DR-U955BT

Multi-format Desktop Reader

User Manual

1. Introduction

The DR-U955BT is an advanced desktop reader for MIFARE Classic®

EV1, MIFARE®DESFire®EV1, UHF, and BLE. It reads the ID data of the

credential and transmits the relevant ID data to any connected access

control software, such as Rosslare’s AxTraxNG™.

It has a slim and attractive design and is built for convenience and

portability. With its USB computer interface, it is quick and easy to install

and runs without any additional power source.

Using the BLE-Admin™or My BLE-ID™apps, the reader can function

like other Rosslare BLE readers and can transmit the BLE ID to the reader.

The Hardware Configuration Tool (HCT) can be used to configure the

reader’s specifications, such as the Wiegand format used.

The reader reads the CSN ID of each credential (MIFARE, UHF, BLE) and

transmits it to the software with the bit length pre-configured by the user.

Figure 1: DR-U955BT

2. Technical Specifications

2.1 Electrical Characteristics

Operating Voltage Range

5 VDC (USB powered)

Standby Current

250 mA

Max. Operation Current

300 mA

Supported Transponders

MIFARE, UHF, BLE

Read Card Distance

UHF and MIFARE: Up to 5 cm (2 in.)

BLE: Up to 6 m (19.7 ft)

Operation Frequency

•RFID: 13.56 MHz

•DR-U955BT US: 902–928 MHz

(America) RFID

•DR-U955BT EU: 865–868 MHz

(Europe) RFID

•Bluetooth: 2.402-2.480 GHz

Output Formats

Supports Wiegand 26-Bit to 64-Bit

2.2 Environmental Characteristics

Operating Environment

Indoor use

Operating Temperature Range

0°C to 63°C (32°F to 145°F)

Storage Temperature Range

-20°C to 63°C (-4°F to 145°F)

Relative Humidity Range

0 to 95% (non-condensing)

2.3 Physical Characteristics

Weight

130 g (4.6 oz)

Dimensions (L x W x H)

123 x 70 x 16.2 mm (4.9 x 2.8 x 0.6 in.)

3. Operation

The DR-U955BT appears as a COM port device when plugged in to a PC and can be used for any application. When a card is presented to the reader, the reader

outputs the Wiegand ID data on the COM port only once until a new card is presented.

You must use the AxTraxNG software to enroll cards. Please refer to the relevant appendix in the AxTraxNG™ Software Installation and User Manual.

For the enrollment reader to function in AxTraxNG, you must know the COM port being used. The COM port can be found in Microsoft Device Management’s

driver details under ‘Ports (COM & LPT)’. The port being used appears as “USB serial Port (COMx)”, where x is the number of the port used.

4. Configuration with the BLE-Admin App

1. Download the BLE-Admin application from Google Play or App Store

using the following QR code.

2. Open the application, select the required reader from the list displayed.

3. Enter the password.

NOTES:

•Use the default password (12345678) when you log in to the

BLE-Admin application for the first time.

•It is highly recommended that you change the password (see step 4).

4. On the main screen, configure the following:

Options

Remarks

Desktop Reader Name

Assign name to select the Desktop Reader Name

Password

Change password

5. Tap Set Configuration and configure the following

Parameters

Options

Remarks

Power

Power = 1 –10

Default = 10

Slide to select the signal power effect

of UHF reading range credentials.

Transmission Protocol

Wiegand

This is a proprietary protocol that the

reader uses to send the tag information

to the AxTraxNG software.

Transmission Protocol

Type

26, 32, 32R, 34,

40, 56, 64 bits

Default = 26 bits

Select number of bits.

NOTE: The My BLE-ID application allows a mobile device to be used as a

credential. Download the application from Google Play or App Store using

the following QR code.

S M A R T

0706-0960664+01

Declaration of Conformity

▪This device complies with Part 15 of the FCC Rules. Operation is

subject to the following two conditions:

▪This device may not cause harmful interference.

▪This device must accept any interference received, including

interference that may cause undesired operation.

▪Changes or modifications not expressly approved by the party

responsible for compliance could void the user's authority to operate

the equipment.

This equipment has been tested and found to comply with the limits for a

Class B digital device, pursuant to part 15 of the FCC Rules. These limits

are designed to provide reasonable protection against harmful interference

in a residential installation.

This equipment generates, uses, and can radiate radio frequency energy

and, if not installed and used in accordance with the instructions, may cause

harmful interference to radio communications. However, there is no

guarantee that interference will not occur in a particular installation. If this

equipment does cause harmful interference to radio or television reception,

which can be determined by turning the equipment off and on, the user is

encouraged to try to correct the interference by one or more of the

following measures:

▪Reorient or relocate the receiving antenna.

▪Increase the separation between the equipment and receiver.

▪Connect the equipment into an outlet on a circuit different from that

to which the receiver is connected.

▪Consult the dealer or an experienced radio/TV technician for help.

Limited Warranty

The full ROSSLARE Limited Warranty Statement is available in the Quick

Links section on the ROSSLARE website at www.rosslaresecurity.com.

Rosslare considers any use of this product as agreement to the Warranty

Terms even if you do not review them.

Contact Information

United States and Canada

Rosslare Security Products, Inc.

Southlake, TX, USA

Toll Free: +1-866-632-1101

Local: +1-817-305-0006

Fax: +1-817-305-0069

support.na@rosslaresecurity.com

Europe

Rosslare Israel Ltd.

22 Ha'Melacha St., P.O.B. 11407

Rosh HaAyin, Israel

Tel: +972-3-938-6838

Fax: +972-3-938-6830

support.eu@rosslaresecurity.com

Latin America

Rosslare Latin America

Buenos Aires, Argentina

support.la@rosslaresecurity.com

China

Rosslare Electronics (Shenzhen) Ltd.

Shenzhen, China

Tel: +86-755-8610-6842

Fax: +86-755-8610-6101

support.cn@rosslaresecurity.com

Asia Pacific, Middle East, Africa

Rosslare Enterprises Ltd.

Kowloon Bay, Hong Kong

Tel: +852-2795-5630

Fax: +852-2795-1508

support.apac@rosslaresecurity.com

India

Rosslare Electronics India Pvt Ltd.

Tel/Fax: +91-20-40147830

Mobile: +91-9975768824

sales.in@rosslaresecurity.com

CERT

ISO 9001

ISO 14001
