SAMES KREMLIN FPro G Bedienungsanleitung

Diagnostic Help / Troubleshooting Guide

Topic Explanation Visual

Bean-shaped

spray

and rotate the head half a turn. If the defect is reversed,

one of the side vents is blocked or deformed.

vents with a spray

of compressed air. If this does not

reverse, the nozzle is probably damaged.

Deported

spray

Thisdeformation is due to a defect in the central spray. It

is necessary to clean the head as described above and

the nozzle. Also check:

•The head is well centered on the nozzle,

•The nozzle is not too big (needle and nozzle must be

adapted),you work with a sufficient needlen opening,

•

With an almost closed needle, the product

supply to

the spray

is not regular in all directions.

Cutted

spray

The pressure of the air sprays at the vents is too high for the

paint flow:

•

needle. The spray is narrower.

•

Increase paint flow.

Spray loaded

in the center

Default inverse of the previous one:

•Either the paint flow rate is excessive for the adopted

spraying air pressure - You should increase the

spraying air pressure and reduce the paint flow rate.

•

Either the paint is too thick - You must then dilute it.

Jerky product

spray

The gun is machine-gunned. The phenomenon is caused

by air entering the paint circuit:

•The container containing the paint may be empty -

Refill with paint.

•The nozzle is not tightened properly and does not fit

properly on its seat - Tighten the nozzle.

If the phenomenon persists, disassemble the nozzle and

clean it.

•Check the nozzle seat and cone fordamage,

reassemble and secure the nozzle.

•Check that the paint is fluid and homogeneous

Reduce air at the vents by closing the adjustment

enough to be vacuumed.

FPRO G / GSP

DIAGNOSTIC / TROUBLESHOOTING

The defect comes from the head - Loosen the ring slightly

Then clean the gun head with solvent and unclog the

Possible symptoms of faults - Causes of faults - Remedies to apply

FPRO G / GSP

DIAGNOSTIC / TROUBLESHOOTING

SAMES KREMLIN Inc.

45001 5 Mile Rd, Plymouth, MI 48170 | TF (800)573-5554 | T (734)979-0100 | F (734)927-0064

931 Progress Ave, Unit 7, Scarborough, ON M1G 3V5 | TF (800)450-0655 | T (416)431-5017 | F (416)431-9171

•

Defaults Root causes Remedies

Paint no longer comes

out of the gun

Nozzle partially or

completely clogged

Disassemble and clean

the nozzle with solvent

and a smooth brush.

The spray narrows at

pump reversals

Viscosity too high Dilute the paint.

The head frequently gets

dirty

Too much air Reduce air pressure.

The paint comes through

air holes in the head

Defective nozzle seal Replace it.

Insufficiently tight nozzle Tighten it.

Product leakage at the

trim level

Worn seal Tighten the liner press

without blocking the

needle.

If the leak is still present

replace the seal and

needle.

Product leakage at the

front of the gun, trigger

released

Impurities in the product Pull the trigger 3-4

times and let it go back

on its own.

Worn out needle or/and

worn out nozzle

Replace the needle

and/or nozzle.

Air leakage at the valve Worn valve Changing the valve.

•

Rubbing on the needlePermanent air leakage at

the gun head when

trigger is released Worn valve

Replace the valve.

Remove the trigger

and check that the

needle slides freely.

•• •

•Check the condition

of the seal.

PLEASE NOTE: Before any action is taken on the gun, please shut off the compressed air supply and depressurize the systems by triggering the gun.

characteristics and services offered as well as equipment and attachments of these.
