RM Tablet PC
User Guide
RTAB910
Table of Contents
Chapter 1 Introducing the Tablet PC
Product Overview
Safety Information
Inventory Checklist
Chapter 2 Around the Tablet PC
Chapter 3 Setting up the Tablet PC
Charging Tablet PC Battery
Using Stylus
TurningOn/OfftheTablet
Putting the Tablet in Standby Mode
Changing New Battery (Hot Swap Time Process)
Calibrating Screen for Stylus Accuracy
Adjusting Screen Brightness
Selecting Screen Orientation
Projecting Materials on Screen
Chapter 4 Defining the PC Function Keys
Button Functions during XP logon
Button Functions after XP logon
Button Configuration
Chapter 5 Protecting the Tablet PC
Cleaning the Screen
Chapter 6 Troubleshooting
Useful Tutorials
Help and Support
QuestionsandAnswers
Before Contacting RM
Contact RM
Appendix
SafetyNotices
Regulatory Compliance
Chapter 1 Introducing the Tablet PC
Product Overview
The Tablet PC combines the versatility of a pen and paper with the functionality of a laptop to
provide a truly mobile tool for work and personal use. This lightweight, portable PC gives
easy access to entering and retrieving information using the latest Windows-based
applications.
There are a vast number of benefits the Tablet PC has to offer.
These include:
The user-centered design of the PC, which allows the user the convenience of
resting a hand on the Tablet PC while writing.
A highly advanced speech recognition system, which converts speech into text.
The lightweight design, which allows business to be, conducted virtually anywhere.
No more hassle with entering information into your PC! With the stylus, text can
written directly on the Tablet PC screen and handwriting is instantly converted into
text.
Safety Information
The following 2 symbols are used in this user manual. Each symbol denotes important and
helpful information that will benefit you while using the computer.
Warning:
This symbol informs you that improper use of equipment or failure to follow
instructions may cause property damage or bodily injury.
* Note:
This symbol offers advice that will allow the user to take full advantage of the
Tablet PC.
To preserve the RM Tablet PC in the best possible condition, the following safety measures
should be observed.
* Note:
View the PC screen from 15” to 18” away.
* Note:
For comfortable viewing and glare reduction, keep the Tablet PC screen away from
direct sunlight or illumination.
* Note:
Minimise touching the screen with fingers, because skin oils are hard to remove and
reduce image clarity.
Warning:
Never remove the rear cover of the Tablet PC, as high voltages may be present.
Warning:
Do not place heavy objects on the Tablet PC or associated cables and peripherals.
Warning:
Avoid operating the PC in outdoor environments of extreme cold, dampness or wetness.
Inventory Checklist
• Tablet PC x 1
• 4-cell Lithium Battery Pack x 1
• Stylus x 1
• Stylus Cord x 1
• Modem Cable x 1
• AC Adapter x 1
• AC power cord and plug x1
• CD x 2
• Mini VGA Cable x 1 (RTAB910-T01 model only)
• Quick Start Guide x 1
Chapter 2 Around the Tablet PC
This section briefly explains some of the hardware features on the Tablet PCc.
Power Button
Finger Print Sensor
(RTAB910-T01model
only)
Joystick Button
Front View
Stylus holder
Memory
Cover
Battery Catch
Battery
Position of system Label
System Reset
Rear View of the Tablet Hard Disk Cover
Flash card slot
(RTAB910-T01 model only)
Stylus Cord
anchor point
Kensington Lock attachment poin
t
PCMCIA 1x Type II Slot
(RTAB910-T01 model only)
USB Firewire (RTAB910-T01
model only)
Top View of the Tablet
DC Input
Docking Station Port
Bottom Side View of the Tablet
Network Port
Headphone Socke
t
VGA Port USB Port
Microphone Socket
Modem Port
Right Side View of the Tablet
What do the lights stand for?
The LEDs or lights and their icons and functions are shown below:
Power Indicator. A steady green light indicates that the Tablet PC is ON.
When in Standby mode, this light flashes slowly. If this light is off, the
Tablet PC is OFF.
Hard Drive Indicator. A flashing green light indicates that the PC hard
drive is operating.
Battery Indicator. A flashing red light indicates low battery. A steady
red light indicates that the battery is charging. No light indicates that the
battery is fully charged when it is attached to the Tablet PC.
