CORDLESS MINI CHAIN SAW
8600
USER MANUAL 1
TECHNICAL SPECIFICATIONS
Model 8600
Voltage 20V
Battery Type Lithium-ion
Battery Capacity 2.0Ah
Maximum Cutting Diameter 6"/150mm
Shain Size 1/4"
Chain Bar Length 195mm
Chain Wheel Teeth 6
No-load Speed 3800RPM
Chain Speed 4.8m/s
Oil Tank Capacity 50ml
Run Time Full-load: 15 min
No-load: 50min
Cuts per battery charge
(Cutting Diameter 100mm)
50~60pcs
Charging Time 60min
Weight 1.67Kg (with one 2.0Ah Battery
Include bar cover,oil bottle 50ml,
1pc 3mm file ,1 pc 2.0Ah
battery,1pc 2.0A charger
CORDLESS MINI CHAIN SAW
2
PART LIST
20V
2000mAh
Saw chain
Sword
Front Hand
Protection
Oil Bottle
Cap Safety Switch
On/Off Switch
Handle
Battery
pack
Rear
Handguard
Fastening Screw
Sprocket Cover
The operating instructions are part of this device. It contains
important information on safety, use and disposal. Before using the
device, make yourself familiar with all operating and safety instructions.
Keep the operating instructions in a safe place and hand over all
documents when passing the device on to third parties.
Intended Use
The cordless wood cutter is only designed for sawing wood. This wood
cutter is not suitable for felling trees. The device is not intended for any
other type of application (e.g. cutting masonry, plastic or food). Using
the wood cutter for improper work can lead to serious injuries to the user
or other people. Any other use that is not expressly permitted in these
operating instructions can damage the device and pose a serious risk
to the user.
The device is intended for use in the DIY sector. It was not designed for
continuous commercial use. The device is intended for use by adults. The
manufacturer is not liable for damage caused by improper use or incorrect
operation. This device is not suitable for commercial use. Before using the
wood cutter, the user must have read and understood all the notes and
USER MANUAL 3
instructions in the user manual. The user must wear appropriate personal
protective equipment (PPE). Only wood may be sawed with the wood
cutter. Materials such as plastic, stone, metal or wood that contain foreign
bodies (e.g. nails or screws) must not be processed!
Security
1) Safety switch
To switch on the device, the switch-on lock must be unlocked.
2) On / off switch with immediate chain stop
When the on / off switch is released, the device switches off immediately.
safety instructions
This section deals with the basic safety regulations for working with the
device.
A wood cutter is a dangerous device which, if used incorrectly or
negligently, can cause serious or even fatal injuries. Therefore, for your
own safety and the safety of others, always observe the following safety
instructions.
SYMBOLS IN THE OPERATING INSTRUCTIONS
Danger sign with information about the prevention of personal injury
or damage to property
Note signs with information on how to better use the device
Wear cut-resistant gloves.
ICONS ON THEDEVICE
Before you start working with the cordless wood cutter, familiarize
CORDLESS MINI CHAIN SAW
4
yourself well with all of the controls.
Read and follow the operating instructions for the machine!
Wear protective glasses.
Be careful of the chainsaw kickback and avoid touching
the tip of the guide bar.
wearing earplugs
wear a hard hat
Wear safety shoes
Please stay away from others
Remove the battery before servicing.
Do not expose the device to rain. The device must neither be damp
nor operated in a damp environment.
Danger from lacerations! Keep your hands off me.
Sword length
Oil the saw chain.
Note the running direction of the saw chain. Caution! Read
the operating instructions.
USER MANUAL 5
lock
loose
Turn indicator
GENERAL POWER TOOL SAFETY WARNINGS
WARNING!
Read all safety warnings, instructions, illustrations and specifications
provided with this power tool. Failure to follow all instructions listed
below may result in electric shock, fire and/or serious injury.
SAVE ALL WARNINGS AND INSTRUCTIONS FOR
FUTURE REFERENCE.
The term “power tool” in the warnings refers to your mains-operated
(corded) power tool or battery-operated (cordless) power tool.
1) WORK AREA SAFETY
a) Keep work area clean and well lit. Cluttered or dark areas invite accidents.
b) Do not operate power tools in explosive atmospheres, such as in the
presence of flammable liquids, gases or dust. Power tools create sparks
which may ignite the dust or fumes.
c) Keep children and bystanders away while operating a power tool.
Distractions can cause you to lose control.
2) ELECTRICAL SAFETY
a) Power tool plugs must match the outlet. Never modify the plug in any
way. Do not use any adapter plugs with earthed (grounded) power tools.
Unmodified plugs and matching outlets will reduce risk of electric shock
b) Avoid body contact with earthed or grounded surfaces, such as pipes,
radiators, ranges and refrigerators. There is an increased risk of electric
shock if your body is earthed or grounded.
c) Do not expose power tools to rain or wet conditions. Water entering a
CORDLESS MINI CHAIN SAW
6
power tool will increase the risk of electric shock.
d) Do not abuse the cord. Never use the cord for carrying, pulling or
unplugging the power tool. Keep cord away from heat, oil, sharp edges
or moving parts. Damaged or entangled cords increase the risk of
electric shock.
e) When operating a power tool outdoors, use an extension cord suitable
for outdoor use. Use of a cord suitable for outdoor use reduces the risk
of electric shock.
f) If operating a power tool in a damp location is unavoidable, use a
residual current device (RCD) protected supply. Use of an RCD reduces
the risk of electric shock.
3) PERSONAL SAFETY
a) Stay alert, watch what you are doing and use common sensewhen
operating a power tool. Do not use a power tool while you are tired or under
the influence of drugs, alcohol or medication. A moment of inattention while
operating power tools may result in serious personal injury.
b) Use personal protective equipment. Always wear eye protection.
Protective equipment such as a dust mask, non-skid safety shoes, hard
hat or hearing protection used for appropriate conditions will reduce
personal injuries.
c) Prevent unintentional starting. Ensure the switch is in the off-position
before connecting to power source and/or battery pack, picking up or
carrying the tool. Carrying power tools with your finger on the switch or
energizing power tools that have the switch on invites accidents.
d) Remove any adjusting key or wrench before turning the power tool
on. A wrench or a key left attached to a rotating part of the power tool
may result in personal injury.
e) Do not overreach. Keep proper footing and balance at all times. This
enables better control of the power tool in unexpected situations.
f) Dress properly. Do not wear loose clothing or jewellery. Keep your hair
and clothing away from moving parts. Loose clothes, jewellery or long hair
can be caught in moving parts.
USER MANUAL 7
g) If devices are provided for the connection of dust extraction and
collection facilities, ensure these are connected and properly used. Use
of dust collection can reduce dust-related hazards.
h) Do not let familiarity gained from frequent use of tools allow you to
become complacent and ignore tool safety principles. A careless action
can cause severe injury within a fraction of a second.
4) POWER TOOL USE AND CARE
a) Do not force the power tool. Use the correct power tool for your
application. The correct power tool will do the job better and safer at the
rate for which it was designed.
b) Do not use the power tool if the switch does not turn it on and off. Any
power tool that cannot be controlled with the switch is dangerous and
must be repaired by Ronix Service Center.
c) Disconnect the plug from the power source and/or remove the battery
pack, if detachable, from the power tool before making any adjustments,
changing accessories, or storing power tools. Such preventive safety
measures reduce the risk of starting the power tool accidentally.
d) Store idle power tools out of the reach of children and do not allow
persons unfamiliar with the power tool or these instructions to operate the
power tool. Power tools are dangerous in the hands of untrained users.
e) Maintain power tools and accessories. Check for misalignment or
binding of moving parts, breakage of parts and any other condition that
may affect the power tool’s operation. If damaged, have the power tool
repaired before use. Many accidents are caused by poorly maintained
power tools.
f) Keep cutting tools sharp and clean. Properly maintained cutting tools
with sharp cutting edges are less likely to bind and are easier to control.
g) Use the power tool, accessories and tool bits etc. in accordance with
these instructions, taking into account the working conditions and the
work to be performed. Use of the power tool for operations different from
those intended could result in a hazardous situation.
h) Keep handles and grasping surfaces dry, clean and free from oil and
CORDLESS MINI CHAIN SAW
8
grease. Slippery handles and grasping surfaces do not allow for safe
handling and control of the tool in unexpected situations.
5) BATTERY TOOL USE AND CARE
a) Recharge only with the charger specified by the Ronix. A charger that
is suitable for one type of battery pack may create a risk of fire when
used with another battery pack.
b) Use power tools only with specifically designated battery packs. Use
of any other battery packs may create a risk of injury and fire.
c) When battery pack is not in use, keep it away from other metal objects,
like paper clips, coins, keys, nails, screws or other small metal objects,
that can make a connection from one terminal to another. Shorting the
battery terminals together may cause burns or a fire.
d) Under abusive conditions, liquid may be ejected from the battery;
avoid contact. If contact accidentally occurs, flush with water. If liquid
contacts eyes, additionally seek medical help. Liquid ejected from the
battery may cause irritation or burns.
e) Do not use a battery pack or tool that is damaged or modified.
Damaged or modified batteries may exhibit unpredictable behavior
resulting in fire, explosion or risk of injury.
f) Do not expose a battery pack or tool to fire or excessive temperature.
Exposure to fire or temperature above 130 °C may cause explosion.
g) Follow all charging instructions and do not charge the battery pack or
tool outside the temperature range specified in the instructions. Charging
improperly or at temperatures outside the specified range may damage
the battery and increase the risk of fire.
6) SERVICE
a) Have your power tool serviced by Ronix service center to use only
identical replacement parts. This will ensure that the safety of the power
tool is maintained.
b) Never service damaged battery packs. Service of battery packs
should only be performed by the Ronix service center.
USER MANUAL 9
SAFETY INSTRUCTIONS FOR PRUNING SAWS
1) GENERAL PRUNING SAW SAFETY WARNINGS:
a) Keep all parts of the body away from the pruning saw when the
pruning saw is operating. Before you start the pruning saw, make sure
the saw chain is not contacting anything. A moment of inattention while
operating pruning saw may cause entanglement of your clothing or body
with the saw chain.
b) Always hold the pruning saw with your hand on the rear handle.
Holding the pruning saw with a reversed hand configuration increases
the risk of personal injury and should never be done.
c) Hold the pruning saw by insulated gripping surfaces only, because
the saw chain may contact hidden wiring. Saw chains contacting a “live”
wire may make exposed metal parts of the pruning saw “live’” and could
give the operator an electric shock.
d) Wear eye protection. Further protective equipment for hearing, head,
hands, legs and feet is recommended. Adequate protective equipment
will reduce personal injury from flying debris or accidental contact with
the saw chain.
e) Do not operate a pruning saw in a tree, on a ladder, from a rooftop, or
any unstable support. Operation of a pruning saw in this manner could
result in serious personal injury.
f) Always keep proper footing and operate the pruning saw only when
standing on fixed, secure and level surface. Slippery or unstable surfaces
may cause a loss of balance or control of the pruning saw.
g) When cutting a limb that is under tension, be alert for spring back.
When the tension in the wood fibers is released, the spring-loaded limb
may strike the operator and/or throw the pruning saw out of control.
h) Use extreme caution when cutting brush and saplings. The slender
material may catch the saw chain and be whipped toward you or pull
you off balance.
i) Carry the pruning saw by the front handle with the pruning saw
switched off and away from your body. When transporting or storing
the pruning saw, always fit the guide bar cover. Proper handling of the
Inhaltsverzeichnis
Andere Ronix Kettensäge Handbücher
