Q175S / Q205S Condensing Boiler

Q175S / Q205S SP 2/2011

SPECIFICATIONS

Rinnai is continually updating and improving products; therefore, specifications are subject to change without prior

notice. Local, state, provincial and federal codes must be adhered to prior to installation.

Standard Features

• Onboard outdoor reset control system with sensor standard

• Prebuilt plumbing kit with insulated Low Loss Header

• Priority DHW standard (3 way valve not included)

• Domestic hot water plate warming

• Modulating Ceramic premix burner

• 5:1 turn down ratio

• Spark ignition

• Exceeds SCAQMD 1146.2 Low NOxrequirements

• Stainless Steel Water tube condensing heat exchanger

• Direct Vent sealed combustion

• Concentric and twin pipe venting adapters included

• Approved for room and closet installations

Optional Accessories

• 3 way valve DHW kit

• RS100 Single zone controller

• Flue Gas temperature sensor

• Room Air Filter

• NG to LP conversion Kit

• LP to NG Conversion Kit

General Specifications

Boiler

Model Boiler

Model

Q175S Q205S

Water content gal 1.8 1.8

Max. supply boiler

temperature °F 176 176

Max operating pressure psi 45 45

Relief valve rating MBH 375 375

Relief valve pressure rating psi 30 30

Dry weight lbs 141 141

Min inlet gas pressure NG "W.C. 4.0" 4.0"

Max inlet gas pressure NG "W.C. 10.5" 10.5"

Min inlet gas pressure LP "W.C. 8.0" 8.0"

Max inlet gas pressure LP "W.C. 14.0” 14.0”

Max equivalent exhaust

vent length ft 80 40

Max equivalent combustion

air vent length ft 80 40

Approved venting materials Polypropylene,

Stainless Steel,

PVC, CPVC

Units

Performance Specifications

Units

Q175S Q205S

Fuel Type NG/LP NG/LP

Input MBH 175 205

Heating Capacity MBH 161 189

AFUE (I=B=R) % 95.7 95.7

Part Load Efficiency

(EN677) % 98.5 98.5

Boiler Model

Electrical Specifications

Units

Q175S Q205S

Electrical Voltage Mains V/Hz 120/60 120/60

Electrical Voltage Controls V 24 24

Power Consumption Max

Load W 210 234

Power Consumption Stand

by Load W 14 14

Recommended Circuit

breaker rating A 15 15

Boiler Model

Q175S / Q205S

Rinnai Corporation • 103 International Drive • Peachtree City, GA 30269 • Toll-Free: 1-800-621-9419 • Fax: 678-364-8643 • www.rinnai.us

DIMENSIONS

inch / mm

A Height 26.8 / 680

B Width 26 / 660

C Depth 15.2 / 385

D Left side / vent 19.5 / 495

E Center to center / vent and air

supply 4.7 / 120

F Back / vent 10.6 / 270

G Left side / gas pipe 2.6 / 65

H Left side / supply pipe 7.3 / 185

J Left side / return pipe 17.5 / 445

K Left side / condensate pipe 20.9 / 530

P Pipe length of g 0.7 / 18

Q Pipe length of c 2 / 50

R Pipe length of e, f, k, r, and w 2.3 / 60

S Back / center of pipe c 1 / 25

T Back / Center of pipe g 1.6 / 40

U Back, / center of pipe e, f, k, r,

and w 2 / 50

V Pipe length vent co-axial

Pipe length vent parallel 2.6 / 65

5.8 / 147

Q175S, Q205S

Top 2 / 50 10 / 250

Back 0 0

Front 6 / 150 24 / 600

Left side 2 / 50 2 / 50

Right

side 2 / 50 2 / 50

Floor /

Ground 12 / 300 30 / 762

Vent 0 0

inch / mm

Minimum required

clearance to

combustibles and

non-combustibles

Recom-

mended

service

clearances

inch / mm

Clearances

2.0”

50mm

2.1”

54mm [5.6”

142mm

10.2”

260mm

12”

305mm

15”

381mm

4.7”

120mm

5.2”

133mm 17.2”

438mm 19.7”

501mm

18.6”

474mm
