July 2006 Rev B

XCP-955

Breakout Panel Technical Guide

LIT000021

CHAPTER 1

XCP-955

8800303674

The XCP-955 is the 25-port RJ-11 breakout panel with SCSI

connector for the ADAM.

Specifications

Dimensions:

18.98” (482mm) L x 1.69” (43mm) H x 0.55” (104mm) D

Weight:

1.6 lb (.725 kg)

J28

DATA

J27

AUDIO DESTINATION

J26

AUDIO SOURCE

XCP-955

RTS SYSTEMS

RJ-12 Connector

Pin 1 Keypanel Data -

Pin 2 Audio Out +

Pin 3 Audio In +

Pin 4 Audio In -

Pin 5 Audio Out -

Pin 6 Keypanel Data +

XCP-955 8800303674

Telco Backcard - Telco Connector - J26

Number Port Function

1 1 Audio From Matrix +

26 1 Audio From Matrix -

2 2 Audio From Matrix +

27 2 Audio From Matrix -

3 3 Audio From Matrix +

28 3 Audio From Matrix -

4 4 Audio From Matrix +

29 4 Audio From Matrix -

5 5 Audio From Matrix +

30 5 Audio From Matrix -

6 6 Audio From Matrix +

31 6 Audio From Matrix -

7 7 Audio From Matrix +

32 7 Audio From Matrix -

8 8 Audio From Matrix +

33 8 Audio From Matrix -

9 9 Audio From Matrix +

34 9 Audio From Matrix -

10 10 Audio From Matrix +

35 10 Audio From Matrix -

11 11 Audio From Matrix +

36 11 Audio From Matrix -

12 12 Audio From Matrix +

37 12 Audio From Matrix -

13 13 Audio From Matrix +

38 13 Audio From Matrix -

14 14 Audio From Matrix +

39 14 Audio From Matrix -

15 15 Audio From Matrix +

40 15 Audio From Matrix -

16 16 Audio From Matrix +

41 16 Audio From Matrix -

17 17 Audio From Matrix +

42 17 Audio From Matrix -

18 18 Audio From Matrix +

43 18 Audio From Matrix -

19 19 Audio From Matrix +

44 19 Audio From Matrix -

20 20 Audio From Matrix +

45 20 Audio From Matrix -

21 21 Audio From Matrix +

46 21 Audio From Matrix -

22 22 Audio From Matrix +

47 22 Audio From Matrix -

23 23 Audio From Matrix +

48 23 Audio From Matrix -

24 24 Audio From Matrix +

49 24 Audio From Matrix -

Telco Backcard - Telco Connector - J27

Number Port Function

11AudioToMatrix+

26 1 Audio To Matrix -

22AudioToMatrix+

27 2 Audio To Matrix -

33AudioToMatrix+

28 3 Audio To Matrix -

44AudioToMatrix+

Telco Backcard - Telco Connector - J26

Number Port Function

Specifications

29 4 Audio To Matrix -

5 5 Audio To Matrix +

30 5 Audio To Matrix -

6 6 Audio To Matrix +

31 6 Audio To Matrix -

7 7 Audio To Matrix +

32 7 Audio To Matrix -

8 8 Audio To Matrix +

33 8 Audio To Matrix -

9 9 Audio To Matrix +

34 9 Audio To Matrix -

10 10 Audio To Matrix +

35 10 Audio To Matrix -

11 11 Audio To Matrix +

36 11 Audio To Matrix -

12 12 Audio To Matrix +

37 12 Audio To Matrix -

13 13 Audio To Matrix +

38 13 Audio To Matrix -

14 14 Audio To Matrix +

39 14 Audio To Matrix -

15 15 Audio To Matrix +

40 15 Audio To Matrix -

16 16 Audio To Matrix +

41 16 Audio To Matrix -

17 17 Audio To Matrix +

42 17 Audio To Matrix -

18 18 Audio To Matrix +

43 18 Audio To Matrix -

Telco Backcard - Telco Connector - J27

Number Port Function

19 19 Audio To Matrix +

44 19 Audio To Matrix -

20 20 Audio To Matrix +

45 20 Audio To Matrix -

21 21 Audio To Matrix +

46 21 Audio To Matrix -

22 22 Audio To Matrix +

47 22 Audio To Matrix -

23 23 Audio To Matrix +

48 23 Audio To Matrix -

24 24 Audio To Matrix +

49 24 Audio To Matrix -

Telco Backcard - Telco Connector - J28

Number Port Function

1-8 1-8 Data +

25-33 1-8 Data -

9-16 9-16 Data +

34-41 9-16 Data -

17-24 17-24 Data +

42-49 17-24 Data -

Telco Backcard - Telco Connector - J27

Number Port Function

XCP-955 8800303674
