Samsung SGH-E780 Bedienungsanleitung

World Wide Web

http://www.samsungmobile.com

Printed in Korea

Code No.: GH68-09841A

English (EU). 04/2006. Rev. 1.0

* Depending on the software installed or your service provider or country,

some of the descriptions in this guide may not match your phone exactly.

* Depending on your country, your phone and accessories may appear

different from the illustrations in this guide.

SGH-E780

User’s Guide

Get started

First steps to operating your phone

SIM card information

When you subscribe to a cellular network, you receive

a plug-in SIM (Subscriber Identity Module) card

loaded with your subscription details, such as your

PIN, and available optional services.

Install and charge the phone

Remove the battery

cover.

If the phone is already

on, first turn it off by

pressing and holding

[].

Insert the SIM card.

Make sure that the gold-

coloured contacts on the

card are face down.

Install the battery. Reattach the cover.

Plug the travel adapter into the phone.

Plug the adapter into a standard AC wall outlet.

Get started

Low battery indicator

When the battery is low:

• a warning tone sounds,

• the battery low message displays, and

• the empty battery icon blinks.

If the battery level becomes too low, the phone

automatically turns off. Recharge your battery.

Power on or off

When the phone is completely charged (the

battery icon becomes still), unplug the adapter

from the power outlet.

Remove the adapter from the phone.

Power on

Do not turn on

the phone when

mobile phone

use is prohibited.

1. Open the phone.

2. Press and hold

[]

3. If necessary, enter the PIN and

press <

Power off

1. Open the phone.

2. Press and hold

[]

Get started

Keys and display

Keys

Perform the function indicated on the bottom

line of the display.

In Idle mode, access your favourite menus

directly.



p. 87

In Menu mode, scroll through menu options.

In Idle mode, launch the web browser.

In Menu mode, select the highlighted menu

option or confirm input.

Send or answer a call.

In Idle mode, retrieve numbers recently

dialled, missed, or received.

Delete characters from the display and

selected item in an application.

In Idle mode, initiate the voice recognition

feature.

End a call.

Press and hold to switch the phone on or off.

In Menu mode, cancel input and return the

phone to Idle mode.

Enter numbers, letters, and some special

characters.

In Idle mode, press and hold

[1]

to access

your voicemail. Press and hold [

] to enter

an international call prefix.

Enter special characters.

In Idle mode, press and hold [

]

to activate

or deactivate Silent mode. Press and hold

[

]

to enter a pause between numbers.

Adjust the phone volume.

In Idle mode, with the phone open, adjust

the keypad tone volume. With the phone

closed, press and hold to turn on the external

display.

In Idle mode, access the

Camera

menu:

press and hold to turn on the camera.

In Camera mode, take a photo or record a

video.

Get started

Display

Press and hold to launch or close the music

player.

Pause or resume playing music.

Return to the previous file during playback.

Move backward in a file when held down.

Skip to the next file during playback. Skip

forward in a file when held down.

Layout

Text and graphics

display messages,

instructions, and

information you enter.

Soft key function

indicators

show the current

functions assigned to

the two soft keys.

Icons

display various icons.

Menu Contacts

Icons

Received signal strength

Call in progress

Out of your service area; you

cannot send or receive calls

Alarm set



p. 72

New text message

New voicemail

New multimedia message

New e-mail

One of the message Inboxes is full

Call diverting feature active



p. 92

Bluetooth active



p. 44

Synchronised with a PC

GPRS network

EDGE network

Get started

Access menu functions

Home Zone, if registered for the

appropriate service

Office Zone, if registered for the

appropriate service

Ringer type



p. 90

• None: Melody

•:Vibration

• : Melody and vibration

• : Vibration then melody

• : Melody then vibration

Silent mode



p. 14

Battery power level

* Depending on your country or service provider, the icons

shown on the display may vary.

Use the soft

keys

The roles of the soft keys vary

depending on the function you are

using. The bottom line of the

display indicates their current role.

Press the left soft

key to select the

highlighted

option.

Press the right soft

key to return to the

previous menu

level.

Select Back

Get started

Customise your phone

Select an

option

1. Press a desired soft key.

2. Press the Navigation keys to

move to the next or previous

option.

3. Press <

Select

> or [ ] to

confirm the function displayed

or option highlighted.

4. To exit, choose either of the

following methods:

• Press <

Back

> to move up

one level.

• Press [ ] to return to Idle

mode.

Use shortcuts

Press the number key

corresponding to the option you

want.

1. In Idle mode, press <

and select

Settings

→

Phone

settings

→

Language

2. Select a language.

1. In Idle mode, press <

and select

Settings

→

Sound

settings

→

Incoming call

→

Ring tone

2. Select a ringtone category.

3. Select a ringtone.

4. Press <

Save

Display

language

Call ringer

melody

Get started

You can set wallpaper for the idle

screen on each display.

For the main display:

1. In Idle mode, press <

and select

Settings

→

Display

settings

→

Wallpaper

→

Main

display

→

Main display

2. Select an image category.

3. Select an image.

4. Press <

Save

For the external display:

1. In Idle mode, press <

and select

Settings

→

Display

settings

→

Wallpaper

→

Cover display

2. Select an image type.

Idle mode

wallpaper

3. For

Clock

, scroll to a clock type

and press <

Save

For

Cover title

, enter a

greeting and press [ ]

For

Wallpaper images

, select

an image category and then an

image.

You can change the colour for the

display components, such as title

bars and highlight bars.

1. In Idle mode, press <

and select

Settings

→

Display

settings

→

Skin

2. Select a colour pattern.

Menu mode

skin colour
