Rocket Fish RF-UPCUWR Bedienungsanleitung
Universal CPU Cooler
RF-UPCUWR User Guide
2
Universal CPU Cooler
Contents
Important safety instructions ..................................3
Features............................................................................4
Package contents.................................................7
Installing the cooler.....................................................8
Installing on an LGA 775/1156 platform .....8
Installing on an AMD platform.....................11
Specifications.............................................................. 15
One-year limited warranty ..................................... 17
3
RF-UPCUWR
Important safety
instructions
1Read these instructions.
2Keep these instructions.
3Heed all warnings.
4Follow all instructions.
5Do not use this apparatus near water.
6Do not block any ventilation openings.
Install in accordance with the
manufacturer's instructions.
7Only use attachments/accessories
specified by the manufacturer.
8The cooler is designed for computer
usage only. Using the cooler in any other
application will void the warranty.
9If you are not familiar with computer
hardware installation, see a qualified
computer technician.
4
Features
Compatible with Intel Socket LGA
775/1156
5
RF-UPCUWR
Compatible with AMD Socket
754/939/940/AM2/AM
6
• Silent CPU cooler at only 18 dBA(at
800 rpm)
• Maximum compatible CPU wattage:
over 130 W TDP
• Three direct-contact heat-pipes with
aluminum fins to provide excellent heat
dissipation
• Option for adding second fan to
increase cooling performance
• 92 mm PWM fan with distinguished
blade shape and anti-vibration rubber
pads
• Easily swappable fan using clips
•Flexiblemountings
7
RF-UPCUWR
Package contents
Item Description Quantity
ACooler 1
BScrews (a) 4
CScrews (b) 8
DK8/AM2 retention plate (A) 1
EK8/AM2 retention plate (B) 1
F775/1156 retention plate (1) 2
G775/1156 retention plate (2) 1
HThermal grease 1
ABC
D
EF
GH
9
RF-UPCUWR
3Remove the protective cover from the
bottom of the cooler, then apply a small
dab (about 1/2 the size of a pea) of
thermal grease on the surface of the
installed CPU. When the cooler is
clamped to the processor, the grease will
spread evenly to form a thin layer.
4Place the cooler on the CPU, then press
the push pins into place two at a time.
10
5Connect the fan power cable. The
following graphic is for reference only.
Refer to the documentation for your
system board for the location of the
power connector.
