RTI ZRP-6 Betriebsanleitung
1
It’s Under Control®
ZRP-6
Installation and Operation Guide
70-210058-23 V1.1
Remote Control Processor
It’s Under Control®
Remote Control Processor
ZRP-6
2
Copyright © 2010
Remote Technologies Incorporated
All rights reserved.
3
It’s Under Control®
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference
in a residential installation.
This equipment generates, uses, and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference by one or more of
the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and the receiver.
Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician
for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to
the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received including
interference that may cause undesired operation.
FEDERAL COMMUNICATIONS COMMISSION NOTICE
117 612 914
DECLARATION OF CONFORMITY (DOC)
The Declaration of Conformity for this product can be found on the RTI
website at: www.rticorp.com/declaration
Remote Control Processor
ZRP-6
4
Read Instructions. Read all safety and operating instructions before
operating the unit.
Retain Instructions. Keep the safety and operating instructions for
future reference.
Heed Warnings. Adhere to all warnings on the unit and in the
operating instructions.
Follow Instructions. Follow operating instructions and instructions
for use.
Heat. Keep the unit away from heat sources such as radiators, heat
registers, stoves, etc., including ampliers that produce heat.
Power Sources. Connect only to the power supply that was included
with the unit.
Power Cord Protection. Route power supply cords so that they are
not likely to be walked on or pinched by items placed on or against
them, paying particular attention to the cords at plugs, at convenient
receptacles, and at the point at which they exit from the unit.
Water and Moisture. Do not use the unit near water—for example,
near a sink, in a wet basement, near a swimming pool, near an open
window, etc.
Object and Liquid Entry. Do not allow objects to fall or liquids to be
spilled into the enclosure through openings.
Cleaning. The unit should be cleaned only as recommended in this
installation and operation guide.
Servicing. Do not attempt any service beyond that described in
the operating instructions. Refer all other service needs to qualied
service personnel.
Damage Requiring Service. The unit should be serviced by qualied
service personnel when:
Objects have fallen or liquid has been spilled into the unit.
The power supply cord or the plug has been damaged.
The unit does not appear to operate normally or exhibits a
marked change in performance.
The unit has been dropped or the enclosure has been damaged.
WARNING!
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK,
DO NOT EXPOSE THE UNIT TO RAIN OR MOISTURE.
SAFETY SUGGESTIONS
5
It’s Under Control®
Remote Technologies Incorporated warrants its products for a period of one
(1) year from the date of purchase from Remote Technologies Incorporated
or an authorized Remote Technologies Incorporated distributor.
This warranty may be enforced by the original purchaser and subsequent
owners during the warranty period, so long as the original dated sales
receipt or other proof of warranty coverage is presented when warranty
service is required. Except as specied below, this warranty covers all
defects in material and workmanship in this product. The following are not
covered by the warranty:
Damage resulting from:
1. Accident, misuse, abuse, or neglect.
2. Failure to follow instructions contained in this Guide.
3. Repair or attempted repair by anyone other than Remote Technologies
Incorporated.
4. Failure to perform recommended periodic maintenance.
5. Causes other than product defects, including lack of skill, competence
or experience of user.
6. Shipment of this product (claims must be made to the carrier).
7. Being altered or which the serial number has been defaced, modied
or removed.
Remote Technologies Incorporated is not liable for any damages caused by
its products or for its failure of its products to perform, including any lost
prots, lost savings, incidental damages, or consequential damages.
Remote Technologies Incorporated is not liable for damages based upon
inconvenience, loss of use of the product, loss of time, interrupted
operation, commercial loss, any claim made by a third party or made by
you for a third party.
Remote Technologies Incorporated’s liability for any defective product is
limited to repair or replacement of the product, at our option.
If your ZRP-6 Remote Control Processor needs service, please contact
Remote Technologies Incorporated by telephone, fax or E-mail for return
information. Please do not return products to Remote Technologies
Incorporated without return authorization.
LIMITED WARRANTY
Remote Control Processor
ZRP-6
6
DISCLAIMER
All rights are reserved. No part of this document may be photocopied,
reproduced, or translated without the prior written notice of Remote
Technologies Incorporated.
The information contained in this document is subject to change without
notice. Remote Technologies Incorporated shall not be liable for errors or
omissions contained herein or for consequential damages in connection with
the furnishing, performance, or use of this guide.
Microsoft, Windows, Windows XP, Windows Vista and Windows 7 are registered
trademarks of Microsoft Corporation in the United States and other countries.
ZigBee is a registered trademark of the ZigBee Alliance.
ZRP-6, Integration Designer, and the RTI logo are registered trademarks of
Remote Technologies Incorporated.
Other brands and their products are trademarks or registered trademarks of
their respective holders.
7
It’s Under Control®
Federal Communications Commission Notice...............3
Safety Suggestions......................................................4
Limited Warranty ........................................................5
Disclaimer ...................................................................6
Contents......................................................................7
Chapter 1 - Welcome ...................................................9
Important Notes ...................................................... 9
Product Contents, Unpacking.................................... 10
Chapter 2 - Features................................................... 11
Chapter 3 - Installation and Operation .......................13
Chapter 4 - Specications...........................................21
Chapter 5 - Troubleshooting.......................................23
Chapter 6 - Service and Support.................................25
Index ......................................................................... 27
TABLE OF CONTENTS
Remote Control Processor
ZRP-6
8
9
It’s Under Control®
Thank you for using the ZRP-6 Remote Control Processor.
The second generation of the award-winning RP-6 Control Processor, the
ZRP-6 raises the level of automation capabilities of any electronics system.
Loaded with features to provide sophisticated control, the ZRP-6 has
built-in IR routing and pass-through, relay control, 12VDC trigger outputs,
voltage sense inputs and Ethernet for program updating. The addition
of two dedicated RS-232 ports allows bi-directional communication from
compatible devices for status feedback such as lighting and volume levels.
Finally, the ZRP-6 stores all of the systems commands for more reliable
macro execution and powerful automation.
The ZRP-6 is the ideal centerpiece for any control system. While the ZRP-6
continues to support communication from RTI 433MHz RF receivers and in-
wall controllers, the next generation of control is at your ngertips when it
is used with separate RTI 2.4GHz transceiver modules (ZM-24) and remote
controls (utilizing ZigBee®mesh network technology).
IMPORTANT NOTES
Please read these important notes about the ZRP-6:
The ZRP-6 should be placed in an area where it is around normal room
temperature (between 60°F to 90°F).
Avoid installing the ZRP-6 in a location where it can come in contact
with direct sunlight.
Do not let the ZRP-6 get wet. It should not be handled with wet hands
or placed in an area where it could get wet.
Do not subject the ZRP-6 to smoke, dust, or vibrations.
Only use the power supply that is specied for the ZRP-6. Using the
wrong type of power supply may result in damage.
Do not disassemble the unit. Service of the ZRP-6 should be
performed by authorized personnel only.
COMPATIBILITY
An IR input insures compatibility with all RTI in-wall and handheld
controllers as well as industry standard IR repeater systems.
SOFTWARE REQUIREMENTS
The recommended minimum system requirements needed to run the
Integration Designer®software are as follows:
Windows XP®, Windows Vista®, Windows 7®or later version of Microsoft
operating system.
CHAPTER 1 | WELCOME
Remote Control Processor
ZRP-6
10
Contents within the box include the following items:
One (1) ZRP-6 Remote Control Processor
• One (1) Installation Guide
• One (1) Universal Power Supply
• One (1) Power Cord
• Two (2) RS-232 adapters
UNPACKING AND INSPECTION
After unpacking your new ZRP-6 Remote Control Processor, save all of the
packing materials in case you ever have to ship the unit.
Thoroughly inspect the ZRP-6 and packing materials for signs of damage.
Report any damage to the carrier immediately. Report any equipment
malfunctions to RTI or an authorized RTI distributor.
CHAPTER 1 | PRODUCT CONTENTS
