Rompa 19723 Bedienungsanleitung



1. ProductName



LightDiffractionTotembyROMPA®



2. ProductCode



19723



3. Colour



Whitebase;largelyblacktube



4. BriefDescription



Awaterfreealternativetobubbletubes.Lightshinesthroughtheslitsinthetubetocreatea

stunningopticaleffect.



5. Contents



LightDiffractionTotem

Powersupply





6. Snoezelen®Stimulations



•Sight

•Vibration



7. BestUse



Forbestresults,useinadarkenedroom.YoumaywishtouseacollartosecureyourTotemto

thewall.Thecollar14694isappropriateforthesetubes.



8. CompatibleROMPA®Products



19847ROMPA®8ColourWirefreeController

19939Wi‐FiInteractiveCarpetSwitchSet

20563Wi‐FiMicrophone

18870TalkingCube

20402MiniTalkingCube

19214ColourChangingPanel

14694Collar



CushionedPlatforme.g.14896…Pleaseseewww.rompa.comforourextensiverangeofcushioned

platforms



AcrylicMirrorPanelse.g.14892…Pleaseseewww.rompa.comforourextensiverangeofmirrors



9. StartingUp



•Placeonaflat,stablefloorthatiscapableofholdingtheweightofthisproduct.

•Connectthemulti‐colouredwiresfromthebottomofthetubetothecircuitboard.

•Attachthetubetothechassisusingthefourboltsprovided(oneineachcorner).

•PlugthePowerSupplyintotheTotemusingthecircularplugsupplied

•Ifusingacushionedplatform,fitthecushionedplatformovertheLightDiffractionTotem,

 makingsurethePowerSupplyisnottrapped.

•PlugtheotherendofthePowerSupplyinatthewall.

•Switchonatthewall.ThegreenLEDlightwillbelit.Theremaybeaslightdelay

•Turnthewheelonthebasetoadjustthespeedofthelightchange.



10. DetailedDescription



Perfectforcustomerswholovebubbletubesbutprefertheconvenienceofthiswater‐free

alternative!Noneedtofillwithwaterandthereforemaintenance‐free!Highlyeffectivevisualand

vibratoryfeature.Lightshinesthroughtheslitsinsidethetube,creatingastunningopticaleffect.

Especiallystrikinginadarkenedroom.WiFicompatible.



USINGTHESUPERINTERACTIVESWITCHBOX17274

(tobepurchasedseparately)



SwitchofftheLightDiffractionTotemcompletely.FirstremovetheDust

ProtectionCover(seeright),makingsurethatthisiskeptinasafeplace

soasnottoloseit.Toremoveit,slideyourfingernailundertheright

handsideofthecoverandgentlypullthisout.Connectyour5Button

SwitchBoxtothebaseoftheLightDiffractionTotem.



•Toselectacolouredlightpressoneofthefourbuttons(red,green,yellow,blue)onthetop.

•ThecentralorangebuttonhasnofunctionastheTotemhasnobubbles.

•Toadjustthespeedofthelightchange/flashrateusetheSPEEDandDELAYbuttons

underneathlabelledCOLOURS.



YOUCANADDANEXTERNALSWITCH(JACK)–WhenaROMPA®switchispluggedintotheJack

SocketonthesideofPushButtonSwitchBox,mostothercontrolswillbeover‐ridden,i.e.Push

Buttons,Coloursetc.



ThereareseveralpossibleoptionswhenaROMPA®switchisused.Usethedialsontheunderside

oftheSuperInteractiveSwitchBox:

1. WiththelefthanddialsettoCOLOURSandtherighthandonetoFLASHON,thenthelights

willcomeonwhentheROMPA®switchisactivated.

2. WiththelefthanddialsettoCOLOURSandtherighthandonetoFLASHOFF,thenthe

lightswillbeonallofthetimeandthelightswillstopwhentheROMPA®switchisactivated.

3. WiththelefthanddialsettoCOLOURSandtherighthandonetoHOLD,thenthelightswill

startwhentheROMPA®switchisactivatedandwillstopwhentheROMPA®switchis

activatedagain.



AllWiFicontrollerssuitableforusewithaROMPA®WiFiBubbleTube(e.g.TalkingCube,Colour

ChangingPanel,WiFiMicrophoneetc)canbeusedremotelywiththisproduct.

11. Safety



•TheLightDiffractionTotemissuitableforuseonalevelhorizontalfloor.

•Alwayssupervisetheuseofthisproduct.



12. TechnicalSpecification



Tubesize:  150cmHx15cmdiameter

Overallheight: 161cmHapprox

PowerSupply: ClassII 

PRI:230‐240V50Hz70VA

SEC:12VMax60VA



13. Installation



I. Placeonaflat,stablefloorthatiscapableofholdingtheweightofthisproduct.

II. Connectthemulti‐colouredwiresfromthebottomofthetubetothecircuitboard–see

imagebelow‐theleadwitha4‐wayconnectorcomingfromthetubeshouldbepulled

throughtheholeinthebaseofthetubepriortomountingthetubeontothechassisand

connectedto‘CONN3RGB+’onthePCBmarked‘SA494’.Thisconnectorisonthefrontedge

ofthelefthandPCBwhenviewedfromtheaccessibleendofthemetaltraycarryingthe3

PCBs.

III. Attachthetubetothechassisusingthefourboltsprovided(oneineachcorner).

IV. TherearetwoscrewholesoneachsideofthePowerSupplyshouldyouwishtowallmount

theunit,orsecureittothefloor.Note:pleasewallmountinawellventilatedarea.No

fixingsaresuppliedasthesedependonthesurfacetheunitwillbeattachedto.ThePower

Supplyboxweighs1.3kg.



Pleasenote:imageaboveshowsa110Vplug–theplugsuppliedwithbeappropriatetothecountryof

thecustomer



V. PlugthePowerSupplyintotheTotemusingthecircularplugsupplied.

VI. Ifusingacushionedplatform(notincluded),fitthecushionedplatformovertheLight

DiffractionTotem,makingsurethePowerSupplyisnottrapped(therewillbeasmall

triangularcut‐outinonesideofthecushionedplatformforthispurpose.

VII. PlugtheotherendofthePowerSupplyinatthewall.

VIII. Switchonatthewall.ThegreenLEDlightwillbelit.Theremaybeaslightdelay.



IV.Theunitwillbegintoflash,displayingasequenceofcolouredlights.Turnthewheel(I)

onthebasetoadjustthespeedofthelightchange.TheLightDiffractionTotemismost

effectiveinadarkenedenvironment.

Pleasenote:



TheConnectormarkedJisforthe17274LEDSuperInteractiveSwitchBoxonly.

ConnectinganyothercabletothissocketmaycausepermanentdamagetotheTotem.



Ensurethattheelectronicsremaindry.





Power

LED

DustProtectorCover

insocketJ

14. CareandMaintenance



•TheLightDiffractionTotemissuitableforuseonalevelhorizontalfloor.

•Alwayssupervisetheuseofthisproduct.



WhenyouneedtoswitchtheTotemOFFafteruse,orbeforemaintenancepleasenotethat:

•ThereisnoON/OFFswitchontheTotemitself,oronthepowersupplyshownbelow.

•Powershouldbedisconnectedbyremovingthemainsplugfromthewallsocket.Donot

disconnectthejackplugofthepowersupplyfromtheroundACsocketatthebaseofthe

Totem.Repeatedlydisconnectingthejackplugfromthisroundsocketislikelytoleadto

damagetotheTotem,andshouldalsobeavoidedforsafetyreasons.





15. Troubleshooting



Intheunlikelyeventofproductfailure,pleasecheckthefollowing:



Problem:Nolights

•CheckthattheTotemispluggedinatthewallandswitchedonatthewall

•Checkthatthepowersupplyisconnected

•CheckthegreenLEDlightison

•CheckallleadsinthebaseoftheTotemarestillconnectedandthattherearenolooseleads



Furthercopiesoftheseinstructionscanbedownloadedatwww.rompa.com

Wehopeyoufindourinstructionsinvaluable.Ifyouhaveanysuggestionsforimprovingthem

furtheryourcommentswillbegreatlyreceived–pleasecontactusat[email protected]



LIGHTDIFFRACTIONTOTEM19723,January2014



1. Produit



TotemaveclumièredediffractiondeROMPA®



2. Code



19723



3. Couleur



Baseblanc;tubenoir



4. BrèveDescription



Objettrèsvisuel.Phénomènedediffraction:Lalumièresepropagepartouslestrousdu

totemetcréedecettemanièreuneffetétonnant,surtoutdanslesenvironnementsnoirs.



5. Contenu



Totemaveclumièredediffraction

Boîted’alimentation

CâbleUSB



6. StimulationsSnoezelen®



•Vue

•Vibration



7. Usage



Pourleseffetsvisuelsencoreplusattrayants,servez‐vousdecetotemdanslesenvironnements

noirs.Onpeutattacherletotemaumurenvousservantducollierd’arrimage14694.



8. ProduitsCompatiblesdeROMPA®



19847Télécommandede8CouleursSansFilROMPA®

19939TapisInteractifsansFil

20563MicrophoneWiFi

18870CubeParlant

20402MiniCubeParlant

19214PanneaudeCouleursChangeantes

14694Collierd’arrimage



PlateformeRembourréeex.14896…Prièredevoirwww.nenko.frlouwww.nenko.bepournotre

grandegammedePlateformesRembourrées



MiroirsenAcryliqueex.14892…Prièredevoirwww.nenko.frlouwww.nenko.bepournotre

grandegammedemiroirs



9. Fonctionnement



•MettezleTotemsurunesurfaceplate,stableetcapabledetenirlepoidsdeceproduit.

•Attachezlesfilsmulti‐colorésdudessousdelacolonneàlaplaquette.

•Attachezlacolonneauchâssisenvousservantdesquatreboulonsfournis(ilyenaundans

chaquecoin).

•Introduisezlaboîted’alimentationdansleTotemenvousservantdelapriserondefournie

•Sivousvousservezd’uneplateformerembourrée,mettez‐lepar‐dessusleTotem–

nepascoincerlaboited’alimentation.

•Branchezl’autreboutdelaboîted’alimentation.

•Lalumièrevertes’allume.Ilyauraunbrefdélai.

•Tournezlecadransurlabasepourajusterlavitesseduchangementdescouleurs.



10. Description



Objettrèsvisuel.Phénomènedediffraction:Lalumièresepropagepartouslestrousdu

totemetcréedecettemanièreuneffetétonnant,surtoutdanslesenvironnementsnoir.

CompatibleavecWiFi.
