Russell Hobbs 22000 Bedienungsanleitung

£10,000 prize draw

EXTRA year guarantee

FREE rewards gallery

www.productregister.co.uk/rhobbs

See back for

details

instructions

Read the instructions, keep them safe, pass them on if you pass the appliance on.

Remove all packaging before use.

A IMPORTANT SAFEGUARDS

Follow basic safety precautions, including:

1 This appliance can be used by persons with reduced physical,

sensory or mental capabilities or lack of experience and

knowledge if they have been supervised/instructed and

understand the hazards involved.

•Children must not use or play with the appliance.

•Keep the appliance and cable out of reach of children.

lDon’t immerse the appliance in liquid.

h The surfaces of the appliance will get hot.

2 Unplug the appliance before assembly, disassembly, or cleaning.

3 Don’t leave the appliance unattended while plugged in.

4 If the cable is damaged, return the appliance, to avoid hazard.

5 Sit the appliance on a stable, level, heat-resistant surface.

6 Fill with at least 2 cups of water, but not above the max mark.

7 There’s a hole in the rear wall of the reservoir, to prevent overﬁlling.

8 Put the carafe on the hotplate before switching the appliance on.

9 Let the appliance cool for about 10 minutes before adding water or re-using, to

avoid spitting.

10 Don’t put the carafe in a microwave oven.

11 Don’t try to adjust the metal band round the carafe, you’ll break the glass.

12 Don’t use accessories or attachments other than those we supply.

13 Don’t use the appliance for any purpose other than those described in these

instructions.

14 Don’t use the appliance if it’s damaged or malfunctions.

household use only

U BEFORE USING FOR THE FIRST TIME

1 Fill the reservoir to the max mark, and run the appliance without coﬀee.

2 Let it cool, discard the water, then use it normally.

C GROUND COFFEE

3 If you want to buy ready-ground coﬀee, medium-ground ﬁlter coﬀee will give you

the best results.

C PREPARATION

4 Sit the appliance on a stable, level, heat-resistant surface.

5 Route the cable so it doesn’t overhang, and can’t be tripped over or caught.

6 Don’t plug it in yet.

C FILLING

7 Remove the carafe from the hotplate.

8 Open the reservoir lid.

9 Fill with the exact amount of water you need

a) use at least 2 cups of water if you’re using ground coﬀee

b) use at least 4 cups of water if you’re using coﬀee beans

c) don’t ﬁll above the max mark

10 Close the reservoir lid.

11 Squeeze the catch into the end of the ﬁlter lid, and open it fully.

12 Put the exact amount of coﬀee into the ﬁlter/grinder:

a) use 1 level tablespoonful of ground coﬀee for each cup

b) use 1 heaped tablespoonful of whole beans for each cup

c) The number of tablespoons of coﬀee must match the number of cups of water

13 Close the ﬁlter lid, and press down to engage the catch.

C SWITCH ON

14 Replace the carafe on the hotplate

15 Put the plug into the power socket.

•The display will glow, showing 12:00 blinking and W+ 12 (coﬀee beans/12 cups).

C COFFEE NOW

16 Ignore the display.

17 Use the Wbutton to cycle the bottom of the display to the grind setting you need:

X= you’re using ground coﬀee

W+ 4, 6, 8, 10, or 12 = you’re using coﬀee beans + the number of cups/tablespoons

18 Press the 1button.

•If you’re using coﬀee beans, the grinder will operate.

19 Shortly afterwards, coﬀee will start to drip into the carafe.

20 When it’s done, the hotplate will keep the carafe warm.

21 The display will count up, to show how long the keep warm function has been

operating. After a set time, the heater will switch oﬀ, display will stop glowing, and

the appliance will go into standby mode.

•The default keep warm time is 40 minutes. You may change this – see below.

22 After about 40 minutes, chemical changes will aﬀect the ﬂavour. It’s best to make a

fresh pot.

C COFFEE LATER

23 Set the clock to the correct time:

a) Use the hand min buttons to set the correct hour and minute.

b) It’s a 12 hour clock – the display shows PM for afternoon.

c) If you overshoot, you can’t step back.

d) The clock will retain its settings until the appliance is unplugged.

24 Set the timer to the time you want to start brewing.

a) Press the Tbutton and hold it for 3 seconds.

b) The display will show Tblinking.

c) If you don’t press anything for 5 seconds, the display will revert to normal – you’ll

have to press the Tbutton, and start again.

d) Use the hand min buttons to set the correct hour and minute.

e) When you’ve set the time, wait 5 seconds, and the display will revert to normal

C ACTIVATION

25 Press the cbutton to activate the timer.

•The display will show Y, to indicate that the timer is active.

C KEEP WARM TIME

26 The default keep warm time is 40 minutes.

27 To change this, press the Ybutton, and hold it in for 3 seconds.

•The display will show the current keep warm time.

28 Use the min button to choose the keep warm time you want – the options are 00, 20,

30, and 40 minutes after brewing has ﬁnished.

29 Press the Ybutton again, to activate your choice.

C BREW STRENGTH

30 Use this feature if you prefer your coﬀee a bit stronger. It slows the brewing process,

lengthening the time the water is in contact with the coﬀee.

31 Use the Zbutton to choose the setting you want – the setting shows in the

bottom right corner of the display:

blank = normal strength(the default setting)

b = stronger

a = even stronger

,If you want to change these settings, you should do so before making coﬀee.

C A QUICK CUP

32 If you want a quick cup of coﬀee before the brewing cycle has ﬁnished:

33 You may remove the carafe at any time. The non-drip valve will prevent coﬀee

dripping on to the hotplate.

34 To prevent the ﬁlter holder overﬂowing, replace the carafe on the hotplate within

about 20 seconds. This may not sound much, but you’ll ﬁnd it’s more than enough

time to pour a couple of cups of coﬀee.

35 Replacing the carafe on the hotplate opens the non-drip valve, to let the coﬀee ﬂow

again.

C CARE AND MAINTENANCE

1 Unplug the appliance and let it cool down before cleaning or storing away.

2 Tip the contents of the ﬁlter into the bin.

3 You may clean the carafe, ﬁlter, and ﬁlter holder in warm soapy water. Rinse

thoroughly afterwards, to remove all traces of soap.

4 Clean the outside surfaces of the appliance with a damp cloth.

5 Clean the inside of the coﬀee mill with a pastry brush.

6 Don’t put any part of the appliance in a dishwasher.

9 Don’t use harsh or abrasive cleaning agents or solvents.

C DESCALING

10 Scale build-up will cause the element to overheat, reducing its working life. It will

also lengthen the brewing time.

11 Descale regularly, at least once a month. If you notice the brewing time getting

longer, shorten the time between descalings. In areas of very hard water it may be

necessary to descale more often, or to use ﬁltered water instead of ordinary tap

water.

12 Use a proprietary brand of descaler suitable for use in plastic-bodied products.

Follow the instructions on the package of descaler. After descaling, run the

appliance twice with fresh water, but without coﬀee, to rinse out any chemical

residues.

R23 descaler, formulated specially for our products, is available online

(back page).

, Products returned under guarantee with faults due to scale will be subject to a

repair charge.

552-783

WENVIRONMENTAL PROTECTION

To avoid environmental and health problems due to hazardous substances in

electrical and electronic goods, appliances marked with this symbol mustn’t be

disposed of with unsorted municipal waste, but recovered, reused, or recycled.

SSERVICE

If you ring Customer Service, please have the Model No. to hand, as we won’t be able

to help you without it. It’s on the rating plate (usually underneath the product).

The product isn’t user-serviceable. If it’s not working, read the instructions, check the

plug fuse and main fuse/circuit breaker. If it’s still not working, consult your retailer.

If that doesn’t solve the problem – ring Customer Service – they may be able to oﬀer

technical advice.

If they advise you to return the product to us, pack it carefully, include a note with your

name, address, day phone number, and what’s wrong. If under guarantee, say where

and when purchased, and include proof of purchase (till receipt). Send it to:

Customer Service

Spectrum Brands (UK) Ltd

Fir Street, Failsworth, Manchester M35 0HS

email: support@russellhobbs.com

telephone: 0845 658 9700 (local rate number)

EGUARANTEE

Defects aﬀecting product functionality appearing within two years of ﬁrst retail

purchase will be corrected by replacement or repair provided the product is used and

maintained in accordance with the instructions. Your statutory rights are not aﬀected.

Documentation, packaging, and product speciﬁcations may change without notice.

JONLINE/SPARES

www.russellhobbs.co.uk for more products and/or spares

IREGISTER ONLINE FOR –

r£10,000 prize draw,

EXTRA year guarantee,

FREE rewards gallery

Visit www.productregister.co.uk/rhobbs

You must register within 28 days of purchase.
