RKC INSTRUMENT SA201 Bedienungsanleitung

IMR01K02-E1

SA201

Communication

Instruction Manual

RKC INSTRUMENT INC.

Temperature Controller

!"Modbus is a registered trademark of Schneider Electric.

!"Company names and product names used in this manual are the trademarks or registered trademarks of

the respective companies.

IMR01K02-E1 i-1

Thank you for purchasing the RKC instrument. In order to achieve maximum performance and ensure

proper operation of your new instrument, carefully read all the instructions in this manual. Please

place this manual in a convenient location for easy reference.

SYMBOLS

: This mark indicates important information on installation, handling and operating

procedures.

: This mark indicates supplemental information on installation, handling and

operating procedures.

: This mark indicates where additional information may be located.

An external protection device must be installed if failure of this instrument

could result in damage to the instrument, equipment or injury to personnel.

All wiring must be completed before power is turned on to prevent electric

shock, fire or damage to instrument and equipment.

This instrument must be used in accordance with the specifications to prevent

fire or damage to instrument and equipment.

This instrument is not intended for use in locations subject to flammable or

explosive gases.

Do not touch high-voltage connections such as power supply terminals, etc.

to avoid electric shock.

RKC is not responsible if this instrument is repaired, modified or

disassembled by other than factory-approved personnel. Malfunction can

occur and warranty is void under these conditions.

CAUTION

: This mark indicates precautions that must be taken if there is danger of electric

shock, fire, etc., which could result in loss of life or injury.

: This mark indicates that if these precautions and operating procedures are not

taken, damage to the instrument may result.

: This mark indicates that all precautions should be taken for safe usage.

WARNING

IMR01K02-E1

i-2

!This is a Class A instrument. In a domestic environment, this instrument may cause radio

interference, in which case the user may be required to take adequate measures.

!This instrument is protected from electric shock by reinforced insulation. Provide

reinforced insulation between the wire for the input signal and the wires for instrument

power supply, source of power and loads.

!Be sure to provide an appropriate surge control circuit respectively for the following:

- If input/output or signal lines within the building are longer than 30 meters.

- If input/output or signal lines leave the building, regardless the length.

!This instrument is designed for installation in an enclosed instrumentation panel. All high-

voltage connections such as power supply terminals must be enclosed in the

instrumentation panel to avoid electric shock by operating personnel.

!All precautions described in this manual should be taken to avoid damage to the

instrument or equipment.

!All wiring must be in accordance with local codes and regulations.

!All wiring must be completed before power is turned on to prevent electric shock,

instrument failure, or incorrect action.

The power must be turned off before repairing work for input break and output failure

including replacement of sensor, contactor or SSR, and all wiring must be completed

before power is turned on again.

!To prevent instrument damage or failure, protect the power line and the input/output lines

from high currents with a protection device such as fuse, circuit breaker, etc.

!Prevent metal fragments or lead wire scraps from falling inside instrument case to avoid

electric shock, fire or malfunction.

!Tighten each terminal screw to the specified torque found in the manual to avoid electric

shock, fire or malfunction.

!For proper operation of this instrument, provide adequate ventilation for heat dispensation.

!Do not connect wires to unused terminals as this will interfere with proper operation of the

instrument.

!Turn off the power supply before cleaning the instrument.

!Do not use a volatile solvent such as paint thinner to clean the instrument. Deformation or

discoloration will occur. Use a soft, dry cloth to remove stains from the instrument.

!To avoid damage to instrument display, do not rub with an abrasive material or push front

panel with a hard object.

!Do not connect modular connectors to telephone line.

NOTICE

!This manual assumes that the reader has a fundamental knowledge of the principles of electricity,

process control, computer technology and communications.

!The figures, diagrams and numeric values used in this manual are only for purpose of illustration.

!RKC is not responsible for any damage or injury that is caused as a result of using this instrument,

instrument failure or indirect damage.

!Periodic maintenance is required for safe and proper operation of this instrument. Some

components have a limited service life, or characteristics that change over time.

!Every effort has been made to ensure accuracy of all information contained herein. RKC makes no

warranty expressed or implied, with respect to the accuracy of the information. The information in

this manual is subject to change without prior notice.

!No portion of this document may be reprinted, modified, copied, transmitted, digitized, stored,

processed or retrieved through any mechanical, electronic, optical or other means without prior

written approval from RKC.

CAUTION

IMR01K02-E1 i-3

CONTENTS

Page

1. OUTLINE ...............................................................................1

2. SPECIFICATIONS.................................................................2

3. WIRING .................................................................................4

4. SETTING ...............................................................................6

4.1 Transfer to Communication Setting Mode .......................................................6

4.2 Setting the Communication Parameters ..........................................................7

4.3 Communication Requirements ......................................................................11

5. RKC COMMUNICATION PROTOCOL ...............................13

5.1 Polling............................................................................................................13

5.1.1 Polling procedures ............................................................................................14

5.1.2 Polling procedure example ...............................................................................17

5.2 Selecting........................................................................................................18

5.2.1 Selecting procedures ........................................................................................18

5.2.2 Selecting procedure example ...........................................................................21

5.3 Communication Identifier List ........................................................................22

6. MODBUS COMMUNICATION PROTOCOL .......................26

6.1 Message Format............................................................................................26

6.2 Function Code ...............................................................................................27

6.3 Communication Mode....................................................................................27

6.4 Slave Response.............................................................................................28

6.5 Calculating CRC-16 .......................................................................................29

6.6 Message Format............................................................................................31

6.6.1 Reading holding registers [03H]........................................................................31

6.6.2 Preset single resister [06H]...............................................................................32

6.6.3 Diagnostics (loopback test) [08H] .....................................................................33

IMR01K02-E1

i-4

Page

6.7 Data Configuration.........................................................................................34

6.7.1 Data range........................................................................................................34

6.7.2 Data processing precautions ............................................................................35

6.8 Communication Data List...............................................................................36

7. INPUT RANGE TABLES.....................................................40

8. TROUBLESHOOTING ........................................................44

9. ASCII 7-BIT CODE TABLE (RFERENCE)..........................47

IMR01K02-E1 1

1. OUTLINE

Temperature controller SA201 interfaces with the host computer via Modbus or RKC communication

protocols. For reference purposes, the Modbus protocol identifies the host computer as master, the

SA201 as slave.

RS-485

RS-232C

Host computer or

PLC, etc.

RS-232C/RS-485

converter

Host computer or

PLC, etc.

SA201

2IMR01K02-E1

2. SPECIFICATIONS

!"!"

RKC communication

Interface: Based on RS-485, EIA standard

Connection method: 2-wire system, half-duplex multi-drop connection

Communication distance: 1 km max.

The maximum communication distance will be affected by the

surrounding conditions.

Synchronous method: Start/stop synchronous type

Communication speed: 2400 bps, 4800 bps, 9600 bps, 19200 bps

Data bit configuration: Start bit: 1

Data bit: 7 or 8

Parity bit: Without, Odd or Even

Stop bit: 1 or 2

Protocol: ANSI X3.28 subcategory 2.5, A4

Polling/selecting type

Error control: Vertical parity (With parity bit selected)

Horizontal parity (BCC check)

Communication code: ASCII 7-bit code

Termination resistor: Externally connected

Xon/Xoff control: None

Maximum connections: 32 instruments maximum including a host computer

Signal logic: RS-485

Signal voltage Logic

V (A) - V (B) ≥2 V 0 (SPACE)

V (A) - V (B) ≤-2 V 1 (MARK)

Voltage between V (A) and V (B) is the voltage of (A) terminal for the

(B) terminal.

2. SPECIFICATIONS

IMR01K02-E1 3

!"!"

Modbus

Interface: Based on RS-485, EIA standard

Connection method: 2-wire system, half-duplex multi-drop connection

Communication distance: 1 km max.

The maximum communication distance will be affected by the

surrounding conditions.

Synchronous method: Start/stop synchronous type

Communication speed: 2400 bps, 4800 bps, 9600 bps, 19200 bps

Data bit configuration: Data bit: 8 (Byte data corresponding to binary data or bit.)

Parity bit: Without, Odd or Even

Stop bit: 1

Protocol: Modbus

Signal transmission mode: Remote Terminal Unit (RTU) mode

Function code: 03H (Read holding registers)

06H (Preset single register)

08H (Diagnostics: loopback test)

Error check method: CRC-16

Error code: 1: Function code error

2: When written to read only (RO) data, When any address other than

0000H to 001AH is specified, etc.

3: When the data written exceeds the setting range, When the specified

number of data items in the query message exceeds the maximum

number of data items available

4: Self-diagnostic error response

Termination resistor: Externally connected

Maximum connections: 32 instruments maximum including a master

Signal logic: RS-485

Signal voltage Logic

V (A) - V (B) ≥2 V 0 (SPACE)

V (A) - V (B) ≤-2 V 1 (MARK)

Voltage between V (A) and V (B) is the voltage of (A) terminal for the

(B) terminal.

4IMR01K02-E1

3. WIRING

!"!"

Terminal number and signal details

Terminal

No.

Signal name Symbol

10 Signal ground SG

11 Send data/Receive data T/R (A)

12 Send data/Receive data T/R (B)

!"!"

Wiring method

#"#"

Connection to the RS-485 port of the host computer (master)

T/R

(

)

T/R

(

)

T/R

(

)

T/R

(

)

(

RXD

)

：

Receive data

(

TXD

)

：

Send data

Host com

uter

(

Master

)

RS-485

T/R

(

)

T/R

(

)

31 max.

Paired wire

Send/Receive

transfer signal

Shielded twisted

pair wire

* R: Termination resistors (Example: 120 Ω1/2 W)

SA201

(Slave)

SD (TXD) and RD (RXD): Negative logic

Communication

terminal

SA201

(Slave)

Communication

terminal

* R

To prevent electric shock or instrument failure, do not turn on the power until all

the wiring is completed.

WARNING

Andere Handbücher für SA201

Inhaltsverzeichnis

Andere RKC INSTRUMENT Temperaturregler Handbücher

RKC INSTRUMENT

RKC INSTRUMENT SA100L Gebrauchs- und Pflegehandbuch

RKC INSTRUMENT

RKC INSTRUMENT X-TIO-A Bedienungsanleitung

RKC INSTRUMENT

RKC INSTRUMENT FZ110 Bedienungsanleitung

RKC INSTRUMENT

RKC INSTRUMENT CB100 Series Gebrauchsanweisung

RKC INSTRUMENT

RKC INSTRUMENT SA200 Series Bedienungsanleitung

RKC INSTRUMENT

RKC INSTRUMENT RB900 Bedienungsanleitung

RKC INSTRUMENT

RKC INSTRUMENT SA200 Series Bedienungsanleitung

RKC INSTRUMENT

RKC INSTRUMENT SA100 Series Bedienungs- und Wartungsanleitung

RKC INSTRUMENT

RKC INSTRUMENT RB100 Gebrauchs- und Pflegehandbuch

RKC INSTRUMENT

RKC INSTRUMENT RB100 Bedienungsanleitung

RKC INSTRUMENT

RKC INSTRUMENT REX-D Series Bedienungsanleitung

RKC INSTRUMENT

RKC INSTRUMENT REX-F9000 Bedienungsanleitung

RKC INSTRUMENT

RKC INSTRUMENT SRZ Z-TIO-A Bedienungsanleitung

RKC INSTRUMENT

RKC INSTRUMENT V-TIO-L Bedienungsanleitung

RKC INSTRUMENT

RKC INSTRUMENT Z-TIO PLC Communication Bedienungsanleitung

RKC INSTRUMENT

RKC INSTRUMENT REX-P48 Series Bedienungsanleitung

RKC INSTRUMENT

RKC INSTRUMENT REX-F9000 Gebrauchs- und Pflegehandbuch

RKC INSTRUMENT

RKC INSTRUMENT SA201 Bedienungsanleitung

RKC INSTRUMENT

RKC INSTRUMENT V-TIO-G Bedienungsanleitung

RKC INSTRUMENT

RKC INSTRUMENT REX-F9000 Bedienungsanleitung

RKC INSTRUMENT

RKC INSTRUMENT REX-S100 Bedienungsanleitung

RKC INSTRUMENT

RKC INSTRUMENT SA201 Handbuch

RKC INSTRUMENT

RKC INSTRUMENT SRV Series Bedienungs- und Wartungsanleitung

RKC INSTRUMENT

RKC INSTRUMENT X-TIO-B Bedienungsanleitung

Beliebte Temperaturregler Handbücher anderer Marken

Swegon

Swegon LUNAd MB Bedienungsanleitung

Lucky Reptile

Lucky Reptile Thermo Control II Bedienungsanleitung

SENSORMETRIX

SENSORMETRIX Argon 100 Bedienungsanleitung

Fuji Electric

Fuji Electric PXE4 Bedienungsanleitung

Yuyao gongyi

Yuyao gongyi XMT-808 series Bedienungsanleitung

Selec

Selec TC544C Bedienungsanleitung

P.W. KEY

P.W. KEY rt-208gt Bedienungsanleitung

Future Design

Future Design FDC-9200 Bedienungsanleitung

BH Thermal

BH Thermal BriskONE Bedienungsanleitung

Omron

Omron E5EX-H Bedienungsanleitung

West Control Solutions

West Control Solutions KS 45 Kurzanleitung

MCS

MCS RITC-15B Bedienungsanleitung

SMC Networks

SMC Networks Thermo-con INR-244-639 Bedienungsanleitung

eltherm

eltherm Ex-TC It Series Bedienungsanleitung

Omron

Omron C200H-TV Series Bedienungsanleitung

industrie technik

industrie technik CA1 Bedienungsanleitung

KRAL

KRAL EET 32 Bedienungsanleitung

dixell

dixell XR420C Verdrahtungsschema
