SGH-S300

WAP Browser

User’s Manual

ELECTRONICS

* Some of the contents in this manual may differ from your phone,

depending on the software installed or your service provider.

Printed in Korea

Code No.: GH68-03352A

English. 12/2002. Rev. 1.0

World Wide Web

http://www.samsungmobile.com

What is WAP?

WAP (Wireless Application Protocol) is the

gateway to a new world of mobile data. It

provides a universal standard, enabling you

to access Web-based interactive information

services and applications directly from your

mobile phone.

Contents

About the WAP Browser............................ 4

Setting Up the WAP Browser..................... 5

Accessing the WAP Browser ...................... 5

Configuring the WAP Browser.................... 7

Getting Started ......................................... 10

Starting the WAP Browser......................... 10

Exiting the WAP Browser .......................... 10

Using the WAP Browser ............................ 11

Using the Soft Keys.................................. 11

Navigating the WAP Browser ..................... 11

Entering Text, Numbers or Symbols ........... 12

Using the WAP Browser Menus ................. 13

Using and Selecting Menu Options ............. 13

Reload ................................................... 13

Home..................................................... 14

Go to URL............................................... 14

Show URL............................................... 14

Edit Home .............................................. 15

About the

WAP Browser

Your phone comes equipped with a WAP (Wireless

Application Protocol) Browser which makes it

possible for you to access the Wireless Web.

The WAP Browser allows you to:

• access up-to-the-minute information via your

phone

• view specially designed text versions of popular

Internet sites including Yahoo!

, CNN Mobile

and the Weather Channel

Browsing the Wireless Web using your phone is

unlike using your computer, in that site providers

have:

• selected only the critical aspects of their site for

wireless phone users

• removed most graphics

Each time you start the WAP Browser, the phone

connects to the Wireless Web and the service

indicator icon ( or ) appears on the display

to inform you that you are:

• are connected to the Wireless Web

• will be billed accordingly (rates vary according to

your service option)

The WAP Browser ends the network connection

after a certain period of inactivity and automatically

reconnects as necessary. For this reason, you may

find that you are billed for several network

connections within a single session. This is normal

and is designed to minimise your bill.

Setting Up the

WAP Browser

Before using the WAP Browser, you must set the

parameters for the proxy server used by your

service provider.

Accessing the WAP Browser

To access the WAP Browser menu:

1. When the idle screen displays, press the

soft key to enter menu mode.

2. Press the or key one or more times until

the

Funbox

menu option displays, and then

press the

Select

soft key. You can also press

the key directly.

Service Provider

07:30

Wed 06 Mar

Menu Name

Organiser

Network

Services

Funbox

Select

Setting Up the WAP Browser

3. Press the or key one or more times to

highlight

WAP Browser

, and then press the

Select

soft key. You can also press the key

directly.

4. Press the or key one or more times to

highlight the required option and then press the

Select

soft key.

Option Description

Home Connects the phone to the

network and loads the homepage

of the Wireless Web service

provider.

Favorite Allows you to store the URL

addresses of your favourite Web

sites. You can access this menu

directly by pressing and holding

down the

key while using the

WAP Browser.

7.2

Select

Funbox

Games

WAP Browser

Downloads

7.2.1

WAP Browser

Home

Favorite

http://

Clear Cache

Select

Settings

Setting Up the WAP Browser

Configuring the WAP Browser

To configure the WAP Browser:

1. In the WAP Browser menu, highlight

Settings

using the and keys, and then press the

Select

soft key. You can also press the key

directly.

Favorite

(continued)

To store a URL address, select an

empty location and enter the

address. Three submenus are

available. Select Goto URL to

access the site quickly, Edit to

edit the selected address and

Erase to delete the selected

address.

http:// Allows you to manually enter a

URL address of the Web site that

you wish to access.

Settings Allows you to set up five proxy

servers for the WAP Browser.

Clear

Cache Clears the information stored in

the cache (the phone’s temporary

memory used to store the most

recently accessed Web pages).

Push

Message

Allows you to set whether or not

you will receive Web messages

from the server, and read or

delete the messages received.

Option Description

Setting Up the WAP Browser

2. Select a proxy server and enter the parameters

required. Contact your service provider for

details.

The remaining options depend on the

Bearer

setting, as indicated below.

When the bearer is set to

Data

Parameter

Description

Profile

Name

Name that you wish to assign to

the HTTP proxy server.

Homepage

URL

Address of your startup

homepage. When the default

homepage displays, you can

delete it using the key and

enter your own choice.

Security

Data transmission mode. Choose

Secure

to protect your data

against unauthorised access;

otherwise, choose

Non-Secure

IP Address

WAP gateway address required to

connect to the Internet.

Bearer

Bearer to be used for each type of

network address accessed:

GPRS

Data

Parameter Description

Name

PPP server login ID.

Password

PPP server password.

Dial-up

Number

PPP server phone number.

Data Call

Type

Data call type:

Analogue

ISDN

Setting Up the WAP Browser

When the bearer is set to

GPRS

Note

: The WAP Browser settings may vary,

depending on the service provider. Contact

your service provider for further information.

3. After selecting each of these settings, a dialog

box displays; you can either enter the

information required or choose between given

options. When you are satisfied with your input,

press the

soft key.

4. When you have finished configuring the WAP

Browser, press the key or the right soft

key.

Parameter Description

User Name

User ID required to connect to the

GPRS network.

Password

Password required to connect to

the GPRS network.

APN

Access point name used for the

address of the GPRS network

gateway.

Getting

Started

Starting the WAP Browser

To start the WAP Browser when the idle screen

displays, press the key or press the

soft

key, followed by the , and keys.

A connection is established with your service

provider and the corresponding homepage displays.

The content of the WAP Browser startup homepage

depends on your Wireless Web service provider. To

scroll through the screen, use the and keys.

Note

: To access the startup homepage from any

other screen in the WAP Browser, use the

Home

option. For more information on the

WAP Browser menus, refer to page 13.

Exiting the WAP Browser

To exit the browser at any time, simply press

the key or press and hold down the key.

Using the

WAP Browser

Using the Soft Keys

A bar containing browser commands is located at

the bottom of the WAP Browser display. The soft

keys below the bar are used to execute these

commands. The two keys are called soft keys

because their function changes depending on the

WAP Browser application in use.

Navigating the WAP Browser

To... Then...

scroll through and

select browser

items

press the or key

until the symbol points to

the required item, and then

press the

soft key to

confirm the selection.

select a numbered

item press the corresponding

numeric key.

return to the

previous page press the

Back

soft key or

the key.

return to the

startup homepage select the

Home

option; for more information

on this option, refer to

page 14.

Using the WAP Browser

Entering Text, Numbers or Symbols

When you are prompted to enter text, the current

text entry mode is indicated on the screen. The

following modes are available.

Note:

To enter symbols, press the key until the

required symbol displays.

Mode Description

Allows you to enter letters in the

alphabet. Press the corresponding

key until the required letter displays.

Allows you to enter numbers.

To... Then...

change

modes

press the key one or more

times.

enter a space

press the key.

edit text

• set the cursor to the right of

the character(s) to be

corrected.

• press the key as required.

• enter the correct character(s).

Using the WAP

Browser Menus

Using and Selecting Menu Options

Various menu options are available when you are

using the WAP Browser to navigate the Wireless

Web.

To access a menu option:

1. Press and hold down the key.

A menu displays.

2. Highlight the required menu option by using the

and keys.

3. Select the option by pressing the

Select

soft

key.

4. If necessary, select the secondary option using

the and keys, and press the

Select

soft

key to confirm.

Note:

The menus may vary, depending on your

version of the WAP Browser.

Reload

This option reloads the current page.

Using the WAP Browser Menus

Home

This option takes you back at any time to the

homepage of the Wireless Web service provider.

Go to URL

This option allows you to manually enter the URL

address of the required Web page.

After entering an address, press the

soft key to

go there directly.

Show URL

This feature displays the URL address of the site to

which you are currently connected. It also enables

you to declare the current site as the startup

homepage.

To... Press the...

declare the current

page as your

startup homepage

Option

soft key, select the

Save to Home

option and

press

Select

set a bookmark for

the current page

Option

soft key, select the

Save to Bookmark

option

and press

Select

cancel your setting

Back

soft key.

Using the WAP Browser Menus

Edit Home

With this feature, you can change the startup

homepage manually.

To change the homepage, enter the required URL

and press the

soft key.

For more information on entering text, numbers or

symbols, refer to page 12.

Andere Handbücher für SGH-S300

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Samsung Handy Handbücher

Samsung

Samsung GT-C3322 Bedienungsanleitung

Samsung

Samsung Galaxy F41 Bedienungsanleitung

Samsung

Samsung SCH-i730 Series Bedienungsanleitung

Samsung

Samsung GT-I9060I/DS Bedienungsanleitung

Samsung

Samsung GT-I8190 Bedienungsanleitung

Samsung

Samsung SGHA637 Bedienungsanleitung

Samsung

Samsung Galaxy Avant Bedienungsanleitung

Samsung

Samsung SGH-E800 Bedienungsanleitung

Samsung

Samsung SM-G355H DS Bedienungsanleitung

Samsung

Samsung GT-S5363 Bedienungsanleitung

Samsung

Samsung SCH-U430 Series Bedienungsanleitung

Samsung

Samsung CDMA SCL21 Bedienungsanleitung

Samsung

Samsung GT-C3110 Bedienungsanleitung

Samsung

Samsung SM-F926B Bedienungsanleitung

Samsung

Samsung SCH-P729 Bedienungsanleitung

Samsung

Samsung SM-C115 Bedienungsanleitung

Samsung

Samsung SM-G996B Bedienungsanleitung

Samsung

Samsung GT-I9308 Bedienungsanleitung

Samsung

Samsung SPH-L500 Benutzerhandbuch

Samsung

Samsung Omnia I910 Bedienungsanleitung

Samsung

Samsung Galaxy S4 Mini Bedienungsanleitung

Samsung

Samsung Galaxy A21 SC-42A Bedienungsanleitung

Samsung

Samsung GT-E3300 Bedienungsanleitung

Samsung

Samsung Galaxy Note20 5G Bedienungsanleitung

Beliebte Handy Handbücher anderer Marken

Zte

Zte BLADE A520 Bedienungsanleitung

Nokia

Nokia Lumia 620 Bedienungsanleitung

Blackbe;rry

Blackbe;rry KEYone Bedienungsanleitung

Bea-fon

Bea-fon X5 Premium Bedienungsanleitung

Blackbe;rry

Blackbe;rry 8707 Series Bedienungsanleitung

Blackbe;rry

Blackbe;rry Storm Betriebsanleitung

LG LM-X420QN Bedienungsanleitung

LifeWatch

LifeWatch V Bedienungsanleitung

Bea-fon

Bea-fon SILVER LINE SL860 Bedienungsanleitung

IKI Mobile

IKI Mobile KF4.5i Bedienungsanleitung

Hitech

Hitech HT-850 Bedienungsanleitung

Yezz

Yezz Fashion F10 Bedienungsanleitung

Point Mobile

Point Mobile PM60 Bedienungsanleitung

Blackbe;rry

Blackbe;rry Q10 Bedienungsanleitung

Blackbe;rry

Blackbe;rry Bold 9900 Bedienungsanleitung

Blackbe;rry

Blackbe;rry STORM 9500 - VERSION 5.0 Bedienungsanleitung

LG LM-K420EMW Bedienungsanleitung

ISAFE MOBILE

ISAFE MOBILE IS655.2 Bedienungsanleitung
