Royal Enfield HIMALAYAN BS VI 2021 Bedienungsanleitung

FOREWORD

Thank you for choosing the Royal Enﬁeld Himalayan.

Your new motorcycle is the product born from Royal Enﬁeld’s vast experience of riding in the Himalayas since decades,

from exhaustive testing in all conditions, and our continuous striving for superior reliability and performance.

Please read this Owner’s Manual carefully before riding so that you will be thoroughly familiar with the proper operation

of the Himalayan’s controls, its features and capabilities.

To ensure a long and trouble-free life for your motorcycle, give it the proper care and maintenance described in this manual.

This Owner’s Manual should be considered a permanent part of your motorcycle and should remain with it even if your

motorcycle is subsequently sold.

The Himalayan features a Tripper™ navigation system, powered by Google Maps and the Royal Enﬁeld App. You can use

it to connect your smartphone with the motorcycle through Bluetooth. To use the Tripper™ and to explore the many rides

around you, install the Royal Enﬁeld App and follow the steps to register your Himalayan.

For support and information, please call 18002100007 anytime between 9 AM - 9 PM any day of the week.

—Team Royal Enﬁeld.

2 Royal Enﬁeld Himalayan

NOTICE

Part No. RAM00 333 /B / Qty. 3000 / Sep. 2021 / 10134

Disclaimer

1. Wash the motorcycle only with plain water. Do not use

any cleaning agen ts or det ergents, especially on

painted surfaces, as it will cause discoloration and

damage to the paint.

2. Do not polish your motorcycle as it will increase the

gloss level and damage the paint.

3. Scratches or marks on painted / plastic surfaces cannot

be removed OR touched up.

4. Warranty is not applicable for discoloration of the

Silencer & Exhaust pipe, as it is a natural process that

will happen during usage.

All information in this manual is based on the latest product

information available at the time of publication. Due to

continuous improvements, there may be discrepancies

between the information in this manual and your motorcycle.

Royal Enﬁeld reserves the right to make production changes

at any time without prior notice and without incurring any

obligation to make the same or similar changes to motorcycles

previously built or sold.

All images shown are for reference to explain and need not to

be exactly the same on the model you own. Technical

speciﬁcations are subject to change without prior notice.

distributed or otherwise dealt without th e express

permission in writing of Royal Enﬁeld”.

NOTE:

This motorcycle meets the BS VI Emission Norms

CONTENTS

Personal and Motorcycle Information ................................. 4

Royal Enﬁeld Himalayan

Technical Speciﬁcations ........................................................ 5

Recommended Lubricants ................................................... 12

Safety Deﬁnitions .................................................................. 13

Motorcycle Identiﬁcation Numbers ..................................... 14

Location of Key Parts ............................................................ 15

Operation of Controls .......................................................... 18

Pre-Operational Checks ....................................................... 48

Safe & Happy Riding ............................................................. 49

Cargo & Accessories ............................................................. 53

Rules of the Road .................................................................. 56

Running in Period ................................................................. 59

Warning Indications & Safety Systems ................................. 60

Starting ................................................................................. 64

Gear Shifting, Riding & Stopping ......................................... 66

Environment Care ............................................................. 70

Parking ................................................................................. 68

Periodical Maintenance Chart ......................................... 71

Tools Kit ............................................................................... 78

First Aid Kit ......................................................................... 79

Minor Maintenance Tips ................................................... 80

Long Trip Precautions ....................................................... 107

Shock Absorber .................................................................. 108

Oﬀ Roading ......................................................................... 109

Washing Procedure ........................................................... 111

Storage Precautions .......................................................... 116

Trouble Shooting ................................................................ 118

Warranty Terms & Conditions ......................................... 122

Emission Warranty ............................................................ 126

Service / Maintenance Record ......................................... 131

Notes .................................................................................... 132

4 Royal Enﬁeld Himalayan

PERSONAL & MOTORCYCLE INFORMATION

Name

Door No./Street

Locality/Town

City Country

Contact Res: Oﬀ:

Mobile : Email :

Licence No. Valid Till :

Model Color :

Engine No.

Vin No.

Tyre make Front : Rear :

Tyre Nos. Front : Rear :

Battery make Battery No.

Sold by

Date of Sale

TECHNICAL SPECIFICATIONS

Royal Enﬁeld Himalayan

ENGINE

Engine Type ............. Single Cylinder, 4 Stroke, SOHC,

................................. Air cooled, Fuel Injection

Bore ......................... 78 mm

Stroke ....................... 86 mm

Displacement .......... 410.94 cc

Compression ratio ... 9.5:1

Max Power ............... 24.3 bhp (17.88 kW) @ 6500 rpm

Max Torque .............. 32 Nm @ 4250 + 250 rpm

Idle rpm ................... 1300 + 100 rpm

Starting System ....... Electric Start

Air ﬁlter element ....... Paper element

Lubrication ............... Forced Lubrication, Wet sump

Engine oil capacity ... 2.3 l (Initial ﬁll only),

.................................. 1.6 - 1.8 l (Subsequent Reﬁlls)

Engine oil grade........ SAE 15 W 50 API SL Grade

.................................. JASO MA 2 Semi Synthetic

Cooling ..................... Air cooled with Oil cooler

IGNITION SYSTEM

Ignition system ......... Electronic ECU / Variable

Spark plug ................. Bosch - UR5CC

Spark plug gap .......... 0.7 to 0.8 mm

6 Royal Enﬁeld Himalayan

TRANSMISSION

Clutch ....................... Wet Multi Plates

Primary drive ............ Gear

Primary ratio ............. 2.312:1

Gear box ................... 5 Speed, Constant Mesh

Gear Ratios

1st Gear ................ 1 2.916:1

TECHNICAL SPECIFICATIONS

2nd Gear ............. 2 1.833:1

3rd Gear .............. 3 1.428:1

4th Gear .............. 4 1.173:1

5th Gear .............. 5 1.000:1

Secondary Drive ....... 5/8” Chain & Sprocket

Secondary Ratio ....... 2.533:1

Drive Chain links ....... 110 links

TECHNICAL SPECIFICATIONS

CHASSIS

Royal Enﬁeld Himalayan

Frame ........................ Half duplex split cradle

Suspension

Front .................. Telescopic, Hydraulic Damping,

........................... Front wheel travel : 200 mm

Rear ................... Swing arm with Linkage type

........................... Hydraulic damping Mono shock,

........................... Rear wheel travel : 180 mm

Brakes

Brake system ..... Dual Channel ABS (Switchable

........................... to Single channel ABS -

........................... Rear Wheel ABS control

........................... deactivation)

Front Disc .......... 300 mm Dia disc.

Rear Disc ........... 240 mm Dia disc.

Tyre size

Front .................. 90 / 90 - 21

Rear ................... 120 / 90 - 17

8 Royal Enﬁeld Himalayan

TECHNICAL SPECIFICATIONS

Steering lock ............. In built

Fuel Type .................. Unleaded Gasoline

CAUTION

Ethanol Content ....... E10 or less

The use of petrol containing more than the speciﬁed

ethanol may cause the fuel tank corrosion & paint

damage and may also damage the rubber tubes in the

fuel line as well.

nIt is recommended to use only unleaded petrol, as

leaded petrol may cause damage to the catalytic

converter.

Tyre Pressures

Solo

Front ................... 25 psi / 1.75 kg/cm

Rear ..................... 32 psi / 2.25 kg/cm

With Pillion

Front ................... 27 psi / 1.89 kg/cm

Rear ..................... 34 psi / 2.39 kg/cm
