Rohde & Schwarz RTP Bedienungsanleitung

R&S®RTP

High-Performance

Oscilloscope

Getting Started

1337994602

Version 07

(=Uñ^2)

This manual describes the following R&S®RTP models with firmware version 5.10

and higher:

●R&S®RTP044 (1320.5007K04)

●R&S®RTP064 (1320.5007K06)

●R&S®RTP084 (1320.5007K08)

●R&S®RTP134 (1320.5007K13)

●R&S®RTP164 (1320.5007K16)

Mühldorfstr. 15, 81671 München, Germany

Phone: +49 89 41 29 - 0

Email: [email protected]

Internet: www.rohde-schwarz.com

Subject to change – data without tolerance limits is not binding.

R&S® is a registered trademark of Rohde & Schwarz GmbH & Co. KG.

Trade names are trademarks of the owners.

1337.9946.02 | Version 07 | R&S®RTP

Throughout this manual, products from Rohde & Schwarz are indicated without the ® symbol, e.g.

R&S®RTP is indicated as R&S RTP.

Contents

R&S®RTP

3Getting Started 1337.9946.02 ─ 07

Contents

1 Safety and regulatory information....................................... 5

1.1 Safety instructions................................................................................5

1.2 Labels on the product.........................................................................11

1.3 Warning messages in the documentation........................................ 12

1.4 Korea certification class A.................................................................12

2 Key Features........................................................................ 13

3 Documentation overview.................................................... 14

3.1 Manuals and instrument help............................................................ 14

3.2 Data sheet and brochure....................................................................15

3.3 Release notes, open source acknowledgment................................ 16

3.4 Application notes, application cards, videos...................................16

4 Preparing for use................................................................. 17

4.1 Lifting and carrying............................................................................ 17

4.2 Unpacking and checking....................................................................17

4.3 Choosing the operating site.............................................................. 17

4.4 Setting up the product........................................................................18

4.5 Considerations for test setup............................................................ 20

4.6 Connecting to power.......................................................................... 21

4.7 Switching on or off............................................................................. 22

4.8 Connecting external devices............................................................. 23

5 Instrument tour.................................................................... 26

5.1 Front panel.......................................................................................... 26

5.2 Rear panel............................................................................................29

5.3 Keys and controls...............................................................................32

Contents

R&S®RTP

4Getting Started 1337.9946.02 ─ 07

6 Operating the instrument....................................................44

6.1 Means of manual interaction............................................................. 44

6.2 Touchscreen display...........................................................................45

6.3 App cockpit......................................................................................... 52

6.4 Working with waveforms....................................................................53

6.5 Rohde & Schwarz smartgrid.............................................................. 56

6.6 Toolbar................................................................................................. 57

6.7 Displaying results............................................................................... 66

6.8 Using dialog boxes............................................................................. 68

6.9 Entering data....................................................................................... 69

6.10 Instrument information and notifications.........................................72

6.11 Getting information and help.............................................................73

7 Setting up the instrument................................................... 77

7.1 Performing a self-alignment.............................................................. 77

7.2 Setting the display language............................................................. 78

8 Contacting customer support............................................ 79

Index..................................................................................... 80

Safety and regulatory information

R&S®RTP

5Getting Started 1337.9946.02 ─ 07

1 Safety and regulatory information

The product documentation helps you to use the product safely and efficiently.

Follow the instructions provided here and in the Chapter 1.1, "Safety instructions",

on page 5.

Intended use

The R&S RTP oscilloscope is designed for measurements on circuits that are

only indirectly connected to the mains or not connected at all. It is not rated for

any measurement category.

The product is intended for the development, production and verification of elec-

tronic components and devices in industrial, administrative, and laboratory envi-

ronments. Use the product only for its designated purpose. Observe the operating

conditions and performance limits stated in the data sheet.

Where do I find safety information?

Safety information is part of the product documentation. It warns you of potential

dangers and gives instructions on how to prevent personal injury or damage

caused by dangerous situations. Safety information is provided as follows:

●In Chapter 1.1, "Safety instructions", on page 5. The same information is

provided in many languages as printed "Safety Instructions". The printed

"Safety Instructions" are delivered with the product.

●Throughout the documentation, safety instructions are provided when you

need to take care during setup or operation.

1.1 Safety instructions

Products from the Rohde & Schwarz group of companies are manufactured

according to the highest technical standards. To use the products safely, follow

the instructions provided here and in the product documentation. Keep the prod-

uct documentation nearby and offer it to other users.

Use the product only for its intended use and within its performance limits. Inten-

ded use and limits are described in the product documentation such as the data

sheet, manuals and the printed "Safety Instructions". If you are unsure about the

appropriate use, contact Rohde & Schwarz customer service.

Safety instructions

Safety and regulatory information

R&S®RTP

6Getting Started 1337.9946.02 ─ 07

Using the product requires specialists or specially trained personnel. These users

also need sound knowledge of at least one of the languages in which the user

interfaces and the product documentation are available.

Never open the casing of the product. Only service personnel authorized by

Rohde & Schwarz are allowed to repair the product. If any part of the product is

damaged or broken, stop using the product. Contact Rohde & Schwarz customer

service at http://www.customersupport.rohde-schwarz.com.

In these safety instructions, the term "product" covers instruments (oscillo-

scopes), probes and their accessories.

Lifting and carrying the instrument

Check the data sheet for the maximum weight of the instrument. A single person

can only carry a maximum of 18 kg safely depending on age, gender and physical

condition. If your instrument is heavier than 18 kg, do not move or carry it by your-

self.

Use the instrument handles to move or carry the instrument. Do not use the

mounted accessories instead of the handles. Accessories are not designed to

carry the weight of the instrument.

To move the instrument safely, you can use lifting or transporting equipment such

as lift trucks and forklifts. Follow the instructions provided by the equipment man-

ufacturer.

Choosing the operating site

Only use the product indoors. The product casing is not waterproof. Water that

enters can electrically connect the casing with live parts, which can lead to elec-

tric shock, serious personal injury or death if you touch the casing. If

Rohde & Schwarz provides accessories designed for your product, e.g. a carrying

bag, you can use the product outdoors.

You can operate the product up to the altitude specified in the data sheet. The

lowest specified altitude for a product of the measurement setup defines the alti-

tude for the complete setup.

The product is suitable for pollution degree 2 environments where nonconductive

contamination can occur. For more information on environmental conditions such

as ambient temperature and humidity, see the data sheet.

Safety instructions

Safety and regulatory information

R&S®RTP

7Getting Started 1337.9946.02 ─ 07

Setting up the product

Always place the product on a stable, flat and level surface with the bottom of the

product facing down. If the product is designed for different positions, secure the

product so that it cannot fall over.

If the product has foldable feet, always fold the feet completely in or out to ensure

stability. The feet can collapse if they are not folded out completely or if the prod-

uct is moved without lifting it. The foldable feet are designed to carry the weight of

the product, but not an extra load.

If stacking is possible, keep in mind that a stack of products can fall over and

cause injury.

If you mount products in a rack, ensure that the rack has sufficient load capacity

and stability. Observe the specifications of the rack manufacturer. Always install

the products from the bottom shelf to the top shelf so that the rack stands

securely. Secure the product so that it cannot fall off the rack.

Connecting to power and grounding

The mains power supply input of the instrument complies with overvoltage cate-

gory II. It has to be connected to a fixed installation used to supply energy-con-

suming equipment such as household appliances and similar loads. Be aware

that electrically powered products have risks, such as electric shock, fire, per-

sonal injury or even death.

Take the following measures for your safety:

●Do not use an isolating transformer to connect the instrument to the mains

power supply.

●Before switching on the product, ensure that the voltage and frequency indica-

ted on the product match the available power source. If the power adapter

does not adjust automatically, set the correct value and check the rating of the

fuse.

●Only use the power cable delivered with the product. It complies with country-

specific safety requirements. Only insert the plug into an outlet with protective

conductor terminal.

●If a product has an exchangeable fuse, its type and characteristics are indica-

ted next to the fuse holder. Before changing the fuse, switch off the instrument

and disconnect it from the power source. How to change the fuse is described

in the product documentation.

Safety instructions

Safety and regulatory information

R&S®RTP

8Getting Started 1337.9946.02 ─ 07

●Only use intact cables and route them carefully so that they cannot be dam-

aged. Check the power cables regularly to ensure that they are undamaged.

Also ensure that nobody can trip over loose cables.

●If the product needs an external power supply, use the power supply that is

delivered with the product or that is recommended in the product documenta-

tion or a power supply that conforms to the country-specific regulations.

●Ensure that you can disconnect the product from the power source at any

time. Pull the power plug to disconnect the product. The power plug must be

easily accessible. If the product is integrated into a system that does not meet

these requirements, provide an easily accessible circuit breaker at the system

level.

Performing measurements

Take the following measures for your safety:

●To ascertain voltage-free state, use an appropriate voltage tester. Any mea-

surement setup including an oscilloscope is not suitable for this purpose.

●The maximum input voltage on channel inputs and the external trigger input

must not exceed the value specified in the data sheet.

●Observe all voltage and current ratings of the instrument, the probes, and the

accessories. Limits and ratings are marked on the products and listed in the

data sheets.

Consider that the rated voltage depends on the frequency. The voltage limita-

tion curves or values are provided in the data sheet. Do not exceed the maxi-

mum measurement voltage from the probe tip to the probe reference lead.

●Never cause any short circuits when measuring sources with high output cur-

rents.

●Use only probes and accessories that comply with the measurement category

(CAT) of your measurement task. The measurement category of the products

is defined in the data sheet. If you use other than Rohde & Schwarz accesso-

ries, make sure that they are suitable for the instrument and the measurement

task.

●Set the correct attenuation factor on the instrument according to the probe

being used. Otherwise, the measurement results do not reflect the actual volt-

age level, and you might misjudge the actual risk.

●When working with high voltages and current probes, observe the additional

operating conditions specified in this safety instructions.

●The probe pins are extremely pointed and can easily penetrate clothes and

the skin. Handle the probe pins with great care. To exchange a probe pin, use

Safety instructions

Safety and regulatory information

R&S®RTP

9Getting Started 1337.9946.02 ─ 07

tweezers or pliers to avoid injuries. When transporting the accessories, always

use the box supplied with the probe.

●Prevent the probe from receiving mechanical shock. Avoid putting excessive

strain on the probe cable or exposing it to sharp bends. Touching a broken

cable during measurements can cause injuries.

●Set up all probe connections to the instrument before applying power.

Working with hazardous voltages

Voltages higher than 30 V RMS, or 42 V peak, or 60 V DC are regarded as haz-

ardous contact voltages. Direct contact with them can cause serious injuries.

Make sure that only electrically skilled persons use the products for measure-

ments on hazardous contact voltages. These working conditions require special

education and experience to perceive risks and to avoid hazards which electricity

can create.

When working with hazardous contact voltages, use protective measures to pre-

clude direct contact with the measurement setup:

●Do not touch exposed connections and components when power is applied.

●Switch off the test circuit while connecting and disconnecting probe leads.

●Use only insulated voltage probes, test leads and adapters.

●Make sure that the input leads fulfill the safety requirements for your measure-

ment.

The delivered input leads might have a jacket wear indicator that indicates a

worn jacket by different jacket color. In this case, do not use the input lead.

Replace it with a new one.

●Do not use 4 mm banana plugs without protection against contact.

Working with current probes

When working with current probes, you can measure high-frequency currents or

currents that contain high-frequency components.

●Switch off the test circuit while connecting the probe.

●Do not attach the clamp to bare unisolated conductors. To avoid injury from a

short circuit, measure at a location on an insulated wire where the insulation is

sufficient for the circuit voltage.

●Connect the probe only to the secondary side of a breaker. With this measure,

you avoid injury, if a short circuit occurs.

Safety instructions

Safety and regulatory information

R&S®RTP

10Getting Started 1337.9946.02 ─ 07

●The following effects can cause burns and fire or damage to the measurement

site:

– Eddy current loss can cause heating of the sensor head.

– Dielectric heating can cause heating of cord insulation and other materials.

Measurement categories

IEC 61010-2-030 defines measurement categories that rate instruments on their

ability to resist short transient overvoltages that occur in addition to the working

voltage. Use the measurement setup only in electrical environments for which

they are rated.

●0 - Instruments without rated measurement category

For measurements performed on circuits not directly connected to mains, for

example, electronics, circuits powered by batteries, and specially protected

secondary circuits. This measurement category is also known as CAT I.

●CAT II:

For measurements performed on circuits directly connected to the low-voltage

installation by a standard socket outlet, for example, household appliances

and portable tools.

●CAT III:

For measurements performed in the building installation, such as junction

boxes, circuit breakers, distribution boards, and equipment with permanent

connection to the fixed installation.

●CAT IV:

For measurements performed at the source of the low-voltage installation,

such as electricity meters and primary overcurrent protection devices.

Safety instructions

Inhaltsverzeichnis

Andere Rohde & Schwarz Prüfgeräte Handbücher

Rohde & Schwarz

Rohde & Schwarz RTM3000 Series Bedienungsanleitung

Rohde & Schwarz

Rohde & Schwarz AMU200A Bedienungsanleitung

Rohde & Schwarz

Rohde & Schwarz RTP044B Bedienungsanleitung

Rohde & Schwarz

Rohde & Schwarz RTH1054MSO Bedienungsanleitung

Rohde & Schwarz

Rohde & Schwarz RTM3000 Series Bedienungsanleitung

Rohde & Schwarz

Rohde & Schwarz ESRP Series Bedienungsanleitung

Rohde & Schwarz

Rohde & Schwarz RT-ZF2 Bedienungsanleitung

Rohde & Schwarz

Rohde & Schwarz RTP Series Bedienungsanleitung

Rohde & Schwarz

Rohde & Schwarz R&S RTP-K28 Bedienungsanleitung

Rohde & Schwarz

Rohde & Schwarz Hameg HMO3522 Bedienungsanleitung

Rohde & Schwarz

Rohde & Schwarz R&S RTM3000 Bedienungsanleitung

Rohde & Schwarz

Rohde & Schwarz R&S CMW-KG2 Series Bedienungsanleitung

Rohde & Schwarz

Rohde & Schwarz RTM3K-COM4 Bedienungsanleitung

Rohde & Schwarz

Rohde & Schwarz RTA4000 Bedienungsanleitung

Rohde & Schwarz

Rohde & Schwarz CMW 500 Bedienungsanleitung

Rohde & Schwarz

Rohde & Schwarz R&S QAR Bedienungsanleitung

Rohde & Schwarz

Rohde & Schwarz FSH-Z2 Bedienungsanleitung

Rohde & Schwarz

Rohde & Schwarz R&S QAR50 Bedienungsanleitung

Rohde & Schwarz

Rohde & Schwarz RTM3K-COM2 Bedienungsanleitung

Rohde & Schwarz

Rohde & Schwarz CTS50 Bedienungsanleitung

Rohde & Schwarz

Rohde & Schwarz R&S ZV-Z51 Handbuch

Rohde & Schwarz

Rohde & Schwarz R&S TS-PIO4 Bedienungsanleitung

Rohde & Schwarz

Rohde & Schwarz CMU 200 Bedienungsanleitung

Rohde & Schwarz

Rohde & Schwarz R&S ATS1000 Handbuch

Beliebte Prüfgeräte Handbücher anderer Marken

SMART

SMART KANAAD SBT XTREME 3G Series Bedienungsanleitung

Agilent Technologies

Agilent Technologies BERT Serial Bedienungsanleitung

Agilent Technologies

Agilent Technologies N3280A Bedienungsanleitung

Vernier

Vernier Go Direct Voltage Bedienungsanleitung

Lifeloc

Lifeloc R.A.D.A.R. Bedienungsanleitung

Fluke

Fluke T5-600 Bedienungs- und Montageanleitung

Mercury

Mercury TSL01 Bedienungsanleitung

MAHA

MAHA MBT Series Bedienungsanleitung

Fuji Electric

Fuji Electric P-61 Bedienungsanleitung

ETC

ETC SealerAtor Bedienungsanleitung

Skyfine

Skyfine ETHYWAY V2 Bedienungsanleitung

Appion

Appion G5 Twin Bedienungsanleitung

PCB Piezotronics

PCB Piezotronics 8159-0112A Bedienungsanleitung

BW Technologies

BW Technologies MicroDock II Bedienungsanleitung

Sun Nuclear

Sun Nuclear 1027 Bedienungsanleitung

Biomark

Biomark HPR LITE READER Bedienungsanleitung

Hioki

Hioki 3169-20 Bedienungsanleitung

Ashcroft

Ashcroft ATE-100 Bedienungsanleitung
