Roland VT-4 Bedienungsanleitung

Owner’s Manual

Before using this unit, carefully read the leaet “USING THE UNIT SAFELY” and “IMPORTANT NOTES.” After reading, keep the document(s) where it will

be available for immediate reference.

[VOLUME] knob

Adjusts the volume of the LINE OUT jacks

and the PHONES jack.

[MIC SENS] knob

Adjusts the input sensitivity of the mic

connected to the MIC IN jacks (front/rear).

[ROBOT] button

Transforms your voice into that of a robot,

with a xed pitch and an expressionless

character.

[MEGAPHONE] button

Gives your voice a distorted character as if

you were speaking through a megaphone.

PEAK indicator

Lights if the mic input level is excessive.

Use the [MIC SENS] knob to adjust the

sensitivity so that this indicator lights

occasionally.

[MANUAL] button

Applies the current settings of the sliders

and the [AUTO PITCH] knob to the sound.

[BYPASS] button

Disables the eects (including reverb).

[KEY] knob

Species the key used when applying the

eect of the [ROBOT] button or the [AUTO

PITCH] knob (p. 5).

Panel Descriptions

[LINE OUT] switch

Switches the audio that is output from the LINE OUT jacks.

STEREO Stereo audio will be output.

MONO The processed sound (L/MONO) and the unprocessed sound (R/BYPASS) will be

output separately.

[PHANTOM] switch

Turn this “ON”if you want phantom power

to be supplied to the MIC IN jack (rear).

* Phantom power is not supplied to the

TRS phone plug.

[AUTO PITCH] knob

Corrects the pitch.

This lets you constrain your vocal to the

key specied by the [KEY] knob, creating

a warbling pitch change that is typical of

dance music.

The amount of correction increases as you

turn the knob toward the right.

If this is “OFF,” correction is not applied.

[HARMONY] button

Adds harmony to your voice.

[VOCODER] button

Transforms the sound into a vocoder voice.

[PITCH] slider

Adjusts the pitch of the voice.

You can adjust this in a range of 1 octave

up or down.

[FORMANT] slider

Adjusts the formant.

Negative (“-”) settings produce a masculine

character; positive (“+”) produce a

feminine character.

[BALANCE] slider

Adjusts the balance between the

unprocessed voice (NORMAL) and the

eect-processed voice (EFFECT).

[REVERB] slider

Adjusts the amount of reverberation.

Scene memory [1]–[4] buttons

Recall eect settings (scenes).

The button of the“recalled” scene memory is lit.

You can store up to eight scenes.

&“Recalling Eect Settings (Scene Memories)”

(p. 6)

Rear panel

Front panel

[POWER] switch

Turning the Power On/O

After you’ve made connections correctly,

turn on the power in the order of this

unit0connected devices.

When turning the power o, do so in the

order of the connected devices0this unit.

MEMO

This unit can operate on USB bus power

or on batteries.

If you want to use it on batteries, install

batteries beforehand (p. 11).

Connecting Your Equipment

LINE OUT jacks

Connect these jacks to your amp or

monitor speakers.

MIC IN jack (rear)

Connect a mic (sold separately) here.

If a condenser mic is connected to the

XLR connector, phantom power can be

supplied (p. 2).

* Pin assignment of MIC IN jack (rear)

1: GND2: HOT

3: COLD

TIP: HOT

RING: COLD

SLEEVE: GND

MIDI IN connector

Connect a MIDI device.

You can use incoming MIDI note messages to

play the robot voice, etc. (p. 5).

USB (O) port

If this port is connected to your computer via a

commercially available USB 2.0 cable, you can

use the VT-4 as a USB audio interface.

* If USB bus power is supplied, the unit

operates on USB bus power.

* To prevent malfunction and equipment failure, always turn down the volume, and turn o all the units before making any connections.

* Before turning the unit on/o, always be sure to turn the volume down. Even with the volume turned down, you might hear some sound when

switching the unit on/o. However, this is normal and does not indicate a malfunction.

PHONES jack

Connect headphones (sold separately)

here.

MIC IN jack (front)

Connect a mic that is compatible with

plug-in power (sold separately).

* This is only for use with a mic that is

compatible with plug-in power.

Transforming Your Voice

Applying an Eect

1. Connect your mic to the MIC IN jack (front or rear).

* If you connect a condenser mic to the MIC IN jack (rear) via an XLR

connector, turn the [PHANTOM] switch on.

2. Turn the [BYPASS] button on.

3. While vocalizing into the mic, use the [MIC SENS] knob to

adjust the input sensitivity.

Adjust the sensitivity so that the PEAK indicator lights occasionally.

* Adjust the input sensitivity accurately. If the mic input level is too

low or too high, the eect won’t work correctly.

4. Press a scene memory button to recall a scene (p. 6).

5. Turn the [BYPASS] button o.

6. Set the [BALANCE] slider to the EFFECT position.

7. Vocalize into the mic.

Your voice processed by the eect is output.

* When inputting voice into the mic, input the voice of only one

person. If multiple voices are input, the eect won’t work correctly.

* Take care that sound from the speaker does not enter the mic.

MEMO

If feedback occurs, set the noise gate (p. 7).

Editing the Eect

1. Press the [MANUAL] button.

You can press a scene memory button to recall a saved eect, and

then edit those eect settings (p. 6).

2. Use the controllers (buttons, knobs, sliders) to edit the

eect settings.

Controller Explanation

[ROBOT]*1 Produces an expressionless voice with a xed

pitch, evocative of a robot.

[MEGAPHONE]*1 Produces a distorted voice, as though you

were using a megaphone.

[VOCODER]*1 Produces a vocoder voice.

[HARMONY]*1 Lets you add harmony to the sound.

[AUTO PITCH] Pitch-corrects your voice.

[KEY]

Species the key that is used when applying

an eect with the [ROBOT] button or the

[AUTO PITCH] knob (p. 5).

[PITCH] Adjusts the pitch of the voice.

[FORMANT] Adjusts the formants of the sound.

[BALANCE]

Adjusts the balance between the normal

voice (NORMAL) and the eect-processed

voice (EFFECT).

[REVERB]*1 Adjusts the amount of reverb (reverberation).

*1 To select an eect variation, hold down an eect button and press a

scene memory button.

&“Eect Variation List” (p. 11)

3. As necessary, save the eect settings in a scene memory

button (p. 6).

Transforming Your Voice

Using the [KEY] knob to specify the key

You can specify the key that is

used when applying an eect

with the [ROBOT] button or the

[AUTO PITCH] knob.

MEMO

To specify a minor scale, turn the knob

three clicks to the right from the desired

key indication.

For example, if you want to set the key

to “Am,” turn the knob three clicks to the

right from the “A”position, setting it to

the “C” position.

Inputting Note Messages to the MIDI IN Connector

You can use note messages input via the MIDI IN connector to play the

robot voice. You can also play the vocoder voice, or generate harmony

notes.

1. Connect a MIDI keyboard or other MIDI device to the

MIDI IN connector.

2. While inputting note messages from the MIDI device,

vocalize into the mic.

The VT-4 switches to robot voice (the [ROBOT] button is lit), and the

robot voice is sounded by the incoming note messages. (The robot

voice turns on automatically.)

3. If you want to add harmony, turn the [HARMONY] button

on, and input your voice.

Up to four notes of harmony are heard based on the note messages

that are input.

4. If you want to perform with a vocoder voice, turn the

[VOCODER] button on, and input your voice.

To exit robot voice, press the [ROBOT] button (the [ROBOT] button

goes dark).

* The setting of the [KEY] knob is ignored if note messages are being

input.

DmEm

G#m A#m

C#m

D#m

F#m

Recalling Eect Settings (Scene Memories)

Eect settings (scenes) that you’ve saved in the scene memory buttons

can be recalled instantly.

You can save up to eight scenes.

Scene 1 Scene 4

Scene 5 Scene 8

MEMO

You can back up the scene memories to your computer (p. 9).

Recalling a Scene

1. Press the scene memory [1]–[4] button that you want to

recall.

The scene memory button lights, and the eect settings (the scene)

is recalled.

To recall scenes 5–8, hold down the [MANUAL] button and press a

scene memory [1]–[4] button.

For example, to recall scene 5, hold down the [MANUAL] button and

press the scene memory [1] button (the [MANUAL] button blinks

slowly).

* When you recall a scene, the current positions of the slider/[AUTO

PITCH] knob/[KEY] knob will not match the actual sound.

* When you adjust the eect after recalling a scene, the setting of the

controller is applied to the sound. At this time, the scene memory

button blinks.

Saving a Scene

Here’s how to save the eect settings to a scene memory button.

1. Use the controllers to adjust the eect.

2. Hold down the scene memory [1]–[4] button in which

you want to save the scene.

When the scene has been saved, all the scene memory buttons

change from blinking0unlit.

For example, if you want to save the settings to scene 5, hold down

the [MANUAL] button and hold down the scene memory [1] button.

Copying a Scene

Here’s how to copy a scene to another number.

1. Press a scene memory [1]–[4] button to recall the scene

that you want to copy.

2. Hold down the copy-destination scene memory [1]–[4]

button.

When the scene has been copied, all the scene memory buttons

change from blinking0unlit.

Suppressing Feedback (Noise Gate)

You can make noise gate settings to suppress feedback.

1. Hold down the [MANUAL] button and press the

[VOCODER] button (keep holding down the [MANUAL]

button).

The scene memory [1]–[4] buttons light.

2. Continuing to hold down the [MANUAL] button, press

one of the memory [1]–[4] buttons to set the noise gate.

Higher-numbered scene memory [1]–[4] buttons apply the noise

gate eect more strongly.

Preventing Unintended Sound (Low Cut Filter)

You can make low cut lter settings to prevent the VT-4 from

unintentionally producing sound in response to low-frequency sounds

nearby (such as the kick sound of a drum set).

1. Hold down the [MANUAL] button and press the

[HARMONY] button (keep holding down the [MANUAL]

button).

The scene memory [1]–[4] buttons light.

2. Continuing to hold down the [MANUAL] button, press

one of the scene memory [1]–[4] buttons to set the low

cut lter.

Higher-numbered scene memory [1]–[4] buttons specify a higher

frequency below which the sound is cut.

Clarifying the Sound (Enhancer)

By applying the enhancer eect, you can improve the clarity of the

high-frequency region.

1. Hold down the [MANUAL] button and press the

[MEGAPHONE] button (keep holding down the

[MANUAL] button).

The scene memory [1]–[4] buttons light.

2. Continuing to hold down the [MANUAL] button, press

one of the memory [1]–[4] buttons to set the enhancer.

Higher-numbered scene memory [1]–[4] buttons apply the enhancer

eect more strongly.

Convenient Functions

Using the VT-4 As a USB Audio Interface

By using a commercially available USB 2.0 cable to connect the VT-4 to

your computer, you can use the VT-4 as a USB audio interface.

* You must install the USB driver before connecting the VT-4 to

your computer.

Download the USB driver from the Roland website.

For details, refer to Readme.htm which is included in the download.

http://www.roland.com/support/

Playback

Sound played back by your computer can be output from the VT-4 via

the following routes.

Computer sound

Route Explanation

OUT Output from the LINE OUT jacks and PHONES jack (no

eect is applied).

TO MIC IN Output from the VT-4 as sound that’s input from the

MIC IN jack.

TO CARRIER

The sound of an external synthesizer that’s input to

“TO CARRIER” of the USB port can be used as the signal

(tonality and pitch) that is the basis of the vocoder

voice.

Turn the external carrier setting (p. 9) “On” when

using this.

Recording

The mic sound processed by the VT-4 can be recorded on your

computer.

Mic sound

Sound Explanation

MIX The sound of the LINE OUT jacks is input.

WET The eect-processed sound is input.

DRY The sound before being eect-processed is input.

Making Settings for Other Functions

1. Turn on the power while holding down the [ROBOT]

button.

The [MANUAL] button blinks.

2. Turn the [KEY] knob to select the parameter that you

want to set.

[KEY]

knob Parameter Value Explanation

CMIDI channel Omni (0),

1–16 Ch

Species the MIDI

transmit/receive channel.

DSaver time O (0), 1–20

min

Changes the time until

the screen saver is

applied.

Convenient Functions

[KEY]

knob Parameter Value Explanation

EExternal

carrier O, On

Species whether the

vocoder eect is applied

(on) or is not applied (o)

to the carrier signal being

input via USB.

FFormant

depth 1–4

Species the range

in which the formant

changes.

GMonitor mode O, On

Species whether the

[VOLUME] knob aects

the volume of only the

PHONES jack (on).

If this is on, the volume

of the LINE OUT jacks

is xed.

APlayback level 0–20

Adjusts the volume

balance between the USB

audio input and the mic

input.

3. Edit the setting of the parameter that you selected.

Operation Explanation

On/o setting On Press the [HARMONY] button

O Press the [VOCODER] button

Operation Explanation

Value setting

Increase by 1 Press the [HARMONY] button

Decrease by 1 Press the [VOCODER] button

Checking the volume

The total value of the scene memory [1]–[4]

buttons that are lit indicates the“ones”place.

The [MEGAPHONE] button is lit if the value is

10–19, and the [ROBOT] button is also lit if the

value is 20.

For example, if the value is “18,” scene memory [1],

[3], and [4] buttons and the [MEGAPHONE] button

are lit.

4. When you have nished making settings, press the

[MANUAL] button.

The setting is saved and VT-4 restarts.

Backing Up or Restoring the Scene Memories

You can use your computer to back up scene memories and restore

them from your computer.

Backing up

1. With the VT-4 powered-o, connect the VT-4 to your

computer via a USB cable.

Convenient Functions

2. While holding down the [VOCODER] button, turn the

power on.

The [ROBOT] button and the [BYPASS] button light, and the scene

memory buttons through the [MANUAL] button blink while moving

between left and right.

3. On your computer, open the “VT-4”drive.

4. From inside the BACKUP folder, copy the backup les to

your computer.

Backup les VT4_PATCH1.PRM (scene 1)–VT4_PATCH8.PRM

(scene 8)

5. When copying is nished, perform the appropriate

operation on your computer to disconnect the USB drive.

6. Turn the power o, and on again.

Restoring

1. As described in “Backing up” (p. 9), open the “VT-4”

drive on your computer.

2. Copy the backup les from your computer into the

RESTORE folder.

3. When copying is nished, perform the appropriate

operation on your computer to disconnect the USB drive.

4. Press the [MANUAL] button.

5. When the blinking button goes dark, turn the power o

and then on again.

Using Batteries Even When Connected to USB

If the VT-4 is connected to a USB port that does not support USB bus

power, such as when using the VT-4 and the MX-1 (Mix Performer) with

AIRA LINK, you can use the VT-4 in battery-powered mode.

1. While holding down the [HARMONY] button, turn the

power on.

The VT-4 is in battery-powered mode.

To return to the usual mode, turn the power o and on again.

Restoring the Factory Settings (Factory Reset)

Here’s how to return the VT-4 to its factory-set state.

1. While holding down the [BYPASS] button, turn the

power on.

The [MANUAL] button blinks.

If you decide to cancel factory reset, turn the power o.

2. Press the [MANUAL] button to execute factory reset.

3. When all buttons blink, turn the power o and on again.

Inhaltsverzeichnis

Andere Roland Transformator Handbücher

Roland

Roland VT-1 Bedienungsanleitung

Beliebte Transformator Handbücher anderer Marken

RAM

RAM TUS404 Bedienungsanleitung

Ortofon

Ortofon ST-80 SE Bedienungsanleitung

Siemens

Siemens GEAFOL Neo Bedienungsanleitung

Uhlenbrock Elektronik

Uhlenbrock Elektronik 28000 Bedienungsanleitung

Monacor

Monacor PATL-100/XC Bedienungsanleitung

FONESTAR

FONESTAR CV-1720 Bedienungsanleitung

Delta Electronics

Delta Electronics Current Sense Transformers TCE1906H Bedienungsanleitung

Hobart

Hobart 6T28-600CL Bedienungsanleitung

Shinkawa

Shinkawa LS Series Bedienungsanleitung

Huawei

Huawei JUPITER-3000K-H1 Bedienungsanleitung

Monacor

Monacor IMG STAGELINE LTR-102 Bedienungsanleitung

Lionel

Lionel ZW Bedienungsanleitung

Enapter

Enapter Electrolyser Bedienungsanleitung

MKC

MKC SET-2010 Bedienungsanleitung

ABB

ABB Relion 615 series Bedienungsanleitung

Monacor

Monacor Security TVI-200 Bedienungsanleitung

Arteche

Arteche KA Bedienungsanleitung

Sygonix

Sygonix 2522120 Bedienungsanleitung
