User Manual

English (CA). 01/2017 Rev. 1.0

SM-A520W

Table of Contents

Basics

4 Read me first

6 Helpful tips if your device heats up

8 Maintaining water and dust resistance

9 Package contents

10 Device layout

12 Battery

17 SIM or USIM card (nano-SIM card)

22 Turning the device on and off

23 Controlling the touchscreen

25 Home screen

31 Lock screen

33 Always On Display

35 Notification panel

37 Entering text

40 Screen capture

40 Opening apps

41 Secure Folder

45 Multi window

50 Transferring data from your previous

device

52 Device and data management

54 Quick connect

57 Sharing features

58 Emergency mode

Applications

59 Installing or uninstalling apps

61 Phone

64 Contacts

67 Messages

70 Internet

72 Email

73 Camera

84 Gallery

89 Game Launcher

92 Samsung Notes

93 Calendar

94 S Health

97 S Voice

98 Voice Recorder

100 My Files

100 Clock

102 Calculator

102 Google apps

Table of Contents

Settings

104 Introduction

104 Connections

116 Sounds and vibration

117 Notifications

117 Display

119 Wallpapers and themes

119 Advanced features

122 Device maintenance

124 Applications

124 Lock screen and security

129 Cloud and accounts

131 Google

131 Accessibility

132 General management

132 Software update

133 About device

Appendix

134 Troubleshooting

Health and Safety

Basics

Read me first

Please read this manual before using the device to ensure safe and proper use.

•

Descriptions are based on the device’s default settings.

•

Some content may differ from your device depending on the region, service provider,

model specifications, or device’s software.

•

Content (high quality content) that requires high CPU and RAM usage will affect the

overall performance of the device. Apps related to the content may not work properly

depending on the device’s specifications and the environment that it is used in.

•

Samsung is not liable for performance issues caused by apps supplied by providers other

than Samsung.

•

Samsung is not liable for performance issues or incompatibilities caused by edited

registry settings or modified operating system software. Attempting to customize the

operating system may cause the device or apps to work improperly.

•

Software, sound sources, wallpapers, images, and other media provided with this device

are licenced for limited use. Extracting and using these materials for commercial or other

purposes is an infringement of copyright laws. Users are entirely responsible for illegal

use of media.

•

You may incur additional charges for data services, such as messaging, uploading and

downloading, auto-syncing, or using location services depending on your data plan. For

large data transfers, it is recommended to use the Wi-Fi feature.

•

Default apps that come with the device are subject to updates and may no longer be

supported without prior notice. If you have questions about an app provided with

the device, contact a Samsung Service Center. For user-installed apps, contact service

providers.

•

Modifying the device’s operating system or installing software from unofficial sources

may result in device malfunctions and data corruption or loss. These actions are violations

of your Samsung licence agreement and will void your warranty.

Basics

•

Be careful not to forget your unlock codes for the screen lock, accounts, and other

security features. If you forget an unlock code, you will not be able to use the device if

you do not reset it. Samsung is not responsible for any data loss or inconvenience caused

by forgotten unlock codes.

Instructional icons

Warning: situations that could cause injury to yourself or others

Caution: situations that could cause damage to your device or other equipment

Notice: notes, usage tips, or additional information

Basics

Helpful tips if your device heats up

When the device heats up while charging the battery

While charging, the device and the charger may become hot. During wireless charging or fast

charging, the device may feel hotter to the touch. This does not affect the device’s lifespan or

performance and is in the device’s normal range of operation. If the battery becomes too hot,

the charger may stop charging.

Do the following when the device heats up:

•

Disconnect the charger from the device and close any running apps. Wait for the

device to cool down and then begin charging the device again.

•

If the lower part of the device overheats, it could be because the connected USB

cable is damaged. Replace the damaged USB cable with a new Samsung-approved

one.

•

When using a wireless charger, do not place foreign materials, such as metal objects,

magnets, and magnetic stripe cards, between the device and the wireless charger.

When the device heats up during use

When you use features or apps that require more power or use them for extended periods,

your device may temporarily heat up due to increased battery consumption. Close any

running apps and do not use the device for a while.

The following are examples of situations in which the device may overheat.

•

During the initial setup after purchase or when restoring data

•

When downloading large files

•

When using apps that require more power or using apps for extended periods

–

When playing high-quality games for extended periods

–

When recording videos for extended periods

–

When streaming videos while using the maximum brightness setting

–

When using the Screen Mirroring feature (When connecting to a TV)

Basics

•

While multitasking (or, when running many apps in the background)

–

When using Multi window

–

When updating or installing apps while recording videos

–

When downloading large files

–

When recording videos while using a navigation app

•

When using large amount of data for syncing with the cloud, email, or other accounts

•

When using a navigation app in a car while the device is placed in direct sunlight

•

When using the mobile hotspot and tethering feature

•

When using the device in areas with weak signals or no reception

•

When charging the battery with a damaged USB cable

•

When the device’s multipurpose jack is damaged or exposed to foreign materials, such as

liquid, dust, metal powder, and pencil lead

•

When you are roaming

Do the following when the device heats up:

•

Keep the device updated with the latest software.

•

Conflicts between running apps may cause the device to heat up. Restart the device.

•

Deactivate the Wi-Fi, GPS, and Bluetooth features when not using them.

•

Close apps that increase battery consumption or that run in the background when

not in use.

•

Delete unnecessary files or unused apps.

•

Decrease the screen brightness.

•

If the device overheats or feels hot for a prolonged period, do not use it for a while. If

the device continues to overheat, contact a Samsung Service Center.

Basics

Precautions for operating environment

Your device may heat up due to the environment in the following conditions. Use caution to

avoid damaging the device or shortening the battery’s lifespan.

•

Do not store your device in very cold or very hot temperatures.

•

Do not expose your device to direct sunlight for extended periods.

•

Do not use or store your device for extended periods in very hot areas, such as inside a

car in the summertime.

•

Do not place the device in any areas that may overheat, such as on an electric heating

mat.

•

When using a wireless charger, do not place foreign materials, such as metal objects,

magnets, and magnetic stripe cards, between the device and the wireless charger.

•

Never use a damaged charger or battery.

Maintaining water and dust resistance

Your device supports water- and dust-resistance. Follow these tips carefully to maintain the

water- and dust-resistance of your device. Failure to do so may result in damage to your

device.

•

Do not immerse the device in water deeper than 1.5 m or keep it submerged for more

than 30 minutes.

•

Do not expose the device to water moving with force.

•

If the device is exposed to clean water, dry it thoroughly with a clean, soft cloth. If the

device is exposed to other liquids, such as salt water, ionized water, or alcoholic beverage,

rinse it with clean water and dry it thoroughly with a clean, soft cloth. If you do not follow

these instructions, the device’s performance and appearance may be affected.

•

If the device has been immersed in water or the microphone or speaker is wet,

sound may not be heard clearly during a call. Wipe the device with a dry cloth or dry it

thoroughly before using it.

•

The touchscreen and other features may not work properly if the device is used in water.

•

Your device has been tested in a controlled environment and certified to be water-

and dust-resistant in specific situations (meets requirements of classification IP68 as

described by the international standard IEC 60529-Degrees of Protection provided

by Enclosures [IP Code]; test conditions: 15-35 °C, 86-106 kPa, 1.5 metre, 30 minutes).

Despite this classification, it is still possible for your device to be damaged in certain

situations.

Basics

Package contents

Check the product box for the following items:

•

Device

•

USB cable

•

USB power adapter

•

Ejection pin

•

Quick start guide

•

The items supplied with the device and any available accessories may vary

depending on the region or service provider.

•

The supplied items are designed only for this device and may not be compatible

with other devices.

•

Appearances and specifications are subject to change without prior notice.

•

You can purchase additional accessories from your local Samsung retailer. Make

sure they are compatible with the device before purchase.

•

Use only Samsung-approved accessories. Using unapproved accessories may cause

performance problems and malfunctions that are not covered by the warranty.

•

Availability of all accessories is subject to change, depending entirely on the

manufacturing companies. For more information about available accessories, refer

to the Samsung website.

Basics

Device layout

Microphone

Back key

Headset jack

Multipurpose jack (USB Type-C)

Front camera

Speaker

Power key

Loud speaker

Touchscreen

Recents key

Home key (Fingerprint

recognition sensor)

Proximity / RGB sensor

Memory card tray
