MAX QUICK START GUIDE 1
NOBODY
GETS
INSPIRED
BY UNTOLD
STORIES
INSPIRED
BY UNTOLD
STORIES
QUICK START GUIDE
MAX
Update Version 2.0 May 2020
SHARE YOUR STORY. SAIL WITH US
MAX QUICK START GUIDEMAX QUICK START GUIDE 32 MAX QUICK START GUIDE 3
CONGRATULATIONS
ON YOUR NEW
SAILMON MAX!
MAX IS MADE FOR
SAILING SO WE WANT
YOU TO GET ON THE
WATER ASAP!
IF YOU WANT TO
LEARN MORE PLEASE
GO TO SAILMON.
COM/MAX/SUPPORT
FOR DETAILED
INSTRUCTIONS OF
ALL CURRENT AND
FUTURE FEATURES.
SEE YOU ON THE
WATER!
SAILMON TEAM
WHAT’S IN THE BOX?
MAX
INDUCTIVE CHARGER AND CABLE
STANDARD MAX MOUNT
CARRYING CASE
QUICK START GUIDE
MAX QUICK START GUIDEMAX QUICK START GUIDE 54
STEP 1:
LET’S GET STARTED!
STEP 2:
CREATE AN ACCOUNT
Follow the on-screen instructions and choose
your preferred way to register. Already a member?
Go to ‘log in’.
Download the Sailmon App and relive, analyse and
share every sailing trip. Connect with friends and
competitors to compare your results.
MAX
MAX QUICK START GUIDEMAX QUICK START GUIDE 76
MAX is all about connectivity. Connect MAX to the
internet to log every trip in the Sailmon App and
keep your device updated with the latest software.
Connect MAX to the internet via Wi or Bluetooth.
Go to Menu > System > Connections to select one
of the two options.
As shown on the image below, MAX has 5 buttons.
Hold the top middle button to turn it on. Once
turned on, the functionalities of the buttons are
described on the screen to make your life easier.
STEP 3:
TURN MAX ON
STEP 4:
CONNECT MAX
TO THE INTERNET
start menu
scroll
up scroll
down
*During sailing functionalities of buttons
are described on the screen.
MAX QUICK START GUIDEMAX QUICK START GUIDE 98
BLUETOOTH INTERNETNETWORKS (VIA WIFI)
Connect MAX to the internet via a phone. Make sure
internet connection sharing on the device is enabled
so MAX can discover the bluetooth connection.
Select the available network in the area you want to
connect. Set the password.
1. Choose your charset: hold the right top button
to go to the next charset. Hold the top left button
to go to the previous charset
2 Move to your character: press on the right top
button to go to the next character. Press the
top left button to go to the previous character.
3 Select your character: press on the right side
button to select the character that is pointed out.
Press the side left button to delete the character.
When nished setting the password, press the top
middle button to connect. If you want to leave this
page earlier, make sure to delete all characters rst
before pressing exit.
MAX QUICK START GUIDEMAX QUICK START GUIDE 1110
Let’s run through the menu to see all options.
Can’t wait to go sailing? Go to the next necessary
STEP 7: CALIBRATE YOUR MAX (page 20).
MENU > EVENT
- General event: log a moment during your trip
for easy retrieval in the Sailmon App.
- Race Finish: log the race nish during your trip
for easy retrieval in the Sailmon App.
- Set course axis: ll in the course axis by entering
a value in degrees between 0 and 359. For
example, the top wind mark or the course the
start vessel is showing.
- Set wind speed: ll in the wind speed in knots
by entering a value in Knots between 0 and 40.
Connect MAX to the Sailmon App to relive, analyse
and share every sailing trip.
1. Open the Sailmon App.
2. Create or choose (slider function) your boat.
MAX can log trips for each boat individually.
3. Press ‘connect device’.
4. Choose the Sailmon device you want to pair.
For now, choose Sailmon MAX.
5. Follow the on-screen instructions on MAX
- Turn on MAX and go to Menu > System >
Attach to Account
- Press on your phone ‘connect to MAX’.
- Press on your phone ‘register a new device’.
- Scan the QR-code on the MAX (by allowing
the camera to scan the code)
STEP 5:
PAIR YOUR MAX
STEP 6:
CONFIGURE YOUR MAX
MAX QUICK START GUIDEMAX QUICK START GUIDE 1312
MENU > SYSTEMMENU > PAGES
SYSTEM INFO:
here you can nd the MAX serial number, current
software version, if your MAX is online or not and
how much data your device still needs to send to
the server.
ATTACH TO ACCOUNT:
here you can nd the QR-code to connect your
MAX to the Sailmon App as explained previous in
this manual.
Build your own pages with data relevant to you.
Select or add the page you want to congure.
1. Change the lay-out: hold the top middle button.
2 Choose the value in the lay-out you want to
change: press the top middle button.
3 Select the value: press the middle right button to
go to the next value. Press the middle left button
to go to the previous value. Press the right top
button to select the value.
When nished selecting all the values, press the top
left button to go back. Your page is automatically
saved. There is no limit on the number of pages you
can set-up. Easily switch between saved pages
during sailing by clicking on the top middle button.
MAX QUICK START GUIDEMAX QUICK START GUIDE 1514
MENU > SYSTEM >
SENSORS > WINDMENU > SYSTEM > SENSORS
CONNECT WIND SENSOR:
connect the bluetooth wind sensor to MAX.
Please check out the wind sensor manual for
more information.
WIND MOUNT OFFSET:
enter a value in degrees between -180 and 180.
UPWIND TWA CORRECTION:
enter a value in degrees between -90 and 90.
DOWNWIND TWA CORRECTION:
enter a value in degrees between -90 and 90.
DOWNWIND TWS CORRECTION:
enter a percentage between 0 and 120.
SET COMPASS OFFSET:
if your MAX is mounted in an angle, ll in a value in
degrees between -180 and 180 here. Your sailing
data will keep accurate.
ZERO HEEL AND PITCH:
press the top right button to zero your heel and
pitch. Please do that before you go sailing and after
mounting your MAX. Once done, you only need to
repeat it if you moved MAX on the boat.
MAX QUICK START GUIDEMAX QUICK START GUIDE 1716
MENU > SYSTEM >
CONNECTIONSMENU > SYSTEM > SENSORS
NETWORKS:
nd an overview of all available networks in the
area. Connect or forget a network as you wish.
BLUETOOTH INTERNET:
connect MAX to the internet via Bluetooth.
Make sure Internet Connection Sharing on your
phone is enabled.
ENABLE WIFI:
enable/disable Wi.
SET UDP INPUT PORT:
add a NMEA transmitter and connect existing
sensors to MAX. Fill in the UDP input port number
and press save.
NO GPS MODE:
enable/disable GPS data. This function is ideal for
classes in which GPS is not allowed.
MAX QUICK START GUIDEMAX QUICK START GUIDE 1918
MENU > SYSTEM >
CHECK FOR UPDATESMENU > SYSTEM > ADVANCED
Check out if your MAX is running the latest software
update. Make sure your MAX is connected to the
internet. Please notice MAX will automatically give a
noticationn if there is a new software update.
DIAGNOSTICS:
review the status of your MAX sensors in depth.
SIMPLE START PAGE:
enable/disable the simple start page that contains
timer and distance to line information only.
E4 SLAVE MODE:
enable/disable connection to the Model E4
Processor to receive more data. Set-up the screen
in our NavDesk App.
NMEA0183 OUTPUT:
enable/disable NMEA0183 output.
FACTORY RESET:
remove all current settings of your MAX.
