Riso Comcolor X1 Series Bedienungsanleitung
Riso Comcolor X1 Series
Geng Started Guide
Basic Prinng from a PC
Using the GDI Interface
Riso (UK) Limited
X1 Series GDI Prinng V.1
Please Note
This publication is intended as a brief introduction to printing from a PC to
a Riso Comcolor X1 Series printer using the built-in GDI controller.
For full instructions please refer to the user guides supplied with the Riso
machine.
Service Helpdesk 020 8236 5832 Supplies (Ink & Staples) 0800 783 2086 Head Office 020 8236 5800
RISO (UK) Limited
1). Producing single sided A4 copies
2). Producing double sided (duplex) copies
3). Enlargement to A3
4). Mul-up - same images on one page
5). Mul-up - different images on one page
6). Booklets (folding and stapling of booklets will require oponal finishing unit installed)
7). Stapling (Portrait) (requires oponal finishing unit installed)
8). Stapling (Landscape) (requires oponal finishing unit installed)
9). Hole Punching (requires oponal finishing unit installed)
10). Cover Sheets (requires oponal finishing unit installed)
11). Secure prinng
12). Prinng Out Secure Print
13). Saving Jobs to Storage
14). Prinng Out Jobs from Storage
Contents
With the document you wish to print open
on your screen:
1). Select > File > Print and the Print Dialogue box shown
opposite will open
2). Select the Riso Comcolor X1 Series printer from the drop
down menu
3). Select > Properes
The Riso Comcolor X1 Series printer properes will
now open up in the [Basic] tab indicated:
1). Select > Auto or Monochrome (Black + White)
2). Select > OK
The Print Dialogue box will reappear:
1). Select > Number of copies:
2). Select > OK
The Riso Comcolor X1 Series will now print the selected
number of copies
A
C
B
1
Producing Single Sided A4 Copies
Follow secon A of page 2 to open up the
Properes of the Riso Comcolor X1 Series then:
1). Select paper size you wish to print on from the drop
down menu > Paper Feed Tray
Choose > Standard Feed Tray for A4
Choose > Feed Tray 3 for A3
Please note that 3110 models will not have a choice of
paper feed trays
A
Select your Double Sided (Duplex) opon:
1). Select > Duplex Print
Choose > Long Edge Binding
Or > Short Edge Binding
2). Select > OK
B
2
Producing Double Sided (Duplex) Copies
LONG EDGE BINDING
SHORT EDGE BINDING
Follow secon A of page 2 to open up the
Properes of the Riso Comcolor X1 Series then:
1). Choose > Feed Tray 3 for A3 size paper
Please note that
A
Select “Paper Size”:
1). Using the drop down menu > Paper size
confirm the size of paper to print out.
2). Select > OK
B
3
Enlargement to A3
Follow secon A of page 2 to open up the
Properes of the Riso Comcolor X1 Series then:
1). Select paper size you wish to print on from the drop
down menu > Paper Feed Tray
Choose > Standard Feed Tray for A4
Choose > Feed Tray 3 for A3
Please note that 3110 models will not have a choice of
paper feed trays
A
Select The “Layout” tab
1). Select > Imposion
From the drop down menu
Choose > Mult-up (Single page)
2). This will then acvate > Pages / Sheets
Choose 2, 4, or 8 of the same image per page
3). Select > OK
B
4
Mul-up - Same image on one page
Follow secon A of page 2 to open up the
Properes of the Riso Comcolor X1 Series then:
1). Select paper size you wish to print on from the drop
down menu > Paper Feed Tray
Choose > Standard Feed Tray for A4
Choose > Feed Tray 3 for A3
Please note that 3010 models will not have a choice of
paper feed trays
A
Select The “Layout” tab
1). Select > Imposion
From the drop down menu
Choose > Mul-up (Mulpage)
2). This will then acvate > Pages / Sheet
Choose 2, 4, or 8 different pages to view per page
3). Select > OK
B
5
Mul-up - Different images on one page
Follow secon A of page 2 to open up the
Properes of the Riso Comcolor X1 Series then:
1). Select paper size you wish to print on from the drop
down menu > Paper Feed Tray
Choose > Standard Feed Tray for A4
Choose > Feed Tray 3 for A3
Please note that 3010 models will not have a choice of
paper feed trays
2). Select > Paper size
to match paper size to be printed
**Please note that if using the oponal finishing unit to fold
and staple an A5 booklet (see step C):
Choose > Feed Tray 2 for A4
A
Select the “Layout” tab
1). Select > Imposion
From the drop down menu
Choose > Booklet
B
The following funcon will require the
oponal Mulfunconal Finisher unit to be fied
Select the “Finishing” tab
1). Select > Booklet binding
From the drop down menu
Choose > Fold and Staple
2). Select > OK
C
6
A4 and A5 Booklets
Select The “Main Sengs” tab
1). For A4 select > Standard Feed Tray
This is the default seng
Select The “Finisher” tab
1). Select > Binding Side
Choose > Leor Right
2). Select > Staple
Choose > 1 posion
2 posion
3). Select > OK
LEFT RIGHT
1 Position 1 Position
2 Position 2 Position
A
B
7
A4 Stapling - Portrait
The following funcon will require the oponal Face Down Offset Stapler
or the Mulfunconal Finisher unit to be fied
