Robustel EG5100 Hardware Manual

RT066_HM_EG5100 1/8

EG5100

Hardware Manual

Version: 1.0.0

Date: July 6, 2022

Robustel EG5100 Hardware Manual

RT066_HM_EG5100 2/8

Regulatory and Type Approval Information

Table 1: Toxic or Hazardous Substances or Elements with Defined Concentration Limits

Radio Specifications

RF technologies

2G, 3G, 4G, GNSS, WiFi, BLE

2G Frequency

GSM: B2/B3/B5/B8

3G Frequency

WCDMA: B1/B2/B4/B5/B6/B8/B19

4G Frequency

LTE FDD: B1/B2/B3/B4/B5/B7/B8/B12/B13/B18/B19/B20/B25/B26/B28

LTE TDD: B34/B38/B39/B40/B41

WiFi Frequency

2.4 GHz: 2.412 ~ 2.484 GHz

5 GHz: 4.915 ~ 5.925 GHz

BLE Frequency

2402 ~ 2480 MHz

Max RF power

35 dBm@GSM, 25 dBm@WCDMA, 23 dBm@LTE, 18.5dBm@WiFi, 4 dBm@BLE

Simplified EU Declaration of Conformity

We, Guangzhou Robustel Co., Ltd. are located at 501, Building #2, 63 Yongan Road, Huangpu District, Guangzhou,

China, declare that this radio equipment complies with all applicable EU directives. The full text of the EU DoC is

available at the following internet address:

www.robustel.com/certifications/

Name of

the Part

Hazardous Substances

(Pb)

(Hg)

(Cd)

(Cr(VI))

(PBB)

(PBDE)

(DEHP)

(BBP)

(DBP)

(DIBP)

Metal

parts

Circuit

modules

Cables

and cable

assemblie

Plastic

and

polymeric

parts

Indicates that this toxic or hazardous substance contained in all of the homogeneous materials for this part is

below the limit requirement in RoHS2.0.

Indicates that this toxic or hazardous substance contained in at least one of the homogeneous materials for this

part might exceed the limit requirement in RoHS2.0.

Indicates that it does not contain the toxic or hazardous substance.

Robustel EG5100 Hardware Manual

RT066_HM_EG5100 3/8

FCC Declaration of Conformity

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:

(1) This device may not cause harmful interference.

(2) This device must accept any interference received, including interference that may cause undesired operation.

IC Declaration of Conformity

This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic

Development Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions:

(1)This device may not cause interference.

(2)This device must accept any interference, including interference that may cause undesired operation of the device.

L’émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme aux CNR d’Innovation,

Sciences et Développement économique Canada applicables aux appareils radio exempts de licence. L’exploitation

est autorisée aux deux conditions suivantes :

(1) L' appareil ne doit pas produire de brouillage;

(2) L' appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d' en

compromettre le fonctionnement.

Radio Frequency Exposure Statement for IC

This device complies with IC exposure limits set forth for an uncontrolled environment. This device shall be installed

and operated with minimum distance 20cm between the radiator & body.

Cet équipement est conforme aux limites d'exposition IC définies pour un environnement non contrôlé. Cet

équipement doit être installé et utilisé avec une distance minimale de 20 cm entre le radiateur et la carrosserie.

Related download link

Find more product documents or tools at:

www.robustel.com/en/documentations/

Technical Support

Tel: +86-20-82321505

Email: support@robustel.com

Web: www.robustel.com

Robustel EG5100 Hardware Manual

RT066_HM_EG5100 4/8

Document History

Updates between document versions are cumulative. Therefore, the latest document version contains all updates

made to previous versions.

Date

Firmware Version

Document Version

Change Description

July 6, 2022

2.0.0

1.0.0

Initial release.

Robustel EG5100 Hardware Manual

RT066_HM_EG5100 5/8

Overview

EG5100 is a new generation of industrial edge computing gateway, supporting global 4G/3G/2G networks for

cellular backhaul, with a fully-fledged Debian 11(bullseye) based operating system able to support thousands of

existing or new ARMv7 (Raspberry Pi compatible) based applications.

Package Checklist

Before commencing installation ensure your package has the following components:

Device

2PIN Terminal

Block

6PIN Terminal

Block

8PIN Terminal

Block

DIN Rail Kit

RCMS Card

Quick Start Guide

Card

Cellular Antenna

(Optional)

Power Supply

(Optional)

WiFi Antenna

(Optional)

Panel Layout(May vary on different models)

Top Panel View Front Panel View Bottom Panel View

Robustel EG5100 Hardware Manual

RT066_HM_EG5100 6/8

Interface Descriptions

1. Serial Ports. Two software configurable serial

ports, could be configured as RS232 or RS485.

Name

RS232 Mode

RS485 Mode

TXD1/A1

data sending

RS485_A

RXD1/B1

data receiving

RS485_B

GND1

Ground

TXD2/A2

data sending

RS485_A

RXD2/B2

data receiving

RS485_B

GND2

Ground

2. Ethernet Ports. Two Ethernet ports, both of them

could be configured as WAN or LAN.

LED

Description

RUN

On, solid

Connected

On, blinking

Transmitting data

Off

Disconnected or connect failure

Rate

Off

10 Mbps mode

100 Mbps mode

3. Reset Button.

Press and Release

RUN LED

Action

Hold less than 3

seconds

On then blink

regularly

Reset

Hold more than 3

seconds but less

than 10 seconds

Blink regularly

blink rapidly

Restore to

factory setting

and reboot

Hold more than

10 seconds

Solid on for 5

seconds then

blink regularly

Do nothing

4. Digital Input and Output Ports. Two sets of digital

inputs and two sets of digital outputs. Some

applications for reference are as below:

Note:The external power supply DC voltage range is 5V~30V, 0.1A max.

5. LED Indicators.

LED

Description

RUN

On, solid

Gateway system is initializing

On, blinking

Gateway starts operating

Off

Gateway is powered off

Note: The RUN LED’s color is green

MDM

Color

2G: Red,3G: Yellow,4G: Green

On, blinking

Link connection is working

Off

Link connection is not working

Green

Strong signal

Yellow

Medium signal

Red

Weak or no signal

Note: The USR LED is defined by user via web UI to

specify different status, the details see the following

sheet.

USR

Description

None

Off

No definition

Net

On, solid

Connection to 4G network is

established

On, blinking

Connection to 2G or 3G

network is established

Off

No connection

SIM

On, solid

Main card is being used

On, blinking

Backup card is being used

IPsec

On, solid

IPsec connection is established

Off

IPsec connection is not

established

Open

VPN

On, solid

OpenVPN connection is

established

Off

OpenVPN connection is not

established

Note: The USR LED’s color is green.

Robustel EG5100 Hardware Manual

RT066_HM_EG5100 7/8

Hardware Installation

1. SIM Card Installation. Remove the SIM card cover

to insert the SIM cards into the device, then screw

up the cover.

2. Antenna Installation. Rotate the antenna into the

antenna connector accordingly.

3. Terminal Block Installation. Insert the 6PIN and

8PIN terminal blocks into the interfaces

connector, then can connect the devices or

sensors to the gateway with wires via

corresponding interfaces e.g. RS232/RS485,

DIDO...

4. Power Supply installation. Insert the power

supply cord into the corresponding terminal block

if needed, then insert the terminal block into the

power connector.

5. DIN Rail Mounting. Use 2 M3 screws to fix the DIN

rail to the device, then hang the DIN rail on the

mounting bracket.

6. Grounding the Device. Grounding will help to

prevent the noise effect due to electromagnetic

interference (EMI). Connect the device to the site

ground wire by the grounding screw before

powering on.

Robustel EG5100 Hardware Manual

RT066_HM_EG5100 8/8

1. Connect the gateway’s Ethernet port to a PC with

a standard Ethernet cable.

2. Before logging in, manually configure the PC with

a static IP address on the same subnet as the

gateway address, click and configure "Use the

following IP address".

3. To enter the gateway's web interface, type

http://192.168.0.1 into the URL field of your

Internet browser.

4. Use login information shown in the product label

when prompted for authentication.

5. After logging in, the home page of the web

interface is displayed, then you can view system

information and perform configuration on the

device.

6. The automatic APN selection is ON by default, if

need to specify your own APN, please go to the

menu Interface->Cellular->Advanced Cellular

Setting->General Settings to finish the specific

setting.

7. For more configuration details please refer to

RT104_SM_RobustOS Pro Software Manual.

(END)
