Roving Networks RN-131 Bedienungsanleitung

www.rovingnetworks.com 1

RN-WIFLYCR-UM-.01

! !

RN-WIFLYCR-UM

WiFly Command Reference,

Advanced Features & Applications

USER MANUAL

RN-WIFLYCR-UM Version 1.0r 9/21/2012

www.rovingnetworks.com Version 1.0r 9/21/2012 2

RN-WIFLYCR-UM

Contents

Introduction ....................................................................................................................... 5!

Features.......................................................................................................................................5!

Configuration................................................................................................................................6!

Entering Command Mode ...........................................................................................................6!

Remote Configuration Using Ad Hoc Mode...................................................................................7!

Command Reference........................................................................................................... 8!

Command Syntax ..........................................................................................................................8!

Command Organization..................................................................................................................8!

Set Commands .............................................................................................................................9!

Get Commands ...........................................................................................................................33!

Status Commands .......................................................................................................................35!

Action Commands .......................................................................................................................37!

File I/O Commands......................................................................................................................40!

Advanced Features & Settings........................................................................................... 42!

Access Point (AP) Mode...............................................................................................................42!

Enabling AP mode...................................................................................................................43!

Enable in Hardware..............................................................................................................43!

Enable in Software...............................................................................................................43!

Using AP Mode .......................................................................................................................44!

Connect to the Module .........................................................................................................44!

Check for the Last Connected Device over TCP .......................................................................44!

View Associated Devices.......................................................................................................45!

Enable the Link Monitor .......................................................................................................45!

Route Data between Clients ..................................................................................................45!

GPIO4, 5 & 6 Alternative Functions......................................................................................45!

Putting the Module to Sleep & Waking It.......................................................................................46!

System & Auto-Connect Timers ....................................................................................................48!

UDP Sleep & Connection Timers...............................................................................................48!

TCP Connection Timers............................................................................................................49!

Opening a TCP Connection ...................................................................................................49!

Closing the TCP Connection..................................................................................................49!

Wake on Sensor Input .................................................................................................................49!

Wake on UART Activity................................................................................................................50!

UART Receiver & RTS/CTS Hardware Flow Control......................................................................50!

Setting GPIO Direction, Alternate Functions & Disabling LEDs.....................................................51!

Setting the Alternate GPIO Functions ....................................................................................53!

Controlling Connections with GPIO Pins .................................................................................54!

Setting Debug Print Levels...........................................................................................................56!

Scan Output Format ................................................................................................................56!

Firmware Version 2.36 & 2.45 ..............................................................................................56!

Firmware Version 2.22 through 2.30 .....................................................................................58!

www.rovingnetworks.com Version 1.0r 9/21/2012 3

RN-WIFLYCR-UM

UART Heartbeat Messages .......................................................................................................58!

Using the Real-Time Clock Function .............................................................................................59!

Time Stamping Packets ...............................................................................................................60!

Advanced Applications ..................................................................................................... 61!

Sending Data using UDP .............................................................................................................61!

UDP Auto Pairing ....................................................................................................................62!

UDP Retry ..............................................................................................................................62!

UDP Broadcast........................................................................................................................62!

Joining Networks & Making Connections........................................................................................63!

Associate with an Access Point .................................................................................................63!

Making Connections ................................................................................................................64!

Setting Up Automatic Connections............................................................................................65!

Controlling Connections using GPIO5 & GPIO6...........................................................................65!

Using DNS Settings.................................................................................................................66!

Using the Backup IP Address/Connect Function .........................................................................66!

Using the HTML Client Feature ....................................................................................................66!

Built-In HTML Client Modes .....................................................................................................67!

Connect to a Web Server Automatically......................................................................................67!

Connect to a Web Server Automatically when UART Data Is Received...........................................68!

Post Binary Data .....................................................................................................................68!

Post Sensor Data Automatically ................................................................................................69!

HTML Client Example: Posting Sensor Data Automatically...........................................................69!

HTML Client Example: Posting UART Data to a Web server..........................................................70!

Upgrading Firmware Via FTP ........................................................................................................71!

FTP Client..................................................................................................................................72!

Connect to an FTP Server.........................................................................................................72!

Creating Files on the FTP Server ...............................................................................................72!

Retrieving Files from the FTP Server .........................................................................................73!

Wi-Fi Protected Setup (WPS) .......................................................................................................73!

Launching a WPS Application...................................................................................................75!

Status LEDs during WPS Process ..............................................................................................75!

Scan Output Format Showing WPS-Enabled Access Point ...........................................................75!

Ad hoc Networking Mode .............................................................................................................77!

Configuring Ad Hoc Mode.........................................................................................................77!

Enable Ad Hoc Mode in Hardware .........................................................................................77!

Enable Ad Hoc Mode in Software ..........................................................................................77!

Scanning for Access Points in Ad Hoc Mode ..............................................................................78!

Analog Sensor Capability .............................................................................................................79!

Sampling Sensor Pins Automatically .........................................................................................79!

Using the Built-In Sensor Power ...............................................................................................80!

Default Configuration ........................................................................................................ 81!

ADHOC PARAMETERS ................................................................................................................81!

BROADCAST PARAMETERS ........................................................................................................81!

www.rovingnetworks.com Version 1.0r 9/21/2012 4

RN-WIFLYCR-UM

COMM PARAMETERS .................................................................................................................81!

DNS PARAMETERS ....................................................................................................................81!

FTP PARAMETERS .....................................................................................................................81!

IP PARAMETERS........................................................................................................................82!

OPTIONAL PARAMETERS ...........................................................................................................82!

SYSTEM PARAMETERS...............................................................................................................82!

TIME SERVER PARAMETERS ......................................................................................................82!

UART PARAMETERS...................................................................................................................83!

WLAN PARAMETERS ..................................................................................................................83!

String Variable Sizes ...................................................................................................................83!

Restoring Default Configuration Settings .......................................................................................84!

Boot-up Timing Values...................................................................................................... 85!

Supported Access Points .................................................................................................. 86!

Command List................................................................................................................... 87!

Known Problems............................................................................................................... 92!

Current Firmware Features & Fixes .................................................................................... 93!

Version 2.36/2.45 9/14/2012......................................................................................................93!

Version 2.30 10/26/2011............................................................................................................94!

Version 2.27 09/08/11................................................................................................................94!

Version 2.23 04/03/2011............................................................................................................94!

Version 2.21 07/11/2010............................................................................................................95!

Version 2.20 06/14/2010............................................................................................................95!

Fixes ......................................................................................................................................95!

Features .................................................................................................................................95!

www.rovingnetworks.com Version 1.0r 9/21/2012 5

RN-WIFLYCR-UM

INTRODUCTION

The Roving Networks WiFly radio module is a complete, standalone embedded wireless LAN access device. The device

has an on-board TCP/IP stack and applications, and in the simplest configuration only requires four pins (power, TX, RX,

and ground). Once you have performed the initial configuration, the device automatically accesses a Wi-Fi network and

sends/receives serial data over the UART.

This user manual is applicable to standalone RN-131 and RN-171 modules, as well as Roving Networks hardware that

includes these modules. Although there are some differences, the RN-131 and RN-171 modules support the same ASCII

command set. The RN-XV device incorporates the RN-171 module; therefore, all RN-171 hardware features apply to the

RN-XV. Table 1 compares the RN-131 and RN-171 module features.

Table 1. Comparing the RN-131 & RN-171

Feature

RN-131

RN-171

Output power

18 dBm (fixed)

12 dBm (programmable)

Lowest power

18 dBm

0 dBm (< 100 mA Tx current)

On-board antenna

Yes

Accurate sleep timer

Yes (32 kHz)

No (+/- 10% error)

GPIO pins available

10, GPIO4 – 13 (GPIO1 – 3 are not available for use)

14, GPIO1 – 14

Default firmware

WiFly_GSX-<version>.img

WiFly_EZX-<version>.img

Refer to the RN-131 and the RN-171 data sheets on the Roving Networks website at http://www.rovingnetworks.com for

more details on their hardware differences and for detailed hardware specifications.

FEATURES

•Fully qualified and Wi-Fi certified 2.4-GHz IEEE 802.11 b/g transceiver

•FCC, CE, ICS certified, and RoHS compliant

•Ultra-low power:

oIntelligent, built-in power management with programmable wakeup

oAccepts 3.3-V regulated or 2- to 3-V battery with on-board boost regulators

oIEEE 802.11 power save and roaming functions

oRN-131: 4 uA sleep, 35 mA Rx, 210 m Tx at 18 dBm (Tx power not configurable)

oRN-171: 4 uA sleep, 35 mA Rx, 185 mA Tx at 12 dBm (Tx power configurable)

•Antenna options:

oRN-131: On-board ceramic chip antenna and U.FL connector for external antenna

oRN-171: RF pad

www.rovingnetworks.com Version 1.0r 9/21/2012 6

RN-WIFLYCR-UM

•Hardware:

o8-Mbit flash memory and 128-Kbyte RAM, 2-Kbyte ROM, 2 Kbyte battery-backed memory

o10 general-purpose digital I/O pins (RN-131)

o14 GPIO pins (RN-171)

o8 analog inputs (14 bits, 1.2 V)

oUART (1 Mbps host data rate) and SPI slave (2 Mbps host data rate) hardware interfaces

oReal-time clock for wakeup and time stamping/data logging; auto-sleep and auto-wakeup modes

•Network support:

oSupports ad hoc and infrastructure mode connections

oPush-button WPS mode for easy network configuration

oOn-board TCP/IP stack

oOver the air firmware upgrade (FTP) and data file upload support

oSecure Wi-Fi authentication via WEP-128, WPA-PSK (TKIP), and WPA2-PSK (AES)

oConfiguration over UART or wireless interfaces using simple ASCII commands

oBuilt in networking applications: DHCP client, DNS client, ARP, ICMP ping, FTP client, TELNET, HTTP,

UDP, and TCP

CONFIGURATION

The WiFly module operates in two modes: data mode and command mode. In data mode, the module can accept

incoming connections or initiate outgoing connections. To configure parameters and/or view the current configuration, you

must put the module into command mode (also called configuration mode).

Entering Command Mode

By default, the module is in data mode. Sending the escape sequence $$$ causes the module to enter command mode.

You must send $$$ together quickly with no additional characters before or after. You must not send a carriage return

(<cr>) or line feed after the $$$ to enter command mode. The module replies with CMD to indicate it is in command

mode. Once in command mode, you can configure the WiFly device using simple ASCII commands; each command ends

with a carriage return <cr>. Most valid commands return AOK; invalid ones return an ERR description. To exit command

mode, send exit <cr>. The module responds with EXIT,indicating that it has exited command mode and entered data

mode.

NOTE: There is a 250-ms buffer before and after the $$$ escape sequence. If characters are sent before or after the

escape sequence within this 250-ms interval, the WiFly module treats them as data and passes them over the

TCP or UDP socket, and the module will not enter command mode.

You can view various parameters, such as the SSID, channel, IP address, serial port, and other settings, and configure

them in command mode. You send commands to the module through the UART or via remotely via telnet. When using the

UART interface, the communications settings should match the WiFly module’s stored settings. The default is 9,600 baud,

8 bits, no parity, 1 stop bit, and hardware flow control disabled. You can enter command mode locally over the UART

interface at any time irrespective of an active TCP connection.

NOTE: Roving Networks suggests using either the TeraTerm (Windows OS) or CoolTerm (Mac OS-X) terminal

emulator program.

When the WiFly module powers up, it attempts to auto-associate with the access point stored in its configuration settings. If

the module cannot find the access point, it enters auto association mode, and scans and attempts to join a network. This

www.rovingnetworks.com Version 1.0r 9/21/2012 7

RN-WIFLYCR-UM

mode may cause the UART to become unresponsive briefly. To avoid configuration problems, the auto-associate feature is

disabled when the module is in command mode, making it easy to configure the module. The auto-associate mode turns

on when you exit command mode.

NOTE: If your module is running firmware version 2.20 or lower, the auto-associate feature is NOT disabled when the

module is in command mode. Therefore, you may lose data sent to the module while it is unassociated,

making it difficult enter command mode and configure the module.

You can disable the auto-associate feature using the set wlan join 0 command. This command prevents the WiFly module

from attempting to associate with a network that does not exist. Alternatively, enable ad hoc mode upon power up using

the GPIO9 ad hoc/factory reset jumper. If this jumper is high on power up, the module does not associate with a network.

While in ad hoc mode, you can configure the network settings.

Remote Configuration Using Ad Hoc Mode

Using ad hoc mode to configure the device eliminates the need for the module to be associated with a network access

point. In ad hoc mode, the module creates it’s own “on demand” network to which you can connect via your computer as

you would with any other network.

To enable ad hoc mode using hardware, set GPIO9 high (3.3 V) at power up. For the RN-134 board, GPIO9 is on pin 1 on

the jumper block (J2). For the RN-174 board, GPIO9 is on the J6 connector. Upon power up with GPIO9 high, the WiFly

module creates an ad hoc network with the following settings:

SSID: WiFly-GSX-XX, where XX is the final two bytes of the devices MAC address

Channel: 1

DHCP: Off

IP address: 169.254.1.1

Netmask: 255.255.0.0

With the ad hoc jumper in place, these settings override any saved configuration settings.

From your computer, connect to the WiFly-GSX-XX network. This open network does not require a pass phrase or pass

key. Currently the WiFly module only supports OPEN mode for creating ad hoc networks.

It may take a few minutes for Windows to assign an IP address and connect to the network. You can check your

computer’s IP address by running the ipconfig command in the Command Window. If connected, this command displays

your computer’s IP address and netmask.

NOTE: The automatically assigned IP address must be on the 169.254.x.ysubnet, otherwise the WiFly module will

not be accessible. If your computer has both wireless and wired interface hardware, you may need to disable

the wired LAN interface hardware before connecting to the ad hoc network. If the wired LAN is enabled, the

computer may assign an IP address that is not on the same subnet as the WiFly module.

Once connected with an appropriate IP address, telnet into the WiFly module on port 2000 using the following command:

telnet 169.254.1.1 2000

The module issues the response *HELLO*. You can now enter command mode using the escape sequence $$$ and

configure the module.

In firmware versions 2.28 and higher, you can disable remote configuration, e.g., for security. To disable remote

configuration, use bit 4 in the TCP mode register by issuing the command:

set ip tcp-mode 0x10

www.rovingnetworks.com Version 1.0r 9/21/2012 8

RN-WIFLYCR-UM

COMMAND REFERENCE

Roving Networks WiFly modules support a variety of commands for configuration. This section describes these commands

in detail and provides examples.

COMMAND SYNTAX

To issue commands to the module, you send a keyword followed by optional parameters. Commands are case sensitive,

and you cannot use spaces in parameters. Use a $to indicate a space, e.g., MY NETWORK should be written as

MY$NETWORK. Hex input data can be uppercase or lowercase. String text data, such as the SSID, is case sensitive.

You can use shorthand for the parameters. For example, the following commands are equivalent:

•set uart baudrate 115200

•set uart b 115200

•set u b 15200

NOTE: You cannot use shorthand for command keywords. For example, s uart baudrate 115200 is illegal.

You can type numbers in decimal (e.g., 115200) or hexadecimal. To enter a number in hex, use 0x<value>. For example,

the hex value FF would be entered as 0xFF.

COMMAND ORGANIZATION

There are five general command categories, as shown in Table 2.

Table 2. Command Types

Command Type

Description

Set commands

Set commands take effect immediately and are stored to memory when the save command is issued.

Get commands

These commands retrieve the stored information and display it.

Status commands

These commands display the interface status, IP status, etc.

Action commands

Use these commands to perform actions such as scanning, connecting, disconnecting, etc.

File I/O commands

Use these commands to upgrade, load and save configuration, delete files, etc.

NOTE: You must save any changes you make using the save command or the module will load the previous settings

upon reboot or power up.

www.rovingnetworks.com Version 1.0r 9/21/2012 9

RN-WIFLYCR-UM

When the system boots, all configuration data is loaded into RAM variables from the config file. The set commands only

modify the RAM copy of the system variables. In general, the IP, WLAN, and UART settings require you to save and reboot

before they take effect because they operate upon power up. For example, you only associate, set the channel, and obtain

an IP address once at power up. Most of the other commands, e.g., COMM settings and timers, take effect immediately,

allowing you to change parameters on the fly, minimizing power usage, and saving flash re-write cycles.

Once configuration is complete, you must save the settings to store the configuration data, otherwise it will not take effect

upon reboot or reset. You can store multiple configurations using the save <filename> command, and you can load them

using the load <filename> command.

SET COMMANDS

These commands begin with the set keyword and include the categories shown in Table 3:

Table 3. Set Commands

Parameter

Description

adhoc

Controls the ad hoc parameters.

broadcast

Controls the broadcast hello/heartbeat UDP message.

comm

Sets the communication and data transfer, timers, and matching characters.

dns

Sets the DNS host and domain.

ftp

Sets the FTP host address and login information.

Specifies the IP settings.

option

Supports optional and infrequently used parameters.

sys

Sets system settings such as sleep and wake timers.

time

Sets the timer server settings.

uart

Specifies the serial port settings such as baud rate and parity.

wlan

Sets the wireless interface settings, such as SSID, channel, and security options.

set adhoc beacon <value>

This command sets the ad hoc beacon interval in milliseconds, where <value> is a decimal number from 0 to 65,436.

Default: 100

Example: set adhoc beacon 120 // Beacons are sent every 120 ms

www.rovingnetworks.com Version 1.0r 9/21/2012 10

RN-WIFLYCR-UM

set adhoc probe <value>

This command sets the ad hoc probe timeout in seconds, where <value> is the number of seconds. The probe

timeout is the number of seconds the module waits for probe responses before declaring, “ADHOC is lost,” and

disabling the network interface.

Default: 5

Example: set adhoc probe 80 // Sets the ad hoc probe timeout to 80 s

set broadcast address <address>

This command sets the address to which the UDP hello/heartbeat message is sent, where <address> is an IP address

in the form <value>.<value>.<value>.<value> with <value> being a number between 0 and 255.

Default: 255.255.255.255

Example: set broadcast address 255.255.255.255 // Sets the broadcast address to 255.255.255.255

set broadcast interval <mask>

This command sets the interval at which the hello/heartbeat UDP message is sent and is specified in seconds. The

value is a mask that is ANDed with a free running seconds counter; if the result is all 0s, a packet is sent. For

example:

•If the interval is 0x1, the module sends one packet every 2 seconds.

•If the interval is 0x2. The module sends two packets every 4 seconds.

•If the interval is 0x3, the module sends one packet every 4 seconds.

•If the interval is 0x6, the module sends two packets every 8 seconds.

•If the interval is 0x7, the module sends one packet every 8 seconds.

The minimum interval value is 1 (every 2 seconds) and the maximum value is 0xff (every 256 seconds). Setting the

interval value to zero disables UDP broadcast messages.

Default: 7

Example: set broadcast interval 6 // Sets the heartbeat UDP message interval to 6 seconds

set broadcast port <value>

This commands sets the port to which the UDP hello/heartbeat message is sent, where <value> represents the port

number.

Default: 55555

Example: set broadcast port 55555 // Sets the port to which the UDP heartbeat is sent to

// 55555

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Roving Networks WLAN-Router Handbücher

Roving Networks

Roving Networks WiFly RN-131GSX Installationshandbuch

Beliebte WLAN-Router Handbücher anderer Marken

Milesight

Milesight UG67 Bedienungsanleitung

Airlogic

Airlogic AirSync Class 1 Betriebsanleitung

Samsung

Samsung WCH730B Bedienungsanleitung

TELEFONICA

TELEFONICA USB Adapter Bedienungsanleitung

NETGEAR

NETGEAR PowerLINE WiFi 1000 Series Bedienungsanleitung

Askey

Askey RAC2V1K Bedienungsanleitung

Alloy

Alloy WLF2454AP-S Bedienungsanleitung

TP-Link

TP-Link TL-WR542G Bedienungsanleitung

NETGEAR

NETGEAR WNR2000v4 Bedienungsanleitung

Hama

Hama 53120 Bedienungsanleitung

Intellinet

Intellinet 524582 Bedienungsanleitung

Asus

Asus RT-N10P Bedienungsanleitung

D-Link

D-Link DIR-506L Bedienungsanleitung

Sapido

Sapido GR297n Bedienungsanleitung

Asus

Asus DSL-N55U Bedienungsanleitung

AMTC

AMTC WR7502 Bedienungsanleitung

Compaq

Compaq CP-2W - iPAQ Connection Point Bedienungsanleitung

SMC Networks

SMC Networks WBR14-N2 FICHE Bedienungsanleitung
