R-892
Portable Air Conditioner
User’s Manual
Thanks for choosing this high quality portable air conditioner. Please read
the Manual carefully before operation. In case of any problem, please
contact professional maintenance personnel in time.
1
MATTERS NEEDING ATTENTION
This machine is for household use only.
This machine is for indoor use only
Please place it in a dry environment.
In case of a blocked air exchange,
do not stack any items around the
machine.
To avoid damages, never place any
heavy items on the machine.
USER KNOWLEDGE
The meanings of this icons used in the manual are as follows:
Please avoid such operations, in case of any safety and health risks.
Please follow the operations, for the safety and health concerns.
2
The filter is to be cleaned regularly for
once every two weeks.
For your health, never drink condensed
water discharged from the machine.
Please unplug the power cord, if the
machine will not be in use for a long
time.
Non-professionals are not allowed to dismantle or
repair the machine. In case of any risks, damaged
power cord shall be replaced by such personnels
as technicians from Maintenance Dept of
manufacturer.
Please wipe the machine with a soft
cloth, instead of wax, diluent or irritant
detergent.
Do not operate the machine with wet hands
or in a humid environment.
3
IMPORTANT SAFETY TIPS
Damaged power cord or plug shall not
be used. Never plug the machine into a
loose socket.
Never damage the power cord, or use
unlisncenced power cord. Please ensure
that voltage is right.
Do not modify or extend the power cord.
A grounded outlet is suggested for the
machine.
In case of electric shock, never plug or
unplug with a wet hand.
Unplug the machine by pulling the plug
instead of power cord.
4
Please turn off the machine before
upluging.
Never turn on/off the machine by the
pluging/unplugging of power cord.
Should any strong noise, smell or smoke
happen, turn off and unplug the machine
for diagnosis.
In case of electric shock from a damaged
power cord, never place any heavy
objects on the power cord.
Never overload the socket by running the
machine with too many high-power electrical
appliances..
Avoid heat source or direct exposure
tosunlight.
5
Keep electrical parts away from water.
Never insert finger or any hard object into
the louver.
If water enters, turn off and unplug the
machine in time, and ask for checkand
repair from a professional serviceman.
Please turn off and unplug machine before
wiping, cleaning or replacing components.
If gas leakage should happen, open the
window for ventilation before running the
machine.
Children under eight years old are not allowed
to use the machine. With a proper awareness
of its usage and dangers, people with limited
physical, sensor or psychological abilities
should use the machine under supervision.
6
SPECIAL WARNING
For a proper work of compressor, place
the machine vertically on a level ground.
For a proper ventilation, keep the machine
at least 50cm from surrounding objects.
Keep away the machine from gasoline or
other flammable liquid.
Avoid spraying agent or any solvent and
flammable substances; otherwise, plastic
parts may deform and electric parts may be
damaged.
5
PRODUCT INTRODUCTION
Handle
MAIN PARTS AND COMPONENTS
3
3
4
1
Air Inlet (bottom) 6
2
Control Panel
Air Outlet Louver
4 5
Castor 10
5
6 RemoteControll 7
Air Inlet (upper)
Hot Air Outlet 10
8
Drainage Nozzle 9
Air Inlet Grille(single)
Double Duct Frame (double)
Exhaust Duct Assembly
Window Sealing Plate Assembly
12 12
7
1
2
3
4
7
8
9
10
11
11
12
12
8
Power key
Press the key to turn ON/OFF the A/C.
Speed key
Press the key to choose high/middle/low speed.
Temperature/ time adjusting key
Press the key at cooling mode to increase/reduce the
setting temperature; press it at timing mode to adjust
timing ON/OFF time; press Up and Down keys
simultaneously to switch between Fahrenheit and
Centigrade degree.
Mode key
Press the key to choose cooling, fan,dry
(Single cooling unit without heating)
Timer key
Press the key at standby mode to set ON time. Press this
key at ON mode to set OFF time.
Temperature/ Time display window
This window displays the adjusted temperature and time.
Swing Button
Press the key for Swing Function.
Temperature Switch Button
The button is to switch between ℃ and ℉
7
Single cooling remote control
7
Heating and cooling remote control
CONTROL PANEL AND REMOTE CONTROLLER
8
Single cooling panel
1
2
3
4
5
6
8
8
8
9
PRODUCT OPERATION
Placement
Place the machine on the horizontal floor
near the window.
For proper ventilation and best machine
performance, the machine should be kept at
least 50cm from surrondings.
Installation
Exhaust duct assembly
Exhaust joint Exhaust pipe Window adapter
Window sealing plate assembly
Single duct Double duct
Window sealing
plate1
Windowsealing
plate2
Button
Screw
Window sealing
plate1
Window sealing
plate2
Window sealing
plate3
PLANCEMENT AND INSTALLATION
50cm
90cm
