Rosslare AC-825 Bedienungsanleitung
Table of Contents
AC-825 Hardware Installation and User Guide iii
Table of Contents
1.1 Features........................................................................................................................10
1.2 AxTraxNG.....................................................................................................................11
1.3 Compatible Readers...............................................................................................12
3.1 Inputs Wiring –Non-Supervised Inputs ......................................................16
3.2 Inputs Wiring –Supervised Inputs .................................................................17
3.3 Outputs Wiring.........................................................................................................17
3.4 Power Supply ............................................................................................................19
3.5 AC-825IP Wiring Communications .................................................................21
3.6 Readers.........................................................................................................................21
3.7 Expansion Boards ....................................................................................................22
4.1 Input Types.................................................................................................................24
4.2 Inputs Description...................................................................................................28
4.3 Outputs ........................................................................................................................31
4.4 Card Readers and Keypads ................................................................................33
5.1 DIP Switch Configuration ....................................................................................41
5.2 Setting AC-825IP Panel Type in AxTraxNG ................................................41
List of Figures
AC-825 Hardware Installation and User Guide v
List of Figures
Figure 1: Sample AC-825IP Configuration.................................................................15
Figure 2: Inputs Wiring –Non-supervised Inputs..................................................16
Figure 3: Door Lock –Failed Close ...............................................................................18
Figure 4: Door Lock –Failed Open...............................................................................19
Figure 5: Wiring Between PS-33 and AC-825IP......................................................20
Figure 6: AC-825IP Wiring Communications............................................................21
Figure 7: Reader Wiring ......................................................................................................22
Figure 8: Slot for Expansion Board................................................................................23
Figure 9: Normally Open Input Connection .............................................................25
Figure 10: Normally Closed Input Connection ........................................................25
Figure 11: Normally Open Supervised Input (Single Resistor) ........................26
Figure 12: Normally Open Supervised Input (Double Resistor)......................27
Figure 13: Normally Closed Supervised Input (Single Resistor)......................27
Figure 14: Normally Closed Supervised Input (Double Resistor)...................28
Figure 15: Connecting Multiple Access Control Panels with AC-825IP ......42
Notice and Disclaimer
AC-825 Hardware Installation and User Guide vii
Notice and Disclaimer
This manual’s sole purpose is to assist installers and/or users in the safe
and efficient installation and usage of the system and/or product, and/or
software described herein.
The system must not be used for purposes other than those for
which it was designed.
The use of the software associated with the system and/or product,
if applicable, is subject to the terms of the license provided as part
of the purchase documents.
ROSSLARE ENTERPRISES LIMITED and/or its related companies
and/or subsidiaries’ (hereafter: "Rosslare") exclusive warranty and
liability is limited to the warranty and liability statement provided in
an appendix at the end of this document.
This manual describes the maximum configuration of the system
with the maximum number of functions, including future options.
Therefore, not all functions described in this manual may be
available in the specific system and/or product configuration you
purchased.
Incorrect operation or installation, or failure of the user to effectively
maintain the system, relieves the manufacturer (and seller) from all
or any responsibility for consequent non-compliance, damage, or
injury.
The text, images and graphics contained in the manual are for the
purpose of illustration and reference only.
Notice and Disclaimer
8 AC-825 Hardware Installation and User Guide
In no event shall manufacturer be liable for any special, direct,
indirect, incidental, consequential, exemplary, or punitive damages
(including, without limitation, any and all damages from business
interruption, loss of profits or revenue, cost of capital or loss of use
of any property or capital or injury).
All graphics in this manual are for reference only, some deviation
between the image(s) and the actual product may occur.
All wiring diagrams are intended for reference only, the photograph
or graphic of the PCB(s) are intended for clearer illustration and
understanding of the product and may differ from the actual PCB(s).
Introduction
AC-825 Hardware Installation and User Guide 9
1. Introduction
The AC-825IP is a state-of-the-art networked access controller and is the
backbone of a medium-scale to high-scale security system that can
handle up to 300,000 users and 500,000 events.
Each AC-825IP access control unit (ACU) supports up to four doors
(In/Out), each with 2 inputs and 1 output, and includes four additional
auxiliary inputs and two auxiliary outputs.
The number of supported doors, inputs, and outputs can be increased by
using the onboard 10-pin expansion slot to connect any of the following
extension boards:
R-805 –16 outputs
S-805 –16 inputs
D-805 –4-door expansion
P-805 –16 inputs and 8 outputs
4 doors, 20 outputs, 4 inputs with R-805
4 doors, 2 outputs, 20 inputs with S-805
8 doors, 4 inputs, 2 outputs with D-805
Driven by Rosslare’s powerful, flexible and easy to use AxTraxNG™
software, the system provides an ideal, modular and expandable solution
for commercial and institutional needs. It provides seamless integration
with Rosslare's range of RFID proximity, PIN, Proximity & PIN, smart card,
and biometric readers with Rosslare’s selection of RFID credentials.
The AC-825IP is ready for installation with a mountable and lockable
metal enclosure integrated with transformer, power supply/charger,
sounder, and control panel.
Introduction
10 AC-825 Hardware Installation and User Guide
Using onboard RS-485, Ethernet TCP/IP, multiple local or remote site
door subnetworks can connect to the AxTraxNG Client/Server PC
software running on Microsoft®Windows®98/ME & NT/2000/XP/7
operating systems.
The AC-825IP platform consists of the following components:
AC-825IP control panel
ME-1505 metal enclosure
PS-33 power supply
Power transformer
4 x 2.2K and 4 x 8.2K resistors for the supervised inputs
The AC-825IP is a powerful and adaptable access control solution with a
range of powerful features:
Controls 1 to 4 doors (DIP switch controlled) or up to 8 doors when
an optional D-805 is mounted.
Four IN/OUT readers, with tamper switch and LED control
12 inputs, selectable as supervised or non-supervised (28 when the
S-805 or the P-805 expansions are installed)
Four Form-C relay outputs (rated 5 A)
2 auxiliary outputs
Built-in sounder generator for chime, bell and siren signals
Panel configuration DIP switch
Uses an AES 128-Bit encryption between the AC-825IP panel and the
AxTraxNG server
Up to 300,000 users
Up to 500,000 history log entries (FIFO) per ACU
RS-485 serial communication (up to 115200 bps)
Introduction
AC-825 Hardware Installation and User Guide 11
Onboard TCP/IP communication
Remote firmware upgrades
Removable terminal blocks
A real-time clock keeps time for up to 2 weeks without power and is
backed up by a battery.
The AxTraxNG software system is custom designed to set up, manage,
and supervise all aspects of an access panel network.
It offers the following capabilities:
User Capacity
10,000,000
Unauthorized Users
30,000
Access Groups
1,000,000
Number of Panels in
System
1,024
Number of Doors in
system
10,240
These options are software and firmware dependent, and may change in
later releases or revisions.
AxTraxNG operates through a dedicated AxTraxNG server computer,
which communicates with the access control panels and can serve an
unlimited number of network clients.
The server also runs the system's SQL database, which contains settings
and definitions for access control across the entire facility. System users
can define new cards holders and users, and control access permissions.
The system includes tools for database backup, input, and export of
previous configurations and automatic backup on a periodic basis.
Introduction
12 AC-825 Hardware Installation and User Guide
AxTraxNG supports all panel types and offers scalability and flexibility in
addition to a range of advanced control features.
The system's configurable links model makes it possible to trigger any
chosen output automatically or report a configurable alarm, based on a
selected input. This allows easy integration with other access systems
such as intruder alarms, CCTV systems.
AxTraxNG can also define a selected set of operations, which are defined
in configurable links, when a panel registers a specified user or group of
users. This can be useful, for example, in access control systems. The
system can assign users with counters, allowing a limited number of
entries to each panel.
AxTraxNG can share user details with Rosslare's BioTrax software system.
The BioTrax system can then download all selected user information to
an AYC-W6500 fingerprint reader.
Fingerprint recognition was not evaluated by UL.
For UL-compliant installations, use any of the following UL-listed
Proximity & PIN and card readers made by Rosslare:
AY-H12, AY-J12, AY-K12, AY-L12, AY-M12, AY-Q12, AYC-F54, AYC-F64,
AYC-G54, AYC-G64, AYC-Q54B, or AYC-Q64B
