Sami wearable junior tech WS-2372 Bedienungsanleitung
WEARABLE
User Manual
WS-2372
Thank you for purchasing the Sami wearable WS-2372. Read the
instructions carefully to obtain optimum results and preserve it for
future reference. Sami has developed wearable devices since 2015 and
we use the best components possible for the product.
1. Quick start guide
Overview
1. Touch screen
2. Heart sensor
3. Charging PIN
Make sure the pins on the charging cable fit correctly
onto the charging terminals on the back of your smart
watch.
Plug the big end of the USB cable to a power source
and after successful charging, a charging icon will
appear on the screen.
Install “Fit4Kid” app on the phone
Search and install the “Fit4Kid” app from Google Play or
App Store. Or scan the following QR code to install the
app directly.
Connect the smart watch with the phone
1. Enable Bluetooth on your smart phone.
2. Open the “Fit4Kid” app on your smart phone, and
then fill in all the requested information in the
“Settings” menu.
3. Tap “Connect device” in the “Settings” menu.
4. Select the smart watch icon to connect.
5. Choose your device name to connect it with your
phone.
6. Please note that you must connect through the app
and not by the bluetooth menu of your phone.
7. You will see pop up windows of permissions while
installing, please accept all of them for the correct
functioning specially referred to location and
background execution.
Unbind smart watch with mobile phone
1. Open “Fit4Kid” app on your smart phone.
2. Tap “Disconnect device” in the “Settings” menu and
confirm “OK”.
3. To disconnect your smart watch with a Phone, click
“Disconnect device” in the “Settings” menu of
“Fit4Kid” app, and go to the Bluetooth settings on
your Phone, then access and select “Forget This
Device”.
Operation Introduction
To switch on the watch, press and hold the center of
the touch screen until the display is on.
To switch off the watch, slide the screen from right to
left on main interface to enter in sub-menu, and then
slide the screen up and down to enter in settings, you
will find power off icon there.
You can press the touch screen, or turn on gesture
control in advanced settings of Fit4Kid and then raise
your hand to light the screen.
2. How to use
Turn on: Press and hold the center of the touch
screen for 3 seconds.
Go to main menu: Slide from right to left on main
interface; slide up and down to check more functions
Select a function: Slide up and down; tap the icon.
Confirm: Tap the icon.
Exit menu: Slide from left to right on the screen.
Check notifications: Slide from left to right on main
interface.
3. Main menu
After turning on the smart watch, the main interface will
be displayed.
From the main interface:
1. Go to the main menu
a. Slide from right to left to enter the main menu.
b. Slide up and down to check more functions.
c. Tap the icon to enter the sub menu. Slide from left to
right to return to the previous menu.
2. Go to the notification shortcut interface
Slide from left to right from the main interface.
3. Go to other shortcuts screen
Slide up and down from the main interface.
No. 1 Brightness
You can adjust screen brightness by click this icon.
No. 2 Find phone
When your smart watch is connected with Fit4Kid, you
phone will ring by click this icon.
No. 3 Shut down
You can shut down your smart watch by click this icon.
No. 4 About
You will find name, address, and firmware version by
click this icon.
4. Functions
Watch faces
There are 3 watch faces. In current watch face, press and
hold the center of the touch screen to choose the one
you like.
Daily activities
The watch will record your daily activity automatically.
Press the step icon to check pedometer, distance and
calories. After synchronizing with APP, these sports data
can be also checked in APP.
Heart rate monitor
Select the heart rate icon to monitor your current
heart rate. To exit the heart rate monitor, please slide to
right.
If you’ve connected your smart watch with APP via
Bluetooth, you can also check your heart rate data in the
app.
Multi-Sport
Tap the sport icon to enter the multi-sport mode.
The smart watch has 4 sports modes: walking, running,
hiking, and cycling. Choose a sport mode you want, and
then do sports. The smart watch will record your
exercise data.
If you want to end the sports, slide the screen to right
and tap the stop icon to finish your sports and save the
data. The smart watch displays your exercise data after
that. If you’ve connected your smart watch with Fit4Kid
via Bluetooth, you can also check your exercise data in
the app.
Note: if the exercise time is less than 5 minutes, the data
cannot be saved.
Sleep monitor
The smart watch automatically monitors your sleep from
10p.m. to 9a.m.
When you get up the next day, the smart watch displays
your sleep report about the time of total sleep, light
sleep and deep sleep. If you’ve connected your smart
watch with APP via Bluetooth, you can also check more
detailed sleep report in the app.
Weather
If you’ve connected your smart watch with Fit4Kid via
Bluetooth, the smart watch will display the weather
forecast.
You can manually set the city or automatically set a city
in APP.
