing or
pausing mode，press or press and hold
“ or ” key to turn up or down the
volume。
EQ sound effect：in any mode’s
play/pause/stop, press ”EQ” key in remote
control to adjust EQ sound effect, in
sequence ”FLAT”, “ROCK”, “POP”,
“CLASS”, “JAZZ” mode
Specification
Bluetooth Specification：
Bluetooth Version:2.1+EDR
USB Jack charging power requirement：
5V/1000mA
Power Output：Class 2，10m is the
maximum connection distance Frequency
Response：2.402GHz ~ 2.480GHz
unlicensed ISM band
Supported Profiles：HSP 、HFP 1.5 、
A2DP and AVRCP Profiles
Supported Devices
iPad 1
iPad 2
iPad 3
iPhone 4
iPhone 4S
iPhone 3G
iPhone 3GS
NOKIA N95
NOKIA N78
Android OS
NOKIA 5800
NOKIA 6110
NOKIA 5300
NOKIA 6230
Blackberry 8310
Blackberry 9700
SAMSUNG Galaxy
SAMSUNG gt-s5628
Sony Ericsson W910i
Remark：Apart from the above mentioned
devices，this unit will function with any device
that supports the Bluettoth function mode.
Package Contents：
1) User manual
2) Power adapter
3) Remote control
Copyright. 2012. Rhythmz. All Rights Reserved
iPad, Iphone, are registered trademarks of
apple corporation in the United States and
other countries. All other brands are registered
trademarks of their respective owners.
Standby Mode
The blue LED indicator will flash once every
five seconds. In standby mode, the device
will receive connection from all devices
already paired previously (maximum 8
devices).
Connection Mode
After successful pairing, the blue LED
indicator will always be on. If there is no
earphone sign on mobile phone screen
before using, please follow the following
steps to activate the Bluetooth connection.
(1) On mobile phone: choose “Rhythmz
BluBoxHD” in pair list to enable the
connection; Press “ ” key or “ ”key
on remote control and select “Accept
Connection” on screen of mobile phone.
(2) To disconnect, press and hold “ ”
key or press“ ”key on remote control or
disconnect it from the mobile phone, and
the device will enter the standby mode.
AUX IN
The Bluetooth function will disconnect
automatically once you plug the AUX IN
cable like MP3/CD and so on into the AUX
IN JACK, and enter into AUX IN mode,
which will then play music from the AUX IN
6．：In Bluetooth mode, pressing the
key will take you back to the previous
song; in AUX IN mode, no effect will
occur if you press the key
7．：In Bluetooth mode, pressing the key
will advance you to the next song;
in AUX IN mode, no effect will occur
whether you press the key
8． EQ：Sound effect set - Equalizer
9． RESET：In Bluetooth mode, pressing
and holding the key for over 10s will
clear all the Bluetooth devices that
were connected before, at the same
time, Blue light flashing rapidly
How to use remote control
1. Before using the remote control, please
remove the PVC insulation film in the
battery buckle. The remote control needs
to face forward towards the main unit
in order to function
2. Prolonged use of the remote control, will
lead to the remote control to work
Slower, a signal that you may need to
replace the bbatery
Please remove the battery and replace it
with a new battery, according to
The illustration below
pay attention to the “＋/－” direction
Power On
Plug the DC 12V power to DC jack at the
back of the unit, then press “ ” key to turn on
the power,
Pairing Mode
Power on the unit and enter into the
Bluetooth mode，there are two ways to
enter this mode，in search mode or
standby mode，Press and hold “ ”key
over 3s。For the first time, when
booting……
1). Place the device you would like to pair
within 1 meter;
2). Press and hold “ ” key for over 3s
and the blue indicatorlight will flash,
meaning it’s in pairing status;
3). Activate the Bluetooth function of your
device to allow it to search the Bluetooth
device (for further details, please refer to
the user manual of your device
you can answer the call or listen to music
via the BluBox Bluetooth speaker.
1. damp environment or underwater operation;
2. heated or high-temperature operation;
3. under the direct sunshine;
4. in a place where the product may be easy to
fall down;
5. Do not disassemble the speaker without
permission, or you’ll not be able to enjoy the
warranty.
Warning
1. Apparatus shall not be exposed to
dripping or splashing and no objects filled
with liquids, such as vases, shall be placed
on the apparatus.
2. Where the mains plug or an appliance
coupler is used as the disconnect device,the
disconnect device shall remain readily
operable.
