DS1000Z Firmware Upgrade Procedure

Date: 12/24/2013

Solution: The DS1000Z may periodically have firmware upgrades. Here is he

procedure for performing he upgrade.

Important

If you choose o perform an upgrade and your uni is damaged, Rigol is no responsible for he

repair or shipping cos s. The User assumes all responsibili y.

Verify he USB (flash) drive ha can be recognized by a Rigol oscilloscope (e.g. DS1102E) as

follows:

• When he oscilloscope is powered up, inser he USB drive in o he USB (Hos ) por

which is loca ed in he fron of he oscilloscope.

• When i promp s “USB device ins all success”, i indica es he flash drive is recognized by he

scope, as shown in Figure 1.

• O herwise he USB drive is no compa ible wi h he oscilloscope No e 1.

DS1000Z Upgrade Steps

1. Wi h he help of your compu er, decompress he upgrade sof ware (RAR) files and place hem

in he op direc ory of he USB drive.

2. Inser s he flash in o he USB (Hos ) por of he oscilloscope, and i will

• Promp “examine he higher/lower-version sof ware, upgrade or no ?”

• Choose “OK” o ac iva e he au oma ic ins allmen process, as shown in Figure 2.

3. Important

During he ins alla ion process, please do no dis urb or remove he USB drive, and make sure

he power supply is s able; o herwise, i may corrup he firmware and cause he oscilloscope o

be unusable, and require fac ory suppor No e 2.

NOTE:

1. Brand, and memory size dependen , no all USB drives in he marke are compa ible wi h

Rigol produc s.

2. Service charges may be required, regardless of validi y of warran y, if upgrade is no an

necessi y of bugs, applica ion failure, sys em fea ure malfunc ioning.

Headquarters

RIGOL TECHNOLOGIES, INC.

No.156,Cai He Village,

Sha He Town,

Chang Ping Dist ict, Beijing,

102206 P.R.China

Tel:+86-10-80706688

Fax:+86-10-80705070

Email: suppo t@ igol.com

USA

RIGOL TECHNOLOGIES,USA INC.

7401 Fi st Place, Suite N

Oakwood Village

OH 44164, USA

Toll f ee: 877-4-RIGOL-1

Office: (440) 232-4488

Fax: (216)-754-8107

Email: info@ igol.com

EUROPE

RIGOL TECHNOLOGIES GmbH

Lindbe gh st . 4

82178 Puchheim

Ge many

Tel: 0049- 89/89418950

Email: info-eu ope@ igoltech.com
