Sagem B2005 Leitfaden

SITE TECHNICAL DOCUMENTATION

B2005

Doc. No. : MTB DTS 2

Version : A

Date : December 21 2005

Produced by SAGEM COMMUNICATION GROUPE SAFRAN

ZI NORD Chemin de Baillot, BP 357, 82003 Montauban cedex, France

Tel (33) 5 63 21 21 21 - Fax (33) 5 63 21 21 54

SAGEM

Montauban, France

Contents REF MTB DTS 2- Indice A - December 21 2005 Page 1

Site technical documentation B2005

Contents REF MTB DTS 2- Indice A - December 21 2005 Page 2

Site technical documentation B2005

CONFIDENTIALITY

This document is SAGEM's limited company property. It can not be reproduced or communicated without the

written license.

Contents REF MTB DTS 2- Indice A - December 21 2005 Page 3

Site technical documentation B2005

Contents

CHAPTER 1 - FOREWORD

1-1 HOW TO USE THE SITE TECHNICAL DOCUMENTATION

1-1-1 Use

1-2 ABREVIATIONS

1-3 COMMENTS SHEET

CHAPTER 2 - DESCRIPTION - OPERATION

2-1 REMINDERS ABOUT THE GENERAL CHARACTERISTICS OF GSM AND PCS NETWORKS

2-2 REMINDERS ABOUT THE HAND SET CHARACTERISTICS

2-3 IN & OUT CONNECTOR

2-3-1 Connector description

2-3-2 Signal description

2-4 IDENTIFICATION

2-4-1 Illustration

2-4-2 Description

2-4-3 Description after reparation

2-5 PHONE BLOCK DIAGRAMS

2-5-1 Block diagram

2-5-2 Standards and environment

2-6 EQUIPMENTS

2-6-1 Battery packs

2-6-1-1 Charactéristics

2-6-1-2 Description

2-6-1-3 Charging time

2-6-2 Mains modules

2-6-2-1 Description

2-6-2-2 Travel mains modules

2-6-2-3 Simple mains modules

CHAPTER 3 - SYMPTOMS

3-1 GENERAL

3-2 LIST OF REPORTED DEFECTS

3-3 ERROR MESSAGES DURING START UP

3-4 OTHER ERROR MESSAGES

3-5 LIST OF OBSERVED DEFECTS

3-6 INFORMATION ABOUT NEW NOTICED FAULTS

SYMPTOM SHEETS

CHAPTER 4 - TESTS AND CHECKS

4-1 GENERAL ABOUT TESTS

4-2 TEST TOOLS

4-3 INSTALLING ON A WORKSTATION (SMT STATION)

4-3-1 Minimum required configuration

4-3-2 Installing the cra downloading kit

4-3-3 Smt functions

Contents REF MTB DTS 2- Indice A - December 21 2005 Page 4

Site technical documentation B2005

TEST SHEETS

CHAPTER 5 - MAINTENANCE PROCEDURES

5-1 TECHNICAL WORK LEVELS

5-2 SHORT LOOP PROCESS

5-3 MAINTENANCE TOOLS

PROCEDURE SHEETS

CHAPTER 6 - ACCESSORIES

6-1 PEDESTRIAN HANDSFREE KIT

6-1-1 Description

6-1-2 Charactéristics

6-2 DATA CABLE PC USB

6-2-1 Description

6-2-2 Charactéristics

6-3 6-3-1 Description

CHAPTER 7 - TECHNICAL INFORMATION BULLETIN

7-1 PURPOSE

7-2 APPLICATION

CHAPTER 8 - ILLUSTRATED PARTS CATALOG

8-1 SPARE PARTS

INDEX

Contents REF MTB DTS 2- Indice A - December 21 2005 Page 5

Site technical documentation B2005

CHAPTER 1 - FOREWORD

This document is common to all B2005 phones in the SAGEM. It is composed of independent

sheets:

-Symptom sheets = Symp Sheet XX

-Test and check sheet= Test Sheet XX

-Maintenance procedure sheet= Proc Sheet X XX

The applicability of a procedure is indicated in the independent sheets title block.

These sheets are updated from time to time in Technical Information Bulletins (TIB).

The information contained in this document is non-contractual, since phone characteristics can

change.

Phones are managed based on SAGEM handset codes; any order for spare parts must refer to

these codes (typical code 25 xxx xxx-x).

1.1 HOW TO USE THE SITE TECHNICAL DOCUMENTATION

This is a modular document. Each sheet is single and independent. In some cases several sheets

may have to be used in order to determine the complete procedure to be applied.

A troubleshooting chapter (chapter 3) is provided and is sorted according to the type of reported

fault, to determine the maintenance procedure to be carried out.

These sheets describe the procedure to be followed. They refer to test sheets or removal and

replacement maintenance sheets. Maintenance ,executed by the repair center, terminates either by

returning the product to the customer, or by dispatching it to level 3 maintenance (return to factory).

The procedure sheets have not systematically consecutive numbers ,but always in a growing

order.

Symp Sheet (Chap. 3)

Test Sheet (Chap. 4)

Proc Sheet (Chap. 5)

Test Sheet (Chap. 4)

Customers

Symptoms

Maintenance

Tests

Checks

Return to SAGEM

level 3

level 0-1-2

All sheets include illustrations to make it easier to read the procedure.

Chapter 1: Foreword, describes general data about this document.

Contents REF MTB DTS 2- Indice A - December 21 2005 Page 1-1

Site technical documentation B2005

Chapter 2: Description - Operation, describes general data and options available in the B2005.

Chapter 3: Symptoms, contains troubleshooting procedures to be carried out on equipment.

Chapter 4: Tests and checks, contains tests and check procedures to be performed on the

equipment.

Chapter 5: Maintenance procedures, contains level 0 to 2 maintenance procedures to be carried out

on the equipment, and the procedure to return to SAGEM level 3.



Chapter 6: Accessories, describes the characteristics of accessories for B2005 phones.



Chapter 7: Technical Information Bulletins, contains the various modifications made to this

documentation.



Chapter 8: Illustrated Parts Catalogue, contains the various reference for spare parts.

1.1.1 Use

The DTS can be used by means of computer or by paper medium

-For circulation on the DTS one can use the contents which consists of bonds hypertext, and in

bottom of each page, one finds a bond which makes it possible to return until the contents.

-For the paper use an index east provides on last page which indicates the numbers of pages of

each heading.

1.2 ABREVIATIONS

AAC Advanced Audio Codeur

ADPCM Adaptive Differential Pulse Codec Modulation

ALS Alternative Line Services

AOC Advice Of Charge

CCD Charged Coupled Device

CLI Calling Line Identification

CLIP Calling Line Identification Presentation

CSTN Colored Super Twisted Nematic

DCS Digital Cellular System

EFR Enhanced Full Rate

EMS Enhanced Message Service

FDN Fixe dial number

GPRS General Packet Radio Service

GSM Global System for Mobile

IMEI Internationnal Mobile Equipment Identity

ISO International Standard Organisation

LCD Liquid Crystal Display

LU Livret d'Utilisation

MMS Multimedia Message Service

PCS Personnal Communication Service

PIN Personal Identity Number

Contents REF MTB DTS 2- Indice A - December 21 2005 Page 1-2

Site technical documentation B2005

PUK PIN Unlocking key

RF Radio Frequence

SAR Specific Absortion Rate

SIM Subscriber Identity Module

SMS Short Message Service

SMS CB Short Message Service Cell Broadcast

SMT Sagem Mobile Tools

TFT Thin Film Transistor

USSD Unstructured Supplementary Service Data

VGA Video Graphics Array

WAP Wireless Application Protocol

WiFi Wireless Fidelity

WSP Wireless Session Protocol

1.3COMMENTS SHEET

Broad experience is very beneficial in several respects. Please let us know your comments so that

we can improve the contents and presentation of this document.

Your suggestions will be read carefully by :

-the design laboratory,

-production,

-the purchasing department,

-the after sales service,

-all users of this document.

All your suggestions are valuable, they will help us to better satisfy you.

Please photocopy and fill in the sheet 1-4.

Contents REF MTB DTS 2- Indice A - December 21 2005 Page 1-3

Site technical documentation B2005

Document title:6LWH7HFKQLFDO'RFXPHQW

Reference :

Date :

Please fill in the following table :

([FHOOHQW *RRG )DLUO\JRRG 3DVVDEOH

Easy to find the required information

Clarity of information provided

Quality and accuracy of information given

Document outline

Document presentation and appearance

Quality of illustrations

General satisfaction

Do you think this document could be improved ? if so, how ? :

Improve the overall view

Improve the table of contents

Improve the structure

Add illustrations

Add details

Add information

Comments : __________________________________________________________________

____________________________________________________________________________

_____________________________________________________________

Would you like to discuss the problems mentioned in this questionnaire? If so, state :

Name of the person to be contacted : ________________________ Phone

: ________________

Company : _____________________________________________ Date

: _________________

Address : ________________________________________________________________

7+$1.<28)253$57,&,3$7,1*,17+,6(148,5<<285&2 (176:,//+(/386

&217,18(72, 3529(7+(48$/,7<2)285'2&8 (17$7,21$1'7+86%(77(5

6$7,6)<<2851(('6

When you have filled in this questionnaire, please send it :

- by mail, to 6$*( 6$

&+( ,1'(%$,//27%3

 217$8%$1&('(;

)5$1&(

<28&$1&217$&78621FUDPRELOH#VDJHPFRP

Contents REF MTB DTS 2- Indice A - December 21 2005 Page 1-4

Site technical documentation B2005

CHAPTER 2 - DESCRIPTION - OPERATION

2.1 REMINDERS ABOUT THE GENERAL CHARACTERISTICS OF GSM 900, DCS 1800 and PCS

1900

Table 1 below gives the characteristics of the radio interface for the GSM 900, DCS 1800 and

PCS 1900 systems :

*60 '&6 3&6

Frequency Band (MHz) 880 - 915

925 - 960 1710 - 1785

1805 - 1880 1850 - 1910

1930 - 1990

Number of time intervals per

TDMA frame 8

Width 2 x W simplex (MHz) 2 x 25 2 x 75 2 x 60

Duplex spacing (MHz) 45 95 80

Modulation speed (kbit/s) 271

Speech throughput (kbit/s) 13 (5,6)

Maximum data throughput (kbit/s) 12

Multiple access Frequency and temporal multiplexing / frequency

duplexing

Cell radius (km) 0,3 to 30 0,1 to 4 0,1 to 4

SAGEM terminal power (W) 2 1 1

7DEOH5DGLR,QWHUIDFH

Table 2 shows powers as a function of the network:

*60 '&6 3&6

Class

number Maximum

nominal

power (W)

Allowable

interval

(W)

Maximum

nominal

power (W)

Allowable

interval

(W)

Maximum

nominal

power (W)

Allowable

interval

(W)

1 - - 1 [0,63 ; 1,6] 1

2 8 [5,0 ; 12,7] 0,25 [0,16 ; 0,4] 0,25

3 5 [3,2 ; 7,9] 4 [2,5 ; 6,3] 2

4 2 [1,3 ; 3,2]

5 0,8 [0,5 ; 1,3]

7DEOH7HUPLQDOVSR HUFODVV

Contents REF MTB DTS 2- Indice A - December 21 2005 Page 2-1

Andere Sagem Handy Handbücher

Sagem

Sagem VS4 Vodafone Bedienungsanleitung

Sagem

Sagem MYH-10 Series Bedienungsanleitung

Sagem

Sagem MY401L Bedienungsanleitung

Sagem

Sagem MYW7 Bedienungsanleitung

Sagem

Sagem MY901C Bedienungsanleitung

Sagem

Sagem MYZ3 Bedienungsanleitung

Sagem

Sagem my411Cv Vodafone Bedienungsanleitung

Sagem

Sagem MYH-10 Series Bedienungsanleitung

Sagem

Sagem MYC3-2 Bedienungsanleitung

Sagem

Sagem MY411V Bedienungsanleitung

Sagem

Sagem MYX5-2V Bedienungsanleitung

Sagem

Sagem MW 304X Bedienungsanleitung

Sagem

Sagem MYV-65 Bedienungsanleitung

Sagem

Sagem my501Ci Bedienungsanleitung

Sagem

Sagem myX-1 twin Bedienungsanleitung

Sagem

Sagem MY X3-2 Bedienungsanleitung

Sagem

Sagem MYX-4 Leitfaden

Sagem

Sagem MY700X Bedienungsanleitung

Sagem

Sagem MyX-8 Bedienungsanleitung

Sagem

Sagem MYMOVIEBOX Bedienungsanleitung

Sagem

Sagem MY401V Bedienungsanleitung

Sagem

Sagem MY700X Bedienungsanleitung

Sagem

Sagem MyX-8 Bedienungsanleitung

Sagem

Sagem MY215X Bedienungsanleitung

Beliebte Handy Handbücher anderer Marken

Zte

Zte BLADE A520 Bedienungsanleitung

Nokia

Nokia Lumia 620 Bedienungsanleitung

Blackbe;rry

Blackbe;rry KEYone Bedienungsanleitung

Bea-fon

Bea-fon X5 Premium Bedienungsanleitung

Blackbe;rry

Blackbe;rry 8707 Series Bedienungsanleitung

Blackbe;rry

Blackbe;rry Storm Betriebsanleitung

LG LM-X420QN Bedienungsanleitung

LifeWatch

LifeWatch V Bedienungsanleitung

Bea-fon

Bea-fon SILVER LINE SL860 Bedienungsanleitung

IKI Mobile

IKI Mobile KF4.5i Bedienungsanleitung

Hitech

Hitech HT-850 Bedienungsanleitung

Yezz

Yezz Fashion F10 Bedienungsanleitung

Point Mobile

Point Mobile PM60 Bedienungsanleitung

Blackbe;rry

Blackbe;rry Q10 Bedienungsanleitung

Blackbe;rry

Blackbe;rry Bold 9900 Bedienungsanleitung

Blackbe;rry

Blackbe;rry STORM 9500 - VERSION 5.0 Bedienungsanleitung

LG LM-K420EMW Bedienungsanleitung

ISAFE MOBILE

ISAFE MOBILE IS655.2 Bedienungsanleitung
