4-outlet Flat-screen Surge

Protector with Noise Filtering

RF-HTS125

QUICK SETUP GUIDE

Congratulations on your purchase of this Rocketsh Surge Protector

with noise ltering.

Your surge protector:

• Provides surge protection for sensitive electronic devices

• Incorporates noise ltering to provide“clean”power that will

maximize the performance of your equipment

Features

• Side-entry AC outlets for a total ush-mount installation.

• Compact design—Fits conveniently behind a wall-mounted

at-panel TV.

• 43 dB EMI/RFI noise ltering—Makes sure that that your

devices receive only“clean”power for maximum product

performance.

• 1,800 joules surge protection—Protects your devices from

damaging power surges and spikes.

• Grounded LED indicator—Lights when a properly grounded AC

outlet is detected. If this LED does not light, contact a licensed

electrician to inspect your wiring.

• Protected LED indicator—Lights when the surge protection

feature is working properly. If this LED does not light or goes out,

the surge protection feature has reached full capacity and can no

longer absorb additional surges and spikes. The surge protector

should be replaced if this light goes out.

Operating instructions

1Plug the surge protector into the lower outlet of a standard 120V

AC outlet, with the plastic knob in the ground plug of the upper

outlet.

2Plug the power cords from up to four devices into the side-entry

AC outlets on the surge protector.

Grounded LED

indicator

Protected LED

indicator

Side-entry

AC outlets

Side-entry

AC outlets

ENGLISH 11-1195

Specications

• Dimensions (L×W×H): 4.97" × 3.55" × 2.20" (including Plug pin)

(126.2 × 90.1 × 55.8 mm)

Electrical specications:

• Load rating: 15 amps

• Line voltage: 125V AC @ 60 Hz

• Surge protection: 3 lines (L-N / L-G / N-G)

• Maximum surge current: 90,000 amps

• Maximum energy dissipation: 1,800 joules

• Clamping voltage: L-N / L-G / N-G = 400 volts

• EMI/RFI noise ltering: Up to 43 dB

• UL-1449 certied

* Standby power consumption: 0.16 watts

Mechanical specications:

• AC outlets: 4

• LED indicators: Grounded, Protected

Other specications:

• Connected equipment limited warranty: $100,000 max

Safety precautions

• RISK OF ELECTRIC SHOCK - Use only in dry locations and only

indoors.

• DO NOT plug into another relocatable power tap.

• DO NOT“daisy chain”surge protectors.

• DO NOT use with any aquarium equipment.

• DO NOT use if correctly grounded outlets are not available.

• DO NOT install this device if there is not at least 30 feet

(10 meters) or more of wire between the electrical outlet and

electrical service panel.

• This device features internal protection that will disconnect the

surge protective component at the end of its useful life, but will

maintain power to the load – WHICH WILL BE UNPROTECTED. If

you don't want your equipment at risk, follow the manufacturer’s

instructions for replacing the device.

Connected equipment limited lifetime warranty: up to

$100,000 equipment coverage

One-year limited product warranty

See included warranty sheet, visit www.rocketshproducts.com or

call 800-620-2790 for additional connected equipment and

product warranty information or for customer service.

Distributed by Best Buy Purchasing, LLC

7601 Penn Avenue South, Richﬁeld, MN USA 55423-3645

ROCKETFISH is a trademark of BBY Solutions,Inc.All other products and

brand names are trademarks of their respective owners.
