Ricoh HP4-R2 Bedienungsanleitung
21/12/2009
Page 1
HP4-R2 TRAINING
DUPLICATOR ENGINE
COURSE OVERVIEW
The course is broken up into several modules. This section outlines these modules.
The course covers the HP4-V2 and the optional peripherals. Software is covered in
separate courses.
The mechanisms are very similar to the Pink Gold/HP4 and Silver duplicator series.
21/12/2009
Page 2
Course Overview
Product Outline
Specifications
Installation
Operation
Machine Overview
Scanning
Image Processing
PRODUCT OUTLINE
The model will be introduced to the class.
The optional peripherals will be introduced to the class.
The product concept, sales points, and targets will be presented.
SPECIFICATIONS
Significant items will be discussed.
INSTALLATION
The class will install their machines and the peripherals.
The class will learn how to access SP modes and user tools.
The class will study how to upgrade the firmware.
OPERATION
This part of the course will cover some points about operating the machine.
MACHINE OVERVIEW
The components will be discussed.
The paper feed path and printing process will be outlined.
SCANNER
The scanner mechanism will be discussed.
IMAGE PROCESSING
This section explains the image processing done inside this machine.
21/12/2009
Page 3
Course Overview
Master Ejection
Master Feed
Drum
Paper Feed
Paper Delivery
Maintenance
Troubleshooting
Optional ADF
MASTER EJECT
This section explains how the used master is removed from the drum before the
new master is wrapped around the drum.
MASTER FEED
This section explains how the new master is wrapped around the drum.
DRUM
This section describes drum drive, ink supply, and the detection of masters on the
drum.
PAPER FEED
This section describes the paper feed, printing pressure, and paper table
mechanisms.
PAPER DELIVERY
This section explains how the printed page is fed out of the machine.
MAINTENANCE
PM is described briefly.
TROUBLESHOOTING
Basic points concerning service codes, diagnostics, and other troubleshooting tools
will be covered.
OPTIONAL ADF
The mechanisms of the optional ADF will be explained.
21/12/2009
Page 4
HP4-R2 TRAINING
DUPLICATOR ENGINE
PRODUCT OUTLINE
21/12/2009
Page 5
PRODUCT CONCEPTS AND MAIN
SALES POINTS
21/12/2009
Page 6
Appearance
Paper delivery
table
(capacity 1,000) Paper feed
table
(capacity 1,000)
Operation Panel
with Large LCD
Screen
The LCD is not a touch-panel.
21/12/2009
Page 7
Product Concept
Mid-range model with more capabilities than current
models in this range
zReplacement for the HP4 and Pink Gold models
zThe engine is based on the Pink Gold series.
21/12/2009
Page 8
Options
50-sheet Document Feeder
Colour Drum
A4 Drum (black only)
Tape Dispenser
Platen Cover
There is no sorter, Opal, or LCS.
The drums cannot be used with the Opal or HQ-Opal.
Introduce the range of available options.
¾The document feeder is the same as used with the Sapphire 2 and HP4.
¾The tape dispenser is almost the same as used with previous models. It is
modified for RoHS compliance.
¾The platen cover is the same type as used with previous models.
21/12/2009
Page 9
Platen Cover/ADF
The customer needs one of the above options.
This is because a platen cover is not installed at the
factory.
21/12/2009
Page 10
Sales Points
Good image quality
zHigh-quality ink and masters
Quiet
zSound-proofing materials are added to areas where
noise occurs
zNoise-generating mechanisms are modified
Reliable
zImproved paper delivery table
zPaper feed retry
Ink and masters: Same as the HP4
Slightly quieter than HP4, because of these modifications
Paper delivery table: The new mechanisms from the Emerald are used.
