SAFARI Montage T-440x Bedienungsanleitung

Visual Learning Served On Demand™

T-440x Tower Server

Installation Guide

Welcome to SAFARI Montage®!

Thank you for choosing the SAFARI Montage Video-On-Demand and Digital Media Management system.

In just a few steps, you’ll have access to fully segmented programs from the ﬁnest educational publishers –

from anywhere on your network. This setup guide covers the following SAFARI Montage server models:

T-440x

Step 1

Step 2

Power Cord Keys (2)

(Styles may vary)

Ethernet Cable

Positioning the SAFARI Montage Server

Place the tower on a sturdy, dry surface near a power source and Ethernet

connection. There should be adequate airﬂow around the server, with temperatures

not exceeding 95ºF.

Unpacking the Hardware

Carefully remove the SAFARI Montage server and the following items from the box,

and place them on a ﬂat surface. If you are missing any of the items below, please

call 1.800.843.4549.

Step 3 Connecting Your SAFARI Montage Server

a. Using the image below as a guide, ﬁrst connect the server to the network by

plugging an Ethernet cable into any active Ethernet port on your network.

b. Connect a monitor and keyboard to the server.

c. Connect the power cord from the back of the server into a grounded outlet. We

highly recommend connecting it to an uninterrupted power supply (UPS).

Note: Please see your hardware warranty for terms related to your server’s

environmental conditions and electrical power.

Monitor

Keyboard

Network

Rear View of the T-440x

Power

Step 4

Step 5 Networking Your SAFARI Montage Server

Access the SAFARI Montage console via the monitor and keyboard that you

connected in Step 3.

1. Choose Option 1, “Networks Settings...”

2. Choose Option 2, Network Cards (IP Address)...

3. Choose the option number associated to the active NIC card.

Once the unit’s boot sequence has completed, the SAFARI Montage console

menu will appear.

Powering Up Your SAFARI Montage Server

Now that the cables have been connected, you can power up the server.

Remove the bezel from the front of the server by unlocking it with the key provided

and press the power button located on the front of the rack-mount server.

T-440x

Power

3. If you chose option 2, enter the appropriate network settings for this device. If you

are assigning SAFARI Montage a static IP, that IP must not be in use by any other

device on your network. You must also ensure that SAFARI Montage has valid DNS

addresses, or the server will not be able to activate.

Assigning an IP address:

1. To assign SAFARI Montage a static IP address, choose option 1, “IP Address (Static)”

and skip to (3).

2. To have SAFARI Montage acquire an IP address automatically, choose option 2, “IP

Address (DHCP).” SAFARI Montage will acquire the required network settings from

your DHCP host. Skip to step 6 on the next page.

Username: admin Password: admin

Step 6

on ”Log in”:

We recommend that you change your administrative account password after the

initial sign on.

Congratulations!

You have completed the basic installation. Your digital content has been pre-

activated and is ready to access.

Now that you are logged in, a great place to get started

is with the Interactive Video Tutorial. The User’s Guide and

the Administrator’s Guide are accessible through the SAFARI

Montage “Help” section, and in the Support section at www.SAFARIMontage.com.

Accessing the SAFARI Montage User Interface

Launch a web browser (e.g., Internet Explorer) from any workstation on

your network.

Enter the URL for your SAFARI Montage server into the address bar, and hit ”enter”

(or ”return” if you are using a Mac). Obtain this URL from your

Network Administrator if necessary.

800.843.4549 • SAFARIMontage.com

PO Box 580, Wynnewood, PA 19096

Troubleshooting

If you have any difﬁculties with installation or need further information, please visit

www.SAFARIMontage.com/support or call a support representative at 800.782.7230.

When calling, please have your server’s serial number available. Your serial

number can be found in the Help > About section of the SAFARI Montage

application and on the back of your server.

Serial Number:

Hostname/URL:

Date Installed:

Additional Content

If you are interested in purchasing additional SAFARI Montage

products or digital content packages, please visit

www.SAFARIMontage.com or contact your sales representative.

NOTICE:

The information in this installation guide is subject to change without notice.

Library Video Company reserves the right to modify the design of its products

and change the information in this installation guide.
