WELCOME
Thank you for purchasing your Rigloo Rescue Ready Refuge. Please read these instructions carefully before
attempting to set up your Rigloo and retain for future reference. If used and cared for properly, your Rigloo
should give you years of hassle free use. We recommend that your Rigloo is insured against accidental damage
as this is not covered by the warranty.
IMPORTANT:
Under certain conditions all tents will suffer from internal condensation. Depending upon the atmospheric
conditions, the weather and the amount of moisture in the ground, the condensation could be quite severe and is
commonly mistaken for leaking, especially as it can run down the inside of the roof and drips off ties tapes and
other internal fittings. If you suspect your Rigloo is leaking it is almost certainly condensation.
The main material is a waterproof Ripstop Polyester(Flysheet) Nylon(Groundsheet) 210T and the main seams of
your Rigloo have been factory taped to help prevent leakage. Upon purchase, please set up your Rigloo and
shower with a garden hose as this expands the sewn thread and helps seal the tent. Seams treated with seam
sealant cannot leak. Seam sealant should also be applied to areas where the taping is damaged or has peeled
away through wear and tear. It can also be applied to areas where a leak may have developed. Seam sealant is
available from all good stockists.
This Rigloo is designed for use in moderate weather. During very strong winds we recommend that you do not inflate at the top of a motorway verge. The Rigloo is designed for
temporary use only of up to 8 hrs. It is not designed to be left unattended and we recommend the tether, pegs and bodyweight of occupier be utilised as anchoring, as far as is
reasonably practicable. There are x 6 loops for guy ropes which will add to the stability of the Rigloo when properly utilised.
We recommend a trial run before using your Rigloo for the first time. This will allow you to familiarise yourself with the Rigloo, its set up and any limitations it may have for your
particular use. Please ensure your rechargeable pump provided is charged fully before use.
ITEM
QTY
Rigloo Shelter
1
Tether cord
2
Carabiner ( not for climbing )
4
Rechargeable battery pump
Top up hand pump
1
1
Pegs/ Guy ropes
12/6
Foil Blankets
2
Glo Sticks
2
Please check the contents of your Rigloo Backpack before use.
SITING YOUR RIGLOO
Minimum floor area 1.8m x 1.2m and approx. 1.2m height
required
Choose a site that is flat and, if possible, protected from the wind.
Try to clear the site of sharp stones to avoid damaging the
groundsheet.
Try to set up your Rigloo with the doors in line with the direction of
wind. Avoid pitching under trees or next to barbed wire as this
could puncture the Rigloo Airframe.
SET UP
Unpack your Rigloo
Ensure tether is fitted to a valve corner where you will be starting.
Fix Tether to a post or small tree (ensure you have room for
inflation).
Roll out and unfold until flat.
Ensure both valves are closed then open one up ready for inflation.
Attach battery pump to correct nozzle and switch on pump.
Peg all 6 points if possible and fix guy lines if required.
Enter Rigloo and help unfold airframe into shape to assist inflation.
Top up pressure with manual pump for rigidity (max 7psi)
WARNING!
The Rigloo is a temporary
inflatable shelter. Care must
be taken not to puncture
the Airframe at all times.
1
During a breakdown or
unplanned stoppage, find
a safe place behind the
barrier as far from passing
traffic as reasonably
practicable. Preferably at
the top of a verge.
3
Once Tethered,
unfold and roll out
your Rigloo. Insert
the peg into the
ground at the corner
where the air valve
you will be inflating is
situated. Make sure
the opposite corner
air valve is tightly
closed in position 1
Trample down an
area of 1.2m x 1.2m
x 1.8m and try to
avoid sharp stones,
branches and
barbed wire that
could potentially
puncture the
Airframe and attach
Tether to anything
with a solid anchor
if possible.
2
5Select the correct
nozzle and
attached the
pump with a click
to the valve in
position 2. Whilst
the pump is
inflating, start to
press or stand in
the remaining
pegs into the
ground.
6As your Rigloo
inflates, flick it about
and help it inflate into
shape as folded
sections of Airframe
will restrict airflow.
Once it is inflated
(0.6psi with pump,
max permitted 7psi
with handpump)
enter Rigloo and wait
for rescue.
Valve position1, Closed
Valve position 2, Inflation
Valve position 3, Deflation
4
PEGS
The Rigloo comes complete with general purpose pegs. These will be suitable for many sites but
there will be some instances where different pegs will be necessary. Your dealer will stock a range
of pegs suitable for different types of ground. For maximum effectiveness, pegs should be driven
into the ground at a 45°angle away from the pegging point.
RAIN
We make our Rigloo as resistant to the weather as possible. Occasionally you may find slight
leakage. This is not a fault with the manufacturing process or materials and can normally be
rectified by spot treating the seam with seam sealant (see below).
SEAMS
The main seams of this Rigloo have been factory taped to help prevent leakage. Over time it may
be necessary to treat the remaining seams with a seam sealant. Seam sealant should also be
applied to areas where the taping is damaged or has peeled away through wear and tear. It can
also be applied to areas where a leak may have developed. Seam sealant is available through all
good stockists.
SUITABILITY
This Rigloo is designed for use in moderate-poor weather. During very strong winds we
recommend that the Rigloo is not inflated on the top of a motorway verge. The Rigloo is designed
for temporary use up to 8 hrs and it is not recommended to leave unattended. Use loops and guy
ropes provided where necessary for increased stability during prolonged exposure to stronger
winds.
UV DEGRADATION
All fabrics can be weakened by prolonged exposure to sunlight. Under normal use your Rigloo will
give long service but use for extended periods in strong sunlight will soon cause deterioration. In
those cases it would be wise to use a site as shaded as possible. UV degradation is not covered
under the warranty. The warranty does not cover tents used on permanent sites, displays or for
commercial purposes.
CONDENSATION
Tents contain a high proportion of synthetic materials and under certain conditions will be effected
by condensation inside the tent. This should not be confused with leaking. Condensation can be
improved by ensuring adequate ventilation. The Rigloo has two doors and enough ventilation over a
short period to avoid this situation. Condensation and its effects are not covered under the
warranty.
SAFETY
DO NOT USE NAKED FLAMES IN OR AROUND THE RIGLOO. DO NOT PIERCE OR ABUSE
THE AIRFRAME.
DEFLATION
After a breakdown we recommend the Rigloo is bundled together and placed in the
vehicle roughly to allow the user a faster exit from the hard shoulder, back on their way.
To pack away the Rigloo:
1. Leave doors partially open to allow airflow to escape
2. Release valve to position 3, the Rigloo will instantly deflate
3. Fold excess material into main floor area
4. Flatten out the Rigloo and push air towards open valves
5. Un-peg at all points except the peg at the tether
6. Fold the Rigloo into 3 sections at the longest side to about 40cm (Backpack size)
7. Fold/roll the Rigloo towards the deflation valve to expel more air and fold to 30cm to fit in the
Backpack.
8. Ensure that the Rigloo is totally dry before storing in a cool, dry, dark space.
CARE
Air fully and ensure it is totally dry before packing away. Store in a well ventilated dry place. A
wet/damp Rigloo could develop mildew.
Dirty Rigloo can be washed using clean water and a soft brush. Do not scrub and never use
detergents.
The Airframe does not need any maintenance but should be protected from damage during
storage. Damage due to improper use, wind damage or neglect is not covered under the
warranty. Have any damage repaired at the first opportunity.
Zips should be treated with care, use two hands to close and open. Never force a zip. We
strongly recommend that you carry the puncture repair kit provided if planning more than one
use over a short period.
Repairs to the tent should be made by a company recommended by Rigloo or your supplying
dealer. Repairs and alterations made by an unauthorised company may invalidate your
warranty.
