Riton X3 TACTIX ARD Bedienungsanleitung

ARD

X3 TACTIX

Table of Contents

3 OpticSpecics

4 TechnicalSpecications

5 ExplanationofMOA

6 ReticleInformation

6 ExplanationofParallax

7 IlluminationSystem

7 FactoryZero,WindageandElevation

8 MountingtheRitonOptic

9 BoreSighting

9 ZeroingtheRiescope

10 Troubleshooting

10 Warranty

THANKYOU

FORMAKINGA

PURCHASEWITH

RITONOPTICS.

We know that you have many

options and we are thankful for

selecting Riton as your optics

provider.

AsacompanyfoundedbyLawEnforcementandMilitaryVeterans,

wetakeourcommitmenttoserviceseriously.Wehavean

unwaveringpassionforofferinghighqualityopticsattheindustry’s

mostcompetitivepricesandmatchedbyincredibleservice.You

willseethedifferenceineverythingwedobecausewearedifferent,

andwedevelopedthiscompanytobeexactlythatsothatyou,the

consumer,geteverythingyoudeserve.Ifyouareeverinneedof

additionalinformationorassistance,pleasecontactus.Wearehere

tocontinualserveyouasavaluedpartner.

X3TACTIXARD

Optic Specics

TheX3TactixARDisaversatilereddotoptic,whetheryou’remountingittoanAR,AK,a

shotgun,orapistol.FeaturingtheRiton2MOAultra-precisereddot,italsocomeswith

threeinterchangeablemountstondtheperfectmountingheightnomattertheplatform.

DETAILED PRODUCT FEATURES:

• CappedTurrets

• AircraftGradeAluminumwith

RuggedDesignReadyforthe

ToughestEnvironments

• 100%Waterproof,Fogproofand

Shockproof(testedupto1200G’s)

• 1MOAWindageandElevation

Adjustment

• AssembledinEP-LevelCleanRoom

Objective

QDRailMount

Turrets

Illumination

Magnication: 1x

ParallaxSetting: 50yds

ObjectiveLensDiameter: 23mm

LensCoating: FullyMulti-Coated,FullWideBand,Waterproof

Coated,LowLightEnhancement

DotSize: 2MOARedDot

FieldofViewat100yds: 68ft

Material: 6061-T6AircraftGradeAluminum

Weight: 4oz/118g

Length: 2.44in/62mm

EyeRelief: Unlimited

ExitPupil:28mm

ClickValueat100yds: 1MOA

AdjustmentRange: 120MOA

Technical

Specications

Explanation of

Minute of Angle (MOA)

MOAunitofarcmeasurementsarebasedondegreesand

minutes.Thereare360degreesinacircleand60minutesina

degreeforatotalof21,600minutes(MOA)inacircle.Aminuteof

anglewillsubtend1.05inchesatadistanceof100yards.

*Graduations can be calculated at additional distances beyond 500 yds.

1MOA 1 IN 2 IN 3 IN 4 IN 5 IN

100Yards 200Yards 300Yards 400Yards 500Yards

Second Focal Plane (SFP) Reticle

ThereticleinyourRitonriescopeisaSecondFocalPlane

(SFP).SFPreticlesarelocatedinrearoftheimageerecting

andmagnifyinglenses.TheadvantageofaSFPreticleisthatit

alwaysmaintainsthesameappearance.Shootersusingreticle

hashmarksshouldbeawarethatthelistedsubtensionsused

forestimatingrange,holdover,andwindagecorrectionareatthe

maximummagnication.

TO CHANGE MAGNIFICATION:

Simplyturnthemagnicationringtothedesiredmagnication

level.Lowerpowersofferawidereldofviewwhilehigherpowers

offerazoomedinfocusedview.

Reticle Information

TheX3TactixARDhasa2MinuteofAngle(MOA)dot,isnight

visioncompatibleandcanrunupto1600hoursononesingle

CR2032battery.

Explanation of Parallax

Parallaxdescribesasituationwherethefocalplaneoftheobjectinthescopeisoffset

fromthereticle.Ifyouhaveparallax,youhaveanopticalillusionthatmustbecorrected.

Parallaxshouldnotbeconfusedwithfocus.Parallaxcompensationchangesneitherthe

focusofthereticlenorthefocusoftheimage;itsimplymovestheplanesatwhichthese

twoobjectsareinfocussothattheysharethesameplane.

TO ADJUST THE PARALLAX:

1. Setyourfastfocuseyepieceforyoureye.Lookatablankbackdropandturnyoureye

pieceinandoutuntilyouhaveacrispsharpreticle.

2. Lookthroughscopeandplacecross-hairontarget.Moveyourheadaroundwithout

leavingexitpupil.Doesthecrosshairmoveorbecomeblurry?

3. Ifthecross-hairmovesorisblurry,setthesideparallaxtoestimatedrange,usethisas

startingpointandnetuneasneeded.

YOUR RITON RIFLESCOPE DOES

NOT HAVE A PARALLAX FOCUS

AND IS FACTORY FOCUSED AT A

DISTANCE OF 100 YARDS.

Mechanical Zero

YourRitonriescopeispre-setfromthefactorywiththereticlein

thecenteroftheadjustmentranges.

TO FIND FACTORY ZERO:

1. Dialturretonedirectionuntilitwillnolongerrotate.

NOTE-Donotforcetheturretpastit’sstoppingpoint.

2. DialturretoppositedirectioncountinghowmanyMOAit

turns.

3. DividethattotalnumberofMOAinhalfanddialtothat

numberforyourfactoryzero.

4. Completethisprocedureforbothwindageandelevation

dialstoapproximatelycenterthereticle.

Illumination System

Thevariableintensityreticleilluminationsystemaidsinlowlight

situations.

TO ACTIVATE THE ILLUMINATION:

1. Rotatetheadjustmentknobineitherdirection.

Note - The illumination knob allows for 6 levels of brightness intensity.

TO CHANGE BATTERY:

1. Unscrewtheoutercap.

2. Removethebattery.

3. ReplacewithanewCR2032batterywithpositivesideout.

4. Re-installthebatterycapandbesuretotightenfully.

Mounting Your Riton Red Dot

TO MOUNT YOUR RITON RED DOT:

1. YourRitonRMDcomewithalower1/3cowitnessmount

2. Usingtheprovidedallenwrenchloosenthebasebolt.Then

attachthelowerbaseandmakesurethisissolidlyseatedin

thebasegroove.Topreventrecoilinjury,positiontheRedDot

sothatyouhaveatleastfourinchesofeyerelief.

3. Besurethebaseclampishookedaroundtheoutsideofthe

rail/base.Pressdownwardandforwardtowardthemuzzle.

Then,rmlytightenthebaseclamphexnut.

4. Note.theRitonRRDhasanunlimitedeyerelief.

5. IfyouplantomountamagnierbehindyourRedDotbesure

toleavesucientspaceforthisasyoumountyourRRD.

Bore Sighting

Boresightingisapreliminaryproceduretoachieveproper

alignmentoftheRMDwiththerie’sbore.Initialboresightingof

theriescopewilldecreasetheamountoftimeandammunition

youneedtouseattherange.

Thiscanbedonebyusingamechanicalorlaserboresighter

accordingtothemanufacturer’sinstructionsorbyremovingthe

boltandsightingthroughthebarrelonsomeries.

TO BORE SIGHT YOUR RIFLESCOPE:

1. Placetheriesolidlyonarestandremovethebolt/bolt

carriergroup.

2. Sightthroughtheboreatatargetapproximately25yards

away.

3. Movetherieandtherestuntilthetargetisvisuallycentered

insidethebarrel.

4. Withthetargetcenteredinthebore,makewindageand

elevationadjustmentsuntilthereddotisalsocenteredover

thetarget.

Note - If a laser bore sighting or any other similar device inside the bore

was used, it must be removed before ring. An obstructed bore can cause

Zeroing the Scope

IMPORTANT SAFETY CHECKS:

• Alwayscheckyourweaponandsurroundingsforsafety.

• Followallweaponmanufacturersafetyguidelines.

• Alwaysshootfromasolidrestusingconsistentandproper

form.

• Besurethatyourtargetisleveltoaidinaccuratesight-in

process.

TO ZERO THE SCOPE:

1. Startsight-inprocessfrom25yards,fromsolidrestre3-shotgroup,ensuringthat

youreatsamespoteachtime.Usegridlinesontargettocenterandlevelyour

crosshairs.

2. Aftertherst3-shotgroup,makeadjustmentstobringbulletimpacttocenteroftarget

you’reshootingat.Repeatthisprocessatwhateverrangeyouchooseandyouwill

haveaccuratezero.

Note - Scope graduations are 1 MOA. Scope turrets are marked with direction of bullet impact change.

At 100 yards a 1 MOA scope adjustment will move bullet impact 1 inch in direction adjusted. At 25

yards that same 1 MOA adjustment will be 4 times smaller, so 1 MOA adjustment at 25 yards will move

bullet impact 1/4 of an inch.

Riton Warranty

AsapartoftheRitonPromisewebelieveinprovidingyouwiththebestpossibleservice,

includingtheindustry’sbestwarranty.Thequalityofourproductsmakesthisthebest

warrantyyou’lllikelyneverhavetouse;however,ashuntersandoutdoorsmenandwomen,

weknowthatbadthingssometimeshappentoeventhemostcautious.

OUR WARRANTY IS SIMPLE:

• NoproofofpurchaseorregistrationrequiredforyourRitonproducts.

• Lifetimewarrantyregardlessoforiginalpurchaser.

• Allwarrantyreplacementswillreceiveabrand-newproductofftheshelf.Wewillnot

everreplacetheproductwitharepairedorrefurbishedproduct.

• Replacementproductwillbeshippedwithin48hoursofreceivingandapprovingyour

return.

• Loss,theftand/ordeliberatelywornanddamagedproductsarenotcovered.Warranty

isVOIDifdamageresultsfromunauthorizedrepairoralteration.

Troubleshooting

Problemsthoughttobeassociatedwiththescopeareoftenactuallymountproblems.Take

timetoensurethemountsaretighttotheRMDandthatRMDissecuredanddoesn’ttwist

ormoveintherings.Conrmthatcorrectbaseandringsarebeingusedandintheproper

orientation.Besuretotorqueringspermanufacturer’sspecs.

Keepinmindtherearemanyissuesthatcancausepoorbulletgrouping.Alwaysutilizea

solidrestandmaintaingoodshootingtechnique.Haveaqualiedgunsmithlookoveryour

rietobesureallthingsareinworkingorder.Seethattheactionandbarrelareproperly

cleaned.Someriesandammunitiondon’tworkwelltogether,trydifferentammunitionand

seeifaccuracyimproves.

1-855-39-RITON

[email protected]

RITONOPTICS.COM
