Ross Video Limited
Squeeze & Tease
Installation Guide
V I S I O N
2
Vision • Squeeze & Tease Installation Guide
• Ross Part Number: 4800DR-317-03
• Release Date: December 9, 2011. Printed in Canada.
The information contained in this guide is subject to change without notice or
obligation.
Copyright
©2011 Ross Video Limited. All rights reserved.
Contents of this publication may not be reproduced in any form without the
written permission of Ross Video Limited. Reproduction or reverse engineering
of copyrighted software is prohibited.
Patents
This product is protected by the following US Patents: 4,205,346; 5,115,314;
5,280,346; 5,561,404; 7,034,886; 7,508,455; 7,602,446; 7,834,886. This
product is protected by the following Canadian Patents: 2039277; 1237518;
1127289. Other patents pending.
Notice
The material in this guide is furnished for informational use only. It is subject to
change without notice and should not be construed as commitment by Ross
Video Limited. Ross Video Limited assumes no responsibility or liability for
errors or inaccuracies that may appear in this guide.
Trademarks
• is a trademark of Ross Video Limited.
• Ross, ROSS, ROSS®, and MLE are registered trademarks of Ross
Video Limited.
•All other product names and any registered and unregistered
trademarks mentioned in this guide are used for identification
purposes only and remain the exclusive property of their
respective owners.
3
Important Regulatory and Safety Notices to Service
Personnel
Before using this product and any associated equipment, refer to the
“Important Safety Instructions” listed in the front of your Engineering
Manual to avoid personnel injury and to prevent product damage.
Product may require specific equipment, and/or installation procedures to be
carried out to satisfy certain regulatory compliance requirements. Notices have
been included in this publication to call attention to these specific requirements.
General Handling Guidelines
• Careful handling, using proper ESD precautions, must be observed.
• Power down the system before PCB removal.
ESD Susceptibility — Avoid handling the switcher circuit
boards in high static environments such as carpeted areas, and
when synthetic fiber clothing is worn. Touch the frame to
dissipate static charge before removing boards from the frame,
and exercise proper grounding precautions when working on
circuit boards.
Environmental Information
The equipment that you purchased required the extraction and use
of natural resources for its production. It may contain hazardous
substances that could impact health and the environment.
To avoid the potential release of those substances into the environment and to
diminish the need for the extraction of natural resources, Ross Video encourages
you to use the appropriate take-back systems. These systems will reuse or
recycle most of the materials from your end-of-life equipment in an
environmentally friendly and health conscious manner.
The crossed-out wheeled bin symbol invites you to use these systems.
If you need more information on the collection, reuse, and recycling systems,
please contact your local or regional waste administration.
You can also contact Ross Video for more information on the environmental
performances of our products.
4 • Package Contents
Package Contents
The contents of the Squeeze & Tease™ upgrade kit depends on the number of
Squeeze & Tease MD channels you are installing. If any items are missing, or
damaged, contact Ross Video Technical Support.
Qtya
a. The number of boards and cards in the upgrade kit depends on the num-
ber of options ordered.
Part# Item
1-3 4800AR-047A Squeeze & Tease MD Carrier Board
1-12 4800AR-048 Squeeze & Tease MD Channel Card
1-6 4800AR-049 Squeeze & Tease MD WARP Card
Squeeze & Tease Overview • 5
Squeeze & Tease Overview
The Squeeze & Tease™ MD option consists of a carrier board and a number of
daughter cards that are installed into the frame.
In order to install the Squeeze & Tease MD option, you must upgrade the
switcher software, install the daughter cards onto the Squeeze & Tease Carrier
Board, and install the Squeeze & Tease Carrier Board into the frame.
Important — Although the Squeeze & Tease Carrier Boards
are hot-swappable, any Squeeze & Tease resources on those
cards that are being used, Flying Keys for example, will be lost
when the board is removed.
The hardware for the Squeeze & Tease MD option consists at least one Squeeze
& Tease MD Carrier Board. On this Squeeze & Tease MD Carrier Board, there
are slots for 4 Squeeze & Tease MD Cards, each providing 2 channels of DVE
resources, and slots for 2 Squeeze & Tease WARP MD Cards.
The total number of Squeeze & Tease MD cards you can use depends on the
number of MLEs you have and the switcher you are installing them into. Refer
to your Vision switcher documentation for the number of Squeeze & Tease MD
and Squeeze & Tease MD WARP cards you can install for each MLE.
Note — Squeeze & Tease MD DVE channel resources are
shared between both MLEs, the MLE-Pair, on the same Video
Processor Board. If all DVE channel resources are applied to
one MLE, there will be no resources available to the other MLE
in the MLE-pair.
6 • Software Upgrade
Software Upgrade
When a new board is installed, the switcher checks the current version of
software on the board. If the software on the board is the same as the software
on the switcher, there is no change. If the board has a software version that is
different than the version on the switcher, the switcher will upgrade the board to
the same version as the switcher. For this reason, it is important that you upgrade
your switcher to the latest version of software prior to installing a new board
into the frame. Refer to your Vision switcher documentation for information on
upgrading the switcher.
S&T MD Channel Card Installation • 7
S&T MD Channel Card Installation
Use the following procedure to install a Squeeze & Tease MD Card onto the
Squeeze & Tease Carrier Board:
1. Place the Squeeze & Tease Carrier Board on a clean, static-free
surface.
2. Locate the Squeeze & Tease MD Channel Card Slot (MD Slots 1
through 4) on the Squeeze & Tease Carrier Board that you want to
install the Squeeze & Tease MD Channel Card into (Figure 1).
Refer to the following tables for information on where to install the
Squeeze & Tease MD Channel Card for your frame configuration.
Table 1 Standard QMD-X Channel Card Slots
Frame
Slot MLE Slot 4 Slot 3 Slot 2 Slot 1
8 MLE 1&2 Yes Yes Yes Yes
6 MLE 3&4 Yes Yes Yes Yes
3 MLE 5&6 Yes Yes
3 MLE 7&8 Yes Yes
Table 2 Octane Frame QMD-X Channel Card Slots
Frame
Slot MLE Slot 4 Slot 3 Slot 2 Slot 1
3 MLE 1&2 Yes Yes
3 MLE 3&4 Yes Yes
Table 3 QMD Channel Card Slots
MLE Slot 4 Slot 3 Slot 2 Slot 1
MLE 1&2 Yes Yes
MLE 3&4 Yes Yes
8 • S&T MD Channel Card Installation
Figure 1 Squeeze & Tease Carrier Board — Daughter Card Slots
3. Align the Squeeze & Tease MD Card so that the 3connectors on the
bottom of the card line up with the connectors in the Squeeze & Tease
MD Card Slot. The Retaining Screw Holes on either side of the card
will line up with the mounts on the board (Figure 2).
Figure 2 Squeeze & Tease MD Card
4. Apply firm, even, pressure to seat the card in the slot.
Caution — Do not overtighten the Retaining Screws. These
screws only need to be snug in order to secure the card in place.
5. Install the 2Retaining Screws into the Retaining Screw Mounts on
the Squeeze & Tease Carrier Board to secure the card in position.
The screws insert from the bottom of the Squeeze & Tease Carrier
Board, into the daughter card.
This completes the procedure for installing the Squeeze & Tease MD Card. Use
this same procedure to install any additional Squeeze & Tease MD Cards.
Squeeze & Tease MD Cards
Connectors
MD Slot 1
WARP Slot 1WARP Slot 2
MD Slot 2MD Slot 3MD Slot 4
Squeeze & Tease WARP
MD Card Squeeze & Tease WARP
MD Card
Retaining Screw Hole
Retaining Screw Hole
S&T WARP MD Card Installation • 9
S&T WARP MD Card Installation
Use the following procedure to install a Squeeze & Tease MD WARP Card onto
the Squeeze & Tease Carrier Board:
1. Place the Squeeze & Tease Carrier Board on a clean, static-free
surface.
2. Locate the Squeeze & Tease WARP MD Slot (WARP Slots 1and 2)
on the Squeeze & Tease Carrier Board that you want to install the
Squeeze & Tease WARP MD Card into (Figure 3). Refer to the
following tables for information on where to install the Squeeze &
Tease WARP MD Card for your frame configuration.
Table 4 Standard QMD-X WARP Card Slots
Frame
Slot MLE Slot 2 Slot 1
8 MLE 1&2 Yes Yes
6 MLE 3&4 Yes Yes
3 MLE 5&6 Yes
3 MLE 7&8 Yes
Table 5 Octane Frame QMD-X WARP Card Slots
Frame
Slot MLE Slot 2 Slot 1
3 MLE 1&2 Yes
3 MLE 3&4 Yes
Table 6 QMD WARP Card Slots
MLE Slot 2 Slot 1
MLE 1&2 Yes
MLE 3&4 Yes
10 • S&T WARP MD Card Installation
Figure 3 Squeeze & Tease Carrier Board — Daughter Card Slots
3. Align the Squeeze & Tease WARP MD Card so that the 3
connectors on the bottom of the card line up with the connectors in the
Squeeze & Tease WARP MD Card Slot. The Retaining Screw
Holes on either side of the card will line up with the mounts on the
board (Figure 4).
Figure 4 Squeeze & Tease WARP MD Card
4. Apply firm, even, pressure to seat the card in the slot.
Caution — Do not overtighten the Retaining Screws. These
screws only need to be snug in order to secure the card in place.
5. Install the 2Retaining Screws into the Retaining Screw Mounts on
the Squeeze & Tease Carrier Board to secure the card in position.
The screws insert from the bottom of the Squeeze & Tease Carrier
Board, into the daughter card.
This completes the procedure for installing the Squeeze & Tease MD WARP
Card. Use this same procedure to install any additional Squeeze & Tease MD
WARP Cards. Next, install the Squeeze & Tease Carrier Board into the frame.
Squeeze & Tease MD Cards
Connectors
MD Slot 1
WARP Slot 1WARP Slot 2
MD Slot 2MD Slot 3MD Slot 4
Squeeze & Tease WARP
MD Card Squeeze & Tease WARP
MD Card
Retaining Screw Hole
Retaining Screw Hole
