Thermoport®As per 07/2006 Subject to technical changes! Page 2
4 Commissioning:
•Electrical connection conditions on site and specifications on the unit’s type plate must be in agreement.
•Unit connection: 1N AC 220 V- 240 V 50 Hz
•The connection cable must use at least the type H05RN–F3G1.02or a cable of equal value!
•Ensure that the electrical power cables of the inserted function elements are not crushed or come into
contact with hot parts of the housing.
•Clean the device thoroughly with a damp cloth before commissioning for the first time.
5 Operation:
5.1 1000 KB
•Connect the power cable of the Thermoport®to the socket. The heating will now start to work until it
reaches 95°C. Then it will shut down and heat up again automatically if the temperature drops.
5.2 50KB and 100KB:
•Wet and dry mode is possible:
•For wet-mode, fill approx. 2 cm water into the Thermoport®(approx. 2 l). The best possible device
efficiency is achieved in wet-mode.
•Operate the device without water.
•Connect the power cable of the Thermoport®to the socket. The heating will now start to work until it
reaches 95°C. Then it will shut down and heat up again automatically if the temperature drops.
5.3 General:
•Recommended pre-heating time before loading: 30 minutes with a closed lid.
•Temperature range: -20°C to +100°C. Please also ensure that the GN-containers you insert do not
undercut or exceed these temperatures.
•Warm food should be inserted at a minimum temperature of +85°C (see HACCP rules)
•The transportation and holding times should not exceed 2 hours (see HACCP rules)
•In the case of liquid food, the GN-containers should be closed with water-tight press-in lids
•To ensure the best insulation effects, please note:
•Leave as little free space inside the Thermoport®as possible
•Close the Thermoport®immediately after fitting and only open again just before serving
Close the door again immediately after removing food
After operation:
•The container should be cleaned inside and outside every time it is used.
6 Cleaning:
•Do not use a high-pressure cleaner on electrical devices as the water may penetrate the electrics.
•To clean the plastic, use a suitable neutral or general purpose cleaning agent. Do not use any cleaning
agents that contain chlorine, sand, soda or acids.
•The Thermoport 50K, 100K, 1000K can be washed in the dishwasher up to +90°C.
•The Thermoport®50KB, 100KB, 1000KB can be washed in the dishwasher up to +90°C if the heating
has been removed.
Proceed as follows:
•Disconnect the plug from the mains supply
•Clean the unit with a damp cloth.
•If necessary remove the heating.
7 Maintenance/ servicing:
The electrical devices must be serviced by an electrician/service technician at least every 6 months.
