Samsung HMX-S16BN Bedienungsanleitung

User Manual

HMX-S15BN/HMX-S16BN

High Deﬁnition Digital Camcorder

www.samsung.com/register

3.5” Wide Touch Screen

This camcorder adopts 3.5” wide touch LCD

supporting 1.15 million pixels which enables

you to record videos and photos in sharp

color and image. And it also provides an

enhanced LCD correction that enables you to

make recordings while monitoring the image

clearly in a bright sunlight.

Equipped with SSD

(Solid State Drive) internal memory

(HMX-S15/S16 only)

This camcorder is equipped with an internal

SSD ﬂash memory. The SSD memory

features a quick booting and response speed

which is favorable to instant imaging.

Unlike a shaky or sensitive HDD (Hard Disk

Drive) camcorder, it is very stable for most

of the cases. The SSD memory causes

extremely low noise with a high endurance,

and its low power consumption helps you

manage the battery more efﬁciently.

Simple With Fingertips!

User-Friendly Touch Screen

If you want to focus on a certain point

while recording, simply tap a desired point.

Optimized to the tapped point, it enables

you to make recording in a professional level

with simple operations. With the enhanced

touch screen-based interface, you can

make recording in simple operations without

knowing the complex menu structure.

Sharp & Vivid 1920 x 1080 Full HD!

It can reproduce the best-ever quality

comparing the capacity using the latest H.264

codec. You can make recording of vivid

images in the Full HD quality, and enjoy full

HD videos (with no loss of quality) via the mini

HDMI connection.

Photos in 10 million pixels

Featured by Samsung’s pixel rising

technology, it reproduces a high deﬁnition

still image in great color reproduction. You

can enjoy a high deﬁnition video of 10 million

pixels without using a separate digital camera.

WiFi instant sharing

wherever you are

(HMX-S15/S16 only)

The WiFi wireless communication technology

enables you to share videos and photos on

the spot wherever taken. With DLNA, you

can transfer and play videos and photos in

wireless connection with a home networking

device such as TV or PC.

key features of your full HD camcorder

iii

Self-Decision on Situation!

Smart Auto

This camcorder automatically recognizes a

recording condition and optimizes itself to

the scene, which enables a novice to make a

quick recording.

Catch the sound!

Internal Zooming Microphone

Equipped with the internal zooming

microphone, it can capture the sound

from the scene clearly. Adjusting the video

zooming focus to a nearby or distant scene,

you will not miss any source of sound

wherever it occurs.

Capture the time! Time Lapse

Recording

You can reconﬁgure otherwise a long time

of video to a shortened one using the time

lapse recording at a speciﬁc time interval.

Time lapse recording enables you to capture

the passage of clouds, blooming of ﬂowers,

natural growing progress of buds, progress

of painting, and other documentary videos of

personal memory. Use this function to make

UGC (User-Generated Content ) videos,

artistic recordings and educational programs.

Video at a Glance!

iVIEW, Storyboard Printing

You get a quick overview of your video and

save it in a single piece of picture. You can

take a glance at the video without playing the

whole length, which is especially useful if you

want to edit the video in a short time.

Direct Upload of Your Videos and

Photos to the Web!

The built-in editing Intelli-studio software

installs directly from this camcorder to your

PC, enabling convenient connection only with

a USB cable. Intelli-studio also allows direct

uploading of your contents to YouTube,

Flickr, or Facebook. Sharing the contents with

your friends is simpler than ever before.

Hello !

SAFETY WARNINGS

What the icons and signs in this user manual mean;

WARNING

Means that there is a potential risk of death or serious injury.

CAUTION

Means that there is a potential risk of personal injury or damage to the

product.

CAUTION

To reduce the risk of ﬁre, explosion, electric shock, or personal injury when

using your camcorder, follow these basic safety precautions.

Means hints or referential pages that may be helpful when operating the

camcorder.

PRECHECK Settings required before using a function.

These warning signs are here to prevent injury to you and others.

Please follow them explicitly. After reading this section, keep it in a safe place for future

reference.

PRECAUTIONS

Warning!

• When using the AC power adapter with your camcorder, connect the adapter to an

outlet with protective grounding.

• Do not expose the camcorder battery to direct sunlight, heaters, radiators, ﬁre, or any

other source of excessive heat.

Caution

If you replace the battery with the wrong battery, you can cause an explosion.Replace only

with the same battery or an equivalent type.

If you plug the AC adapter into a 240V AC outlet, be sure to use a suitable plug adapter.

before reading this user manual

Thank you for purchasing this Samsung

Camcorder. Please read this user manual

carefully before you use the camcorder and

keep it handy for future reference. Should

your camcorder fail to operate correctly, refer

to Troubleshooting.

This User Manual covers HMX-S10,

HMX-S15, and HMX-S16 models.

The HMX-S15 and HMX-S16 have a

32GB, and 64GB built-in storage media

(SSD) respectively but also use memory

cards.

The HMX-S10 do not have built-in storage

media (SSD) and use memory cards.

Although some features of HMX-S10

models are different, they operate in the

same way.

Illustrations of model HMX-S10 are used

in this user manual.

The displays in this user manual may not

be exactly the same as those you see on

the LCD screen.

Designs and speciﬁcations of the

camcorder and other accessories are

subject to change without any notice.

In this user manual, the icon or symbol in

the parenthesis appearing in a description

of a submenu item indicates it will

appear on the screen when setting the

corresponding item.

Ex) Submenu item of “iSCENE” page ??

- “Sports” ( ): Recording people

or objects in motion. (If set,

corresponding icon ( ) will appear

on the screen.)

•

The following terms are used in this

manual:

• ‘Scene’ refers to the point where you

press the Record Start/Stop button to

start recording until you press again to

pause the recording.

• The terms ‘photo’ and ‘still image’ are

used interchangeably with the same

meaning.

This camcorder records video in H.264

(MPEG4 part10/AVC) format and in

High Deﬁnition Video (HD-VIDEO) or

Standard Deﬁnition Video (SD-VIDEO).

You can play back and edit the video

recorded by the camcorder on a

personal computer with the built-in

software in this camcorder.

Please note that this camcorder is not

compatible with other digital video

formats.

Before recording important video,

make a trial recording.

Play back your trial recording to make sure

the video and audio have been recorded

properly.

The recorded contents cannot be

compensated for:

- Samsung cannot compensate for any

damage caused when a recording

cannot be played back because of a

defect in the camcorder or memory

card. Samsung cannot be responsible

for your recorded video and audio.

•

IMPORTANT INFORMATION ON USE

Before using this camcorder

About this user manual

- Recorded contents may be lost due

to a mistake when handling this

camcorder or memory card, etc.

Samsung shall not be responsible for

compensation for damages due to the

loss of recorded contents.

Make a backup of important recorded

data.

Protect your important recorded data

by copying the ﬁles to a PC. We also

recommend you to copy it from your PC

to other recording media for storage.

Refer to the software installation and USB

connection guide.

Copyrights: Please note that this

camcorder is intended for individual

use only.

Data recorded on the storage media in

this camcorder using other digital/analog

media or devices is protected by the

permission of the owner of the copyright,

except for personal enjoyment. Even if

you record an event such as a show,

performance or exhibition for personal

enjoyment, it is strongly recommended

that you obtain permission beforehand.

It is recommended to use the camcorder

at least once a month to maintain its

performance and life.

Check the image resolution before

developing photos.

Make sure to check all functions of

the camcorder to prevent a inevitable

recording failure before recording.

For Open Source licenses information,

refer to the “Opensource.pdf” in the

provided CD-ROM.

•

• All the trade names and registered

trademarks mentioned in this manual or

other documentation provided with your

Samsung product are trademarks or

registered trademarks of their respective

holders.

• The SD logo is a trademark. The SDHC

logo is a trademark.

• Microsoft®, Windows®, Windows Vista

®and DirectX®are either registered

trademarks or trademarks of the Microsoft

Corporation in the United States and/or

other countries.

• Intel®, Core™, and Pentium®are the

registered trademarks or trademarks of

the Intel Corporation in the United States

and other countries.

• Macintosh, Mac OS are either registered

trademarks or trademarks of Apple Inc. in

the United States and/or other countries.

• YouTube is a trademark of Google Inc.

• Flickr™ is a trademark of Yahoo.

• Facebook is a trademark of Facebook Inc.

• HDMI, the HDMI logo and High-Deﬁnition

Multimedia Interface are trademarks or

registered trademarks of HDMI Licensing

LLC.

• Adobe, the Adobe logo, and Adobe

Acrobat are either registered trademarks

or trademarks of Adobe Systems

Incorporated in the United States and/or

other countries.

• All the other product names mentioned

here in may be the trademark or registered

trademarks of their respect companies.

Furthermore, “TM” and “®” are not

mentioned in each case in this manual.

Notes regarding trademarks

before reading this user manual

vii

Warning

To Reduce The Risk Of Fire Or Electric Shock, Do Not Expose This Apparatus To Rain Or

Moisture.

Caution

Apparatus shall not be exposed to dripping or splashing and no objects ﬁlled with liquids, such

as vases, shall be placed on the apparatus.

To disconnect the apparatus from the mains, the plug must be pulled out from the mains

socket, therefore the mains plug shall be readily operable.

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this apparatus near water.

6. Clean only with dry cloth.

7. Do not block any ventilation openings. Install in

accordance with the manufacturer’s instructions.

8. Do not install near any heat sources such

as radiators, heat registers, stoves, or other

apparatus (including ampliﬁers) that produce

heat.

9. Do not defeat the safety purpose of the polarized

or grounding-type plug. A polarized plug has

two blades with one wider than the other. A

grounding type plug has two blades and a

third grounding prong. The wide blade or the

third prong are provided for your safety. If the

provided plug does not ﬁt into your outlet,

consult an electrician for replacement of the

obsolete outlet.

10. Protect the power cord from being walked on

or pinched particularly at plugs, convenience

receptacles, and the point where they exit from

the apparatus.

11. Only use attachment/accessories speciﬁed by

the manufacturer.

12. Use only with the cart, stand, tripod, bracket, or

table speciﬁed by the manufacturer,

or sold with the apparatus.

When a cart is used, use caution

when moving the cart/apparatus

combination to avoid injury from tip-

over.

13. Unplug this apparatus during lightning storms or

when unused for long periods of time.

14. Refer all servicing to qualiﬁed service personnel.

Servicing is required when the apparatus has

been damaged in any way, such as power-

supply cord or plug is damaged, liquid has been

spilled or objects have fallen into the apparatus,

the apparatus has been exposed to rain or

moisture, does not operate normally, or has

been dropped.

important safety instructions

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,

DO NOT REMOVE COVER (OR BACK).

NO USER-SERVICEABLE PARTS INSIDE

REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

This symbol indicates that dangerous

voltage consisting a risk of electric

shock is present within this unit.

This symbol indicates that there are

important operating and maintenance

instructions in the literature

accompanying this unit.

viii

15. Apparatus shall not be exposed to dripping or

splashing and no objects ﬁlled with liquids, such

as vases, shall be placed on the apparatus.

16. VENTILATION:

Slots and openings in the cabinet are provided

for ventilation to ensure reliable operation

of the CAMCORDER and to protect it from

overheating. These openings must not

be blocked or covered. Never place your

CAMCORDER on a bed, sofa, rug, or other

similar surface: on or near a radiator or heat

placed in a built-in installation such as a

bookcase or rack unless proper ventilation is

provided or the manufacturer’s instructions have

been adhered to.

17. POWER SOURCES:

The CAMCORDER should be operated only from

the type of power source indicated on the label.

If you are not sure of the type of power supply

at your home, consult your appliance dealer

or local power company. A CAMCORDER is

intended to be operated from battery power, or

other sources, refer to the operating instructions.

18. GROUNDING OR POLARIZATION:

This CAMCORDER may be equipped with

either a polarized 2-wire AC line plug (a plug

having one blade wider than the other) or a

3-wire grounding type plug, a plug having a third

(grounding) pin. If you are unable to insert the

plug fully into the outlet, try reversing the plug.

If the plug still fails to ﬁt, contact your electrician

to replace your outlet. Do not defeat the safety

purpose of the polarized plug.

19. POWER-CORD PROTECTION:

Power-supply cords should be routed so that

they are not likely to be walked on or pinched

by items placed upon or against them, paying

particular attention to cords or plugs, convenient

receptacles, and the point where they exit from

the unit.

20. OUTDOOR ANTENNA GROUNDING:

CAMCORDER, be sure the antenna or cable

system is grounded to provide some protection

against voltage surges and built-up static

charges, Section 810 of the National Electrical

Code, ANSI/NFPA No. 70-1984, provides

information with respect to proper grounding of

the mast and supporting structure, grounding

of the lead-in wire and supporting structure,

grounding of the mast and supporting structure,

grounding of the lead-in wire to an antenna

discharge unit, size of grounding to conductors,

location of antenna-discharge unit, connection

to grounding electrodes and requirements for

the grounding electrode. See ﬁgure below.

21. LIGHTNING:

For added protection of this CAMCORDER

during a lightning storm or when it is left

unattended and unused for long periods of time,

unplug it from the wall outlet and disconnect

the antenna or cable system. This will prevent

damage to the CAMCORDER due to lightning

and powerline surges.

22. POWER LINES:

An outside antenna system should not be

located in the vicinity of overhead power lines

or other electric light or power circuits where it

can fall into such power lines or circuits. When

installing an outside antenna system, extreme

care should be taken to keep from touching

such power lines or circuits as contact with

them might be fatal.

important safety instructions

GROUNDING CONDUCTORS

(NEC SECTION 810-21)

GROUND CLAMPS

POWER SERVICE GROUNDING

ELECTRODE SYSTEM

(NEC ART 250, PART H)

NEC NATIONAL ELECTRICAL CODE

ELECTRIC

SERVICE

EQUIPMENT

GROUND

CLAMP

ANTENNA

LEAD IN

WIRE

ANTENNA

DISCHARGE UNIT

(NEC SECTION 810-20)

23. OVERLOADING:

Do not overload wall outlets and extension

cords as this can result in a risk of ﬁre or electric

shock.

24. OBJECTS AND LIQUIDS:

Never push objects of any kind into this

CAMCORDER through openings as they may

touch dangerous voltage points or short out

a part that could result in a ﬁre or electric

shock. Never spill liquids of any kind onto the

CAMCORDER. Should spillage occur, unplug

unit and have it checked by a technician before

use.

25. SERVICING:

Do not attempt to service this CAMCORDER

yourself. Opening or removing covers may

expose you to dangerous voltage or other

hazards. Refer all servicing to qualiﬁed service

personnel.

26. DAMAGE REQUIRING SERVICE:

Unplug this CAMCORDER from the wall outlet

and refer servicing to qualiﬁed service personnel

under the following conditions:

a. When the power-supply cord or plug is

damaged.

b. If any liquid has been spilled onto, or objects

have fallen into the CAMCORDER.

c. If the CAMCORDER has been exposed to

rain or water.

d. If the CAMCORDER does not operate

normally by following the operating

instructions, adjust only those controls that

are covered by the operating instructions.

Improper adjustment of other controls may

result in damage and will often require

extensive work by a qualiﬁed technician

to restore the CAMCORDER to its normal

operation.

e. If the CAMCORDER has been dropped or

the cabinet has been damaged.

f. When the CAMCORDER exhibits a distinct

change in performance, this indicates a need

for service.

27. REPLACEMENT PARTS:

When replacement parts are required, be sure

the service technician has used replacement

parts speciﬁed by the manufacturer and having

the same characteristics as the original part.

Unauthorized substitutions may result in ﬁre,

electric shock or other hazards.

28. SAFETY CHECK:

Upon completion of any service or repairs to

this CAMCORDER, ask the service technician

to perform safety checks to determine that the

CAMCORDER is in safe operating order.

29. To prevent damage which may result in ﬁre or

shock hazard, do not expose this appliance to

rain or moisture.

30. If this power supply is used at 240V ac, a

suitable plug adaptor should be used.

31. This product is covered by one or more of the

following U.S. patents:

5,060,220 5,457,669 5,561,649 5,705,762

5,987,4176,043,912 6,222,983 6,272,096

6,377,524 6,377,5316,385,587 6,389,570

6,408,408 6,466,532 6,473,7366,477,501

6,480,829 6,556,520 6,556,521

6,556,5226,578,163 6,594,208 6,631,110

6,658,588 6,674,6976,674,957 6,687,455

6,697,307 6,707,985 6,721,2436,721,493

6,728,474 6,741,535 6,744,713

6,744,9726,765,853 6,765,853 6,771,890

6,771,891 6,775,4656,778,755 6,788,629

6,788,630 6,795,637 6,810,2016,862,256

6,868,054 6,894,963 6,937,552

USER INSTALLER CAUTION:

Your authority to operate this FCC certiﬁed

equipment could be voided if you make changes or

modiﬁcations not expressly approved by this party

responsible for compliance to part 15 FCC rules.

NOTE:

Hg LAMP(S) INSIDE THIS PRODUCT CONTAIN

MERCURY AND MUST BE RECYCLED OR

DISPOSED OF ACCORDING TO LOCAL,

STATE OR FEDERAL LAWS. For details

see lamprecycle.org, eiae.org, or call

1-800-Samsung (7267864)

NOTE:

This equipment has been tested and found to

comply with the limits for a Class B digital device,

pursuant to part 15 of the FCC Rules.

These limits are designed to provide reasonable

protection against harmful interference in a

residential installation.

This equipment generates, uses and can radiate

radio frequency energy and, if not installed and used

in accordance with the instructions, may cause

harmful interference to radio communications.

However, there is no guarantee that interference will

not occur in a particular installation.

If this equipment does cause harmful interference

to radio or television reception, which can be

determined by turning the equipment off and on, the

user is encouraged to try to correct the interference

by one or more of the following measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment

and receiver.

- Connect the equipment into an outlet on a

circuit different from that to which the receiver is

connected.

- Consult the dealer or an experienced radio/TV

technician for help and for additional suggestions.

The user may ﬁnd the following booklet prepared

by the Federal Communications Commission

helpful: “How to Identify and Resolve Radio-

TV Interference Problems.” This Booklet is

available from the U.S. Government Printing

Ofﬁce, Washington, D.C. 20402, Stock No.

004-000-00345-4.

FCC Warning

The user is cautioned that changes or modiﬁcations

not expressly approved by the manufacturer could

void the user’s authority to operate the equipment.

This device complies with Part 15 of FCC Rules.

Operation is subject to the following two conditions;

(1) This device may not cause harmful interference,

and

(2) This device must accept any interference

received, including interference that may cause

undesired operation.

CALIFORNIA USA ONLY

This Perchlorate warning applies only to

primary CR (Manganese Dioxide) Lithium coin

cells in the product sold or distributed ONLY

in California USA

“ Perchlorate Material - special handling may

apply, See www.dtsc.ca.gov/hazardouswaste/

perchlorate.”

important safety instructions

FCC RF Radiation Exposure Statement:

This equipment complies with FCC RF

radiation exposure limits set forth for an

uncontrolled environment.

This equipment is hand-held used only and it

should be installed and operated with a

minimum distance of 20 centimeters between

the radiator and your body.

This device and its antenna must not be co-

located or operating in conjunction with any

other antenna or transmitter. This

equipment has been tested and found to

comply with the limits for a class B digital

device, pursuant to part 15 of the FCC

Rules. These limits are designed to provide

reasonable protection against harmful

interference in a residential installation.

Andere Handbücher für HMX-S16BN

Inhaltsverzeichnis

Andere Samsung Camcorder Handbücher

Samsung

Samsung SMX C10 - Camcorder - 680 KP Bedienungsanleitung

Samsung

Samsung VP-W80U Bedienungsanleitung

Samsung

Samsung 8 VP-M50 Betriebsanleitung

Samsung

Samsung Gear 360 Originalbetriebsanleitung

Samsung

Samsung VP-M110B Betriebsanleitung

Samsung

Samsung VP-D103 Betriebsanleitung

Samsung

Samsung VP-M2100B Betriebsanleitung

Samsung

Samsung VP-L906 Bedienungsanleitung

Samsung

Samsung VP-D55, VP-D60, VP-D65 Betriebsanleitung

Samsung

Samsung SC HMX20C - Camcorder - 1080p Bedienungsanleitung

Samsung

Samsung SC-DC563 Betriebsanleitung

Samsung

Samsung SCD180 Betriebsanleitung

Samsung

Samsung HMX-H204BN Bedienungsanleitung

Samsung

Samsung VP-MX10 Bedienungsanleitung

Samsung

Samsung SC-D93 Betriebsanleitung

Samsung

Samsung SC-X105(L) Betriebsanleitung

Samsung

Samsung HMX-H106SN Benutzerhandbuch

Samsung

Samsung VP-D107 Betriebsanleitung

Samsung

Samsung VP-D11 Betriebsanleitung

Samsung

Samsung VP-X300L Betriebsanleitung

Samsung

Samsung SC-D371 Bedienungsanleitung

Samsung

Samsung HMX-E10BN Bedienungsanleitung

Samsung

Samsung SCD180 Betriebsanleitung

Samsung

Samsung VP-D97I Betriebsanleitung

Beliebte Camcorder Handbücher anderer Marken

Toshiba

Toshiba CAMILEO Z100 Bedienungsanleitung

Panasonic

Panasonic NV-VS40B Bedienungsanleitung

Canon

Canon RC 260 Bedienungsanleitung

Sony

Sony Handycam DCR-DVD7E Bedienungsanleitung

Brinno

Brinno TimeLapse TLC200 Bedienungsanleitung

JVC

JVC GR-SXM68AC Kurzanleitung

Panasonic

Panasonic AG-HMC152EN Bedienungsanleitung

Insignia

Insignia NS-DCC5HB09 - Camcorder - 720p Bedienungsanleitung

MYDLINK

MYDLINK DCS-6100LH Bedienungsanleitung

Sony

Sony video Hi8 Handycam CCD-TR555 Bedienungsanleitung

SECURECOM

SECURECOM V-5014B Bedienungsanleitung

Panasonic

Panasonic HDC-SD100 Bedienungsanleitung

Sharper Image

Sharper Image U-VIDEO Bedienungsanleitung

JVC

JVC AA-V15EG Bedienungsanleitung

Canon

Canon LEGRIA HV40 Bedienungsanleitung

Sony

Sony Handycam DCR-VX2000 Bedienungsanleitung

RCA

RCA CC616 Bedienungsanleitung

Panasonic

Panasonic NVM40 Bedienungsanleitung
